Friax MPC Genesis Plus - Vintage User manual

Installation Manual
MPC Genesis Plus - Vintage
GB-NT-MPC-0321
From N°20FR-TC-16800
"FRIAX industrie" in a constant endeavour to improve its products reserves the right to change
any information contained in this leaflet without prior warning

MPC
Genesis - Vintage
Contents of the package
MPC
Genesis - Vintage
Packaging
MPC
Genesis - Vintage
Safety
P
H
L
Thank you for choosing a FRIAX's Monobloc system to control the aging of your wine.
Take the me to read this manual. It will help you understand the steps to install and adjust the MPC series.
What is a cellar Monobloc system FRIAX ?
The MPC serie is a refrigeraon system specially designed to keep the opmum temperature and humidity at
the aging of your wines. The system is composed of three essenals elements which are the evaporator, the
condenser unit and the regulaon box. These elements are interconnected by a refrigerant pipe and an
electrical connecon.
At the delivery, you must find in your package, your Monobloc, the installaon manual and the accessories
describde on page 3. Check package to detect any damage on the carton. Note on the delivery of the carrier all
the observaons about the package condion, this could be useful in case of damage.
If in doubt contact your dealer.
When unpacking check that the material inside the package corresponds to the checklist on the box.
Off pallet dimensions:
750 mm x 490 mm x 510 mm ( P x L x H)
-Be sure to install the unit in a sheltered place.
-It is advisable to remove the device from its packaging with the help of someone.
-Connect the power supply once the enre installaon is complete.
2

3
This symbol indicates that the installaon manual should be read carefully.
This symbol indicates that a service technician should handle this equipment in
referring to the installaon manual.
This symbol indicates that informaon is available, such as the manual
operang instrucons or installaon manual.
Warning
READ THE MANUAL CAREFULLY BEFORE USING THE APPLIANCE
and keep it for future reference.
Improper installaon or use can result in injury to persons,
damage to property, and cancellaon of the manufacturer's warranty. Failure to follow instrucons
safety and local standards in force during installaon or use discharges the
manufacturer of any responsibility.
Make sure to install the device in a place protected from bad weather and frost.
- Be aware that some refrigerant gases can be odorless.
- Any intervenon on a refrigeraon circuit must be carried out by an authorized professional.
by an accredited body cerfying the competence to handle refrigerant fluids.
- The device must be free of any obstrucon at all mes to ensure good
operaon and reduce safety risks.
- Do not puncture any component of the refrigerant circuit.
- Use cauon when handling equipment to avoid malfuncon.
- The device must be installed in accordance with local wiring regulaons.
- Make sure that the characteriscs of the device are compable with those of the electrical installaon.
- Make sure that the mains socket is connected to earth.
- Do not use the device if it is damaged
- Do not connect the power supply unl the enre installaon is complete.
- Always switch off the appliance and unplug it from the mains for cleaning and maintenance.
- Do not put your hands or objects in the air inlets and outlets.
- Do not try to repair the device yourself.
- Any use and / or modificaon not approved by the manufacturer may be dangerous for your
safety and health.
- This appliance must not be used by children.
- The user must understand and be aware of the potenal dangers associated with the use of the device.
- Use only the means and / or tools recommended by the manufacturer for defrosng or cleaning.
MPC
Genesis - Vintage

Packing
Safety MPC
Genesis - Vintage
Specificaons
MPC 30 MPC 48
Cooling capacity 780 W** 1100 W**
Heang capacity 800 W 800 W
Voltage 230 V - 50Hz 230 V - 50 Hz
Current heang mode 4.4 A
Power consumpon 365 W / 2,3 A 508 W / 3,2 A
Airflow cellar side
2m 2m
Refrigerant R134A R134A
nominal outside temperature
32°C 32°C
8 - 18 °C8 - 18 °C
Weight 45 kg 49 kg
4.4 A
Current cooling mode 4 A 5 A
365 m3/h
310 m3/h
Temperature seng range
Airflow outside
510 m3/h
405 m3/h
Maximum volume of the cellar 30m3* 48m3*
* in a perfectly insulated room (PU 60mm on all sides).
** on the following condions: 12 ° C in the cellar / 32 ° C outside.
Power cable lenght
4

