Fuji Xerox DocuPrint CM305 df User manual

DocuPrint CM305 df
Service Manual 1st Edition

• This service manual covers the following models
FUJI XEROX Co. Ltd. Color Laser Printer
DocuPrint CM305 df
•Related Materials
No other related materials issued other than this
service manual.
•Confidentiality
• This service manual is issued intending use by
maintenance service personnel authorized by
FUJI XEROX Co. Ltd.
Copying, transferring or
leasing this manual without prior consent by
FUJI XEROX Co. Ltd. is prohibited.
• When a page becomes irrelavant (e.g.
superceded by a replacement page), destroy
the page by burning or shredding it.
• Handle with care to avoid loss or damage of
the manual.
•Revision and Modification Information
When design changes or revisions relating to
this service manual occur, the overseas
technical information or overseas service
bulletin may be issued as supplementary
information until such changes are
accomodated in the updated version of this
service manual.
CAUTION
Important changes including
revisions of spare part
numbers and adjustment
specifications must
immediately be reflected on
the respective pages of this
service manual upon
reception of such
information.
Edited by: Fuji Xerox Co., Ltd. CS/TS
MinatoMirai Center Bldg. 7F
3-6-1 Minatomirai Nishi-ku, Yokohama, Kanagawa 220-0012, JAPAN
TEL: [phone]
[XEROX] [The Document Company] are registered trademarks.
PRINTED IN JAPAN
DocuPrint CM305 df
Service Manual 1st Edition Issued: January 2011

Company Name
Department Name
Telephone No.
Full Name Employee No.

Preface
Getting to know the Service Manual
How to use the Service Manual
Terms and Symbols
Abbreviations
Chapter 1 Service Call Procedure
Chapter 2 Troubleshooting
Chapter 3 Image Quality Troubleshooting
Chapter 4 Disassembly / Assembly and Adjustments
Chapter 5 Parts List
Chapter 6 General
Chapter 7 Wiring Data
Chapter 8 Accessories (Not yet issued)
Chapter 9 Installation
Chapter 10 Machine Overview

Preface

Preface
Table of Contents
Table of Contents
1 Getting to know the Service Manual.............................................................. Preface-1
2 How to use the Service Manual..................................................................... Preface-1
2.1 Contents of Manual ......................................................................................................Preface-1
2.2 Information on Updating ...............................................................................................Preface-2
3 Terms and Symbols....................................................................................... Preface-3
4 Abbreviations................................................................................................. Preface-4

Introduction
1. Getting to know the Service Manual
Preface-1
1. Getting to know the Service Manual
This manual is used as the standard service manual for the DocuPrint CM305 df.
• Publication Comment Sheet
Enter any comments and/or corrections regarding the DocuPrint CM305 df service manual into
the Publication Comment Sheet, and send it to FX/TS/OSG through the OpCo TS or CS
department.
2. How to use the Service Manual
This manual describes the standard procedures for the servicing of the DocuPrint CM305 df. Refer
to Chapter 1 Service Call Procedure for efficient and effective servicing during maintenance calls.
2.1 Contents of Manual
• Hardware
This manual summarizes all technical information on the DocuPrint CM305 df.
• Chapters
This manual is divided into ten chapters as described below.
Chapter 1 Service Call Procedure
This chapter describes the general work and servicing procedures for the maintenance of the
DocuPrint CM305 df.
Chapter 2 Troubleshooting
This chapter describes the troubleshooting procedures other than image quality
troubleshooting of the DocuPrint CM305 df. It also describes how to use the diagnostics and
some programs.
Chapter 3 Image Quality Troubleshooting
This chapter describes the image quality troubleshooting procedures of DocuPrint CM305 df.
Chapter 4 Disassembly / Assembly and Adjustments
This chapter describes the disassembly, assembly, adjustment and replacement procedures
for components of the DocuPrint CM305 df.
Chapter 5 Parts List
This chapter contains spare parts list for DocuPrint CM305 df.
Chapter 6 General
This chapter contains the following general information on DocuPrint CM305 df.
6.1 Specification
6.2 Tools / Service Consumables / Consumables / Modification
6.3 Service Data
6.4 Service Mode

