FUHR multitronic 881 Manual

WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Installation, operation and maintenance instructions
7V08 / DIN 18251-3, Class 3
MBW20-EN/06.20-30
Declaration of
performance
881/881GL
Installation instructions for panic
and emergency exit door locks
MBW10.
Type 3+11
www.fuhr.de
www.f
u
hr.
de
Please note the additional
information:

2WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Content
1 Introduction 3
2 Important information/safety instructions 4
2.1 Basic components | Setting possibilities 5
2.2 certifications | labelling of the locks 6
2.3 Scope of supply of a multitronic-set 8
3 Installation examples 10
3.1 Version 1 – Standard – with cable junction/without control unit 10
3.2 Version 2 – Standard – with tappet contact/without control unit 12
3.3 Version 3 – Standard – with tappet contact and switching power supply unit on the frame/without control unit 14
3.4 Version 4 – Standard – All-inclusive for installation in the door 16
3.5 Version 5 – Project – All-inclusive with DIN rail components 18
3.6 Version 6 – Project – All-inclusive with control box 20
4 Installation instructions 22
4.1 Routing and drilling operations 22
4.2 installation 27
5 Commissioning 34
5.1 Operation verification check on the fabricator’s premises 34
5.2 Commissioning on site 34
6 External connection options 35
6.1 THE Control unit 36
6.2 The radio receiver 41
6.3 The drive unit’s multi-functional jack 42
7 Wiring diagram 43
8 Control via FUHR radio access control systems 44
8.1 The programming keys 44
8.2 Tuning in and deleting user radio keys 45
9 Maintenance and care 48
9.1 Contact device 49
9.2 Battery change of the radio keys 50
10 Technical data 51
10.1 multitronic-Set 51
10.2 Master/user radio key 51
10.3 4-channel radio key with wall bracket 51
10.4 multitronic control with radio receiver 52
10.5 Radio receiver 52
10.6 multitronic drive unit 52
10.7 multitronic switching power supply unit (installation in the door frame) 53
11 Troubleshooting 54
11.1 Use with the radio receiver module 55
12 Optional accessories 56
For this manual in other languages see www.fuhr.de
www.fuhr.de
www.f
u
hr.
de
Important advices which have to be noticed

3
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
The FUHR multipoint locking system multitronic 881 locks doors electromotively – at all times and fully automated.
• Particularly reliable – strong and fast – due to two parallel high performance motor drives.
• This saves energy as the door always closes imperviously.
• Enables secure locking of main entrance doors, apartment doors or back doors.
• Suitable for use with all door materials as well as for burglary-resistant doors in accordance with EN 1627 RC 2 and RC 3.
The standard locking and unlocking functions in detail:
Special functions are described in chapter 6.
Locking (closing):
All locking components are locked automatically 3 sec. after the door has been closed over. (This can however in emergency
situations – e.g. in the event of power failure – also be carried out mechanically by turning the key.)
Unlocking (opening) from the outside:
• By using the FZG free-running profile cylinder’s key (depending on the drive-gear position; 4 turns)
• Optionally by means of a FUHR radio access system e.g. transponder, finger print scanner or similar access control systems
Unlocking (opening) from the inside:
• Via the door lever handle as usual or by using the FZG free-running profile cylinder’s key (depending on the drive-gear
position; 4 turns)
• Optionally via a domestic intercom system (6-12 V AC, 6-24 V DC or potential free)
• Optionally by means of a FUHR radio access system e.g. transponder
• Optionally by means of another access system (release signal via potential-free contact)
• Optionally by means of a contemporary BMS device (Building Management System)
Do not operate the lever-handle during the electrical locking and unlocking procedure!
The optional ServoAccess version:
In addition to the standard functions above, ServoAccess provides an additional operation comfort due to a motorized sup-
port when opening mechanically. The multitronic 881 ServoAccess is opened from its locked basic position by the first key
turn. As a further benefit, the servo function supports the already smooth opening when the lever handle is operated slowly.
This function is particularly suitable for applications where the mechanical opening is done by key e.g.:
• In multi-family houses, where the operation of the access control is reserved for the owner for various reasons
• Office buildings in which only a time switch controls the activation and outside the „main times“ the key (locking system)
should be used
• For groups of people who for various reasons do not use access control, e.g. small children or elderly people who prefer the
conventional key for door opening
Further electrical connections are available for: (some are only operated by controler)
1 Introduction
• Alarm systems
• Access control systems
• Electrically operated door openers
• External control LED
• Time switches (permanent-open function or day latch
function, via cable or radio activation)
• Electronical shutdown signal

4WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
2 Important information/safety instructions
These instructions are aimed at door fabricators and contain important information regarding installation, commissioning and
operation pertaining to the FUHR multipoint locking system multitronic 881. Please read carefully prior to installation and com-
missioning. The points raised here provide supplementary information to the FUHR Product Liability Information for door locks,
see www.fuhr.de. In the event of non-compliance with these imperative instructions, faultless system operation cannot be war-
ranted. We assume that the installation as well as commissioning and maintenance is carried out exclusively by professional staff.
The FUHR multipoint locking system multitronic 881 has been designed and manufactured taking safety-related regulations
and harmonised standards into account. This product’s safety features are an essential pre-requisite for the EN 14846 accredita-
tion. Therefore no alterations or modifications may be carried out other than those described in these instructions.
The safety of the FUHR multitronic product largely depends on its correct installation and regular mainte-
nance! The installation of the electronic components requires particular care, since abrasion points, defective
cables, damaged contacts, etc. affect security and can lead to the malfunction of the system. Please ensure
that all components are in perfect functioning condition prior to installation. Damaged or defective compo-
nents may not be used under any circumstances. Use the locking system only in technically perfect condition!
Malfunctions that impair security are to be eliminated immediately. Until the malfunction has been elimina-
ted, the drive unit is to be switched off and operated mechanically! The power supply unit’s power feed is to
be disconnected when working on the locking system and live components.
The FUHR multipoint locking system multitronic 881 has been engineered to be used in conjunction with the provided FUHR
multitronic components. All specified components must be installed to ensure the requirements outlined in EN 14846 are met.
We accept no liability for improperly installed systems and/or the use of non-original or non factory approved system accessory
parts. The modification of components or the use of non approved accessory components can cause malfunctions. Material
damage or personal injury resulting from non-compliance with the installation, operation and maintenance instructions or inap-
propriate operation invalidates the warranty. We assume no liability for any consequential damage.
The FUHR multipoint locking system multitronic 881 must be protected from humidity. It is not suitable for
areas with high humidity and chemical substances.
The FUHR multipoint locking system multitronic 881 has been primarily designed for installation in main entrance doors, apart-
ment doors and back doors. Products manufactured in accordance with EN 14846 requirements provide a high level of personal
protection and adequate protection against intrusion when fitted to a suitable door and door frame. The system with 2 hook
bolts (type 3) has been tested and certified in accordance with DIN EN 179. The variants with 2 round bolts (type 8) and with
2 hook and dual round bolts (type 11) have been tested and certified in accordance with DIN EN 1125. For this purpose durability
testing in the highest grade (grade 7) with 200,000 operations was carried out successfully. The product was tested, approved
and certified for fire resistance on a single leaf aluminium door by MPA Braunschweig (certification number PB 3019/2006).
For use in heavily frequented doors (more than 50 operations per day) e.g. in public or office building projects,
it is necessary to use either of the two day-latch functions during busy periods (refer to chapter 6.1.4).
Do not operate the lever-handle during the electrical locking and unlocking procedure!
The installation steps depicted on the following pages serve as a schematic diagram. Due to the numerous profiles available on
the market, there may be slight deviations in specific points. It is therefore imperative that the profile-related routing drawing
provided with the FUHR multitronic set is adhered to. Please contact your sales partner or the manufacturer in the event of
discrepancies or queries. The indicated sequence in these installation instructions is exemplary. The sequence may be varied if
required.
IMPORTANT!
All components contained in the set (particularly the control unit and the radio key) are coordinated and should not be
used in conjunction with other sets.

