Freescale Semiconductor TWR-MEM-PISMO User manual

Quick Start Guide
TWR-MEM-PISMO
PISMO2 Memory Module
TOWER SYSTEM

2
Quick Start Guide
TWR-MEM-PISMO
Freescale Tower System
The TWR-MEM-PISMO module is part of the Freescale Tower System,
a modular development platform that enables rapid prototyping and
tool re-use through reconfigurable hardware. Take your design to the
next level and begin prototyping with the Tower System today.
Get to Know the TWR-MEM-PISMO
PISMO2
Socket
LEDs
Voltage I/O
Switches
User Mode
Switches
Primary
Connector
SPI Module Header
Secondary
Connector
Spansion 1 Gb GL-S
Flash PISMO2 Module
Spansion 128 MB SPI
Multi-I/O Flash Module

TOWER SYSTEM
3
TWR-MEM-PISMO Features
• Expandablememoryplatformcompatiblewiththe
Freescale Tower System
• IncludedSpansion1GbGL-SMirrorBitEclipseflash
PISMO2 module
• IncludedSpansion128MBMirrorBitSPImulti-I/Oflashmodule
• CLPDsupportsavarietyofFlexBusandLPCbusinterfaces
• PISMO2memorysocketsupporting:
16-bitADMmemory
6-bitADPmemory
BurstNORmemory
4/8-biteMMC
• SelectableI/OvoltageforthePISMO2interface(1.8or3.3volt)
• MIOSPIconnectorsupportingSpansionmulti-I/OSPI

4
Step-by-Step Installation Instructions
Set the “Working Mode” user
switch(SW1)andthe“VIO”
switches(MEM_VIO&CPU_VIO)to
the correct configuration for your
Tower System controller module.
Refer to the jumper settings table
for additional details.
AttachtheincludedSpansion
1GbGL-SMirrorBitEclipseflash
PISMO2 module to the PISMO2
socket on the TWR-MEM-PISMO.
Ensure that the keyed connector
is securely connected.
AttachtheincludedSpansion
128MBMirrorBitSPImulti-I/O
flash module to the 9-pin header.
EnsurethatthePin1indicator
(triangle)ontheSPImoduleis
orientedtowardsPin1ofthe
9-pinconnector(J4).
AssembleyourTowerSystem,
including at minimum a Tower
System controller module and the
TWR-MEM-PISMO module with
the attached memory modules.
Visitfreescale.com/TowerPISMO
for example projects for select
Tower System controller modules.
Quick Start Guide
1
2
3
4
5

Switch Option Setting Description
SW1-
Dip1
Memory
Interface Type
On FlexBusExternalBusInterface
Off LPCExternalBusInterface
SW1-
Dip2
Address/
DataMuxing
On Muxed:DataLineIsSharedwithAddressLine
Off Non-Muxed:DataLinesAreDedicated
SW1-
Dip3 DataWidth On 8-bitData
Off 16-bitData
SW1-
Dip4
TWR-ELEV
Usage
On Primary Only
Off Primary and Secondary*
SW1-
Dip5 ForFutureUse On
Off
SW1-
Dip6 ForFutureUse On
Off
* Not all Tower System Controller modules utilize the external bus interface on the secondary side, please refer to the
respective Tower System Controller documentation to verify if this setting is applicable.
TOWER SYSTEM
5
TWR-MEM-PISMOJumperOptions
The following is a list of all jumper options. The default installed jumper settings are
shown in white text within the black boxes.
Continued...

* Not all Tower System Controller modules utilize the external bus interface on the secondary side, please refer to the
respective Tower System Controller documentation to verify if this setting is applicable.
Quick Start Guide
6
Switch Option Setting Description
SW1-
Dip7 ForFutureUse On
Off
SW1-
Dip8 ForFutureUse On
Off
SW2 CPUVoltageI/O 3V3 CPLDInterfacestheControllerat3.3volts
1V8 CPLDInterfacestheControllerat1.8volts
SW3 MEMVoltage
I/O
3V3 CPLDInterfacesthePISMO2Memoryat3.3volts
1V8 CPLDInterfacesthePISMO2Memoryat3.3volts
JumperOptions(continued)
The following is a list of all jumper options. The default installed jumper settings are
shown in white text within the black boxes.

TOWER SYSTEM
7
ExampleConfiguration
The following is a list of example settings for a subset of the supported Tower System
ControllerModules.
Controller
Module
SW1 Setting (0-On,
1-Off) 1-2-3-4-5-6-7-8 Description
TWR-K60N512 0-1-0-0-0-0-0-0 8-bitNon-MuxedFlexBus
(PrimarySideOnly)
0-0-1-0-0-0-0-0 16-bitMuxedFlexbus(PrimarySideOnly)
TWR-MCF5225X 0-1-0-0-0-0-0-0 8-bitNon-MuxedFlexBus
(PrimarySideOnly)
0-0-1-0-0-0-0-0 16-bitMuxedFlexbus(PrimarySideOnly)
TWR-MCF5441X
0-1-0-1-0-0-0-0 8-bitNon-MuxedFlexBus
(Primary+Secondary)
0-0-1-1-0-0-0-0 16-bitMuxedFlexbus
(Primary+Secondary)
TWR-MPC5125
1-1-0-1-0-0-0-0 8-bitNon-MuxedLPC
(Primary+Secondary)
1-0-1-1-0-0-0-0 16-bitMuxedLPC(Primary+Secondary)
1-1-1-1-0-0-0-0 16-bitMuxedLPC(Primary+Secondary)*
* In this mode the TWR-MPC5125 is limited to 32MB address space

For more information, visit freescale.com/Tower
Join the online Tower community at towergeeks.org
Freescale and the Freescale logo are trademarks of Freescale semiconductor,
Inc.,Reg.U.S.Pat.&Tm.Off.Allotherproductorservicenamesarethe
propertyoftheirrespectiveowners.©2011FreescaleSemiconductor,Inc.
DocumentNumber:TWRPISMOGSGREV0
AgileNumber:926-78665RevA
Visitfreescale.com/TowerPISMO for information
ontheTWR-MEM-PISMOmodule,including:
• Usermanual
• Schematics
• Exampleapplication
• CPLDcode
Support
Visitfreescale.com/support for a list of phone
numbers within your region.
Warranty
Visitfreescale.com/warranty for complete
warranty information.
