FrontLine FLBEDYD9392B8F User manual

m a n u a l
EOS Quadrant

Installation instructions:
Quadrant
Adjustment range: (-25mm / -5mm) x (-30mm / -5mm) x 1900mm
Mounting Preparation
After opening the packaging, read the instructions carefully. Check whether all parts are present and there is no sign of shipping
damage. If you find any problem, please contract your retailer directly.
Necessary tools:
spirit level electric drill crosstip screw driver pencil rubber hammer
knife ruler silicon sealant driver inner hexagon spanner wrench
Packing list:
2.5mm
5mm
8EQ3
8EQ5
8EQ8 8EQ9
8EQ14
8EQ15
8EQ16
8EQ15
8EQ14
8EQ12
8EQ21
8EQ3
8EQ5
8EQ9 8EQ8
8EQ1 8EQ2 8EQ4 8EQ6 8EQ7 8EQ10
8EQ11 8EQ12 8EQ17 8EQ18 8EQ19 8EQ20
10x 6x 4x 1x 4x
4x
10x
2x
2x
2x
2x
2x

1
8EQ3
8EQ3
2
1. If the quadrant is placed onto a tray, first take a spirit
level to check whether the tray is placed horizontal. In case
the quadrant is installed directly onto the floor, please
proceed with step 2.
2.Put the wall profiles 8EQ3 against the wall, ensuring the distance
between the profile and the wall is correct. Please make sure profile to
be 5mm away from outside edge. Adjust the profile to make sure it is
vertical by using a spirit level. Mark the holes on the wall.
8EQ1(8x)
3
8EQ2(8x)
4
3. Drill the holes ( 6mm) according to the marks and
insert the wall plugs 8EQ1 into the holes.
Ø4. Fix the wall profiles 8EQ3 with the St4x30 screws 8EQ2 to the
wall.

8EQ5 8EQ5
5
6.1
Flex. 25mm
8EQ20(2x)
8EQ6(2x)
8EQ21
8EQ19(2x)
6
6.2
6.3
6.3 6.2
5.Insert the fixing glass 8EQ5 into the wall profiles. 6. Adjust the position of vertical profile and wall profile to suitable
position and then mount rail profile 8EQ21 by assembling fixing
part 8EQ19 and 8EQ20 on fixing panels. Cover 8EQ6 on the back
of 8EQ20.
8EQ7(2x)
8EQ8
8EQ2(2x)
8EQ6(2x)
7
7.1
8EQ1(2x)
8EQ8
7.Attach the vertical sealer 8EQ8 on the fixing panel 8EQ5. Put
the bottom bracket 8EQ7 on the fixing glass panel and mark the
hole for the bracket. Drill the holes (6mm) according to the marks
and insert the wall plugs 8EQ1 into the holes. Fix the bracket 8EQ7
with the St4x30 screws 8EQ2 to the tray. Put the cover 8EQ6 on
screw.
Attach the vertical sealer 8EQ8 to fixing panel 8EQ5.
8EQ11(4x)
8EQ14
8EQ15
8EQ14
8EQ15
8
8. Assemble rollers 8EQ11 on sliding panel 8EQ14. Attach bottom
seal 8EQ15 on the bottom of glass.

9
9.1
9.Put the sliding panel on the rail profile.
Adjust the top roller to make sure sliding panel is vertical to the rail
profile. The roller’s washer is eccentric. Please adjust the eccentric
washer to right position and fasten the nut.
8EQ9
8EQ12(2x)
8EQ9
10
10.Attach magnetic strip 8EQ12 to sliding panel 8EQ14.
Attached vertical sealer 8EQ9 to the other side of sliding
panel.
11
8EQ10(4x)
8EQ12(2x)
11.1
11.2
11.Assemble the fixing part 8EQ10 on sliding panel below rail profile. 8EQ10 is eccentric. Adjust the distance between rail profile
and 8EQ10 to be 0.5mm.
Mount handle 8EQ12 on the sliding panel.

8EQ4(6x)
8EQ16
8EQ4(6x)
14
13
12
13.2
13.1
8EQ17(2x)
8EQ18(2x)
12.5
12.1
12.2
12.3
12.4
12. Put silicon glue on the back of bottom aluminum strip 8EQ16. Put it on the tray edge between brackets 8EQ7.
Put the profile cover 8EQ18 on the vertical profile and put profile cover 8EQ17 on the wall profile.
13. Drill the holes (6mm) on vertical profile into wall profile
8EQ3 and door profile. Use rubber washers and screws 8EQ4
to fix them in place. Press the screw caps over screws.
14. Finally, at all points connects to the wall, shower tray/floor and
the profiles, use silicone sealant only on the outside of the shower
enclosure.