Introduction
2. How to use the Service Manual
Preface-2
Chapter 7 Wiring Data
This chapter describes the wiring data of DocuPrint CM305 df.
7.1 Plug / Jack Location List
7.2 Wire Network (Undescribed)
7.3 BSD (Undescribed)
7.4 Connection Wiring Diagram
7.5 Interconnection Wiring Diagram of Parts
Chapter 9 Installation
This chapter contains the Installation procedure of the DocuPrint CM305 df.
9.1 Installation
9.2 Removal (Undescribed)
Chapter 10 Machine Overview
This chapter gives an overview of the functions of the main components of DocuPrint CM305
df.
2.2 Information on Updating
This manual will be revised and sent to each customer engineer as specified below. Revisions must
be incorporated correctly to keep the manual up-to-date.
Updating Procedure
• When the entire manual is revised, "1st Edition" on the front cover will be renewed to 1st Edition,
2nd Edition, 3rd Edition and so on.
• When this manual is partially revised, revisions will be sequentially indicated as Revision A,
Revision B, Revision C, etc. All revised pages will be marked accordingly with "Revision A",
"Revision B", "Revision C" and so on.
Revision Sidebar
When any paragraph, table or figure has been added or amended, a revision sidebar will be
added to indicate where the revision was made.
(Example)
If the same page is changed again due to a subsequent revision, revision sidebars associated
with the previous revision(s) will be deleted.

Introduction
3. Terms and Symbols
Preface-3
3. Terms and Symbols
Specific terms and symbols used in any particular chapter are described in the Preface for that
section. The terms and symbols described here are used throughout this manual.
• The terms and symbols used at the beginning of a text are defined as follows:
DANGER
Indicates an imminently hazardous situation, such as death or serious
injury if operators do not handle the machine correctly by disregarding
the statement.
WARNING
Indicates a potentially hazardous situation, such as death or serious
injury if operators do not handle the machine correctly by disregarding
the statement.
CAUTION
Indicates a potentially hazardous situation, such as injury or property
damage if operators do not handle the machine correctly by
disregarding the statement.
INSTRUCTION
Indicates that the printer or its components may be damaged if the instructed
procedure is not strictly observed.
NOTE
Used to emphasize the procedure, servicing, and regulation.
REFERENCE
Used to describe the technical terminology and supplementary explanations.
OBJECTIVE
Used to explain purpose of adjustment.
• REP : Indicates the disassembly/assembly procedure for reference.
• ADJ : Indicates the adjustment procedure for reference.
• PL : Indicates the parts list for reference.
• ASSY : Means Assembly.
Safety Critical Components (SCC)
Control of the safety of components that are designated Safety Critical Components shall conform to
Fuji Xerox Co. Ltd-stipulated rules and regulations on Safety Critical Components.
As to replacement of any component designated SCC, the complete component unit must be
replaced. It must never be disassembled or no individual internal parts of it must be replaced.
Installation of any part other than the ones designated by Fuji Xerox Co. Ltd. shall be strictly
prohibited because it cannot be guaranteed in quality and safety.
Important Information Stored Component (ISC)
Important Information Stored Components store customers’ important information they have entered
after machine installation. When replacing Important Information Stored Components, you must
replace and discard them, following the procedure described in Chapter 4 Adjustments. Take care
never to let customer information leak out.

Introduction
4. Abbreviations
Preface-4
4. Abbreviations
Abbreviations
This manual contains abbreviations that are specific to this manual, as well as general
abbreviations, which include:
ADC Automatic Density Control
AG Analog Ground
APS Auto Paper Select
ARC Auto Registration Control
ASSY Assembly
ATS Auto Tray Switching
BBlack
BCR Bias Charge Roll
Bk Black
BLK Black
BLU Blue
BRN Brown
BTR Bias Transfer Roll
C Cyan
CLN Cleaner
CRU Customer Replaceable Unit
CRUM CRU Monitor
CTRG Cartridge
DET Detoner Roll
DEVE. Developer
DIAG. Diagnostic
DISP Dispense
dpi dots per inch
DTS Detack Saw
DUP Duplex
ESB Electro Static Brush
ESS Electric Subsystem
FFront
FEED, FDR Feeder
FIP Fault Isolation Procedure
GND Ground
GRN Green
GRY Gray
HT Half Tone
HUM Humidity
HVPS High Voltage Power Supply
ICDC ImageCountDispenseControl
ID Image Density, or Identification
IBT Intermediate Belt Transfer
INTL, INLK Interlock
IOT Image Output Terminal
KBlack
LLeft
L/H Left Hand
LD Laser diode
LDD Lightly Doped Drain
LED Light-emitting diode
LEF Long Edge Feed
LH Left Hand
LV Low Voltage
LVPS Low Voltage Power Supply
M Magenta
MAG Mag. Roll
MCU Machine Control Unit
MOB Marks On Belt
MOT Motor
MSI Multi Sheet Inserter
N/P No Paper
NVM Non Volatile Memory
OEM Original Equipment
Manufacuring
OHP Overhead Project
OP Operation
OPC Organic Photo Conductor
ORN ORANGE
PC Personal Computer
PCDC Pixel Count Dispense Control
PH Paper Handling
PHD Printer Head
PNK Pink
POP Paper On Photoreceptor
PPM Prints Per Minute
PR,P/R Process
PV Print Volume
PWB(A) Printed Wiring Boad
(Assembly)
R Right
RRear
R/H Right Hand
REF Refresher
REGI. Registration
RH Right Hand
ROS Raster Output Scanner
ROT Rotary
RTC Rubber Tube Charger
RTN Return
SEF Short Edge Feed
SG Signal Ground
SMH Special Material Handler
SNR Sensor
SOL. Solenoid
SOS Start Of Scan
STM Single Tray Module
SW Switch
TEMP. Temperature
TM Tray Module
TNER, TNR Toner
TP Thermopile
TR Transfer
VIO Violet
WHT White
XERO Xerographic
Y Yellow
YEL Yellow

