Fulham HOTSPOT FHSCP-UNV-12W-L-SD User manual

P20
3350mAh
Emergency LED Driver
General Specifications
Universal Voltage: 120-277V~
Output Voltage Range: 12-55V
Output Current: 0.2-1A
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 1 of 8
2023-953 Rev B
Output Wattage: 12W
Test Switch: Bi-Color Indicator Light

6.5W
Input Power
Current Rated
Output Power
Output Voltage Range
1A Max
Input Current
12W
Output Short Protection
Output Open Protection
Input Voltage / Frequency 120-277V~ , 50/60Hz
0.12A
1 Channel
Emergency Mode Protections
Line-Neutral 1kV, Line & Neutral-Ground 2kV
Input Surge Protection
Standby Power 0.85W
Output Class
Number of Output Channels
RFI/EMI
Ambient Operating Temperature Range
Sound Rating
Service Life
IP Rating
Battery Type Ternary lithium battery
10.8V
335mA ±8%
FCC Part 15 ClassA
0°C To 55 °C( 32 °F To 131 °F)
LED Class2
50,000 hours
A
Warranty 5 years
Battery Voltage
Battery Capacity
Battery Charge Current
Battery Recharge Time
Battery Discharge Time Min 90 Minutes
24 Hours
20
IP
Safety Standards UL 924/UL 1310/CSA C22.2 No.141
Test Switch Remote Mounting Distance
Battery ON/OFF Wire + Connector
65.6' (20m) Max.
I
Battery Over Voltage Protection
Battery Under Voltage Protection
Battery Hot Plug at Normal Mode Protection
Battery Hot Plug at Emergency Mode Protection
12-55V
Indicator Light Bi Color
2A Max
Input Power Pass-Through Rating (White/Black Lead)
FHSCP-UNV-12W-L-SD
Suitable for use in dry and damp locations

E477042

Mechanical Data
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 2 of 8
2023-953 Rev B
FHSCP-UNV-12W-L-SD
Length
Width
Overall Dimensions
12.48"
(317mm)
1.689"
(42.9mm)
1.079"
(27.4mm)
Height
12.067"
(306.5mm)
Mounting
E477042
1.063"
[27mm]
1.689"
[42.9mm]
R0.118"
[3mm]
12.067"
11.61"
[306.5mm]
[295mm]
12.48"
[317mm]
18±0.5"24±0.5"
9.25±0.5"
12±0.5"
[457±12.7mm][610±12.7mm]
[235±12.7mm]
[305±12.7mm]
1.079"
[27.4mm]

Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 3 of 8
2023-953 Rev B
FHSCP-UNV-12W-L-SD
Wall Plate: FHSWLPWH
70.5
(2.78”)
115.5
(4.55”)
Ø12.7
(0.50”)
84
(3.31”)
1.“Charge push to Test”plate
2. (2) 6-32 x ½”LG mounting screws
Wall plate and screw color:
white with black lettering
Accessories
Test switch wire
Red
Black
transparent 28±0.2''[ mm]
0.40±0.12''[ mm]
0.33''[8.3mm]
0.79±0.12''[20±3mm]
mm
0.61''
E477042

Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 4 of 8
2023-953 Rev B
Wiring Diagram (Emergency Only)
WHT(N)
BLK/Red(L)
BLACK
DRIVER MUST
BE GROUNDED
BLUE
LED DRIVER
RED (From LED driver)
WALL
SWITCH
HOT( 120V ~ 277V)
WHT/BLK(N-OUT)
LED ARRAY
BLU/WHT
RED/WHT
BLK/Red(L)
WHT(N)
HOT( 120V ~ 277V)
WHT/BLK(N-OUT)
LED ARRAY
BLU/WHT
RED/WHT
WHITE
Wiring Diagram
FHSCP-UNV-12W-L-SD
test switch
BATTERY
CONNECTOR
test switch
BATTERY
CONNECTOR
FHSCP-UNV-12W-L-SD
FHSCP-UNV-12W-L-SD
PRELIMINARY
E477042
RED(From LE D driver)
DRIVER MUST
BE GROUNDED

Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 5 of 8
2023-953 Rev B
Test Switch Indicator Status:
Test Switch Operations:
FHSCP-UNV-12W-L-SD
EM Test: Press and hold test button (1s) to enter EM mode for testing in normal AC powered.
E477042
LED Indicators Status EM Driver Status/Mode
●Solid Green
●
●
Flashing (0.1s on/3s off)
●
●
Flashing (1s on/1s off)
Flashing (4s on/1s off)
Flashing (1s on/1s off) Battery PACK fault. (Including Self-test/self-diagnostic)
System OK/AC OK.
Normal working in EM mode.(Including Self-test/self-diagnostic)
Self-diagnose process ongoing.
Battery PACK not found.(Including Self-test/self-diagnostic)
●Over voltage protection. (Including Self-test/self-diagnostic)
●Over current protection.(Including Self-test/self-diagnostic)
●Over temperature protection.(Including Self-test/self-diagnostic)
●Self-diagnose process current fault..
Solid Red
Solid Red
Flashing (1s on/7s off)
Flashing (0.1s on/3s off)
Long press (10s) exit emergency mode.

Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 6 of 8
2023-953 Rev B
Important Safety Instructions
CAUTION: Do not let power supply cords touch hot surfaces.
CAUTION: Do not use outdoors.
CAUTION: Do not mount near gas or electric heaters.
CAUTION: This equipment has not been investigated for use in an air-handling fixture, it is not suitable
Do not use this emergency driver with accessory equipment other than recommended by manufacturer;
failure to follow this may cause an unsafe condition. Servicing should only be performed by qualified service
personnel.
Important: An un-switched AC power source of 120VAC to 277VAC is required.
When using electrical equipment and this lighting device basic safety precaution should
be followed at all times including but not limited to the following:
PLEASE READ CAREFULLY AND FOLLOW ALL INSTRUCTIONS FOR YOUR OWN SAFETY
Do not use this emergency driver for other than intended use.
Equipment should be mounted in locations and at heights where it will not readily be subjected to
tampering by unauthorized personnel.
Important: Indicator (LED light) illuminated indicates battery in charge mode when AC power is applied.
It is recommended and required by applicable code to test emergency function to ensure proper operation of
the system; push the test switch for sixty (60) seconds every 30 days to ensure the emergency driver is
functioning as by illuminating the LED light source. Conduct a ninety minute (90) discharge test one time (1) per year;
LED light source should be illuminated for a minimum of ninety minutes (90).
ASSEMBLY and FIELD INSTALLATION WIRING: WARNING: AC power must be off before proceeding
with assembly or installation of emergency driver.
TESTING SYSTEM: The emergency battery requires a charge minimum of one (1) hour before testing the
circuit. A full charge requires Twenty-four (24) hours.
Important: Double insulation used between the supply and battery circuit.
Important: Intermittent re-charging circuit.
Important: The recharging device remains safe after abnormal operating condition.
SAVE THESE INSTRUCTIONS
Manufacturer:
North China
Fulham Electronic Co. Ltd.
No. 9 heyingRoad, Nanshao Zhen Changping Science and technology Park, Beijing, P.R. China
Fulham Head Quarters:
Fulham Co., Inc
12705 South Van NessAve.
Hawthorne, CA90250
FHSCP-UNV-12W-L-SD
IMPORTANT: In order to maintain proper operation and warranty coverage, the battery must be recharged once per
year prior to installation.
CAUTION:Device has to be checked and re-activated to keep emergency function after installation.
in a heated air outlet.
De-energize before opening.
CAUTION: Sealed unit. Battery not replaceable. Replace entire unit when necessary.
Use with grounded, UL Listed, dry or damp location rated fixtures.
E477042
WARNING: Install in accordance with the national and local electrical code. Disconnect power before servicing. Driver must
be grounded.
ATTENTION: L'installation doit être conforme aux normes du code national électrique. Débranchez l'alimentation avant
l'entretien. Pilote doivent être mis à la terre.

Guidelines
LED load
Mounting / Cooling
Fulham Hotspot Plus LED drivers are designed to drive passive LEDs, -COB's and -LED assemblies Proper function is not
guaranteed when (LED) loads with active components are used.
•
Above an output power of 12W, the driver needs to be mounted on a heat conductive surface of at least 40cm². Always
test if the surface is sufficient enough before installing the driver.
•
Short-circuit protection
In case of a short circuit the LED driver switches to protection mode. After the removal of the short-circuit the LED driver
will Latch ,need restart AC Power.
•
Driver must be grounded by means of the Driver case.
Grounding
•
No-load Operation
In no-load operation the output voltage will not exceed the specified open circuit output voltage.
•
Battery Maintenance
In order to maintain proper operation and warranty coverage, the battery must be recharged once per year prior to installation.
•
Warranty
Reference Fulham's limited Warranty: https://cdn.fulham.com/PDFs/Limited-Warranty.pdf
•
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 7 of 8
2023-953 Rev B
FHSCP-UNV-12W-L-SD
Hot Swapping
This driver does not support hot swapping of the LEDs
•
E477042

Part Number Matrix
Product Image: LED Driver
FHSCP-UNV-12W-L-SD
Packaging
Master Carton
Fulham Co. Inc.: 12705 South Van Ness Ave., Hawthorne, CA 90250 Tel.: [phone] Fax.: [phone].
Specifications subject to change without notice.
[email protected] www.fulham.com
Page 8 of 8
2023-953 Rev B
FHSCP-UNV-12W-L-SD
FHS
FHS = FireHorse HotSpot Driver
LED Driver
CP
CP = Constant Power
Driver Type
UNV
UNV = 120V-277V
Input Voltage
12W
12W = 12 Watts
Power
L
L = Long Case
Case Type
SD
SD = Self Diagnostic
Special Features
L W H
15.5”(394mm)
OUTER DIMENSION
10.79”(274mm) 8.39”(213mm)
QUANTITY
Gross
Weight
20.1lbs.
(9.1kg) 15pcs.
Net
Weight
17.9lbs.
(8.1kg.)
E477042