MPC
Genesis - Vintage
MPC
Genesis - Vintage
Equipement's table
HGR: Humidifier
CWR: Stabilizaon of humidity
KCH: electric heater
KPC: control of the condensing pressure
KFG: Ducted kit
RC : Compressor crankcase heater with opmi-
zaon soware and saving energy
KLP: Water pressure limiter kit
RSF: Wireless control
KBPL: Plenum
KGDD: double deflecon grille
KGS: insulate flexible duct.
Accessories
S: Standard / A:Accessories
Monobloc FRIAX comes with
- 4 corners of wall mounts
- A power supply cable 2m (230V single phase) - A box with wireless remote, table stand for
remote control and two baeries
- A flexible drain tube Ø 16 2m length
- A bag containing screws fixing brackets on the air condioner.
5
MPC 30 Genesis-plus MPC 48 Genesis-Plus MPC 30 Vintage MPC 48 Vintage
HGR %
CWR
KCH
KPC
RSF
RC
- - S S
S S S S
S S S S
S S S S
S S S S
S S S S
KGS
A A A A
KFG
KLP
KBPL
KGDD
A A A A
A A A A
A A A A
A A A A

Dimensions
480
449
616
628
674
Connecng the
drain
Ø 16
Operang principal
Power/ fuse holder/ switch
off
Inside cellar
Evaporator
Outside cellar
condenser
Ousde 32°C Cellar 12°C
Condenser Evaporator
KCH
Compressor
MPC
Genesis - Vintage
Humidifier water
supply 20/27 male on
vintage models
6

MPC
Genesis - Vintage
Installaon
Implementaon
- The air condioner must be installed in an open
area.
- In order to have a perfect distribuon of the air, it
is advisable to install the air condioner in height.
- All natural and mechanical venlaon should be
avoided in the cellar.
- Ensure that the hot air is discharged into a ven-
lated and sheltered room.
- Check the strength of the wall on which the unit is
aached.
- Respect the dimensions of the reservaon
- Never put obstacles in front of the blowing and
sucon facades of the device.
485 mm
454 mm
Hole dimensions
570mm Maximum
38 38
227
485
147
24
23
454
147
Posions of the holes for the brackets
7

MPC
Genesis - Vintage
Installaon
The monobloc-body is adapted
to be fixed at 5 different depths
of recess.
In certain posions and depending on the material of
the wall, it may be necessary to add reinforcements to
prevent the unit from pping
8
562
114
463 213
328 348
193 483
58 618

MPC
Genesis - Vintage
Installaon
Put the unit in the wall
install angle device. Use screws and anchors (not supplied) adapted to the wall type
(1) Connect the drain
Connect the drain tube (Ø 16) to the bend’s extremity with
the providing clamp.
(2) For Vintage models,
Connect the water supply to the HGR% humidifier.
The use of a KLPWSECU kit is essenal when the water
pressure is above 2.8bars.
9
(1)
(2)
Outside the Cellar
Inside the Cellar
A
B
C
D
E
E
F
G
H
A
Kits KLPWSECU
Optional kits
3/4” F
KLPWSECU
Secure connection kit for humidier HGR%
A:10 m 1/4" polyethylene exible tubing
B:One overow safety valves
C:One Isolation valve 1/4" 1/4 "
D:One Pressure limiter valve 1/4"
E:Three 1/4 - 3/4 "
F:One Y 1/4"-1/4"-1/4"
KLPR20
Extension kit of 20 m
G:20 m 1/4" polyethylene exible
tubing
H:One1/4" 1/4 " nipple JG
Max cold water pressure
10 bar at 21 °C
Inside the cellar
Outside the cellar

MPC
Genesis - Vintage
Wireless Remote
Power supply: 2 x 1.5V (AAA) baeries provided
The remote control could be installed in any room. Its maximum range is 100m in a
completely open area. This distance could be extremly reduced by thickness of walls
and the locaon of the cellar. It is possible to fix directly the remote to the unit by
using the screw holes on the MPC facade.
+
+
-
-
60
83
80
26
10

MPC
Genesis - Vintage
Wireless remote
Conguration type
Key lock indicator
Crankcase heater indicator
Silent indicator (EC fan evaporator)
Heating indicator
Cooling indicator
Condenser temperature probe
Humidier indicator (
VINTAGE model )
Cellar temperature probe
Parameter number
Setup mode
Radio frequency signal
Temperature or humidity indicator (option)
Battery charge level indicator
°C / °F or humidity (%) unit indicator
Speed condensor fan
Speed evaporator fan
Time (12 AM/PM or 24 h)
existing if EC evaporator fan
existing if EC condenser fan
Minus for negatives values
Lighting control
%
1
23456789
10
11
12
14
15
13
18
17 16
OK
-
+
Menu key
Return
Navigation key
Start key
Stand by
Stop
Navigation key
Validation key
-Red : heating mode
-Green : cooling mode
-Flashing red : Alarm
19
20
21
22
12
13
14
15
16
17
18
19
20
21
22
1
2
3
4
5
6
7
8
9
10
11
11

