FujiFilm ApeosPro C810 User manual

Control Panel
Features of Control Panel
Pressing the Home button displays the Home
screen.
1. Power/Power Saving button
The power switches on.
Note
■ When “Please wait...” is displayed, the machine
is warming up. The use of machine is not avail-
able during this time.
■ If the power does not switch on, confirm that
the power plug is connected.
2. NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3. Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine or the fax is stored in a local folder.
4. Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5. Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
6. Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
2
Home Button
[Pause]
[Pins] [Address]
[Apps]
1
3
4
7
5
6
7. Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
and use its functions.
• [Pins]: You can execute a job again using Job Direc-
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
• [Address]: You can register addresses and other
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
September 2023 GM1517E5-5 Edition 1
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
User's Manual
ApeosPro C810
ApeosPro C750
ApeosPro C650
■ This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■ Parts of this manual is subject to change without prior notice.
■ The screen shots and the illustrations in this manual are used as examples. They may differ from yours depending on the
model, the software, or the OS.

2
Switching the Power Off
When the power is switched off, all the machine functions
are stopped.
Important
Do not switch the power off when the machine is in the
following states. If the power is switched off, the data
that is being processed may be deleted.
- During data reception (Data indicator is lit)
- Within 5 seconds after ejection of paper
- During copying or scanning
1. Press the Power/Power Saving button.
Note
Long pressing the Power/Power Saving button also
switches off power.
2. Tap on [Power Off Device].
Creating Pin
If you create a pin of Job Direction History of a job that is
executed in the past, you can easily execute the job with the
same settings.
Note
■ Job direction histories and created pins are managed by
each user.
■ Pinned job direction histories are not overwritten.
■ A pin created in an Administrator mode is shared by all
users.
■ Change/deletion of a shared pin can be performed in an
Administrator mode.
Creating Pin of Job Direction History
1. Log in.
2. On the Home screen, tap on [Pins].
3. Tap on on the right side of the history for
which you want to create a pin and tap on
[Create Pin].
Executing the Job from the Pinned Job
Direction History
On the [Pins] screen, tap on at the right side
of the pinned job and tap on [Start Now].
Loading Paper
Important
■ Do not place paper or other objects in the reserved
space of the tray. It may cause paper jams or machine
malfunction.
■ While the printer is processing a job, do not remove the
Paper Tray used for the job.
Note
Before loading the paper into the Paper Tray, fan a stack
of paper well. This will separate the sheets, and it can
prevent paper jamming.
This section explains how to load the plain paper into the
tray 1 to 4.
Loadable Paper
Paper size (mm) Tray 1, 2
Width: 100 to 330
Length: 148 to 488
Tray 3, 4
Standard size:
Max: A4 /Letter
Min: JIS B5
Paper weight (g/m2) 52 to 300
1. Pull out the Paper Tray until it stops.
2. When paper is already loaded in the tray,
take out the paper.

3
3. When loading paper whose size is JIS B4 or
larger, pinch the knob and lift the paper rear
end guide, and set the guide into the hole
for the indicated size.
1
2
3
4. Pinch the guide clip(s) and adjust to the
correct paper size.
There are two guide clips on the tray 1 and 2 and one
guide clip on the tray 3 and 4.
5. Fan a stack of paper, face the print surface
down, and then load the paper with edges
aligned according to the direction of the ar-
row.
Important
Do not load paper above the maximum fill line. It may
cause paper jams or machine malfunction.
Note
Adjust the guide clip(s) correctly to the size of paper.
If the guide clip(s) is not adjusted correctly, the machine
cannot feed the paper properly, resulting in paper jams.
6. Push in the Paper Tray.
7. When you have changed the paper type, set
the Paper Tray on the Device screen.
1. Tap on > [Device] > [Paper Tray Settings].
2. After tapping on the number for the Paper Tray
you have loaded the paper, configure the paper
items, and then tap on [OK].
8. When printing, configure the paper settings
from the printer driver.

