ROUTER BITS & SETS Router Bit Sets
Five Piece Introductory Bit Set
• This four-piece set transforms to five pieces by using a bearing to convert
the beading bit into a rounding over bit.
• Includes a flush trim, straight, Roman ogee and beading bit.
• All bits have 1/4" shanks.
• Includes attractive wooden storage box and extra bearing.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on hand-held and table-mounted portable routers.
Application: Fundamental bit set for novice woodworkers
Five Piece Introductory Bit Set
• Freud’s new Five Piece Introductory Set provides an economical yet very
useful introduction to the wide world of possibilities offered by your 1⁄2"
collet router.
• Includes a flush trim, straight, Roman ogee, and rounding over bit.
• All bits have 1⁄2" shanks.
• Set comes in Freud’s unique shadow box case, this set hangs on the wall
or mounts on the bench to keep bits handy and safe.
• Cuts all composition materials, plywoods, hardwoods, and softwoods.
• Use on hand-held and table-mounted portable routers.
Application: Fundamental bit set for novice woodworkers
Red Item Numbers Indicate 1/2" ShankSee individual bit for scale profile
# 91-103
# 42-104 # 04-108 # 36-114# 38-100
# 88-104
Bit Type Item Overall Bearing Carbide Number Large Shank Overall
Number Dia. Dia. Height of Flutes Radius Dia. Length
Item Number 88-104
Bearing Flush Trim Bit 42-104 1/2" 1/2" 1" 2 – 1/4" 2-13/16"
Double Flute Straight Bit 04-108 1/4" – 1" 2 – 1/4" 2-1/2"
Roman Ogee Bit 38-100 1-1/16" 3/8" 1/2" – 5/32" 1/4" 2-3/16"
Beading Bit 36-114 1-1/4" 3/8" 5/8" – 3/8" 1/4" 2-3/16"
Rounding Over Bit* 34-114 1-1/4" 3/8" 5/8" – 3/8" 1/4" 2-3/16"
* Use included bearing #62-104 to convert 36-114 Beading Bit into 34-114 Rounding Over Bit.
Bit Type Item Overall Bearing Carbide Number Large Shank Overall
Number Dia. Dia. Height of Flutes Radius Dia. Length
Item Number 91-103
Bearing Flush Trim Bit 42-110 1/2" 1/2" 1" 2 – 1⁄2" 3-1/4"
Double Flute Straight Bit 12-100 1/4" – 3/4" 2 – 1⁄2" 2-3/8"
Roman Ogee Bit 38-104 1-1/16" 3/8" 1/2" – 5/32" 1⁄2" 2-3/8"
Rounding Over Bit 34-124 1-1/4" 1/2" 5/8" – 3/8" 1⁄2" 2-5/8"
*Beading Bit 36-124 1-1/4" 3/8" 5/8" – 3/8" 1⁄2" 2-5/8"
* Use included bearing #62-104 to convert 34-124 Beading Bit into 36-124 Rounding Over Bit.
