Fromm A480 Guide

13411001.en/MAS/© 12.03
CE Declaration of conformity
We declare that the machine A480
is in conformity with the following standard or
standardised documents:
98/37/EEC
FROMM Holding AG
Hinterbergstrasse 26
CH - 6330 Cham
08.12 2003
R.Fromm
Director
OPERATION MANUAL / SPARE PARTS LIST
PNEUMATIC COMBINATION
PUSHER TYPE TOOL
MODEL A480
13.4110.01

2
INDEX PAGE
1 SAFETY INSTRUCTIONS 3
2 WARRANTY CONDITIONS AND LIABILITY 4
3APPROPRIATEUSE 4
4 CHART OF TYPES 4
5 TECHNICAL DATA 5
5.1 Dimensions without suspension bracket . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.2 Steel strap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.3 Seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.4 Joint. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.5 Compressed air. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.6 Sound information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5.7 Vibration information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6 INSTALLATION 6
6.1 Compressed air connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6.2 Suspension of tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
7 MAINTENANCE 7
7.1 Air - unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7.3 Lubrication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
8 JOINT CONTROL 7
9 SPARE PARTS LIST 13.4110.01 10
10 OPERATION 13
10.1 Feeding the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
10.2 Introducing the tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
10.3 Tensioning the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
10.4 Sealing the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10.5 Releasing the tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10.6 Tension regulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3
1 SAFETY INSTRUCTIONS
Read these instructions carefully. Failure to follow these instructions can result in severe personal injury.
Eye injury hazard
Failure to wear safety glasses with side shields can result in
severe eye injury or blindness. Always wear safety glasses with
side shields which conform to ANSI Standard Z87.1.
Operation
Tool must not be used by persons not properly trained in their use.
Before tensioning strap, read and understand the tool operating
instructions. Failure to follow the operating instructions or improper
load positioning could result in strap breakage.
Become familiar with your tool and keep fingers away from areas
that can pinch or cut.
Joints
You are fully responsible to review the joints made by your tool.
Become familiar with the seal control and seal adjustment descri-
bed in this operation manual. Misformed joints may not secure the
load and could cause serious injury. Never handle or ship any load
with improperly formed joints.
Dispensing strap
Only dispense strap from a dispenser specifically designed for
strap.
Tuck strap end back into dispenser when not in use.
Protective gloves
When handling strap, always wear protective gloves.
Strap warnings
Never use strap as a means of pulling or lifting loads. Failure to fol-
low these warnings can result in severe personal injury.
Strap breakage hazard
Improper operation of the tool, excessive tensioning, using strap
not recommended for this tool or sharp corners on the load can
result in a sudden loss of strap tension or in strap breakage during
tensioning, which could result in the following:
• A sudden loss of balance causing you to fall.
• Both tool and strap flying violently towards your face.
Note as follows:
• If the load corners are sharp, use edge protectors.
• Place the strap correctly around a properly positioned
load.
• Positioning yourself in-line with the strap, during tension-
ing and sealing, can result in severe personal injury from
flying strap or tool. When tensioning or sealing, position
yourself to one side of the strap and keep all bystanders
away.
• Use the correct strap quality, strap width, strap gauge and
strap tensile strength recommended in this manual for
your tool. Using strap not recommended for this tool can
result in strap breakage during tensioning.
Cutting tensioned strap
When cutting strapping, use the proper strapping cutter and keep
other personnel and yourself at a safe distance from the strap.
Always stand to side of the strap, away from the direction the loo-
sened strap end will fly. Use only cutters designed for strap and
never hammers, pliers, hacksaws, axes, etc.
Fall hazard
Keep your working area tidy. Untidiness of your working area may
cause a risk of injury. Maintaining improper footing and/or balance
when operating the tool can cause you to fall. Before tensioning
and especially in elevated areas, always establish good balance.
Both feet should be securely placed on a flat, solid surface, espe-
cially when working in elevated areas. Do not use the tool when
you are in an awkward position.
Pay attention to the rules and regulations for preventions of acci-
dent which are valid for the work place.
Tool hazards
A well maintained tool is a safe tool!
Check tool regularly for broken or worn parts. Do not operate a
tool with broken or worn parts.
Never modify any tool. Modification can result in severe bodily
injury.

