Fujitsu ASUG09LZBS Service manual

AIR CONDITIONER
Wall mounted type
DESIGN & TECHNICAL MANUAL
INDOOR
ASUG09LZBS
ASUG12LZBS
ASUG15LZBS
OUTDOOR
AOUG09LZAS1
AOUG12LZAS1
AOUG15LZAS1
DR_AS141EF_02
2022.10.14

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
FGLair™ is trademark of Fujitsu General Limited in the United States, other countries or both.
Google Play™ is trademark of Google LLC.
App Store® is a service mark of Apple Inc., registered in the U.S. and other countries.
Copyright © 2021, 2022 Fujitsu General Limited. All rights reserved.

CONTENTS
Part 1. INDOOR UNIT...........................................................................1
1. Specifications................................................................................................2
2. Dimensions....................................................................................................4
2-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS ...........................................4
3. Wiring diagrams ............................................................................................6
3-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS ...........................................6
4. Capacity table................................................................................................7
4-1. Cooling capacity...............................................................................................................7
4-2. Heating capacity ..............................................................................................................9
5. Fan performance .........................................................................................11
5-1. Air velocity distributions..................................................................................................11
5-2. Airflow ............................................................................................................................13
6. Operation noise (sound pressure).............................................................16
6-1. Noise level curve............................................................................................................16
6-2. Sound level check point .................................................................................................17
7. Safety devices .............................................................................................18
8. External input and output...........................................................................19
8-1. External input.................................................................................................................20
8-2. External output...............................................................................................................21
8-3. Combination of external input and output.......................................................................22
8-4. Details of function ..........................................................................................................23
9. Remote controller .......................................................................................36
9-1. Wireless remote controller .............................................................................................36
10. Function settings .......................................................................................38
10-1.Function settings by using remote controller.................................................................38
10-2.Custom code setting for wireless remote controller.......................................................46
10-3.Switching the temperature unit of remote controller......................................................47
11. Accessories.................................................................................................48
12. Optional parts .............................................................................................49
12-1.Controllers ....................................................................................................................49
12-2.Others ...........................................................................................................................50

Part 2. OUTDOOR UNIT.....................................................................51
2-1. Specifications...........................................................................................52
2. Dimensions..................................................................................................53
2-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 ..................................53
3. Installation space ........................................................................................54
3-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 ..................................54
4. Refrigerant circuit .......................................................................................57
4-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 ..................................57
5. Wiring diagrams ..........................................................................................58
5-1. Models: AOUG09LZAS1, AOUG12LZAS1, and AOUG15LZAS1 ..................................58
6. Capacity compensation rate for pipe length and height difference........59
6-1. Models: AOUG09LZAS1 and AOUG12LZAS1 ..............................................................59
6-2. Model: AOUG15LZAS1..................................................................................................60
7. Additional charge calculation ....................................................................61
7-1. Models: AOUG09LZAS1 and AOUG12LZAS1 ..............................................................61
7-2. Model: AOUG15LZAS1..................................................................................................61
8. Airflow..........................................................................................................62
8-1. Model: AOUG09LZAS1..................................................................................................62
8-2. Model: AOUG12LZAS1..................................................................................................62
8-3. Model: AOUG15LZAS1..................................................................................................63
9. Operation noise (sound pressure).............................................................64
9-1. Noise level curve............................................................................................................64
9-2. Sound level check point .................................................................................................65
10. Electrical characteristics..........................................................................66
11. Safety devices .............................................................................................67
12. Accessories.................................................................................................68
CONTENTS (continued)

Part 1. INDOOR UNIT
WALL MOUNTED TYPE:
ASUG09LZBS
ASUG12LZBS
ASUG15LZBS

1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASUG09LZBS ASUG12LZBS ASUG15LZBS
Power supply 208/230 V ~60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated kW 2.64 3.52 4.25
Btu/h 9,000 12,000 14,500
Min.—Max. kW 0.91—3.52 0.91—3.99 0.91—5.39
Btu/h 3,100—12,000 3,100—13,600 3,100—18,400
Heating
Rated kW 3.52 4.69 5.28
Btu/h 12,000 16,000 18,000
Min.—Max. kW 0.91—6.45 0.91—6.48 0.91—7.00
Btu/h 3,100—22,000 3,100—22,100 3,100—23,900
Heating
(17°F)*1
Rated kW 2.17 2.93 3.28
Btu/h 7,400 10,000 11,200
Max. kW 4.69 5.13 6.30
Btu/h 16,000 17,500 21,500
Heating
(5°F)*2
Rated kW 4.51 4.87 5.13
Btu/h 15,400 16,600 17,500
Max. kW 4.51 4.87 6.15
Btu/h 15,400 16,600 21,000
Input power
Cooling Rated
kW
0.50 0.79 1.04
Min.—Max. 0.11—0.85 0.11—0.99 0.15—1.56
Heating Rated 0.66 1.01 1.15
Min.—Max. 0.17—1.93 0.17—1.94 0.15—2.19
Heating
(17°F)*1
Rated 0.60 0.88 1.01
Max. 2.06 2.59
Heating
(5°F)*2
Rated 2.10 2.09 2.03
Max. 2.10 2.75
Current Cooling Rated A 2.5 3.8 4.8
Heating 3.3 4.7 5.2
EER2 Cooling kW/kW 5.28 4.46 4.09
Btu/hW 18.0 15.2 13.9
COP2 Heating kW/kW 5.34 4.64 4.60
Btu/hW 18.2 15.8 15.7
SEER2 Cooling Btu/hW 33.1 29.4 25.3
HSPF2 Heating Btu/hW 13.4 12.9 12.8
Power factor Cooling %87 90 94
Heating 87 93 96
Moisture removal pints/h (L/h) 2.5 (1.2) 2.7 (1.3) 4.0 (1.9)
Maximum operating current*3Cooling A9.4 9.9
Heating 10.9 13.4
Fan
Airflow rate
Cooling
HIGH
CFM (m3/h)
542 (920) 583 (990)
MED 406 (690) 459 (780)
LOW 312 (530) 312 (530)
QUIET 206 (350) 241 (410)
Heating
HIGH 542 (920) 600 (1,020)
MED 406 (690) 459 (780)
LOW 312 (530) 312 (530)
QUIET 206 (350) 241 (410)
Type × Qty Crossflow fan × 1
Motor output W 59
Sound pressure level*4
Cooling
HIGH
dB (A)
43 45
MED 37 40
LOW 31 32
QUIET 23 26
Heating
HIGH 43 45
MED 36 39
LOW 31 32
QUIET 23 26
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 31-7/16 × 1-1/16 (210 × 798 × 26.6)
Main2: 5-5/16 × 31-7/16 × 13/16 (135 × 798 × 20.0)
Sub1: 3-5/16 × 31-7/16 × 1/2 (84 × 798 × 13.3)
Sub2: 3-5/16 × 31-7/16 × 1/2 (84 × 798 × 13.3)
Fin pitch FPI
Man 1: 21
Main 2: 23
Sub 1: 18
Sub 2: 18
Rows × Stages
Main 1: 2 × 10
Main 2: 2 × 8
Sub 1: 1 × 4
Sub 2: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net in (mm) 11 × 38-9/16 × 9-7/16 (280 × 980 × 240)
Gross 12-11/16 × 42-7/16 × 13-5/8 (322 × 1,078 × 346)
Weight Net lb (kg) 29 (13)
Gross 37 (17)
Connection pipe Size Liquid in (mm) Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.7)
Method Flare
Drain hose Material PP+LLDPE
Tip diameter in (mm) Ø7/32 (Ø13.8) (I.D.), Ø5/8 to 21/32 (Ø15.8 to 16.7) (O.D.)
- 2 - 1. Specifications
WALL MOUNTED ASUG09-15LZBS WALL MOUNTED ASUG09-15LZBS

Type
Wall mounted
Inverter heat pump
Model name ASUG09LZBS ASUG12LZBS ASUG15LZBS
Operation range Cooling °F (°C) 64 to 90 (18 to 32) %RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller type Wireless (Wired, Mobile app*5 [FGLair™] [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 80°FDB (26.67°CDB)/67°FWB (19.44°CWB), and outdoor temperature of 95°FDB (35°CDB)/75°FWB (23.9°CWB).
– Heating: Indoor temperature of 70°FDB (21.11°CDB)/59°FWB (15.56°CWB), and outdoor temperature of 47°FDB (8.33°CDB)/43°FWB (6.11°CWB).
– *1: Heating (17°F): Indoor temperature of 70°FDB (21.11°CDB)/60°FWB (15.56°CWB), and outdoor temperature of 17°FDB (-8.33°CDB)/15°FWB (-9.44°CWB).
– *2: Heating (5°F): Indoor temperature of 70°FDB (21.11°CDB)/60°FWB (15.56°CWB), and outdoor temperature of 5°FDB (-15.0°CDB)/4°FWB (-15.56°CWB).
– Test conditions are based on AHRI 210/240 2023.
– Pipe length: 25 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *3: Maximum current is maximum value when operated within the operation range.
• *4: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *5: Available on Google Play™ store or on App Store®. Optional WLAN Adapter is also required. For details, refer to the setting manual.
M condition
Model name ASUG09LZBS ASUG12LZBS ASUG15LZBS
Capacity
Cooling
Rated kW 2.64 3.52 4.25
Btu/h 9,000 12,000 14,500
Min.—Max. kW 0.91—3.52 0.91—3.99 0.91—5.39
Btu/h 3,100—12,000 3,100—13,600 3,100—18,400
Heating
Rated kW 3.52 4.69 5.28
Btu/h 12,000 16,000 18,000
Min.—Max. kW 0.91—6.45 0.91—6.48 0.91—7.00
Btu/h 3,100—22,000 3,100—22,100 3,100—23,900
Heating
(17°F)*
Rated kW 2.17 2.93 3.28
Btu/h 7,400 10,000 11,200
Max. kW 4.69 5.13 6.30
Btu/h 16,000 17,500 21,500
Input power
Cooling Rated
kW
0.50 0.79 1.04
Min.—Max. 0.11—0.85 0.11—0.99 0.15—1.56
Heating Rated 0.66 1.01 1.15
Min.—Max. 0.17—1.93 0.17—1.94 0.15—2.19
Heating
(17°F)*
Rated 0.60 0.88 1.01
Max. 2.06 2.59
Current Cooling Rated A 2.5 3.8 4.8
Heating 3.3 4.7 5.2
EER Cooling kW/kW 5.28 4.46 4.09
Btu/hW 18.0 15.2 13.9
COP Heating kW/kW 5.34 4.64 4.60
Btu/hW 18.2 15.8 15.7
SEER Cooling Btu/hW 33.1 29.4 25.3
HSPF Heating Btu/hW 14.2 14.0 13.4
Power factor Cooling %87 90 94
Heating 87 93 96
NOTES:
Specifications are based on the following conditions:
• Cooling: Indoor temperature of 80°FDB (26.67°CDB)/67°FWB (19.44°CWB), and outdoor temperature of 95°FDB (35°CDB)/75°FWB (23.9°CWB).
• Heating: Indoor temperature of 70°FDB (21.11°CDB)/59°FWB (15.56°CWB), and outdoor temperature of 47°FDB (8.33°CDB)/43°FWB (6.11°CWB).
• *: Heating (17°F): Indoor temperature of 70°FDB (21.11°CDB)/60°FWB (15.56°CWB), and outdoor temperature of 17°FDB (-8.33°CDB)/15°FWB (-9.44°CWB).
• Test conditions are based on AHRI 210/240 2017.
• Pipe length: 25 ft (7.5 m), Height difference: 0 ft (0 m). (Between outdoor unit and indoor unit.)
- 3 - 1. Specifications
WALL MOUNTED ASUG09-15LZBS WALL MOUNTED ASUG09-15LZBS

2. Dimensions
2-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS
Unit: in (mm)
Outline of indoor unit
1-7/16 (37) 1-7/16 (37)
15-3/4 (400) 3-9/16
(90)
16-1/4 (413)3-1/16
(77)
2-7/8
(73)
16-7/16 (417)2-3/8
(61)
16-7/8 (429)
4-1/2 (115)
2-13/16 (72)
for pipe inlet
Ø 2-9/16 (65)
for pipe inlet
Ø 2-9/16 (65)
38-9/16 (980) 9-7/16 (240)
11 (280)
- 4 -
2-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS 2. Dimensions
WALL MOUNTED ASUG09-15LZBS WALL MOUNTED ASUG09-15LZBS

¢Installation space requirement
Provide sufficient installation space for product safety.
Unit: in (mm)
Wall hook bracket
Outline of the indoor unit
2 (50) or more
3 (71) or more
2(40)or more 3 (70) or more
5 (117) or more
60 (1,500) or more
71 (1,800) or more
7 (160) or more
- 5 -
2-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS 2. Dimensions
WALL MOUNTED ASUG09-15LZBS WALL MOUNTED ASUG09-15LZBS

3. Wiring diagrams
3-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS
- 6 -
3-1. Models: ASUG09LZBS, ASUG12LZBS, and ASUG15LZBS 3. Wiring diagrams
WALL MOUNTED ASUG09-15LZBS WALL MOUNTED ASUG09-15LZBS