5
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
The delivery content depends on the respective version. The
basic components are described below.
Multipoint locking system with one-piece or standard
strike plates
Latch conversion
Setting possibilities
± 2mm
2.1 BASIC COMPONENTS | SETTING POSSIBILITIES
Adjustment of one-piece/
standard strike plates
A reliable function of the door system is only guaranteed if
lock and door have been installed correctly and hinges and
one-piece/standard strike plates have been adjusted cor-
rectly. In order to achieve an optimal tightness of the door,
the one-piece/standard strike plates can be adjusted as
follows:
SW 2
Contact
magnet
Standard
strike plate
type 4/10/11
multitronic 881
type 11
One-piece
strike plates
type 4/10/11
90°
SW 4
2.
1.
± 2mm
± 2mm
SW 4

6WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
multitronic 881/881GL – type 11
1309 CPR 0422
EN 1125:2008 3-7-6-B-1-3-2-1/2-A /B-B
1309 CPR 0421
EN 179:2008 3-7-6-B-1-3-5-1/2-A /B-B /D
multitronic 881/881WA – type 8
1309 CPR 0422
EN 1125:2008 3-7-6-B-1-3-2-1/2-A /B-B
1309 CPR 0421
EN 179:2008 3-7-6-B-1-3-2-1/2-A /B-B/D
multitronic 881 – type 8, double-leaf
1309 CPR 0422
EN 1125:2008 3-7-6-0-1-3-2-1/2-A /B-A
1309 CPR 0421
EN 179:2008 3-7-6-0-1-3-2-1/2-A/B-A
multitronic 881/881GL/881WA – type 3
1309 CPR 0421
EN 179:2008 3-7-6-B-1-3-4-1/2-A /B-B /D
Panic locks EN 1125 + Panic exit locks EN 179
WARNING! Please note at all costs!
The CE-conformity according to DIN EN 1125 or DIN EN 179 is only given, when the FUHR panic locks 881/881GL /
ServoAccess are installed with the tested and certificated components. Further information can be found on our website
www.fuhr.de.
2.2 CERTIFICATIONS | LABELLING OF THE LOCKS
Emergency exit devices in accordance with EN 179Panic locks in accordance with EN 1125 and emergency
exit devices in accordance with EN 179

7
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Certified in accordance with DIN 18251-3.
Certified in accordance with QM342.
Further certifications/tests:
Tested in accordance with EN 14846.
Under testing

8WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system multitronic 881
incl. electromotive drive unit
One-piece keep or individual keeps
Profile related version,
incl. magnetic contact
(Art.no. VNZM14195)
Control unit with radio receiver and visual locking
indicator
Preassembled cable connectors (length 200 and 300 mm)
Switching power supply unit (transformer)
Profile related version,
230 V AC input/12 V DC output, Cable connectors 230 V
(length 3000 mm – surface-mounted cable), earth/ground
cable (length 400 mm) and 12 V (length 200 mm)
preassembled
Surface-contact device for electricity and data transfer
Preassembled cable connector (length 250 mm)
Tappet contacts for electricity and data transfer
Cable connector (length 4000 mm), with preassembled
multi-functional jack
2.3 SCOPE OF SUPPLY OF A MULTITRONIC-SET
The components shown here do not necessarily correspond to the scope of supply of your door. What the delivery contents
really include depends on the respective version.

9
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Radio key
to be handed over to the end user;
3-channel radio key as remote control,
1 pc. with red buttons = master key
2 pcs. with turquoise buttons
Cover plate, cable guides and end caps
for safe cable-laying (only for doors with Euro groove);
2 m. cover plate
6 pcs. double cable guides
2 pcs. end caps
Cable protection sleeves
3 pcs.
Profile-related routing drawing

10 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system
FUHR multitronic 881/881
GL /ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Concealed or surface-mounted cable junction
Art. no. VNZ80090/VNZ80089
DIN rail power supply unit
Art.no. VNZT80345
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove
Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
Cable protection sleeves –
Art. no. VNZ80022
6-core connection cable | 10 m | with one couplerArt.
no. VNZ80075
3 Installation examples
3.1 VERSION 1 – STANDARD – WITH CABLE JUNCTION/WITHOUT CONTROL UNIT
Functions:
• Opening impulse via a two-way intercom system
• Connects up to external indicator LED Art. no. VNZ80067
System components:

11
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Principle of connection
b) Energised impuls (6-12 V AC o. 6-24 V DC): yellow cable on / red cable on
Drive unit power supply 12 V DC:
Thick red cable on
Thick black cable on
Opening impulse from two-way intercom system or access control system:
a) Potential-free impulse: yellow cable / green cable
Cable from motor lock
Cable from two-way intercom system
DIN rail power
supply unit
12 V DC
The white cable has no function in this installation version.
Switch cabinet with
DIN rail power supply unit

12 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system
FUHR multitronic 881/881
GL /ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Profile related tappet contacts
Cable connector (length 4000 mm) with
preassembled multi-functional jack
Contact surface
Cable connector (length 250 mm)
preassembled
DIN rail power supply unit
Art. no. VNZT80345
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove – Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
Cable protection sleeves –
Art. no. VNZ80022
3-core connection cable | 8 m | with one coupler
Art. no. VNZ80063A
3.2 VERSION 2 – STANDARD – WITH TAPPET CONTACT/WITHOUT CONTROL UNIT
Functions:
• Opening impulse via a two-way intercom system
• Connects up to external indicator LED Art. no. VNZ80067
System components:

13
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Contact surfaces’ cable
Cable from two-way intercom system
Opening impulse from two-way intercom system or access control system:
Potential-free impulse or energised impulse (6-12 V AC oder 6-24 V DC)*
to be connected to the white cable. Note the connector pin assignment on the drive unit!
Drive unit power supply 12 V DC:
Red cable on
Black cable on
Switch cabinet with
DIN rail power supply unit
DIN rail power
supply unit
12 V DC
*The DC power supply can also be operated with an AC opening impulse.
Principle of connection
PLEASE NOTE – connector pin assignment on
the drive unit:
If the tappet contacts are used without the control
unit, the white cable from the green drive unit‘s
coupler for the door opening impulse must be shif-
ted from terminal 1 to:
• auf in case of potential-free impulse: to terminal 4
• in case of an electrical impulse: to terminal 7

14 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system
FUHR multitronic 881/881
GL /ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Profile related tappet contacts
Cable connector (length 4000 mm) with
preassembled multi-functional jack
Contact surface
Cable connector (length 250 mm)
preassembled
Profile related switching
power supply unit
For installation in the door frame
230 V AC input/12 V DC output,
Cable connectors 230 V
(length 3,000 mm - surface-mounted
cable), Earth cable (length 400 mm)
and 12 V (length 200 mm)
Preassembled
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove – Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
End caps for cover plate –
Art. no. VNZ80022
4-core connection cable | 1 m | with two couplers
Art. no. VNZ80118B
3.3 VERSION 3 – STANDARD – WITH TAPPET CONTACT AND SWITCHING PO-
WER SUPPLY UNIT ON THE FRAME/WITHOUT CONTROL UNIT
Functions:
• Opening impulse via a two-way intercom system
• Connects up to external indicator LED Art. no. VNZ80067
System components:

15
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Principle of connection
Black cabel White cable
Opening impulse from two-way intercom system or access control system:
Potential-free or energised impulse (6-12 V AC or 6-24 V DC) ,
Note the connector pin assignment on the drive unit!
Power supply unit
Contact surfaces
Tw o-way intercom system
Access control system
Connecting cable VNZ80118B,
Cable length 1 m.
Imperative to install
between contact surface
and power supply!
PLEASE NOTE – connector pin assignment
on the drive unit:
If the tappet contacts are used without the
control unit, the white cable from the green
drive unit‘s coupler for the door opening impul-
se must be shifted from terminal 1 to:
• auf in case of potential-free impulse: to
terminal 4
• in case of an electrical impulse: to terminal 7