Chapter 1 Service Call Procedure

Chapter 1 Service Call Procedure
Chapter 1 Service Call Procedure CONTENTS
1.1 Before Starting the Servicing....................................................................................1-1
1.1.1 Safety .....................................................................................................................................1-1
1.1.2 Notes on the Handling of Customer Information ....................................................................1-3
1.1.3 Other Things to Note ..............................................................................................................1-4
1.2 Servicing Call Procedure ..........................................................................................1-5
1.3 Detailed Contents of the Service Call.......................................................................1-6
1.3.1 TRIM Servicing Procedure .....................................................................................................1-6
1.3.2 TRIM Check List.....................................................................................................................1-7
1.4 Machine Consumables and Periodic Replacement Parts.........................................1-9

1 - 1
Chapter 1 Service Call Procedure
1.1 Before Starting the Servicing
1.1.1 Safety
To prevent any accident that may occur during maintenance servicing, any WARNING or CAUTION
regarding the servicing must be strictly observed. Do not perform any hazardous operation.
1. Power Supply
To prevent electrical shocks, burns, or injury, etc., be sure to switch OFF the machine and
disconnect the plug before starting the maintenance servicing. If the machine has to be switched
ON, such as when measuring the voltage, take extra care to prevent an electrical shock.
2. Drive Area
Never inspect or lubricate the drive area such as the gears during the machine operation.
3. Heavy Parts
The weight of the machine is 29.6kg. When moving the machine to ensure sufficient working
space, take extra care to prevent back pain.
4. Safety Device
See that safety devices for preventing mechanical accidents, such as fuses, circuit breakers,
interlock switches, etc., and those for protecting customers from injury, such as panels and
covers, function properly. Modifications that hinder the function of any safety devices are strictly
prohibited.
5. Installing and removing the parts
The edge of parts and covers may be sharp, take care not to touch them. If the oil gets onto your
hand, wipe it off before getting on with the servicing. When removing parts or cables, do not pull
them out by force but remove them slowly.
6. Specified Tools
Follow the instruction when a tool is specified.
7. Organic Solvents
When using an organic solvent such as the Drum Cleaner or Machine Cleaner, pay attention to
the following:
• Ensure good ventilation in the room to prevent too much intake of the solvent.
• Do not use heated solvent.
• Keep away from fire.
• Wash your hands throughly after use.
8. Cleaning the Toner and Developer
As the toner may cause a dust explosion, sweep the spilt toner into a waste container. When
using a cleaner to clean the remaining toner, be sure to use the FX standard toner-proof cleaner
and not a customer's cleaner. Also, as the developer also contains toner, exercise the same
caution during cleaning.
9. Modifications
If any modifications are deemed necessary for the printer, submit an Application for Approval of
Modification prior to performing any work.

1 - 2
Chapter 1 Service Call Procedure
10.Lithium battery
Lithium battery is used in the following component.
• PWBA ESS AIO (PL8.1.2)
CAUTION
If not replaced properly , the battery can explode. Dispose of the old
battery according to the instructions.
11.Other Safety Precautions
For safety, you should also pay attention to precautions other than the above 1 to 10 items.
Follow the SAFE WORKING PRACTICES FOR ENGINEERS issued by FXAP EH & S
(Environmental Health and Safety) to ensure greater safety during servicing,