MPC
Genesis - Vintage
First start
Step I - Set the cellar fan speed
-For MPC 30 select the value * and confirm.
-For MPC 48 select the value * and confirm.
* Values for installaon without sheath.
When the device is installed outside the cave (OUT mounng) and the evaporator is clad, refer to the specific
instrucons EU-NT-MPC-KFG for speed adjustment.²
Step II - Starng
Seng the
speed evapora-
tor fan cellar
Even if the screen
is blank Press
for 6 seconds
Change the
screens with
OK
OK
confirm with
-
+
Change the value with
or
Access to
menu
Parameters Display Handling
See below the value
set according to the
device
Login with
Shorten the waing
period ** hold
Start the unit with the
remote control
The unit starts in heang
or cooling mode. If the set
is idencal to the tempe-
rature of the cellar, the
screen shows no opera-
on.
The unit starts.
If the icons and
are flashing the unit is in
standby mode.
Press
for 2 seconds
or
becomes xed
or
xed or ashing
** It is the preheating of the compressor crankcase heater which avoid any blow of liquid during the
rst start. It is preferable to respect this period until its completion
To exit the menu,
press
funcons Handling Views Remarks
Remarks
12

MPC
Genesis - Vintage
Sengs: temperature and humidity *
OK
Seng Handling Display Remarks
Adjust the tempe-
rature setpoints
and humidity (Vin-
tage Version)
Press
For 2 seconds Flashing
Flashing
Flashing
Flashing
Displays the current value
of the setpoint tempera-
ture
Displays the current value
of the set point humidity
(* Only on Vintage models)
Displays the value of
setpoint desired humidity
(* Only on Vintage models)
Displays the value of the
desired setpoint tempera-
ture
Returns to the display of
measured values in the
cellar
%
%
OK
confirm with
OK
confirm with
-
+
Change the value with
or
-
+
Change the value with
or
Step III - Set the cellar temperature and humidity
Restart the unit with the
remote control Resume in step II
Stop the unit with the
remote control.
Press
for 6 seconds
funcons Handling Views Remarks
Step IV - Stop the unit
Red LED on unit. The air
condioner is stopped but
the funcon of compres-
sor protecon remains
acve RC**
** If the unit remains ofor a long period of time, it is better to stop it this way. This will protect the
compressor when restarting
* Only on Vintage models
13

MPC
Genesis - Vintage
User menu
funcons Handling Views Remarks
Display the tempera-
ture or humidity of the
cellar
Put the fan in the cellar
in silent mode
Exit silent mode
Press
Press
Lock the keypad on the
remote control
Unlock the keypad on
the remote control
Pause the remote
screen
Out of standby screen
Stop the machine with
the remote
Start the unit with the
remote control
Flashing
Fixed
The display alternately
shows the value of the
temperature and humidity
(Only available on Vintage
model)
The fan switches to low
speed for 10 minutes
The fan returns to its
normal speed
Manipulaon buons no
longer possible to change
the sengs
Buons are accessible to
change the sengs
The screen turns off aer
a few seconds. The
appliance connues to
operate
The screen turns on and
displays the current values
Red LED on unit. The air
condioner stopped but
the compressor protecon
remains acve RC (crank-
case heater)
%
-
Press -
Then simultaneously
on
Then simultaneously
on
Press
Disappearing
Disappearing
Flashing
%
The unit starts.
If the lights and
are flashing the unit is in
standby mode.
or
xed
defrost mode Hold
Starts a manual defrost in
addion to the automac
defrost all 7 hours
Press
for 2 seconds
Press
for 2 seconds
Press
for 2 seconds
Press
for 2 seconds
Press
for 6 seconds
Lighng control
Press
5 Seconds
+
Lighng on / off
14

MPC
Genesis - Vintage
User menu
Seng the me
display. 12 or 24
hours
Seng the
temperature
unit
Seng the me
Set hours
Minute seng
Seng ° C / ° F
Switches from 12 h
AM / PM display on
24
Access to
menu
Parameters Display Handling
OK
OK
confirm with
-
+
Change the value with
or
Login with
OK
OK
confirm with
-
+
Change the value with
or
Login with
OK
OK
confirm with
OK
confirm with
-
+
Change the value with
or
-
+
Change the value with
or
Login with
Remarks
Even if the screen
is blank Press
for 6 seconds
Change the
screens with
To exit the menu,
press
15

