C150-E146-02EN
M4097D Image Scanner
Operator's Guide

M4097D
Image Scanner
Operator's Guide

i
February, 2000 First edition
February Second edition
Revised contents
Specification No. C150-E146-02EN
Date publishedEdition
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equip-
ment.
NOTE
• The use of a non-shielded interface cable with the referenced device is prohibited.
The length of the parallel interface cable must be 3 meters (10 feet) or less. The
length of the serial interface cable must be 15 meters (50 feet) or less.
• The length of the power cord must be 3 meters (10 feet) or less.
01
02

ii
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conformme à la norme NMB-003 du
Canada.
As an ENERGYSTAR ® Partner, Fujitsu Limited has determined that this scanner
meets ENERGYSTAR® guidelines for energy efficiency. ENERGYSTAR® is a
U. S. registered mark.
The contents of this manual may be revised without prior notice.
All Rights Reserved, Copyright © 2000 FUJITSU LIMITED.
Printed in Japan.
No part of this manual may be reproduced in any form without permission.

iii
FUJITSU FRANCE S.A.
I, Place des Etats-Unis, SILIC 310, 94588
Rungis cedex, FRANCE
TEL:[phone]
FAX:[phone]
http://www.fujitsu-europe.com/home/
FUJITSU COMPUTERS (SINGAPORE) PTE,
LTD.
20 Science Park Road #03-01, Tele Teck
Park Singapore Science Park II, Singapore
117674 Republic of Singapore
TEL:[phone]
FAX:[phone]
http://www.fujitsu-computers.com.sg/
FUJITSU HONG KONG Limited
10/F, Lincoln House, Taikoo Place, 979
King’s Road, Island East, Hong Kong
TEL:[phone]
FAX:[phone]
TLX:62667
http://www.fujitsu.com.hk/
FUJITSU ITALIA S.p.A.
Via Nazario Sauro, 38 20099 Sestos,
Giovanni (MI), ITALY
TEL:[phone]
FAX:[phone]
http://www.fujitsu-europe.com/home/
FUJITSU NORDIC AB
Kung Hans väg,S-192 68 Sollentuna,
SWEDEN
TEL:[phone]
FAX:[phone]
http://www.fujitsu-europe.com/home/
FUJITSU LIMITED
International Operations
Marunouchi 1-6-1, Chiyoda-ku,Tokyo 100
JAPAN
TEL:[phone]
FAX:[phone]
TLX:J2283
Cable:”FUJITSU LIMITED TOKYO”
http://www.fujitsu.co.jp/
FUJITSU COMPUTER PRODUCTS OF
AMERICA,INC.
2904 Orchard Parkway,San Jose.
California 95134-2022,U.S.A.
TEL:[phone]
FAX:[phone]
http://www.fcpa.com/
FUJITSU AUSTRALIA LIMITED
Fujitsu Hause 2 Julius Avenue North Ryde N.S.W
2113 AUSTRALIA
TEL:[phone]
FAX:[phone]
http://www.fujitsu.com.au/
FUJITSU CANADA,INC.
2800 Matheson Blvd.East,Mississauga.
Ontario L4W 4X5,CANADA
TEL:[phone]
FAX:[phone]
http://www.fujitsu.ca/
FUJITSU DEUTSCHLAND GmbH.
Frankfurter Ring 211,
8000 München 40,F.R,GERMANY
TEL:[phone]
FAX:[phone]
http://www.fujitsu.de/
FUJITSU ESPAÑA,S.A
Edificio torre Europa 5a
Paseo de la Castellana 95 Madrid 28046,SPAIN
TEL:[phone]
FAX:[phone]
http://www.fujitsu-europe.com/home/
FUJITSU EUROPE LTD.
2,Longwalk Road,Stockey Park,Uxbridge
Middlesex,UB11 1AB,U.K
TEL:[phone]
FAX:[phone]
http://www.fujitsu-europe.com/home/
Please send your comments on this manual or on Fujitsu products
to the following addresses:

iv
IMPORTANT NOTE TO USERS
READ ALL OF THIS MANUAL CAREFULLY BEFORE USING THIS PRODUCT.
IF NOT USED CORRECTLY, UNEXPECTED INJURY MAY BE CAUSED TO
USERS OR BYSTANDERS.
While all efforts have been made to ensure the accuracy of all information in this
manual, FUJITSU assumes no liability to any party for any damage caused by
errors or omissions or by statements of any kind in this manual, its updates or
supplements, whether such errors are omissions or statements resulting from
negligence, accidents, or any other cause. FUJITSU further assumes no liability
arising from the application or use of any product or system described herein; nor
any liability for incidental or consequential damages arising from the use of this
manual. FUJITSU disclaims all warranties regarding the information contained
herein, whether expressed, implied, or statutory.
FUJITSU reserves the right to make changes to any products herein, to improve
reliability, function, or design, without further notice and without obligation.

