Frigidaire FAS256R2A - 25,000-BTU Window Air... User manual

M40L0004.eps FAS256R2A Parts.eps 63611615.eps
Product No. FAS296R2A1
Series heavy duty
Color white
Volts 230/208
BTU-Cooling 28500/28000
Owner's Guide 66121617en
Installation Instructions 66121625
Market North America
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995487955
07/04/03
(EN/SERVICE/KC)
099
ROOM AIR
CONDITIONER
Model No.
FAS296R2
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995487955 FAS296R2A1
04/07 2
RECOMMENDED SPARE PARTS

FAS296R2A1 Publication No: 5995487955
# Functional Parts 3 04/07
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
POS. NO PART NO. DESCRIPTION
1 5304459566 Cabinet, wrapper/sleeve
2 # 5304459567 Condenser
3 # 5304459568 Tube, inlet, condenser
4 # 5304459570 Tube, outlet, condenser
5 5304459571 Cover, condenser/fan, top
6 5304459169 Nut, M8
7 5304459170 Washer, #8
8 5304459171 Washer, #8
9 # 5304459172 Fan Blade, propeller
10 5304459572 Shroud, condenser fan
11 5304459175 Nut, M6
12 5304459176 Washer, #6
13 # 5304459573 Motor, fan
14 # 5304459575 Capacitor, motor
15 5304459178 Cover, capacitor box
16 5304459183 Strap, capacitor clamp
17 5304459576 Bulkhead, air system
18 5304459775 Scroll, blower housing, rear
19 5304459578 Door, fresh air vent, with lever
20 5304459580 Scroll, blower housing, front
21 5304459192 Link, lever/vent door
22 5304459581 Cover, top plate, blower scroll
23 # 5304459187 Blower Wheel, centrifugal fan
24 5304459188 Washer, #10
25 5304459189 Washer, #10
26 5304459190 Nut, M10
29 # 5304459584 Evaporator
30 5304459194 Clip, sensor support
31 # 5304459196 Transformer
32 # 5304459585 PC Board, control, main
33 # 5304459234 Relay
35 5304459586 Control Box
36 # 5304459592 Power Cord, electric, LCDI
37 5304459237 Clamp, wiring
38 # 5304459439 Ionizer, clean air
39 5304459593 Bulkhead, control system
40 # 5304459597 Control Panel Assembly, console
41 # 5304459601 PC Board, display/input
42 5304459604 Control Panel, display console
43 5304459608 Overlay, control display
44 5304459244 Handle, vent control
45 5304459246 Nut, M6, with washer
46 5304459268 Clamp, sump tube
47 # 5304459610 Tube, sump
49 # 5304459614 Compressor, with overload
50 5304459616 Grommet, compressor
51 5304459256 Nut, compressor, M8, w/washer
53 5304459619 Base, unit chassis
54 5304459621 Tray, drip pan, foam
55 # 5304459623 Tube, discharge
56 # 5304459627 Tube, capillary

Publication No: 5995487955 FAS296R2A1
04/07 4
RECOMMENDED SPARE PARTS

FAS296R2A1 Publication No: 5995487955
# Functional Parts 5 04/07
* Non-Illustrated Parts
RECOMMENDED SPARE PARTS
POS. NO PART NO. DESCRIPTION
57 # 5304459630 Tube, suction
58 # 5304459631 Front Assembly, complete panel
59 5304459633 Panel, frame, front
60 5304459272 Gasket, vertical louver, rubber
61 # 5304459635 Louver, vertical
62 5304459636 Knob, auger wheel, louver
63 # 5304459637 Filter, air
64 # 5304459639 Louver, horizontal
65 5304459641 Panel, front grille, tilt-out
66 # 5304459106 Remote Control, transmitter
69 5304459642 Frame, shutter, left
70 5304459643 Frame, shutter, right
71 5304459644 Shutter, accordion panel
72 5304459645 Retainer, shutter, cabinet sides
73 5304459537 Bracket, support, left, angle
74 5304459538 Bracket, support, right, angle
75 5304459646 Rail, shutter track, top
76 5304459559 Seal, sash, window stuffer
77 5304459560 Seal, bottom rail, cab/chassis
78 5304459647 Seal, top rail, cabinet
79 5304459774 Kit, shutter lock, screw/washers
83 5304459648 Hardware Kit, installation

Publication No: 5995487955 FAS296R2A1
04/07 6
WIRING DIAGRAM