4a480man.en_teil1
2 WARRANTY CONDITIONS AND LIABILITY
FROMM Holding AG warrants all its strapping tools and machine heads during a period of 24 months from the
date of installation at the end-user's sight by the distributor, however, not later than 30 months from the date of
shipment to the distributor of FROMM Holding AG.
The warranty includes all deficiencies clearly resulting from poor manufacturing or faulty materials. Damage
claims as a result of production shutdowns and claims for damage to persons and to property resulting from
warranty deficiencies cannot be asserted by the customer.
The warranty excludes:
• wearing parts
• deficiencies resulting from improper installing, incorrect handling and maintaining the tool
• deficiencies resulting from using the tool without or with defective security- and safety devices
• disregard of directions in the operation manual
• arbitrary modifications of the tool
• deficient control of wearing parts
• deficient repair works of the tool
• Use of consumable products not recommended by FROMM Holding AG
We reserve the right to modify the product at any time in order to improve its quality.
3 APPROPRIATE USE
The tool model A480 has been designed to strap packages with steel strapping exclusively.
The warranty / liability excludes:
• non appropriate use of the tool,
• disregard of directions in the operation manual,
• disregard of control- and maintenance instructions.
4 CHART OF TYPES
Uniflex = Strap with max. tensile strength of 850 N/mm2(123 000 psi)
Ultraflex = Strap with max. tensile strength of 1100 N/mm2(160 000 psi)
Item
no. Model Strap quality: Uniflex and Ultraflex Max. tens- ioningforce Max. tens - ioning speed
Strap width Strap thickness Nlbs mm/s inch/s
13.4050 A480/10/0.38-0.63/4.5 10 mm / 3/8" 0.38-0.63 mm / .015-.025" 4500 1000 100 4.0
13.4052 A480/10/0.38-0.63/2.5 10 mm / 3/8" 0.38-0.63 mm / .015-.025" 2500 560 180 7.1
13.4070 A480/13/0.38-0.63/4.5 13 mm / 1/2" 0.38-0.63 mm / .015-.025" 4500 1000 100 4.0
13.4072 A480/13/0.38-0.63/2.5 13 mm / 1/2" 0.38-0.63 mm / .015-.025" 2500 560 180 7.1
13.4090 A480/16/0.38-0.63/4.5 16 mm / 5/8" 0.38-0.63 mm / .015-.025" 4500 1000 100 4.0
13.4092 A480/16/0.38-0.63/2.5 16 mm / 5/8" 0.38-0.63 mm / .015-.025" 2500 560 180 7.1
13.4110 A480/19/0.38-0.63/4.5 19 mm / 3/4" 0.38-0.63 mm / .015-.025" 4500 1000 100 4.0
13.4112 A480/19/0.38-0.63/2.5 19 mm / 3/4" 0.38-0.63 mm / .015-.025" 2500 560 180 7.1

5
a480man.en_teil1
5 TECHNICAL DATA
5.1 Dimensions without suspension bracket
5.2 Steel strap
5.3 Seals
5.4 Joint
Joint strength: approx. 55% of the strap’s tensile strength.
A single-notch (one pair of cut notches) is made per cycle.
5.5 Compressed air
Tool Package
Length: 304 mm / 11.86" 440 mm / 17.16"
Width: 145 mm / 5.66" 253 mm / 9.87"
Height: 155 mm / 6.05" 170 mm / 6.63"
Weight: Net Gross
4.5 kg / 9.9 lbs 5 kg / 11 lbs
Width: 10 - 19 mm/ 3/8" - 3/4" (see chart of types)
Thickness: 0.3 8- 0.63 mm /.015 - .025" .
Quality: The A480 model allows the use of all current steel straps with tensile strengths
ranging from 87 000 to 160 000 psi (600 - 1100 N/mm2).
Straps with a low breaking elongation are not suitable for the A480 tool.
Strap width: Seal dimensions:
10 mm / 3/8" 10x22x0.6 / 3/8"x7/8"x0.024", with overlapping flanges
13 mm / 1/2 " 13x22x0.6 / 1/2"x7/8"x0.024", with overlapping flanges
16 mm / 5/8" 16x22x0.6 / 5/8"x7/8"x0.024", with overlapping flanges
19 mm/ 3/4" 19x22x0.6 / 3/4"x7/8"x0.024", with overlapping flanges
Joining thread: G 1/4"
Air tube: Min. inside diameter = 8 mm / 3/8"
Working pressure: 4.2 - 6 bar / 60 - 87 psi
Max. air pressure: 6 bar / 87 psi
Air consumption: Tensioning Sealing
450 Nl / 15.8 cu.ft. per minute 2.5 Nl / 0.09 cu.ft. per cycle