v
Preface
This manual explains how to use the M4097D image scanner.
This manual contains chapters on the following topics:
COMPONENTS
INSTALLATION AND CONNECTIONS
OPERATING INSTRUCTIONS
ADF DOCUMENT SPECIFICATIONS
SCANNER SPECFICATIONS
SETUP MODE
It also contains a Glossary of Terms and an Index.
Refer to Cleaning and Maintenance Guide for information about the routine
operation of the M4097D.
The Reference Guide contains chapters on OPERATING INSTRUCTIONS,
CLEANING, REPLACEMENT OF PARTS, ADJUSTMENT and TROUBLE-
SHOOTING.
The M4097D is a very fast and highly functional image scanner developed
for volume filing, using charge-coupled device (CCD) image sensors. This
scanner features duplex scanning and high quality image processing with an
automatic document feeder (ADF).

vi
Important information that requires special attention is indicated as follows:
WARNING
WARNING indicates that personal injury may result if you do not follow a
procedure correctly.
CAUTION
CAUTION indicates that damage to the scanner may result if you do not follow a
procedure correctly.
Indicates care required to avoid pinching of fingers or hands.
NOTICE/NOTE
A NOTICE provides “how-to” tips or suggestions to help you perform a procedure
correctly.
A NOTE is particulaly useful for first-time users.
Official Fujitsu part names are indicated with an initial capital letter, as in the part
name, “Pick roller.”
Conventions

vii
CONTENTS
vii
❑
CHAPTER 1 COMPONENTS
Checking the Components ........................................................ 1-1
Units and Assemblies ............................................................... 1-2
Operator Panel.......................................................................... 1-5
❑
CHAPTER 2 INSTALLATION AND CONNECTIONS
Precautions ............................................................................... 2-1
Inspection.................................................................................. 2-2
Repositioning the Shipping Lock ............................................... 2-4
Cable Connections .................................................................... 2-5
Mounting the Stacker ................................................................ 2-7
Setting the SCSI ID and the SCSI Terminator .......................... 2-8
❑
CHAPTER 3 OPERATING INSTRUCTION
Turning the Power On ............................................................... 3-1
Waking up the Scanner from the Low Power Mode .................. 3-2
Manual Feed Mode Setting ....................................................... 3-3
Loading Documents on the ADF ............................................... 3-4
Loading Documents on the Flatbed .......................................... 3-9
Loading Documents Larger than the Document Bed .............. 3-10
Reading a Page from a Thick Book ........................................ 3-11
❑
CHAPTER 4 ADF DOCUMENT SPECIFICATION
Document Size.......................................................................... 4-1
Document Quality ..................................................................... 4-2
ADF Document Feeder Capacity .............................................. 4-4
Areas not to be Perforated ........................................................ 4-5
Grounding Color Areas ............................................................. 4-6
Double Feed Detection Condition ............................................. 4-7
Job Separation Sheet ............................................................... 4-8
❑
CHAPTER 5 SCANNER SPECIFICATIONS
Basic Product Specification....................................................... 5-1
Installation Specification............................................................ 5-2
Dimensions ............................................................................... 5-3

viii
❑
CHAPTER 6 CONSUMABLES AND OPTIONS
Consumables ............................................................................ 6-1
Options...................................................................................... 6-2
Video Interface Option .............................................................. 6-3
IPC-4D Option........................................................................... 6-8
❑
CHAPTER 7 SETUP MODE
Activating the Setup Mode ........................................................ 7-1
Contents of the Setup Mode ..................................................... 7-2
❑
GLOSSARY OF TEAMS ............................................................................... GL-1
❑
INDEX.............................................................................................................. IN-1
❑
Declaration of Conformity
viii

ix
COMPONENTS
INSTALLATION AND
CONNECTIONS
OPERATING
INSTRUCTION
DOCUMENT
SPECIFICATION
ix
COMPONENTS
INSTALLATION AND CONNECTIONS
OPERATING INSTRUCTION
DOCUMENT SPECIFICATION
SCANNER SPECIFICATIONS
CONSUMABLES AND OPTIONS
SETUP MODE
GLOSSARY OF TERMS
INDEX
GLOSSARY
OF TERMS
SPECIFICATIONS
SETUP MODE
INDEX
CONSUMABLES AND
OPTIONS

