Frisco 156786 User manual

1-800-672-4399
Available exclusively at
END TABLE
LITTER BOX ENCLOSURE
INSTRUCTION MANUAL

1-800-672-4399
Available exclusively at
OVERVIEW
In only 10 steps, you’ll have a brand new covered litter box for your kitty—and a chic end table, great to hold a plant, clock
or your keys!
GEAR UP
You’ll need a Phillips head screwdriver (not included). A power tool is not recommended.
IT TAKES TWO
We recommend this as a two-person project.
ASSEMBLY INSTRUCTIONS FOR ITEM #156786
1 Door Panel (#3)
1 Right Panel (#6)
1 Bottom Panel (#4)
1 Bottom Trim (#5)
1 Left Panel (#1)
1 Back Panel (#7)
1 Shelf Panel (#2)
1 Top Panel (#8)
1 Bottom Metal Hinge (D)
6 x M3.5 x 10mm
Wood Screws (F)
12 Cam Locks (G)
1 Door Handle (H)
1 Metal Plate (I)
1 Top Metal Hinge (E)
1 x M3.5 x 20mm Screw (A)
12 Cam Lock Bolts (C)
16 Wooden Dowels (B)
+2 Extra
+1 Extra
+1 Extra
PARTS INCLUDED
Prior to assembly, please be sure to identify and sort all parts shown below.

1-800-672-4399
Available exclusively at
STEP 2aGrab the bottom panel (#4). Locate the outer holes
on each long side and insert 2 wooden dowels (B). Repeat for the
other side.
STEP 2bGrab the shelf panel (#2). Locate the outer holes on
each long side and insert 2 wooden dowels.
STEP 1aLocate the door panel with entrance hole (#3) and
stand upright. This will be the front door. Place the screw (A) through
the hole from the back, located on the left side of the panel. Now
fasten the door handle (H) using the screw and tighten fully.
STEP 1bLocate the 4 small holes at the top and bottom of
the door. Take the two metal hinges (D & E) and use the 4 small
screws (F) to attach them to the back of the panel.
STEP 1cLocate the remaining 2 holes on the back of the door.
Attach the metal plate (I) using 2 small screws (F) and tighten fully.
STEP 4a Place the left-side panel (#1) on a flat and clean surface.
Align the wooden dowels on the shelf panel installed in step 2b with
the holes on the left-side panel. Hint—the pre-installed magnet
should be facing away from the cam lock holes.
STEP 4bAlign the wooden dowels in the bottom panel and the
cam lock bolts on the left-side panel and push down lightly. Hint—
the pre-installed metal triangle plate should be facing toward the
shelf panel.
STEP 4cInsert 2 cam locks (G) into the bottom side of the shelf
panel (#2) and turn cam locks clockwise to secure. Repeat the same
for the bottom panel (#4).
STEP 5 Find the door panel (#3) and align the metal hinge
with the hole on the metal triangle plate on Shelf panel (#2).
Align opposite metal hinge with hole on the metal triangle plate
on the bottom panel (#4). Hint—wiggle the shelf and bottom
panel slightly to ensure the hinges are engaged in the holes.
Close the door (magnet will hold door in place).
STEP 6 Locate the 2 holes on each side of the bottom trim
(#5) and insert 4 wooden dowels into all 4 holes. Attach the
bottom trim by aligning the dowels with the 2 holes to the
bottom of the left panel (#1). on the back of the enclosure.
2a
1c1b1a
6
4
5
STEP 3 Lay left-side panel (#1) on a flat surface with the
threaded holes facing up. Insert 4 cam lock bolts (C) into the
threaded holes located at both ends of the panel. Tighten the
cam lock bolt using a screwdriver, do not over tighten. Repeat
tightening the 4 cam lock bolts for the right-side panel (#6).
3
2b

1-800-672-4399
Available exclusively at
WARNINGS AND CAUTIONS
Please read all warnings and instructions thoroughly before assembling.
• Grab a friend—it’s recommended that two people assemble this product.
• Assembly should be completed on a clean, level surface.
• Power tools are not recommended for assembly.
• Please handle all panels and hardware with care to avoid any damage.
• This litter box cover is intended for pet use only.
• Do not sit or stand on the assembled product.
CLEANING INSTRUCTIONS
Spot clean with a damp cloth as needed
STEP 9 Locate the top panel (#8), insert 4 cam lock bolts
into the threaded holes located at the four corners of the top
panel, tighten using the screwdriver. (Do not over tighten).
Insert 4 wooden dowels into the 4 remaining open holes.
9
STEP 10 Align cam lock bolts and dowels on top panel (#8)
with holes on the top of left/right panels (#1 & #6) and gently
press down to engage with the enclosure. Insert cam locks into
the large hole on the left and right panels (#1 & #6). Turn cam
locks clockwise to secure.
10
NICE AND TIGHT? ALRIGHT!
After you double-check to make sure ALL cam locks are securely tightened, your stylish litter enclosure can
be open for business!
Tip: To protect against messes, we recommend placing a potty pad under the litter box.
CALL OUR FRIENDLY CUSTOMER SERVICE TEAM ANYTIME.
WE’RE HERE 24/7! 1-800-67-CHEWY (672-4399)
QUESTIONS?
STEP 7 Align cam lock bolts on the right panel (#6) to the
top of the partially built enclosure and push down to secure in
place. Gently flip the enclosure upright. Insert cam locks into
shelf and bottom panel (2 per panel). Turn cam locks clockwise
to secure assembly.
STEP 8 Locate the back panel (#7). Slide into the 2 grooves
on the back of the enclosure.
7 8