6a480man.en_teil1
5.6 Sound information
The A-weighted equivalent continuous sound level at the work place of the machine operator is
typical 83 dB (A).
This value was determined according to DIN 45 635 T3 (11.85).
5.7 Vibration information
The weighted effective value of the acceleration typically amounts to less than 2,5m/s2.
This value was determined according to DIN EN 28 662 T1 (01.93).
6 INSTALLATION
6.1 Compressed air connection
The compressed air is preferably connected to the tube connection A48.1306 using a coupling. An air-unit
consisting of a separator for water and dirt, a pressure regulator with a manometer and a lubricator should be
installed within a range of 15 ft / 5 meters. The compressed air must be free from dirt, rust and moisture.
6.2 Suspension of tool
It is possible to suspend the tool in its three main working positions on a spring loaded balancer by providing
the tool with the necessary suspension bracket. The standard suspension bracket A48.1301 is always
automatically supplied with the tool.
Standard position
Standard suspension bracket A48.1301.
2 screws N1.1125
Vertical position
Standard suspension bracket A48.1301
2 screws N1.1125
Horizontal position
Side suspension bracket A48.1304.
2 screws N1.1125
Ordering separately

7
a480man.en_teil1
7 MAINTENANCE
Depending on the working conditions and the use of the tool the following maintenance has to be made
periodically:
7.1 Air - unit
• Checking the air-pressure daily.
• Checking oil-level daily.
• The water separator must be emptied before it is full (unless automatic).
• The filter has to be cleaned following the instructions of the manufacturer of the air- unit.
Oil for the air-unit
HL or CL ISO-VG 10
7.2 Cleaning
If impact of dirt and dust is considerable and if painted straps are used the feed wheel must be cleaned
regularly. Normally it is sufficient to blow out this part by using an air gun.
7.3 Lubrication
The worm gear is filled with MOLYKOTE BR 2 PLUS. Use the same type of grease after repairs.
When being exchanged, all valve parts and other movable parts have to be greased with grease of type
ESSO BEACON 2 or with any equivalent product.
The diaphragm must always be rubbed with TALCUM before being installed.
8 JOINT CONTROL
A regular control of the joint is necessary. The joint can be checked visually and the person controlling can
easily judge the quality of the joint. Following illustration shows a proper joint:
Sharp edged or misformed joints which do not appear as shown have to be taken away from the load
immediately. The tensile strength of these joints is insufficient and they could cause serious injury.
Having faulty joints proceed as follows:
• Checking the sealing cycle for improper use.(see OPERATION)
• Having faulty joints in spite of proper use, inspect the tool for worn or damaged parts. In case of
wearing out or damaging replace tool parts as needed.

