FujiFilm ASK-300 Owner's manual

Ref. No. LB-1201E (SK·12·03·F1079·F9711) Printed in Japan ©2012 FUJIFILM Corporation
Small yet brings a great chance
for success to your business
For photo print business
For event photo business
For various business purposes
ASK-300
Dimension
Print size Description Number of prints
per Box
Printing speed
(approx)(*2)
3.5 ✕5 in. (89 ✕127 mm)
4✕6 in. (102 ✕152 mm)
5✕7 in. (127 ✕178 mm)
6✕8 in. (152 ✕203 mm)
T RL-CF900
T RK-CF800
T R2L-CF460
T R68-CF400
900 prints
800 prints
460 prints
400 prints
11.2 seconds/print
12.3 seconds/print
19.0 seconds/print
21.4 seconds/print
*1: Windows, Windows XP, Windows Vista, Windows 7 are registered trademarks of Microsoft Corporation in the United States and other countries.
Macintosh, Mac OS are registered trademarks of Apple Inc. in the United States and other countries.
*2: Not including data processing/transferring time.
Consumables Lineup
Dye-sublimation Printer
This compactly designed 170mm-high
printer can be installed in an area
equivalent to A3 paper size with
minimal interference.
Compact Size
ASK-300 Specifications
Printing Method
Gradation
Print resolution
Operation for paper exchange
Dimensions (W ✕ D ✕ H)
Weight
USB interface (rear side)
Driver software (*1)
Power consumption
EMC & Safety & Environment
Accessories
Dye-Sublimation Thermal Transfer
256 levels (8 bit) per color (Y, C, M)
300 ✕ 300 dpi
Semi-Auto Loading
10.8 ✕ 17.6 ✕ 6.7 in. (275 ✕ 446 ✕ 170 mm)
approx. 12 kg (26.4 lb)
High-Speed USB Ver.2.0 ✕ 1 port (Type B)
Windows® (32-bit) Windows XP® / Windows Vista®/ Windows 7®
(64-bit) Windows Vista®/ Windows 7®
Macintosh® Mac OS® 10.5 (Leopard)/10.6 (Snow Leopard)/10.7 (Lion)
2.4 A (220-240 VAC, 50/60 Hz), 4.6A (120 VAC, 50/60 Hz)
EMC FCC / CE, UL, CCC, CB(IEC/EN), RoHS, GOST-R, BSMI, KC
spacers (2 pcs), paper strip bin (1pcs),
paper tray (1 pcs), Operation Manual (1pcs),
Detailed Manual (1 pcs)
Replacement of paper and ink ribbons
is easily performed by pulling out the
front panel of the printer.
Easy Operation
A separator creates different passages of air for the
thermal head and power supply. The high air pressure
in the printer prevents dust from entering.
Dust-Proof Design to Protect Prints from Dirt
With power consumed in sleep mode, only 0.5W or
less, the printer contributes to energy saving and
cost reduction.
Energy Saving Design
ASK-300 can be used with the compact kiosk
DPC-Portable to make the best matching
system (Quick Print Station), enabling you to
start a new print business instantly.
Instant Business Startup
A variety of functions for smooth operation
6.7 in.
(170 mm)
10.8 in. (275 mm) 17.6 in. (446 mm)

An array of solutions for a successful business
For Business Expansion
Fujifilm’s Superior Image Quality
ASK-300solutions ―Fujifilm’s superior image quality prints
enhance a wide range of businesses Image Intelligence™
Fujifilm’s proprietary image processing
technology, Image Intelligence™
automatically compensates for
problematic conditions, such as poor
lighting, excessive backlight, high
contrast, underexposure or
overexposure. It reproduces beautiful
images as the eye sees them.
ASK-300 can be used in diversified business
scenes in a combination with various
equipment or software, producing superior
quality prints in any system configuration.
With this printer, starting a new business is
possible with a small initial investment.
FUJIFILM Quality Thermal Photo Paper
The proprietary coating technology,
developed through Fujifilm’s
experience in silver halide photos,
realizes superior whiteness,
glossiness and rich expressive
gradation. It reproduces skin tones
smoothly and scenery realistically.
The number of terminals and printers in the system configuration
can be changed easily to suit to the business scale and purpose.
The photos taken can be incorporated with templates or
texts and printed right on the spot. This compact system
can provide various types of event photos at facilities like
amusement parks, aquariums and cruise ships, as well as
at occasions like sport games and wedding parties.
You can start the print business right away with this
compact kiosk system, just after its installation. Shop
clerks and customers can easily order and print beautiful
photos instantly on their own. The ID photo format is
provided as a standard feature.
Just by connecting a computer with the printer driver
installed, ASK-300 can print high quality images for use in
any offices and workplaces such as design offices,
construction sites and portrait studios.
At photo shops and retail shops At amusement facilities and events At offices and studios
End user side Shop clerk side
DPC Portable
ASK-300
Software Computer
Computer ASK-300Digital camera ASK-300
DPC Portables
ASK-300
Computer
*A DPC-Portable can be connected with up to four printers and five order terminals.
*DPC-Portable can be connected to ASK-300, ASK-2500 and ASK-4000.
Example of configuration
MCYBL
M
C
Y
BL