4
Document Glass
Loadable paper
Paper size (mm) Width: Up to 297
Length: Up to 432
1. Open the Document Cover, and wipe off
any dirt from the Document Glass.
2. Load the document face down with the
document aligned with the upper left cor-
ner of the Document Glass.
3. Close the Document Cover.
Copy/Fax/Scan
1. Set the document.
Document Feeder
Loadable paper
Paper size (mm) Width: 84 to 297
Length: 140 to 432
Paper weight (g/m2) Single side printing: 38 to 200
Double side printing: 50 to 200
Note
When the Fax Kit is installed, the loadable paper size is
up to 600 mm for the length.
1. Open the Document Cover.
2. Wipe off any dirt adhering to the glass strip
and white plastic area located in the left side
of the Document Glass.
3. Close the Document Cover.
4. Confirm that the document is free of tag pa-
per, adhesive tape, staples, and clips, and
stretch out the document if it is wrinkled or
folded.
5. Align the upper left corner of the document
so that the original size is correctly detected.
6. Load the document face up (when the doc-
ument is 2-sided, place the front side up) in
the center of Document Feeder.
Important
Do not set documents above the maximum fill line. It
may cause paper jams or machine malfunction.
Multiple
sheets
7. When the confirmation indicator lights up,
move the document guide to align with
both edges of the document.
8. Open the Document Stopper.
Document Feeder
Attention Light
Note
To prevent a document from being left behind, “Docu-
ment Feeder Attention Light” is turned on after the Scan
job is completed and turned off after approx. 3 sec.
1 sheet

5
2. On the [Apps] screen, tap on the desired Application icon.
FaxScanCopy
Copy
1. As needed, configure the setting items.
2. Tap on [Start].
Scan (Email)
Note
■ [Scan to Folder], [Scan], [USB], and [Scan to Desktop] are
also available as methods for scanning.
■ To send an e-mail, the e-mail settings need to be config-
ured in the Device beforehand.
1. Specify the recipient by directly entering us-
ing the keyboard or by tapping on the Address
Book ( ).
Note
■ When specifying multiple recipients by directly entering
using the keyboard, tap on [Add Recipient], and then enter
the recipient.
■ To change the recipient type (To/Cc/Bcc), tap on .
2. Tap on [Done] or [OK].
3. Tap on and configure the setting items as
needed.
4. Tap on [Start].
Fax
1. Enter by the keyboard or by tapping on the
Address Book ( ) or Redial ( ) to specify the
recipient.
2. Tap on [Done] or [OK].
3. Tap on and configure the setting items as
needed.
4. Tap on [Start].

6
Electrical Safety
WARNING
This product shall be operated by the power source as indicated
on the product's data plate. Consult your local power company
to check if your power source meets the requirements.
WARNING: Connect this product to a protective earth
circuit.
This product is supplied with a plug that has a protective
earth pin. The plug fits only into an earthed electrical outlet.
This is a safety feature. If the plug doesn't fit to the outlet, con-
tact an electrician to replace the outlet to avoid risk of electric
shock. Never use an earthed adapter plug to connect the prod-
uct to the electrical outlet that has no earth connection termi-
nal. Improper connection of a grounding conductor may cause
electric shock.
Plug the power cord directly into a grounded electrical
outlet. To prevent overheat and a fire accident, do not
use an extension cord, a multi-plug adaptor or a multiple
connector. Consult your local representative to check if an out-
let is grounded.
Connect this product to a branch circuit or an outlet that
has larger capacity than the rated ampere and voltage of
this product. See the data plate on the rear panel of this
product for its rated ampere and voltage.
Never touch the power cord with wet hands. It may
cause electric shock.
Do not put an object on the power cord.
Always keep the plug connection free of dust. The dusty
and damp environment may bring about minute electric
current in a connector. It may generate heat and eventu-
ally cause a fire accident.
To avoid the risk of electric shock and a fire accident,
only use the power cord supplied with this product or
the ones designated by our company. The power cord is
exclusive use for this product. Do not use it for any other prod-
uct. Do not damage or alter the power cord. Damage and alter-
ation may generate heat and eventually cause electric shock or
a fire accident. If the power cord is damaged or insulated wires
are exposed, contact your local representative for its replace-
ment. Do not use a damaged or uninsulated cord to avoid the
risk of electric shock and a fire accident.
CAUTION
Unplug this product to turn off power completely. Install
this product near an outlet to easily unplug it in case of
emergency.
When cleaning this product, always switch off and un-
plug it. Access to a live product interior may cause elec-
tric shock.
Do not unplug or re-plug this product with the switch on.
Plugging and unplugging a live connector may deform
the plug and generate heat, and eventually cause a fire
accident.
Hold the plug not the cord when unplugging this prod-
uct, or it may damage the cord and cause electric shock
or a fire accident.
Switch off and unplug the product when it (i.e., fax func-
tion) is not used over weekends or long holidays. Please
note that it cannot receive fax message during switch-
off.
Once a month, switch off this product and check if
■ the power cord is plugged firmly into an electrical out-
let;
■ the plug is not excessively heated, rusted or bent;
■ the plug and electrical outlet are free of dust; and
■ the power cord is not cracked or worn down.
Once you notice any unusual condition, switch off and unplug this
product first and contact your local representative.
Safety Notes
Before using this product, read “Safety Notes” carefully for
safety use.
This product and recommended supplies have been tested
and found to comply with strict safety requirements includ-
ing safety agency approvals and compliance with environ-
mental standards. Follow the following instructions for safe-
ty use.
WARNING
Any unauthorized alteration including an addition of new
functions or connection to external devices may not be cov-
ered by the product warranty. Contact your local represen-
tative for more information.
Follow all warning instructions marked on this product. The
warning marks stand for the followings:
DANGER
Used for item that if not followed
strictly, can lead death or severe or
fatal injuries and the possibility to do
it is comparatively high.
WARNING Used for items that if not followed
strictly, can lead to severe or fatal
injuries.
CAUTION
Used for items that if not followed
strictly, can cause injuries to user or
damages to machine.
: A symbol for items to pay attention to when handling ma-
chine. Follow instructions carefully to use machine safely.
Caution Caution for
electrostatic
breakage
Flammable Explodable Electric
shock
Heated
surface
: A symbol for prohibited items. Follow instructions careful-
ly to avoid any dangerous acts.
: A symbol for items that must be performed. Follow in-
structions carefully to carry out these essential tasks.
Unplug Ground/EarthInstructions
Prohibited No fire Do not touch Do not use in
bathroom
Never touch
with wet hand
Keep away
from wet
Do not tear
down
Moving
object
Pinched fingers Rotating Parts
Hazard
Sharp Edge
Hazard

7
Machine Installation
WARNING
Do not locate this product where people might step on
or trip over the power cord. Friction or excessive pres-
sure may generate heat and eventually cause electric
shock or a fire accident.
CAUTION
Never locate this product in the following places:
■ Near radiators or any other heat sources
■ Near volatile flammable materials such as curtains
■ In the hot, humid, dusty or poorly ventilated environment
■ In the place receiving direct sunlight
■ Near cookers or humidifiers
Keep away the packing materials of product from small
children. The thin film may cling to nose and mouth and
prevent breathing.
Locate this product on a level and sturdy surface that
can withstand a weight of 250 kg (minimum configura-
tion). Otherwise, if tilted, the product may fall over and
cause injuries.
Locate this product in a well-ventilated area. Do not ob-
struct ventilation openings of the product. Keep the min-
imum clearance as follows for ventilation and an access
to the power plug. Unplug the product if an abnormal condition
is noted.
Minimum configuration
100
793
663
23580
20
1791
1759
1659
(Unit: mm)
Do not incline the product at more than 10° angle. Oth-
erwise, it may fall over and cause injuries.
10°
10
°10°10
°
Always lock the wheels of this product after installation.
Otherwise, it may fall over or slide and cause injuries.
To bundle wires and cables, always use the cable ties and
spiral tubes that our company supplies. Otherwise, it
may cause some defects.
Operational Safety
WARNING
The operator’s product maintenance procedures are de-
scribed in the manuals supplied with this product. Do not
carry out any other maintenance procedures not de-
scribed in the manuals.
This product features safety design not to allow opera-
tors access to hazard areas. The hazard areas are isolat-
ed from operators by covers or protectors which require
a tool to remove. To prevent electric shock and injuries, never
remove those covers and protectors.
To avoid the risk of electric shock and a fire accident,
switch off and unplug the product promptly in the fol-
lowing conditions, then contact your local representa-
tive.
■ The product emits smoke or its surface is unusually hot.
■ The product emits unusual noise or odor.
■ The power cord is cracked or worn down.
■ A circuit breaker, fuse or any other safety device becomes ac-
tivated.
■ Any liquid is spilled into the product.
■ The product is soaked in water.
■ Any part of the product is damaged.
Do not insert any object into slots or openings of this
product. Do not put any of the followings on the product:
■ Liquid container such as flower vases or coffee cups
■ Metal parts such as staples or clips
■ Heavy objects
If liquid is spilled over or metal parts are slipped into the prod-
uct, it may cause electric shock or a fire accident.
Do not place liquid, particles, small metal pieces or their
containers in consumable storage spaces. Spills may
cause electric shock or fire due to short-circuit.
Do not place dangerous objects (e.g., fragiles, volatile
and flammable chemicals, creatures) in consumable
storage spaces. Otherwise, it may cause catching fire.
Do not use conductive paper such as origami paper, car-
bonic paper or conductively-coated paper. When paper
jam occurs, it may cause short-circuit and eventually a
fire accident.
When cleaning this product, use the designated cleaning
materials exclusive to it. Other cleaning materials may
result in poor performance of the product. Never use
aerosol cleaners to avoid catching fire and explosion.
When you play the media (e.g., CD-ROM, DVD) supplied
with the product, always use said media-enabled device.
Otherwise, large sound may damage its speakers or your
ears.

8
CAUTION
Always follow all warning instructions marked on or sup-
plied with this product. To avoid the risk of burn injuries
and electric shock, never touch the area with the “Heated
surface” or “Electric shock” marks on.
Keep electrical and mechanical safety interlocks active.
Keep the safety interlocks away from magnetic materi-
als. Magnetic materials may accidentally activate the
product and cause injuries or electric shock.
A ground fault interrupter is embedded in this product. If
current leakage occurs, the ground fault interrupter au-
tomatically cuts off power circuit to prevent electric
shock and a fire accident. The ground fault interrupter is nor-
mally ON. Check once a month if the ground fault interrupter
works properly in accordance with the following procedures:
For AC 220 to 240 V model
1. Switch off the product.
2. Press the RESET button to the reset position. The button
will be depressed even after the pushing force is re-
leased.
RESET button
3. Press the TEST button lightly with a sharp edge such as a
pen tip. The depressed RESET button will stick out again.
This is the end of the check procedure.
TEST button
4. Press the RESET button back to the depressed position.
For AC 110 to 127 V model
1. Press the TEST button.
TEST button
2. Check that the RESET button is turned OFF and in the “O”
state.
RESET button
TEST button
3. Turn ON the RESET button (in the “|” state”).
If the circuit does not work properly, contact your local rep-
resentative.
Do not attempt to remove a paper deeply jammed inside
the product, particularly a paper wrapped around the
fusing unit or the heat roller. Otherwise, it may cause in-
juries or burns. Switch off the product immediately and contact
your local representative.
Never touch the paper output area of the finisher
during operation. It may cause injuries.
Be careful in removing jammed staples.
Be careful not to get injured by waste staples when de-
taching a staple waste container.
Waste staples may come out with output paper. Be care-
ful not to get injured by the staples.
Never touch safety interlocks. When a front cover is
open, safety interlocks become activated to stop the ma-
chinery. Do not apply pressure on safety interlocks with a
coin or screwdriver. Otherwise, the machinery may become ac-
tivated and cause injuries.
Do not staple punched holes of paper. Sharp points of a
staple may cause injuries.
Be careful not to drop an object when you bring it out
from consumable storage spaces. Otherwise, you may
get injured.
Grip the handhold on a door of consumable storage
spaces when you open and close it. Do not hold an upper
or bottom edge of the door. Otherwise, you may get in-
jured.
Do not add a shock to a door of consumable storage
spaces. Otherwise, the door may break to drop off and
you may get injured.
Do not apply excessive force to hold thick document on
the document glass. It may break the glass and cause in-
juries.
For continuous operation more than 1 hour, take a 10 -
15 minute break every hour to rest your eyes.
To move this product to another location, contact your
local representative.
Ventilate well during extended operation or mass copy-
ing or printing. It may affect the office air environment
due to odor such as ozone in a poorly ventilated room.
Provide proper ventilation to ensure the comfortable and safe
environment.

