FREE MOTION GZFW2071.2 User manual

Visit our website at
www.freemotionfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Model No. GZFW2071.2
Serial No.
Write the serial number in the
space above for future reference.
QUESTIONS?
At FreeMotion Fitness, we are
committed to providing com-
plete customer satisfaction. If
you have questions, see HOW
TO CONTACT CUSTOMER
CARE on the back cover of this
manual.
OWNER’S
MANUAL
Serial Number Decal

TABLE OF CONTENTS
2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
HOW TO CONTACT CUSTOMER CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

3
1. Read all instructions in this manual before
using the exercise station. Use the exercise
station only as described in this manual.
2. It is the purchaser’s responsibility to ensure
that there is enough space around the exer-
cise station for the intended exercise. Do not
crowd the exercise station.
3. Using the four 9/16” anchor holes to provide
maximum stability, anchor the exercise sta-
tion to the floor where required or whenever
possible.
4. It is the responsibility of the owner to ensure
that all users of the exercise station are ade-
quately informed of all precautions.
5. All users of the exercise station should be
instructed to report any injury or exercise sta-
tion irregularity to facility staff immediately.
6. Make sure all parts are properly tightened
before each use of the exercise station.
Replace any worn parts immediately.
7. Use the exercise station only on a level sur-
face. Cover the floor beneath the exercise
station to protect the floor.
8. Always wear athletic shoes for foot protec-
tion while exercising.
9. Keep hands and feet away from moving
parts. Do not lean on or rest your hands on
the exercise station when it is in use.
10. Keep children under 12 and pets away from
the exercise station at all times.
11. The exercise station is designed to support a
maximum user weight of 350 pounds. Do not
use the exercise station with weights.
12. Keep the exercise station indoors, away from
moisture and dust. Do not put the exercise
station in a garage or covered patio, or near
water.
13. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool-
ing down.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the exercise station.
IMPORTANT PRECAUTIONS

Pull-up Handle
ASSEMBLED DIMENSIONS:
Height: 93 in. / 236 cm
Width: 48 in. / 122 cm
Depth: 46 in. / 117 cm
4
Backrest
Crunch Arm
Step
Anchor Holes
Anchor Holes
Dip Arm
BEFORE YOU BEGIN
Thank you for selecting the FREEMOTION EPIC™ DIP
CHIN AB strength equipment. The strength equipment
is designed to help develop the major muscle groups of
the upper body. Whether your goal is to tone your body,
build dramatic muscle size and strength, or improve
your cardiovascular system, the strength equipment will
help you to achieve the specific results you want.
For your benefit, read this manual carefully before
using the strength equipment. If you have questions
after reading this manual, see HOW TO CONTACT
CUSTOMER CARE on the back cover of this manual. To
help us assist you, please note the product model
number and serial number before calling.The model
number is GZFW2071.2. The serial number can be
found on a decal attached to the strength equipment
(see the front cover of this manual).
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.

5
MAINTENANCE
It is important for safe and trouble-free operation of your FREEMOTION EPIC strength equipment to perform
routine preventive maintenance on a regular basis. Instruct all personnel to perform equipment inspection and
maintenance requirements. Personnel must record and report any accident. To maintain the strength equip-
ment’s warranty, use only FREEMOTION EPIC parts for repair or replacement. For any questions or concerns,
see HOW TO CONTACT CUSTOMER CARE on the back cover of this manual.
SCHEDULED MAINTENANCE
DAILY
1. Upholstery—General cleaning:
•Wipe using a soft cloth dampened with a light
solution of mild soap and warm water.
•If necessary, use a soft bristle brush with the
cleaning solution.
•Rinse thoroughly using a soft cloth dampened
with clean water. Dry thoroughly.
2. Upholstery—Difficult stains:
•Spray the stain with a non-abrasive household
cleaner such as FORMULA 409®cleaner,
SIMPLE GREEN®,or a similar product.
•Rub the area gently and let it sit for a few min-
utes.
•Rinse thoroughly using a soft cloth dampened
with clean water. Dry thoroughly.
•Repeat if necessary using a soft bristle brush.
Optional method for difficult stains:
•Rub the area gently using a soft cloth damp-
ened with rubbing alcohol.
•Rinse thoroughly using a soft cloth dampened
with clean water.Dry thoroughly.
CAUTION: When using any cleaning product, try
it first in an inconspicuous place to ensure that
there is no damage to the material. Follow the
directions and adhere to the safety precautions of
the manufacturer of each cleaning product used.
FreeMotion Fitness and its vendors cannot be
held liable for damage or injuries resulting from
the use or misuse of cleaning products.
3. Frames:
•Wipe using a soft cloth dampened with a light
solution of mild soap and warm water. Rinse
thoroughly using a soft cloth dampened with
clean water.Dry thoroughly.
Important: Do not use abrasive cleaners
because they may scratch the equipment. Strong
cleaners and abrasives will damage decals. Use
caution around decals. Do not use solvents such
as lacquer thinner, kerosene, gasoline, or similar
liquids.
WEEKLY
1. Hardware:
•Check all nuts and bolts. Tighten them as
required. Important: All FREEMOTION EPIC
cushions are fabricated using dense plywood
with tee-nuts installed for bolting to the machine
framework. Because these tee-nuts are held by
the plywood, they will not withstand the torque
that standard nuts and bolts will. Therefore,
when tightening the cushion bolts, turn them
only until they are snug and the cushion does
not move or feel loose. Overtightening may strip
the tee-nuts from the plywood and make it
impossible to remove the cushion in the future.
2. Grips:
•Check and replace as needed.

6
Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice.
Key No. Qty. Description Key No. Qty. Description
PART LIST—Model No. GZFW2071.2 R0106A
1 1 Base
2 1 Upright
3 1 Right Arm
4 1 Left Arm
5 2 Foot Rest
6 2 Arm Pad
7 1 Backrest
8 4 Small Rubber Handgrip
9 4 Large Handgrip
10 4 3/8” x 4” Bolt
11 4 3/8” x 1 1/4” Flat Head Bolt
12 8 3/8” x 1” Non-patch Bolt
13 2 3/8” x 4” Non-patch Bolt
14 4 3/8” x 7 1/4” Bolt
15 14 3/8” Nylon Locknut
16 2 3/8” x 3” Bolt
# 1 Owner’s Manual
If replacement parts are needed, or if parts are missing or damaged, see HOW TO CONTACT CUSTOMER
CARE on the back cover of this manual.

7
EXPLODED DRAWING—Model No. GZFW2071.2 R0106A
1
2
3
4
5
5
6
6
7
8
8
8
8
9
9
15
15
11
11
12
12
13
13
14
14
15
10 16
15
15
10

Part No. GZ7354 R0106A Printed in USA © 2006 ICON IP, Inc.
HOW TO CONTACT CUSTOMER CARE
If you have questions after reading this manual, or if you require assistance, please contact Customer Care at
the address and phone number listed below. Please be prepared to give the following information:
•The MODEL NUMBER of the product (GZFW2071.2).
• The NAME of the product (FREEMOTION EPIC™ DIP CHIN AB strength equipment).
• The SERIAL NUMBER of the product (see the front cover of this manual).
• When ordering replacement parts, please also give the KEY NUMBER and DESCRIPTION of the part(s) (see
the PART LIST and the EXPLODED DRAWING on pages 6 and 7 of this manual).
Customer Care: 1-800-201-2109, Monday–Friday, 8 a.m.–5 p.m. Mountain Time
FreeMotion Fitness, Inc. • 1096 Elkton Dr., Suite 600 • Colorado Springs, CO 80907