MPC
Genesis - Vintage
User menu
Access to
menu
Parameters Screens Manipulations
OK
OK
confirm with
-
+
Change the value with
or
Login with
OK
OK
confirm with
-
+
Change the value with
or
Login with
OK
OK
confirm with
-
+
Change the value with
or
Login with
Remarks
This parameter is
set to 0 at the
factory. It may be
modified only in
the case where
there would be a
difference
between the
seng tempera-
ture and the real
temperature of
the cellar.
This parameter is
set to 0 at the
factory. It may be
modified only in
the case where
there would be a
gap between the
moisture displayed
and the real humi-
dity of the cellar.
Only available on
model Vintage
Lets venlaon at
low speed when
the air condioner
reaches its setpoint
temperatures and
humidity, to have a
permanent air
circulaon in the
cellar.
It is recommended
to leave this seng
enabled when the
evaporator is
ducng (version
OUT).
Calibrang the
temperature
sensor
Calibraon of
humidity probe
Seng the fan
status when the
setpoint is
reached
Even if the screen
is blank Press
for 6 seconds
Change the
screens with
To exit the menu,
press
16

Alarms codes MPC
Genesis - Vintage
Genesis temperature signal lost
type 2
Lower threshold wine cellar temperature
type 1
Upper threshold wine cellar temperature
type 1
Faulty wine cellar temperature
type 2
Vintage temperature signal lost
type 2
type 1
type 1
Upper threshold wine cellar humidity
type 1
type 2
Outside unit temperature signal lost
type 1
Upper threshold outside unit temperature
type 1
Faulty outside unit temperature
type 2
Faulty inside unit motor fan
type 2
type 2
Radio signal lost
type 1
AS1c
A SL
A SH
A SO
AS2c
A SL
A SH
AHRH
A SO
AS3c
AS3H
AS3O
AVEc
AVCc
A rF
Faulty outside unit motor fan
Upper threshold wine cellar temperature
Lower threshold wine cellar temperature
Faulty wine cellar temperature
Alarm code Error source
Cellar T° sensor
T° sensor + HR% cellar
(on Vintage model)
Condenser T° sensor
Evaporator fan
condenser fan
wireless communicaon
Type of error
Description
17
Two types of errors may appear on the wireless remote control.
Type 1 alarm : The Green and red LED on the front panel flashes.
Type 2 alarm : The red LED on the front panel flashes.
Contact your hardware vendor
OK
OK
OK

18
Reset
The reset will change the parameters to their factory value
Set the fan speed, temperature and humidity
Restart the unit
With the remote
Press .
For 2 seconds
Unit starts
If symbol or
flashes, unit is
in stand by mode
Press
unl or
become fixed
Press simultaneously
OK
Push
+10 Seconds
SPC
MPC
Genesis - Vintage
How to reset to factory configuraon with te remote controller.

MPC
Genesis - Vintage
Compressor
Fan
Heater
Wiring diagram
Solenoid valve on vintage
series
Crankcase heater
Temperature sensor
Temperature & humidity sensor
on Vintage series
GND
PWM1
TAC
CP HGR KCH EVF CDF POWER Sonde
cond
T°
LL L L L
N N N N N
blue
Yellow
White
Blue
Blue
Black
Black
5 x 20
10A GT
LN
T°+HGR
or
On Vintage
model
LNLN
EVF
RC
LN
LN
16 A max
AUX (light)
NC NO
COM
COM
NC
NO
(Example)
TC
TS
Klixon
TC
Klixon
TS
3
2
1
EC
0-10V
Jaune Yellow gelb
10V
Rouge+Red rot
GND
Bleu Blue blau
19

The following maintenance operations repeated every 6 months will allow your MPC air conditioner to maintain
its performance in optimal ways to ensure its longevity and that of your wines.
WARNING
Before carrying out any maintenance operations, switch othe appliance with the remote control,
cut othe power supply to the main circuit breaker.
Condenser maintenance (hot side)
Disassemble the front panel using an Allen key to access the air condenser battery.
Use a vacuum cleaner to remove dust. Be careful not to damage the ns.
Check that there are no leaves or any other object that could interfere with proper operation.
Maintenance of the evaporator (cold side)
Remove the front panel using an Allen key to access the air evaporator battery.
Use a vacuum cleaner to remove dust. Be careful not to damage the ns.
Disassemble the condensate pan using a screwdriver, clean it with water and then replace it.
Check that the drain is not blocked.
Maintenance
20
MPC
Genesis - Vintage
