Funkwerk EGO FLASH User manual

129 8001 1.04
US
English
Operating Manual

EGO FLASH
Funkwerk Dabendorf reserves the right to modifi cations in the course of technological progress and deviations from the delivery
scope! All rights reserved! Reproduction, in whole or in part, is only permitted with the prior written consent of Funkwerk
Dabendorf GmbH!

1Inhaltsverzeichnis
2 List of illustrations ........................................................................................................ 6
3 Introduction / foreword ................................................................................................. 7
4 Safety notes................................................................................................................... 8
5 Scope of delivery / package content.............................................................................. 9
6 Installation guide........................................................................................................... 10
6.1 Determination of required configuration .....................................................................................................10
6.1.1 Vehicle ................................................................................................................................................................................ 10
6.1.2 Mobile Telephone ............................................................................................................................................................... 10
6.1.3 Muting (radio muting) ........................................................................................................................................................ 10
6.1.4 Converting the EGO FLASH into an already-installed Funkwerk hands-free car kit .................................................... 10
6.1.5 Add-on speakers / Car audio telephone connection........................................................................................................ 10
6.1.6 Car audio line-in input ....................................................................................................................................................... 11
6.2 Verbauorte ....................................................................................................................................................11
6.2.1 Checking cable lengths ..................................................................................................................................................... 11
6.2.2 Selection of the installation location for the electronics box.......................................................................................... 11
6.2.3 Selection of the point of installation for the microphone ................................................................................................ 12
6.2.4 Selection of site for installing the control unit with integrated display .......................................................................... 12
6.3 Installation....................................................................................................................................................13
6.3.1 Mounting the electronics box ............................................................................................................................................ 13
6.3.2 Mounting the microphone.................................................................................................................................................. 13
6.3.3 Mounting the control unit with integrated display ........................................................................................................... 14
6.4 Connection scheme ......................................................................................................................................14
6.5 Installation of the ISO connecting cable ......................................................................................................15
6.5.1 Checking the mute inputs.................................................................................................................................................. 16
6.5.2 Checking the installation................................................................................................................................................... 17
6.5.3 Additional external speakers ............................................................................................................................................ 17
2 |3

6.6 Connecting the components to the electronics box.....................................................................................18
6.7. Connection of the EGO iDapter to the electronics box.................................................................................20
7 Operating instructions................................................................................................... 21
7.1 Features........................................................................................................................................................21
7.1.1 Overview of features.......................................................................................................................................................... 21
7.2 Symbols ........................................................................................................................................................22
7.2.1 Key functions...................................................................................................................................................................... 22
7.2.2 Symbols in the status bar.................................................................................................................................................. 23
7.2.3 Speller symbols ................................................................................................................................................................. 23
7.2.4 Symbols for menu options................................................................................................................................................. 24
7.3 Speller ..........................................................................................................................................................24
7.4 Getting started..............................................................................................................................................25
7.4.1 About Bluetooth®technology ............................................................................................................................................ 25
7.4.2 On / Off function................................................................................................................................................................. 25
7.4.3 Enter Bluetooth®PIN......................................................................................................................................................... 25
7.4.4 Hands-free mode ............................................................................................................................................................... 26
7.4.5 Automatic coupling ............................................................................................................................................................ 26
7.4 .6 Call...................................................................................................................................................................................... 26
7.5 The menus ....................................................................................................................................................28
7.5.1 User management ............................................................................................................................................................. 31
7.5.2 Settings............................................................................................................................................................................... 32
7.5.3 iPodTM Player ...................................................................................................................................................................... 34
7.5.4 Music player ....................................................................................................................................................................... 35
7.5.5 Contacts list ....................................................................................................................................................................... 36
7.5.6 Call lists ............................................................................................................................................................................. 36
7.5.7 Messages ........................................................................................................................................................................... 37
7.6 Voice control .................................................................................................................................................37
EGO FLASH

8 Software update ............................................................................................................ 40
9 Service .......................................................................................................................... 41
10 Spares parts and accessories ....................................................................................... 44
11 Technical data ............................................................................................................... 47
12 Certification................................................................................................................... 47
13 Conformity statement ................................................................................................... 48
14 Hotline........................................................................................................................... 50
4 |5