A
B
C
D
E
1 2 3
A48.1134
A48.1132
N1.2135 
 N1.1110
 A48.1108
 A48.1108
 A48.1104
 A48.1111
N1.5302
N1.5302
N1.5302N1.5302
 A48.1116
N1.1170 A48.1117
N4.9135
N2.4902
A48.1112 
A48.1113 
A48.1110 
A48.1114 
A48.1115
N1.2105
N1.1208
A48.1127 
N1.6207
A48.1129
A48.1133 A48.1130 N2.2102
 A48.1128
N3.2312
A48.0113
A48.1244
A48.1223
N2.2106
N2.2106
N1.1168
N7.1201
N3.2314
A48.1221
A48.1217
 A48.1222
N2.3201
 N7.1101
 A48.1109
N2.5144 
N2.2129
A48.1133
A48.1130
 N1.2135
N2.5802

 A48.1231
 A48.1119
A48.1131
N1.1202
N1.6207
N1.6207
A48.1118
 N2.5145
N1.1125
A48.1301
N1.5301
A48.1236
N41.9129N41.9128
A48.1304
A48.1210
 A48.1241

4567
 A48.1227
A48.1229 
A48.1228 
N6.6230 
N3.1708 
N2.5151 
 A48.1229
N2.5102 
N1.1125
A48.1213
N1.2136 
N6.5195 
A48.1120
A48.1121
N6.6701 
A48.1238 
N1.1143
N1.2209
A48.1232
A48.1233
A48.1234 
 N6.6229
 N3.1708
 N2.5102
N3.2313
 N2.5131
N3.4102
N2.3201
 A48.1218
N3.4307
A48.1235 
 A48.1224
N3.2314
A48.1220
N3.1131 A48.1226
L2.1108
A48.1306
A48.1238 
N6.5195 
 Loctite 222
 Loctite 542
 Talkum
 ESSO Beacon 2
 Molykote BR 2 plus

Loctite 243
 Loctite 648
 UHU plus Endfest 300
A48.1237
A48.1214
N1.1539
N1.5103
 N6.5133
 N6.6230
A48.1230
13411001Z
A48.1212 

[ ] = Group * = Wearing parts
10 13411001.een
9 SPARE PARTS LIST 13.4110.01
13.4110.01 A480/19/0.38-0.63/4.5 A480.0001.01 11.06.02
Item-No. in group Pcs. Description Dimension Field
[A48.0113] 1 JAW ASSEMBLY 19 MM D1
A48.1104 *A48.0113 2 CUTTING JAW D2
A48.1108 *A48.0113 2 NOTCHING KNIFE D1+
A48.1109 A48.0113 2 JAW PIN D2
A48.1110 A48.0113 2 FRONT TOGGLE LINK C2
A48.1111 A48.0113 2 LEVER BOLT D1
A48.1112 A48.0113 1 PISTON ROD C2
A48.1113 A48.0113 1 ROD BAR BOLT C2
A48.1114 A48.0113 1 SIDE PLATE C3
A48.1115 A48.0113 1 SPACER BUSH C3
A48.1116 A48.0113 1 SIDE PLATE C1
A48.1117 A48.0113 2 SPACER BUSH C2
[A48.1118] 1 CYLINDER BOTTOM B2
A48.1119 1 PISTON PLATE B3
[A48.1120] 1 CYLINDER COVER A4
[A48.1121] 1 TENSIONING RING B4
A48.1127 *1 CUTTER 19 MM C3
A48.1128 *1 CUTTER JACK E3
[A48.1129] A48.1134 1 CONNECTION PLATE D3
A48.1130 A48.1134 2 STOP BOLT D3+
A48.1131 1 JAW GUIDE B3
A48.1132 1 COVER PLATE C1
A48.1133 2 TONG GUIDE D3+
[A48.1134] 1 CONNECTION PLATE C3
[A48.1210] *1 TENSIONING BODY D4
A48.1212 A48.1210 1 DISTANCE BOLT D4
A48.1213 *1SLIDEPLATE D4
[A48.1214] 1 GEAR BODY D5
A48.1217 1 TENSION SHAFT E3
A48.1218 1 WORM WHEEL C5
A48.1220 1 END COVER C6
A48.1221 *1 TENSIONING WHEEL E3
A48.1222 1 PIVOT PIN D3
A48.1223 A48.1244 1 END COVER E2
A48.1224 1 WORM D5
A48.1226 1 BEARING JACKET D6
A48.1227 1 VALVE SHELL C4
A48.1228 1 VALVE SHELL C5
A48.1229 2 VALVE BOLT C4+
A48.1230 1 LEVER BODY B5
A48.1231 1 SHAFT C4
A48.1232 1 TENSIONER VALVE LEVER B5
A48.1233 1 SEALING VALVE LEVER C5
A48.1234 1 CATCH C5
A48.1235 1 CATCH PIN D5
A48.1236 1 HANDLE C3
A48.1237 1 SIEVE D5
[A48.1238] 2 HOSE A5+
A48.1241 A48.1210 1 DISTANCE DISK E4
[A48.1244] 1 END COVER E1
[A48.1301] 1 SUSPENSION A3

