FREE MOTION Epic F802.0 User manual

CAUTIO
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
QUESTIO S?
If you have questions, or if parts
are damaged or missing, please
see HOW TO CO TACT
CUSTOMER CARE on the back
cover of this manual.
Model o. F802.0
Serial o.
Write the serial number in the
space above for reference.
Serial Number Decal
OW ERʼS MA UAL
www.freemotionfitness.com

2
TABLE OF CO TE TS
IMPORTANTPRECAUTIONS ................................................................3
WARNINGDECALPLACEMENT ..............................................................4
BEFOREYOUBEGIN ......................................................................5
PARTIDENTIFICATIONCHART ..............................................................6
ASSEMBLY ...............................................................................7
ADJUSTMENT ...........................................................................18
MAINTENANCEANDTROUBLESHOOTING ...................................................19
CABLEDIAGRAM.........................................................................21
PARTLIST ..............................................................................25
EXPLODEDDRAWING ....................................................................26
HOWTOCONTACTCUSTOMERCARE ...............................................BackCover
FREEMOTION is a registered trademark of ICON IP, Inc.

3
IMPORTA T PRECAUTIO S
1. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or per-
sons with pre-existing health problems.
2. Use the strength equipment only as
described in this manual.
3. It is the responsibility of the owner to
ensure that there is enough space around
the strength equipment for the intended
exercise.
4. Use the strength equipment only on a level
surface. Cover the floor beneath the
strength equipment to protect the floor.
5. Anchor the strength equipment to the floor
with the anchor strap where required or
where possible to provide maximum stability.
6. It is the responsibility of the owner to
ensure that all users of the strength equip-
ment are adequately informed of all
precautions, have read and understood all
warning and caution labels, and are
informed of how to use the strength equip-
ment properly.
7. All users of the strength equipment should
be instructed to report any injury or
strength equipment irregularity to facility
staff immediately.
8. Keep children under age 12 and pets away
from the strength equipment at all times.
9. The strength equipment is designed to sup-
port a maximum user weight of 350 lbs.
(159 kg).
10. Always wear athletic shoes for foot protec-
tion while exercising.
11. Keep hands and feet away from moving
parts. Do not lean on or rest your hands on
the strength equipment while it is in use.
12. Make sure that the weight pin is completely
inserted into one of the weight plates.
13. Check each cable, cable connection, and
pulley before each use of the strength
equipment. Make sure that all parts are
properly tightened. Replace any worn parts
immediately.
14. Make sure that each cable remains on the
pulleys at all times. If a cable binds while
you are exercising, stop immediately and
make sure that the cable is on the pulleys
and that nothing is interfering with the cable
or the pulleys.
15. Over exercising may result in serious injury
or death. If you feel faint or if you experi-
ence pain while exercising, stop
immediately and cool down.
WAR I G: To reduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on your strength equipment before using your strength
equipment. FreeMotion Fitness assumes no responsibility for personal injury or property damage
sustained by or through the use of this product.

4
WAR I G DECAL PLACEME T
This drawing shows the location(s) of the warning decal(s). If a decal is missing or illegible, see the
back cover of this manual and request a free replacement decal. Apply the decal in the location
shown. Note: The decal(s) may not be shown at actual size.

5
Assembled Dimensions:
Height: 6 ft. 7 in. (201 cm)
Width: 4 ft. 4 in. (132 cm)
Depth: 5 ft. 7 in. (170 cm)
BEFORE YOU BEGI
Thank you for selecting the FREEMOTION®EPIC™
LAT/HIGH ROW strength equipment. With unrestricted
motion, you can work your bodyʼs muscle groups the
way you do naturally, to train more effectively and
efficiently.
For your benefit, read this manual carefully before
using the strength equipment. If you have questions
after reading this manual, please see the back cover
of this manual. To help us assist you, note the product
model number and serial number before contacting us.
The model number and the location of the serial num-
ber decal are shown on the front cover of this manual.
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.
Row Handle
Lat Handle
Weights
Seat
Weight Pin
Thigh Pad
Latch
Counterweight
Tower
Drop-down
Weight/ nob
Right Arm
Left Arm

6
M8 x 25mm Socket
Screw (75)–2
M10 Locknut
(32)–4
M10 x 35mm Socket
Screw (71)–7
Stop Screw (74)–1
M10 x 85mm Socket Bolt (67)–4
M6 Washer
(34)–4
M8 Washer
(76)–2
M10 Washer
(31)–15
M4 x 13mm
Self-tapping
Screw (27)–2
25mm Snap
Ring (39)–2
M6 x 15mm
Screw (35)–4 M8 x 25mm Screw
(77)–4
Refer to the drawings below to identify small parts used for assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the
parentheses is the quantity needed for assembly. ote: If a part is not in the hardware kit, check to see if it
has been preattached. To avoid damaging parts, do not user power tools.
PART IDE TIFICATIO CHART

