Funkwerk AUDIO 2010 User manual

Handsfree System
156 8010 1.01
Operating Manual

-2-
Audio 2010
Funkwerk Dabendorf GmbH
Maerkische Straße
D - 15806 Dabendorf
Phone: [phone] - 0
Fax: [phone] - 300
[email protected]
www.fwd-online.de
Rights to changes and deviations from the scope of delivery reserved as required by technical pro-
gress! All rights reserved! Copies, also excerpt-related, only with written approval!

-3-
Table of contents
Audio 2010
Table of contents
Notes on safety ................................................................................ 4
Functions of the Audio 2010 ........................................................... 5
Functional overview ........................................................................... 5
Symbols ............................................................................................ 6
Key functions ..................................................................................... 6
Symbole der Statusleiste ................................................................... 8
Speller symbols .................................................................................. 8
Menu item symbols ........................................................................... 8
Speller ................................................................................................ 9
Operational startup .......................................................................... 9
Bluetooth®technology ..................................................................... 10
Switching on / Switching off ............................................................ 10
Entering PIN Bluetooth®.................................................................. 10
Handsfree mode (handsfree profile) ................................................ 11
Automatic connecting ...................................................................... 11
Calling ............................................................................................... 11
The menus ....................................................................................... 13
Voice control .................................................................................. 24
Language .......................................................................................... 24
Activation and sequence .................................................................. 25
Service ............................................................................................. 28
FAQ - Frequently Asked Questions .............................................. 29
Software updating ......................................................................... 31
Hotline ............................................................................................. 31

-4-
Audio 2010
Notes on safety
Notes on safety
IMPAIRMENT OF TRAFFIC SAFETY!
Inattention can lead to dangerous traffic situations. Also in the
handsfree mode, you must always pay attention to the traffic situa-
tion. The telephone may be used by the driver during driving in
handsfree mode only! Dispense with a telephone call in difficult
situations, as appropriate!
NOTE:
Dependent on the software, it can be that individual functions are
not yet available! Please note the information about this at
www.fwd-online.de.

-5-
Functions of the Audio 2010
Audio 2010
Functions of the Audio 2010
Functional overview
•Call functions ➯Incoming call
➯Outgoing call
➯Automatic redialing
•Status indicator ➯Rechargeable battery status of the mobile telephone
➯Network status indicator
➯New SMS
➯Call in absence
➯User icon with initials
➯Multipoint / single connection
•Integrated voice control ➯Call in absence
•Recorded announcement ➯Connection confirmation by voice
➯Name announcement of the incoming
caller
•SMS ➯Reading and answering of SMS messages
•Takeover of the call lists and the telephone directory of the mobile telephone
•Multipoint technology ➯2 mobile telephones are simultaneously
connected with the Audio 2010
•Registration of up to 10 mobile telephones
•Reproduction of music files of the mobile telephone via
Bluetooth®audio-streaming (A2DP)
•iPodTM Player*
* Requires accessories

-6-
Audio 2010
Symbols
Symbols
The actuator of the Audio 2010 is provided with an OLED display and a total of 8
keys. The display shows a short overview of the existing keys. The functions of
the individual keys are explained in this section.
Key functions
➔ Die -key (green) serves for call acceptance.
A further function is the selection of menu items. During the play-
back of music, the key takes over the function of „Play“ and
„Pause“.
Brief description : Accepting, selection of menu items,
termination of the screen saver
➔ The -key (red) can reject an incoming call and end an ongoing
call. During the playback of music, the title can be stopped with the
-key.
Furthermore, the system can be switched off by short pressing.
Brief description : Hang up, reject, stop, termination of the
screen saver, activate voice dialing of
the telephone
-Key
-Key
-Key
-Key
-Key (red)
-Key (green)
-Key
-Key (Buzzer)
(green)
(red)

-7-
Symbols
Audio 2010
➔ During the music playback, a skip to the next title can be made with .
Furthermore, navigation through the menu and the Speller can be
implemented with this key (explanation Pg. 9.
Brief description: Title skip forward, navigation through menu and
Speller, termination of the screen saver
➔ The -key serves to skip to the previous title during the music
playback. Furthermore, navigation through the menu and the Speller
can be implemented with this key.
Brief description : Title skip backward, navigation through menu
and Speller, termination of the screen saver
➔ With the -key the volume is increased during a telephone call, with
voice control and during music playback. In addition, navigation
through the menu and the Speller can be implemented with this key.
Brief description : Volume increase, navigation through menu and
Speller, termination of the screen saver
➔ With the -key the volume is reduced during a telephone call, with
voice control and during music playback. In addition, navigation
through the menu and the Speller can be implemented with this key.
Brief description : Volume reduction, navigation through menu
and Speller, termination of the screen saver
➔ The voice control of the Audio 2010 is activated by short pressing of
the voice command key (buzzer). For possible speech commands,
refer to Chapter „Voice control“ (see Page 24).
The mobile telephone's own voice control is activated by long pressing
of the voice command key
.
NOTE:
The Audio 2010 is provided with a screen saver. After 60 seconds inac-
tivity, the display switches itself off automatically. With any arbitrary
key press, the display can be turned on again. This key press does not
implement any function, rather it switches the display, however this
does not apply for the - key (buzzer) which remains permanently
active.