[ ] = Group * = Wearing parts
11
13411001.een
[A48.1306] 1 HOSE CONNECTION E6
[L2.1108] 1 AIR MOTOR D7
L2.1201 L2.1108 1 EXHAUST RING --
L2.1203 L2.1212 1 PLASTIC JACKET --
[L2.1212] L2.1108 1 HOUSING --
L2.1301 L2.1108 1 END PLATE --
L2.1302 L2.1108 1 PARALLEL PIN --
L2.1303 L2.1108 1 CYLINDER --
L2.1304 *L2.1108 5 VANE --
L2.1305 L2.1108 1 ROTOR --
L2.1306 L2.1314 1 KEY --
L2.1308 L2.1108 1 SILENCER --
L2.1309 L2.1108 1 PLANET SHAFT --
L2.1310 L2.1108 2 NEEDLE CAGE --
L2.1311 L2.1108 2 GEAR WHEEL --
L2.1312 L2.1108 2 SHAFT --
L2.1313 L2.1108 1 BEARING RING --
[L2.1314] L2.1108 1 END PLATE --
L2.1402 L2.1108 32 BEARING NEEDLE --
L2.1403 L2.1108 2 GEAR WHEEL --
L2.1404 L2.1108 2 SHAFT --
L2.1405 L2.1108 1 BEARING RING --
L2.1408 L2.1108 1 PLANETARY CAGE --
L2.1409 L2.1413 1 AIR INLET RING --
L2.1410 L2.1413 1 TENSION SCREW --
L2.1411 L2.1413 1 THROTTLE HEAD --
L2.1412 L2.1413 1 THROTTLE SCREW --
[L2.1413] L2.1108 1 AIR INLET HEAD --
L2.1505 L2.1108 1 KEY --
N1.1110 2 SCREW M5 X 8 D3
N1.1125 2 SCREW M6 X 16 A3+
N1.1125 A48.1301 2 SCREW M6 X 16 A3
N1.1143 1 SCREW M6 X 35 B4
N1.1168 2 SCREW M5 X 16 E1
N1.1170 2 SCREW M6 X 35 C1
N1.1202 2 SCREW M5 X 10 B3
N1.1208 A48.0113 2 SCREW M5 X 25 C3
N1.1539 1 HEXAGON SCREW M5 X 14 D4
N1.2105 A48.0113 1 COUNTERSUNK SCREW M5 X 25 D2
N1.2135 2 COUNTERSUNK SCREW M5 X 12 D3+
N1.2136 1 COUNTERSUNK SCREW M5 X 8 E4
N1.2209 2 COUNTERSUNK SCREW M4 X 18 B5
N1.5103 1 HEXAGON NUT M5 D4
N1.5301 1 RETAINING NUT M6 A4
N1.5302 A48.0113 3 RETAINING NUT M5 C1
N1.6207 2 SPRING LOCK WASHER M5 B3+
N1.6207 A48.0113 2 SPRING LOCK WASHER M5 C3
N1.6701 L2.1108 2 TOOTH LOCK WASHER --
N2.2102 1 PARALLEL PIN 5 m6 X 16 D3
N2.2102 A48.1134 2 PARALLEL PIN 5 m6 X 16 D3
N2.2106 2 PARALLEL PIN 5 m6 X 20 E2
N2.2129 A48.1134 2 PARALLEL PIN 5 m6 X 10 D3
N2.3201 2 WOODRUFF KEY 4 X 6.5 X 15.72 D3+
13.4110.01 A480/19/0.38-0.63/4.5 A480.0001.01 11.06.02
Item-No. in group Pcs. Description Dimension Field

