Friedrich PDE07K Series User manual

PTACPRTS PD B-A (1-05) ** Digits vary with model.
Parts Manual
PTAC PD Series (Electronic Controls)
Packaged Terminal Air Conditioners
Packaged Terminal Heat Pumps
Serial Number LEAP and Later
MODELS
PDE07K**B-A
PDE07R**B-A
PDE09K**B-A
PDE09R**B-A
PDE12K**B-A
PDE12R**B-A
PDE15K**B-A
PDE15R**B-A
PDH07K**B-A
PDH07R**B-A
PDH09K**B-A
PDH09R**B-A
PDH12K**B-A
PDH12R**B-A
PDH15K**B-A
PDH15R**B-A

2
PTAC Model Number Identification Guide......................................................................................................3
PTAC Serial Number Identification Guide ......................................................................................................3
Unit Assembly................................................................................................................................................. 4
Unit Assembly Parts List................................................................................................................................. 5
Air Handler ..................................................................................................................................................... 6
Air Handler Parts List ..................................................................................................................................... 7
Control Box Assembly .................................................................................................................................... 8
Front Cover Assembly .................................................................................................................................. 10
Notes ............................................................................................................................................................ 11
Table of Contents

3
UNIT IDENTIFICATION
Model Number Code
PD H 07 K 3 S B A
Engineering Digit
Design Series
Options
S = Standard
R = Remote Thermostat
C = Seacoast Protection
X = Seacoast / Remote
Nominal Heater Size
(@ 230V or 265V)
0 = No Heater
2 = 2.5KW
3 = 3.4KW
5 = 5.0KW
Voltage
K = 208/230V - 1Ph. - 60Hz.
R = 265V - 1Ph. - 60Hz.
Nominal Cooling Capacity
07 = 7000 BTUh
09 = 9000 BTUh
12 = 12000 BTUh
15 = 15000 BTUh
System
X = Accessory
E = Cooling with or
without electric heat
H = Heat Pump with
Auxiliary Heat
Series
PD = P Series Digital PTAC
Serial Number L E A P 00000
Production Run Number
Decade Manufactured
L = 0 C = 3 F = 6 J = 9
A = 1 D = 4 G = 7 Product Line
B = 2 E = 5 H = 8
R = RAC
Year Manufactured P = PTAC
A = 1 C = 3 E = 5 G = 7 J = 9 E = EAC
B = 2 D = 4 F = 6 H = 8 K = 0 V = VPAK
H = DSS
Month Manufactured
A = Jan D = Apr G = Jul K = Oct
B = Feb E = May H = Aug L = Nov
C = Mar F = Jun J = Sep M = Dec
PTAC Serial Number Identification Guide

4
UNIT ASSEMBLY
17
13
10 11
15
16
14
12
18

5
REF. PART NO. DESCRIPTION 07 09 12 15 NOTES
N/S 25059400 Coil, Indoor 111–
N/S 25065000 Coil, Indoor –––1
10 25014820 Coil, Outdoor 1111
10 25014821 Coil, Outdoor 1111 Seacoast
10 25064800 Coil, Outdoor- Heat Pump Only –––1
10 25064801 Coil, Outdoor- Heat Pump Only –––1 Seacoast
11 25024915 Compressor, 230 Volt 1–––
11 25024908 Compressor, 230 Volt –1––
11 25024907 Compressor, 230 Volt ––1–
11 25024910 Compressor, 230 Volt –––1
11 25024914 Compressor, 265 Volt 1–––
11 25024913 Compressor, 265 Volt –1––
11 25024912 Compressor, 265 Volt ––1–
11 25024911 Compressor, 265 Volt –––1
12 03760548 Cap Tube A/C-Electric Only 1–––
12 03760547 Cap Tube A/C-Electric Only –1––
12 03760511 Cap Tube A/C-Electric Only ––1–
12 01389985 Cap Tube A/C-Electric Only –––1
12 03760547 Cap Tube, Cooling, Heat Pump 1–––
12 03760547 Cap Tube, Cooling, Heat Pump –1––
12 01390000 Cap Tube, Cooling, Heat Pump ––1–
12 01389975 Cap Tube, Cooling, Heat Pump –––1
13 03760473 Cap Tube, Heating, Heat Pump 1–––
13 03760547 Cap Tube, Heating, Heat Pump –1––
13 01389975 Cap Tube, Heating, Heat Pump ––1–
13 01389985 Cap Tube, Heating, Heat Pump –––1
14 25057200 Check Valve 1–––
14 25057201 Check Valve –111
15 25022010 Reversing Valve Kit (Includes Solenoids) 11––
15 25022020 Reversing Valve Kit (Includes Solenoids) ––11
16 25022050 Solenoid Coil 230 Volt 1111
16 25022060 Solenoid Coil 265 Volt 1111
17 60179903 Condensate Valve (bellows type) 1111
18 25014502 Drain Pan 1111
N/S 61764537 Overload Compressor 230 Volt 1–––
N/S 61764535 Overload Compressor 230 Volt –1––
N/S 61764521 Overload Compressor 230 Volt ––1–
N/S 61764532 Overload Compressor 230 Volt –––1
N/S 61764543 Overload Compressor 265 Volt 1–––
N/S 61764542 Overload Compressor 265 Volt –1––
N/S 61764541 Overload Compressor 265 Volt ––1–
N/S 61764538 Overload Compressor 265 Volt –––1