-8-
Audio 2010
Symbols
Symbols of the status bar
Field strength symbol - Display of the
current reception field strength of the
mobile telephone
SMS symbol - Display for received
SMS
Arrow symbol - Display for call in
absence
Display of the initials of the user
Battery symbol - Mobile telephone is charged
Battery symbol - Display of the storage battery capacity of the
mobile telephone
Display of the initials of the user, as well as display that a
„Multipoint“ connection exists
Speller symbols
Symbol for confirming the input
Symbol for deletion of the last character
Symbol for change to the number input
Symbol for change to the input of lower case letters
Symbol for change to the input of upper case letters
Symbol for change to the input of additional characters
Symbol, to exit the voice command key
Menu item symbols
Activated option: This symbol appears before a menu item if it is
activated as an option.
Deactivated option: This symbol appears before a menu item if it
can be activated as an option.

-9-
Operational startup
Audio 2010
Speller
The Speller is controlled with the -, -
keys. The -key (green) or the -key is
used for confirming the selection, and the
-key (red) in order to end the Speller.
The Speller enables the compiling of individual alphabetic characters or numbers,
as well as telephone numbers or names. It is available for various functions of
the Audio 2010, for example for the dialing of a telephone number or the gene-
ration of a telephone directory entry. The operation of the Speller is explained
below:
➔ Entering numbers
Navigate to a digit by activating the -, -keys and accept this through
pressing the -key (green). You can delete the last digit of the number in
each case through pressing the - symbol. If the number is entered com-
pletely, this can be selected through pressing the - symbol. In order to
exit the Speller, press the -key (red).
➔ Entering name or text
Analogous to the number input, you can also enter names or whole texts
with the Speller. Navigate to a character by activating the -, -keys and
accept through pressing the - key (green). You can delete the last
character in each case through pressing the - symbol. If the name is
entered completely, this can be saved through pressing the - symbol. In
order to exit the Speller, press the -key (red). A switchover between
upper case letters, lower case letters, digits and additional characters is
possible using the symbols described under Chapter „Speller symbol“,
which can be selected with the -, - keys.
Operational startup
Take time to become familiar with the operation of the Audio 2010 in connection
with the mobile telephone. First of all, make some telephone calls where you can
determine the optimal conditions for volume and speech direction before you
use the Audio 2010 in traffic. For operational startup, the vehicle should be par-
ked in a quiet place. A prior arrangement with another call subscriber who can
take some time is advantageous in supporting you in making test connections.

-10-
Audio 2010
Operational startup
Bluetooth®technology
Bluetooth
®
technology is a radio technology and thus it makes possible commu-
nication without cables. Data and voice can be transmitted simultaneously. No
line of sight connection between the participating devices has to exist for this
purpose. The radio range is 10 m. Faults through other electrical devices or
obstacles in the free field can lead to a lower range. The frequency band in which
Bluetooth
®
works is released almost worldwide. That, and the fact that every
Bluetooth
®
product is tested and qualified for trouble-free cooperation with other
Bluetooth
®
devices, ensures maximum compatibility of devices from different
manufacturers. The Audio 2010 supports the Bluetooth
®
hands-free profile. This
means that you can operate mobile telephones which support the Bluetooth
®
hands-free profile. As appropriate, look up in the operating instructions of your
mobile telephone which profile it supports. A2DP (Advanced Audio Distribution
Profile) is a technology which allows the transmission of stereo audio signals wit-
hout wires via Bluetooth
®
to a corresponding receiver. Please refer to our Inter-
net homepage to find out about compatible mobile telephones.
Switching on / Switching off
With the first operational startup of your Audio 2010, you must start the Audio
2010 through switching on the ignition. You will see the start logo and the main
screen is displayed. If no connection to the mobile telephone exists, or if no user
is found, the main menu has limited functionality. In order to establish a connec-
tion to the Audio 2010, you must select the menu item „User administration“
with the - key (green). A „New user“ is selected there. The Audio 2010 then
searches for mobile telephones in your reception area. If your mobile telephone
should not be found, you can start the search again. As appropriate, please refer
to the section „Problem elimination“. If the name of your mobile telephone is
displayed, select it with the -key (green). After the connection with the
Audio 2010, the full functionality of the main menu is provided. Functionalities
which the mobile telephone does not support are not optional. If the ignition is
switched off, the Audio 2010 switches itself off. If the ignition is switched off
during a telephone call, this telephone call is maintained and continues. The
Audio 2010 is then switched off only on ending the telephone call with hanging
up.
Entering PIN Bluetooth®
After some seconds, you are requested to enter the Bluetooth
®
PIN. Enter in the
mobile telephone the PIN which is indicated on the display of the Audio 2010.