7
ASSEMBLY
• Assembly requires two persons.
•Because of its weight and size, assemble the
strength equipment in the location where it will be
used. Make sure that there is enough clearance
around the strength equipment.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
• For help identifying small parts, see page 6.
• The following tools (not included) are required for
assembly:
one adjustable wrench
one Phillips screwdriver
a set of metric hex keys
snap ring pliers
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
1
1. Remove all parts (24, 29, 31, and 32) from the
Connecting Frame (38).
Identify the Long Cable (40) and the Short
Cable (not shown). Orient the Long Cable as
shown, and insert it through the Connecting
Frame (38).
Reattach the Large Pulley (24) to the
Connecting Frame (38) with the M10 x 50mm
Socket Bolt (29), the two M10 Washers (31),
and the M10 Locknut (32). Make sure that the
Long Cable (40) is between the Large Pulley
and the indicated rod.
2. Remove the M10 Locknut (32), the two M10
Washers (31), the M10 x 135mm Socket Bolt
(78), and the Large Pulley (24) from the Main
Frame (68).
Orient the Connecting Frame (38) as shown,
and set it on the indicated side of the Main
Frame (68).
Route the Long Cable (40) through the Main
Frame (68) as shown.
Reattach the Large Pulley (24) to the Main
Frame (68) with the M10 x 135mm Socket Bolt
(78), the two M10 Washers (31), and the M10
Locknut (32). Make sure that the Long Cable
(40) is below the Large Pulley.
38
29
31
31
31
31
32
32
40
24
Rod
Large
End
Small
End
24
38
68
78
40
2

8
3
3. Attach the Connecting Frame (38) to the Main
Frame (68) with three M10 x 35mm Socket
Screws (71) and three M10 Washers (31). Do
not tighten the Socket Screws yet.
4
4. Orient the Tower Frame (1) as shown, and set it
near the Connecting Frame (38). Have a sec-
ond person hold the Tower Frame to prevent
it from falling until you complete step 5.
Remove the two M10 x 30mm Socket Screws
(30), the two M10 Washers (31), and the Small
Pulley Bracket (6) from the back of the Tower
Frame (1).
Next, remove all parts (24, 29, 31, and 32) from
the Small Pulley Bracket (6).
38
68
31
31
71
71
31
31
31
32
6
1
38
30
24
29

9
5
5. Insert the Long Cable (40) through the Tower
Frame (1) as shown.
Attach the Connecting Frame (38) to the Tower
Frame (1) with four M10 x 35mm Socket
Screws (71) and four M10 Washers (31). Start
all four Socket Screws, and then tighten
them.
See step 3. Tighten the three M10 x 35mm
Socket Screws (71).
6
6. Route the Long Cable (40) upward through the
Small Pulley Bracket (6). Attach the Large
Pulley (24) inside the Small Pulley Bracket with
the M10 x 50mm Socket Bolt (29), the two M10
Washers (31), and the M10 Locknut (32) that
you removed in step 4.
Then, attach the Small Pulley Bracket (6) to the
Tower Frame (1) with the two M10 x 30mm
Socket Screws (30) and the two M10 Washers
(31) that you removed in step 4.
7
7. Identify the Rear Shroud Base (3), which has a
hole in the center, and the Front Shroud Base
(4). Orient the Shroud Bases as shown.
Insert the end of the Long Cable (40) upward
through the Rear Shroud Base (3).
Attach the Shroud Bases (3, 4) to the Tower
Frame (1) with four M6 x 15mm Screws (35)
and four M6 Washers (34).
40
31
1
38
31
71
31
31
31
32 6
1
30
24
40
29
4
1
3
40
34
35
34
35

10
8
8. Loosen the two M8 x 35mm Set Screws (19) a
few complete turns; it is not necessary to
remove the Set Screws.
Look under the top of the Tower Frame (1) and
remove the two 25mm Snap Rings (39) from
the two Weight Guide Bushings (18).
Lift the Weight Guide Bushings (18) until the
upper ends of the Weight Guides (7) are free.
Next, tip the upper ends of the Weight Guides
(7) forward or backward, and slide the two
25mm Snap Rings (39), the Drop-down Weight
(10), the two Upper Weight Bumpers (16), and
the Top Weight (9) upward off the Weight
Guides.
9
9. Look at the decals on the eleven 20-pound
Weights (8), and find the decal that has the
largest number on it. Orient that 20-pound
Weight so that the decal is facing the Main
Frame (68), and slide the 20-pound Weight onto
the Weight Guides (7).
Repeat this step with the remaining 20-
pound Weights (8).
Then, repeat this step with the seven 10-
pound Weights (44).
10
16
9
39
1
19 18
18
19
8
68
Decals
7
7
44