COMPONENTS
This chapter describes the components of the scanner, part names,
operator panel arrangement, and the function of parts and LED
indicators. After unpacking the scanner, confirm that all compo-
nents have been received by checking them against the list in the
first section.
Checking the Components
Units and Assemblies
Operator Panel
CHAPTER
1

1-1
1
Checking the Components
These high precision components must be handled carefuly.
Confirm that all the components shown in the following figure have been received.
If any component are missing, please contact your sales agent.
Power cable
for North America Power cable
for Europe
Scanner
Pad ASY
Manuals
and Driver

1-2
Units and Assemblies
This section shows exterior view and assemblies of the scanner. This section also provides the name
of each part and describes its functions.
Units
M4097D
eDocument
holding pad
wDocument bed
qDocument cover
rAutomatic document
feeder(ADF)
uOperator panel
tStacker
oADF lever
!2Third party slot
iADF paper chute
yPower switch
!0Power inlet
!1Interface connectors
NOTE
The shipping lock must be switched to the operating position before the scanner can be used. Refer to
page 2-4.

1-3
No. Function
1 Document cover Closes over and keeps in place document to be read.
2 Document bed Holds document to be read. Also called the Flatbed (FB).
3 Document holding pad Presses a document to the Document bed.
4 Automatic document feeder (ADF) Automatically feeds documents to the reading position.
5 Stacker Stacks the read documents.
6 Power switch Turns the power on or off.
7 Operator panel Contains indicator panel that indicates scanner status.
8 ADF paper chute Holds documents to be fed by the automatic document
feeder (ADF).
9 ADF lever Opens or closes ADF to enable removal of documents
jammed in the feeder.
10 Power inlet Connects to an AC power outlet with the power cable.
11 Interface connectors Connects to the host system with interface cables.
12 Third party slot A Fujitsu Video Interface Option Board is installed.

1-4
Assemblies
Thumb screw
Guide A ASY
Pick roller 2
Pick roller 1
Stacker
Pad ASY

1-5
Arrangement
The operator panel is located on the upper right hand side of the scanner. The panel consists of an
LCD display (16 character x 2 line), LEDs and buttons.
Operator Panel
Operator panel
Exit
Enter
Stop
Previous
Next
Send To/
Start Read
Check

1-6
Button/LED Function
Name of the button Function
and LED
Button Next Displays the next screen.
Previous Displays the previous screen.
Moves cursor to the left.
Moves cursor to the right.
Exit • When you are entering settings on the operator panel, pressing this button
immediately returns you to the “Scanner Ready” screen.
Enter Records parameter currently selected by cursor.
Send To/ Operational only when Manual start mode is set or “Read” lamp lights;
Start starts the reading when video interface option is used. Some of application
Softwares Use this button.
Stop • When “Check” LED lights, pressing this button releases error status (turn
off “Check” and returns to “Scanner Ready” screen).
Operational only during reading operation; stops the reading when video
interface option is used.
Also turns off “Check” lamp.
LED Indicates that the scanner is ON.
Read Indicates that the scanner is reading or ready to read.
Check • If it lights, means that an alarm occurred. Pressing “Stop” button turns
“Check” lamp off.
• If it blinks at one second intervals, means that a jam or double feed has
been detected. With jammed paper, removing the jammed paper turns off
“Check” lamp. With a double feed, pressing “Stop” button turns off “Check”
lamp.
• If blinks at four seconds intervals, means that cleaning the ADF is
necessary.

1-7
Counter Display
The scanner is provided with the counter display.
Paper counter
Abrasion counter
Function
The paper counter counts the number of scanned sheets from
the start of reading until Paper Empty or an error is detected.
The counter is automatically reset at the start of reading. The
counter is used for checking the number of sheets to be
scanned at one butch.
Counter
Paper counter
Abrasion counter
NOTE
When the counter value is 0, no number is displayed.
When the
button is pressed
When the
button is pressed
The counter increments each time a document is scanned. The
counter is not initialized, until the power is turned off. The
counter can be used, for example, for checking the number of
sheets that have been scanned in one day.
Abrasion counter counts the accumulated number of the scanned sheet. This
counter increments at every 10 sheets. This counter is useful to check the cleaning
cycle or parts replacement cycle. How to reset is described in Chapter 6.

1-8
Operation status
Operation status is indicated by the following message:
<Power-on>
<Reading>
<Waiting for Start> Scanner displays followig screen when waiting Start button pressed.
(Only When Video Interface
Option is installed.)
<Cleanig request> When the Pick roller cleaning is necessary, the scanner displays as
follows on the upper line.
When the ADF glass cleaning is necessary, the scanner displays as
follows on the LCD.
Clean the Pick roller or ADF glass in accordance with the manual,
“Cleaning and Maintenance”.