16 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system
FUHR multitronic 881/881 GL
/ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Profile related tappet contacts
Cable connector (length 4000 mm) with
preassembled multi-functional jack
Contact surface
Cable connector (length 250 mm)
preassembled
Control unit with master radio key
For installation in the door frame
Cable connectors (length 300
and 200 mm), preassembled
Art. no. VNZSTP0419
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove – Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
Cable protection sleeves –
Art. no. VNZ80022
Profile related switching
power supply unit
For installation in the door frame
230 V AC input/12 V DC output,
Cable connectors 230 V
(length 3,000 mm - surface-mounted
cable), Earth cable (length 400 mm)
and 12 V (length 200 mm)
Preassembled
3.4 VERSION 4 – STANDARD – ALL-INCLUSIVE FOR INSTALLATION IN THE DOOR
Functions:
• Opens via FUHR radio-controlled access control modules
such as radio key, fingerprint scanner or transponder
• Integration in facility management systems
• Connection to external access control systems
• Connects up to an alarm system
• Radio activation of permanently open and day latch function
• Connects up to a swing door opener
• Connects up to time switches (permanently-open function)
• Connects up to external indicator LED Art. no. VNZ80067
• Input signal to electronically disconnect the access control
systems for alarm systems
System components:

17
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Principle of connection

18 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
3.5 VERSION 5 – PROJECT – ALL-INCLUSIVE WITH DIN RAIL COMPONENTS
Functions:
• Opens via FUHR radio-controlled access control modules
such as radio key, fingerprint scanner or transponder
• Integration in facility management systems
• Connection to external access control systems
• Connects up to an alarm system
• Radio activation of permanently open and day latch function
• Connects up to a swing door opener
• Connects up to time switches (permanently-open function)
• Connects up to external indicator LED Art. no. VNZ80067
• Input signal to electronically disconnect the access control
systems for alarm systems
Multipoint locking system
FUHR multitronic 881/881 GL
/ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Profile related tappet contacts
Cable connector (length 4000 mm) with
preassembled multi-functional jack
Contact surface
Cable connector (length 250 mm)
preassembled
Control unit with master radio key
For installation in the door frame
Cable connectors (length 300
and 200 mm), preassembled
Art. no. VNZSTP0419
3-core connection cable | 8 m | with one coupler
Art. no. NZ80063A (refer to the illustration on page 12)
DIN rail power supply unit
Art. no. VNZT80345
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove – Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
Cable protection sleeves –
Art. no. VNZ80022
System components:

19
WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Principle of connection
black/14
white/13
red/15
DIN rail power
supply unit
12 V DC
/2
/1

20 WWW.FUHR.DE
multitronic
881/881GL/ServoAccess
Multipoint locking system
FUHR multitronic 881/881
GL /ServoAccess
incl. electromotive
drive unit
Profile related
one-piece keep +
magnetic contact
for the drive unit
to be ordered
separately
Art. no. VNZM14195
Profile related tappet contacts
Cable connector (length 4000 mm) with
preassembled multi-functional jack
Contact surface
Cable connector (length 250 mm)
preassembled
Control box with integrated mains adapter
and master radio key
Art. no. VNZASTP043
3-core connection cable | 8 m | with one coupler
Art. no. NZ80063A (refer to the illustration on page 12)
Cable protection elements for secure cable laying:
Cover plate | 2 m | F16 – Art. no. VNZ33171X |
F20 – Art. no. VNZ33172X | F24 – Art. no. VNZ33173X
Double cable guides for Euro-groove – Art. no. VNZ13845
End caps for cover plate |
F16 – Art. no. VNZ13846 |
F20 – Art. no. VNZ13847
Cable protection sleeves –
Art. no. VNZ80022
3.6 VERSION 6 – PROJECT – ALL-INCLUSIVE WITH CONTROL BOX
Functions:
• Opens via FUHR radio-controlled access control modules
such as radio key, fingerprint scanner or transponder
• Integration in facility management systems
• Connection to external access control systems
• Connects up to an alarm system
• Radio activation of permanently open and day latch function
• Connects up to a swing door opener
• Connects up to time switches (permanently-open function)
• Connects up to external indicator LED Art. no. NZ80067
• Input signal to electronically disconnect the access control
systems for alarm systems
System components:
