Fujitsu SMARTCASE S500 User manual

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 1 of 18 www.fujitsu.com
Assembly Instructions
SMARTCASE S500 & D3544-Sx
_
________________________________________________________________________________________________________

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 2 of 18 www.fujitsu.com
Table of Contents
Step 1 Preparing the Chassis .........................................................................................................................................3
Step 2 Installing the Heatsink .......................................................................................................................................4
Step 3 Inserting additional Modules (Memory / M.2 / …)...............................................................................................7
Step 4 Mainboard Assembly ........................................................................................................................................10
Step 5 Optional Components.......................................................................................................................................12
Installing WLAN Antennas......................................................................................................................................12
Speaker Assembly ...................................................................................................................................................13
Installing USB Type C Extension Cable...................................................................................................................14
Step 6 Closing the Chassis ...........................................................................................................................................15
Step 7 Adding Stands...................................................................................................................................................17

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 3 of 18 www.fujitsu.com
Step 1 Preparing the Chassis
Open the chassis with two hands by putting some pressure on your thumbs to push the cover reverse.
Remove top cover and unpack the accessories.
(Chassis kit content)
Rear Cover
Remove protective foil of
heat spreader pad!

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 4 of 18 www.fujitsu.com
Step 2 Installing the Heatsink
Fujitsu provides both a passive and an active heatsink solution, and a common mounting backplate.
Before assembling the mainboard into the chassis, it is recommended to install the optional onboard components
like cooler, RAM, M.2, etc.).
Mounting Backplate
Do not remove the insulating
foil of the backplate, otherwise
the mainboard may be
damaged due to possible short
circuit
(backplate position)
Note: Mounting holes
are asymmetrical!

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 5 of 18 www.fujitsu.com
Note:
Recommended mounting torque
for heatsink screws: 0.6Nm
(max. 0.8Nm)
Passive Heatsink
Note: The assembly solution with the coloured plastic part as shown above will be replaced
by an alternative “SoC die-crack-protection” implementation in future.
Hold the heatsink with one hand so
that it doesn’t tilt while installing the
screws
Assemble all 4 screws according to the
order shown. Each screw can be
tightened immediately!
Finally, remove the coloured plastic
part by turning it carefully clockwise.
This coloured plastic part is used for
secure assembly of the heatsink in
order not to damage the CPU die (“die
crack protection”).
After assembly, this part can be
scrapped
Note:
Recommended mounting torque for heatsink
screws: 0.6Nm (max. 0.8Nm)
Passive heatsink positioning:
Gaps of the passive heatsink must be located
towards the border of the mainboard
Mounting Backplate:
Do not remove the insulating foil of the
backplate, otherwise the mainboard may be
damaged due to possible short circuit
2
3
4
1
5

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 6 of 18 www.fujitsu.com
Active Heatsink
Note: The assembly solution with the coloured plastic part as shown above will be replaced
by an alternative “SoC die-crack-protection” implementation in future.
Note:
Recommended mounting torque for heatsink
screws: 0.6Nm (max. 0.8Nm)
Active heatsink positioning:
Heatsink must be positioned according to
Mounting Backplate:
Do not remove the insulating foil of the
backplate, otherwise the mainboard may be
damaged due to possible short circuit
Hold the heatsink with one hand so
that it doesn’t tilt while installing the
screws
Assemble all 4 screws according to the
order shown. Each screw can be
tightened immediately!
Finally, remove the coloured plastic
part by turning it carefully clockwise.
This coloured plastic part is used for
secure assembly of the heatsink in
order not to damage the CPU die (“die
crack protection”).
After assembly, this part can be
scrapped
2
3
4
1
5

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 7 of 18 www.fujitsu.com
Step 3 Inserting additional Modules (Memory / M.2 / …)
The following picture shows some possible M.2 modules
Attention: Do not touch any pins! Touch the memory at the outside edges only.
Do not stick a barcode onto any modules!
The following procedure is recommended in order to ensure secure electrical contact:
Insert the memory angular and
pay attention to the notch!
Remove the memory again
completely from the DIMM
socket!
Insert memory again
Press down the memory until it
clicks into place
Do not press in the middle of the
memory, but press down on the
outside edges
Mainboard
M.2 2242
SSD/ Storage
M.2 SSD / Storage
2280
M.2 2230
WLAN
Memory

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 8 of 18 www.fujitsu.com
WLAN module / M.2. module assembly
First remove the M.2 mounting screws.
Insert M.2 module angular into the socket (while paying attention to the coding / notch).
Both modules, as shown in the picture, have to be touched on the outside edges only.
For the M.2 SSD (left socket), the assembly nut and screw are pre-installed for a 2240mm module.
In order to install a 2260 module, the 2240 assembly nut has to be moved to the 2260 position first.
For a 2280 module, the 2240 assembly nut has to be removed, and the pre-installed M.2 WLAN (2230) nut
is used for both M.2 2230 WLAN and M.2 2280 SSD
Recommended torque for the M.2 screw is 0.2Nm, and 0.3Nm for the nut.
Pay attention
to the notch
2240 screw /
nut position
Common 2280/2230
screw / nut position
2260 screw /
nut position

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 9 of 18 www.fujitsu.com
Sample installation M.2 2280 SSD module and M.2 2230 M.2 WLAN module:
Both modules are fixed by one common screw.

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 10 of 18 www.fujitsu.com
Step 4 Mainboard Assembly
1. Swing in the mainboard (rear chassis side)
2. Move it carefully to the final position
Take care for the heat spreader pad! Protective foil must be removed first!
Insert the chassis rear cover as shown above.
Push down the mainboard carefully while the four mounting holes fit onto the chassis nuts.
1
2

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 11 of 18 www.fujitsu.com
Assemble the four mounting screws (included in the chassis kit).
Recommeded torque = 0.6Nm

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 12 of 18 www.fujitsu.com
Step 5 Optional Components
Installing WLAN Antennas
Please check the color-coding of the antennas. On the chassis front side the antenna bays are marked black
respectively gray .
Please note that the plastic front bezel has to be removed first.
Push the antenna cables completely through the
opening in the housing and pay attention to the
antenna cable notch (see red circles).
Carefully install the WLAN antennas. The metal plate
must not be bent.
Insert the black antenna cable in the hooks (see red circles), and then plug the black antenna cable to socket #1 of
the M.2 WLAN module. Plug the gray antenna cable to socket #2.
Note: Consider correct installation / position of the antenna cable in order to avoid possible collision with the USB
Typ- C connector

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 13 of 18 www.fujitsu.com
Speaker Assembly
Please note that the plastic front bezel has to be removed first.
Insert speaker into “rubber”
Install speaker+rubber in fronbezel
Speaker cable is led to mainboard via appropriate chassis aperture.
Re-assemble plastic front bezel carefully and install speaker connector to mainboard
Speaker Rubber
Speaker
speaker location

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 14 of 18 www.fujitsu.com
Installing USB Type C Extension Cable
Install the USB Type C bracket to the chassis rear cover.
Then connect the USB cable connector to the appropriate mainboard connector.
The USB cable should be bent slightly as required.

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 15 of 18 www.fujitsu.com
Step 6 Closing the Chassis
Slide the cover on top of the chassis pushing it forward.
Some pressure may be required.

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 16 of 18 www.fujitsu.com
Close the chassis rear cover using the screws included in the kit delivery.

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 17 of 18 www.fujitsu.com
Step 7 Adding Stands
The desk stands included in the chassis kit can be used either for horizontal or vertical use.
They can be fixed by plastic clips, in addition there are screws included for more secure stand assembly.
Insert the clips into the holes of the stands.

Assembly Instructions SMARTCASE S500
__________________________________________________________________________________________________________________________________________________________
Page 18 of 18 www.fujitsu.com