[ ] = Group * = Wearing parts
12 13411001.een
N2.4902 2 HAMMER HEAD BOLT 1.85 X 4.76 C2
N2.5102 2 PRESSURE SPRING 0.6 X 8 X 14/6 C4+
N2.5131 1 PRESSURE SPRING 0.5 X 6 X 15/7.5 C4
N2.5144 1 PRESSURE SPRING 3 X 54 X 125/6.5 C4
N2.5145 1 PRESSURE SPRING 2.8 X 36 X 55/5 A2
N2.5151 1 PRESSURE SPRING 0.3 X 2.8 X 11/11.5 C5
N2.5802 1 BENDING SPRING 2.5 X 11.5/3.25 C4
N3.1102 L2.1108 4 BALL BEARING 15 X 32 X 9 --
N3.1108 L2.1108 1 BALL BEARING 6 X 19 X 6 --
N3.1109 L2.1108 1 BALL BEARING 8 X 22 X 7 --
N3.1131 1 BALL BEARING 12 X 32 X 10 D6
N3.1708 2 BALL 10 MM C4+
N3.2312 1 NEEDLE BUSH 15 X 21 X 14 D3
N3.2313 1 NEEDLE CASE 12 X 18 X 12 C4
N3.2314 1 NEEDLE CASE 15 X 21 X 12 C6
N3.2314 A48.1244 1 NEEDLE CASE 15 X 21 X 12 E2
N3.4102 1 THRUST BEARING CAGE 15 X 28 X 2 C5
N3.4307 2 THRUST RACE 15 X 28 X 1 D5
N41.9128 1 ADHESIVE LABEL 30 X 10 X 0.1 A4
N41.9129 1 ADHESIVE LABEL p max. 6 bar/87 psi A4
N4.9135 1 NUMBER PLATE <<A480>> B2
N6.5133 1 REDUCING COUPLING D5
N6.5195 2 FITTING A4+
N6.6229 4 O-RING 14 X 1 C4
N6.6230 2 O-RING 8 X 1.5 C4+
N6.6234 L2.1413 1 O-RING 7.1 X 1.6 --
N6.6505 L2.1413 1 FLAT SEAL 21 X 17 X 1,5 --
N6.6701 1 DIAPHRAGM B4
N7.1101 A48.1244 1 BUSH 10 X 15 X 10 D2
N7.1201 A48.1244 1 SEALING DISK 16 E2
13.4110.01 A480/19/0.38-0.63/4.5 A480.0001.01 11.06.02
Item-No. in group Pcs. Description Dimension Field

13
a480man.en_teil2
10 OPERATION
10.1 Feeding the strap
The strap is fed through the seal, around the
package to be strapped and again through the seal.
The strap end is then bent. The operator then
tensions the loose loop manually making sure that
the bent strap end is adjacent to the object to be
strapped.
10.2 Introducing the tool
The upper strap is held with the left hand; the right
hand lifts the air motor and introduces the tool from
the right to the left and from the rear to the front. The
air motor is then released.
10.3 Tensioning the strap
The tension valve lever A48.1232 is pressed down.
The lever is caught completely and the strap is
tensioned until the air motor stalls. If the cycle has to
beinterruptedthecatchA48.1234 hastobepressed
to the left.
Always wear safety
glasses with side shields
which conform to ANSI
Standard Z87.1.
When handling strap,
always wear protective
gloves.

14 a480man.en_teil2
10.4 Sealing the strap
The sealing valve lever A48.1233 is pressed down
until the seal is notched and the upper strap
sheared; the tensioning process is interrupted
automatically.
10.5 Releasing the tool
The tool can be released from the strapping without
any further action after completing the strapping
cycle. By lifting the air motor the strap end is
removed from the tool.
10.6 Tension regulation
The tension is regulated by the continuous
adjustment of the throttle screw L2.1412. The air
supply is reduced by turning the screw clockwise.
The throttle screw is located at the rear end ofthe air
motor.