9
Consumable
WARNING
Store all consumables in accordance with the instruc-
tions given on its package or container.
Never use a vacuum cleaner for spilled toner and residual
toner in this product, toner cartridge or waste toner con-
tainer. It may catch fire by electric sparks inside a vacu-
um cleaner and cause explosion. Use a broom or a wet cloth to
wipe off the spills. If you spill a large volume of toner, contact
your local representative.
Never throw a toner cartridge into an open flame. Re-
maining toner in the cartridge may catch fire and cause
burn injuries or explosion. If you have a used toner car-
tridge no longer needed, contact your local representative for
its disposal.
Never throw a waste toner container into an open flame.
Toner may catch fire and cause burn injuries or explo-
sion. If you have a used waste toner container no longer
needed, contact your local representative for its disposal.
CAUTION
Keep drum cartridges and toner cartridges out of the
reach of children. If a child accidentally swallows toner,
spit it out, rinse mouth with water, drink water and con-
sult a physician immediately.
When replacing drum cartridges and toner cartridges, be
careful not to spill the toner. In case of any toner spills,
avoid contact with clothes, skin, eyes and mouth as well
as inhalation.
■ If toner spills onto your skin or clothing, wash it off
with soap and water.
■ If you get toner particles in the eyes, wash it out with
plenty of water for at least 15 minutes until irritation is
gone. Consult a physician if necessary.
■ If you inhale toner particles, move to a fresh air location and
rinse your mouth with water.
■ If you swallow toner, spit it out, rinse your mouth with water,
drink plenty of water and consult a physician immediately.
Regulation
Radio Frequency Emissions (Class A digital
device) (European Union)
WARNING: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the
user may be required to take adequate measures.
WARNING: In order to allow this equipment to operate in close
proximity to Industrial, Scientific and Medical (ISM) equipment,
the external radiation from ISM equipment may have to be lim-
ited or special mitigation measures taken.
Changes or modifications to this equipment not specifically ap-
proved by our company may void the user’s authority to operate
this equipment.
Radio Frequency Emissions (Class A digital
device) (United Kingdom)
WARNING: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the
user may be required to take adequate measures.
WARNING: In order to allow this equipment to operate in close
proximity to Industrial, Scientific and Medical (ISM) equipment,
the external radiation from ISM equipment may have to be lim-
ited or special mitigation measures taken.
Changes or modifications to this equipment not specifically ap-
proved by our company may void the user’s authority to operate
this equipment.
Radio Frequency Emissions (Class A digital
device) (Maldives)
WARNING: This is a Class A product. In a domestic environment
this product may cause radio interference in which case the
user may be required to take adequate measures.
WARNING: In order to allow this equipment to operate in close
proximity to Industrial, Scientific and Medical (ISM) equipment,
the external radiation from ISM equipment may have to be lim-
ited or special mitigation measures taken.
Changes or modifications to this equipment not specifically ap-
proved by our company may void the user’s authority to operate
this equipment.
Radio Frequency Emissions (Class A digital
device) (USA)
Note: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in
a commercial environment.
This equipment generates, uses, and can radiate radio frequen-
cy energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be re-
quired to correct the interference at his own expense.
Changes or modifications to this equipment not specifically ap-
proved by our company may void the user’s authority to operate
this equipment.
• EU/UK
Shielded cables must be used with this equipment to
maintain compliance with Council Directive 2014/30/EU.

10
Environment
Disposal of Electrical and Electronic Equip-
ment in Professional/Business Equipment
(European Union)
In the European Union: This symbol on the product, or
in the manual and in the warranty, and/or on its pack-
aging indicates that this product shall not be treated as
household waste. Instead it should be disposed in com-
pliance with agreed national procedures.
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences to the environment
and human health, which could otherwise be caused by inap-
propriate waste handling of this product. Please contact your
local representative prior to disposal.
This symbol on the batteries or accumulators indicates
that those batteries shall not be treated as household
waste.
If your equipment contains easy removal batteries or
accumulators, please dispose these separately according to
your local requirements.
The recycling of materials will help to conserve natural resourc-
es. For more detailed information about recycling this product,
please contact your local authorities and ask for the correct way
of disposal.
USA only
Perchlorate Material - special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Telephone Line Cord
CAUTION
To reduce the risk of fire, use only No. 26 American Wire
Gauge (AWG) or larger telecommunication line cord.

11

Read Before Using
Before using the machine, please read “License Agreement” (terms for using the Adobe Inc. software) provided in the “Reference
Guide Main Unit”.
Reference Guide is available on the official site of our company.
Use the software only after you agree with all applicable terms and conditions. By using the software, you are agreeing to be
bound by the terms and conditions. If you do not agree to “License Agreement”, please contact the dealer you purchased the
product.
The manuals for this product may include descriptions about the models, features, and separately-sold accessories that are un-
available depending on the country and/or region. Contact your local representative for more information.