6
AIR HANDLER
26
24
25
23
27
24
28
30
29
21
22
23
20

7
REF. PART NO. DESCRIPTION 07 09 12 15 NOTES
20 25038401 Discharge Screen 1111
21 25067500 Air Deflector 1111
22 25016011Deck 1111
23 25059160 Heater, 2.5 kW @ 230 Volt 1111
23 25059161 Heater, 3.4 kW @ 230 Volt 1111
23 25059184 Heater, 5.0 kW @ 230 Volt 1111
23 25059162 Heater, 2.5 kW @ 265 Volt 1111
23 25059163 Heater, 3.4 kW @ 265 Volt 1111
23 25059185 Heater, 5.0 kW @ 265 Volt 1111
24 25036400 Support Brace (condenser) 1111
25 60542006 Condenser slinger blade 1111
26 25036801 Condenser Shroud 1111
27 25015300 Fresh Air Door Screen 1111
27 25034900 Fresh Air Door Insulation 1111
28 25014400 Motor Mount Bracket 1111
29 25014600 Motor, 230 Volt 1/15 HP 2P 11––
29 25014610 Motor, 230 Volt 1/10 HP 2P ––11
29 25014601 Motor, 265 Volt 1/15 HP 2P 11––
29 25014611 Motor, 265 Volt 1/10 HP 2P ––11
30 25069100 Blower Wheel 7-9 11––
30 25069000 Blower Wheel 12-15 ––11
N/S 25014306 Scroll 7-9 11––
N/S 25014306 Scroll 12-15 ––11
N/S 60217902 Seal, Motor to Wall 1111
N/S 25015900 Fresh Air Door Latch 1111
N/S 25045100 Fresh Air Door Cable 1111
N/S 25059620 Primary Limit Switch 145°F 2.5-3.4 kW 1111
N/S 25059621 Primary Limit Switch 155°F 5 kW ––11
N/S 25059618 Secondary Limit Switch 200°F 1111
N/S 61828200 Suction Dryer 1111
N/S 60308101 Liquid line Dryer (not for heat pump) 1111Cooling Only
N/S 25065700 Jumper, Heater 1111

8
CONTROL BOX ASSEMBLY
REF. PART NO. DESCRIPTION 07 09 12 15 NOTES
49 60500190 LCDI, 15A (2.5kW @ 230 Volt) 1111
49 60500191 LCDI, 20A (3.4kW @ 230 Volt) 1111
49 60500192 LCDI, 30A (5.0kW @ 230 Volt) 1111
58 20061450 Strain Relief 15/20A 1111
58 20086915 Strain Relief 30A 1111
50 25070050 Electronic Control Kit 1111See Note*
51 61921152 Dual Thermistor 1111
52 61921153 Single Thermistor 1111Heat Pump
53 25067900 Thermistor Holder 2222
54 25070102 Heat Cool Escutcheon 1111
55 25070103 Cool Only Escutcheon 1111
56 25070104 Remote Thermostat Escutcheon 1111
N/S 61080541 Capacitor, 20/5 @ 370 (230 Volt) 1–––
N/S 61080573 Capacitor, 15/5 @ 440 (265 Volt) 1–––
N/S 61080539 Capacitor, 25/5 @ 370 (230 Volt) –1––
N/S 61080571 Capacitor, 20/5 @ 440 (265 Volt) –1––
N/S 61080565 Capacitor, 30/5 @ 370 (230 Volt) ––1–
N/S 61080571 Capacitor, 20/5 @ 440 (265 Volt) ––1–
N/S 61080565 Capacitor, 30/5 @ 370 (230 Volt) –––1
N/S 61080571 Capacitor, 20/5 @ 440 (265 Volt) –––1
51
52
55
56
54
*Note: Electronic Control Kit includes: Electronic Control Board, Dual Thermister, Single Thermister, Thermister Holder (2),
Escutcheons (Heat/Cool, Cool Only, Remote Thermostat) and Installation Instructions
58
49
53
RYW BGLGHCD1D2F1F2
JP1
12345678
ON DIP
88
50

9
FRONT COVER
REF. PART NO. DESCRIPTION 07 09 12 15 NOTES
60 25037904 Front Cover Complete (Includes Door and Filters) 1 1 1 1
61 25031903 Control Door 1 1 1 1
62 25025903 Grille, Discharge 1 1 1 1
63 25037804 Filter 2 2 2 2
N/S 25060600 Thumb Screw 2 2 2 2
N/S 25060500 Speed Nut (U-Type) 2 2 2 2
60
63
61
62

NOTES