List of illustrations
Fig. 01 Scope of Delivery ............................................................................................................ 9
Fig. 02 Signal transmission of the Bluetooth®antenna ............................................................. 11
Fig. 03 Installation locations for the electronics box ................................................................ 12
Fig. 04 Installation location for microphone .............................................................................. 12
Fig. 05 Electronics box dimensions ........................................................................................... 13
Fig. 06 Connection for the mini ISO connection cable ............................................................... 14
Fig. 07 Installation procedure .................................................................................................... 15
Fig. 08 Type-dependent pin allocation ....................................................................................... 16
Fig. 09 Plug wiring scheme ........................................................................................................ 16
Fig. 10 Connection system ......................................................................................................... 16
Fig. 11 a/b View after changing cables ............................................................................................ 17
Fig. 12 Additional external loudspeakers .................................................................................. 18
Fig. 13 Electronics box connection ............................................................................................ 19
Fig. 13a Connection of EGO iDapter ............................................................................................. 20
Fig. 14 Status bar ....................................................................................................................... 23
2
EGO FLASH

Introduction / foreword
Congratulations on your new EGO!
Whether you’re browsing through your contacts list, reading SMS messages or selecting music for playback – EGO FLASH is a
practical all-rounder with a razor-sharp OLED display and intuitive controls. Its handy size and sleek design make it a must-have
accessory for your car.
The installation of your EGO FLASH in your car requires specialized knowledge and skills. We therefore recommend that the in-
stallation be performed by a qualified professional.
Before installation in your car, please make sure that your mobile phone is fully compatible with EGO FLASH. If you are uncertain,
please consult your dealer or a qualified workshop. Our service team will also be happy to help you with any information you may
require. Further information on compatibility between EGO FLASH and various mobile phones can be found on our website.
3
6 |7

Safety notes
1. Incorrect installation – Incorrect installation may lead to damage to the units and/or your car! Specialized knowledge
and skills are required for installing the system. We strongly recommend that the system be installed by a qualified
professional.
2. Risk of injury – Unsuitable installation locations may become a source of injury in an accident situation, or may inhibit the
correct functioning of essential safety equipment. Please carefully read the notes in the „Installation“ chapter carefully!
3. Risk of injury/material damage – the removal of vehicle lining with sharp or pointed objects may lead to injuries or
material damage.
4. Road safety risk – Diverted attention can lead to dangerous situations in traffic. Even when using hands-free phone
systems, your complete attention must be paid to the current traffic conditions. It is always advisable to avoid
phone calls while driving in difficult traffic situations!
5. Damage to airbags – An incorrect installation location may cause damage to, or inhibit the correct function of, your
airbags. Do not install the components within the deployment area of the airbags!
6. Insulation damage – Damaged insulation can lead to equipment and wiring damage. The cables and leads may not be
under tension when installed. Install the cables and leads in such a way as to avoid pinching or abrasion.
7. Polarity and shorting damage – Cables connected with reversed polarity, or in such a way as to produce a short
circuit, can lead to serious damage to your equipment. Before commencing installation, make sure that the car
battery is disconnected.
8. Damage to essential vehicle components – Essential vehicle components or wiring can be damaged when drilling
mounting holes or screwing in self-threading screws. Please make sure there is always sufficient space behind the
screw holes and drilled holes!
9. Interference with on-board electronics – Despite the extreme protection against interference, incorrect installation can
lead to interference with the vehicle electronic systems. Please read the vehicle manufacturer’s notes to this effect!
10. Appropriate use – The EGO FLASH is intended exclusively for use in vehicles with Bluetooth®mobile phones and A2DP
devices.
11. Damage caused by inappropriate replacement parts – Inappropriate spare or replacement parts may lead to
malfunctions. Please use only the approved parts listed in the section „Spares parts and accessories“!
12. Road safety risk – For your own safety, never initiate the coupling procedure while your vehicle is in motion!
4
EGO FLASH

Scope of delivery / package content
[1] Electronics box
[2] Control unit with integrated OLED display
[3] Microphone
[4] ISO-cable for connection to the car electrical system
[5] Self-adhesive pad
[6] Quick Guide
[7] Safety manual
PLEASE MAKE SURE THE CONTENT OF THE PACKAGE is complete. If any parts are missing, please don‘t hesitate to contact our
service hotline team: (+1) 858.566.2170, Mon – Fri, 8 AM to 5 PM (PST)
5

[1]
[2] [3]
[6]
[7]
[4]
Fig. 01:
Scope of Delivery
[5]
Safety Instructions
1. Improper installation – Improper installation may cause damages to the unit or to the vehicle! einstallation of the hands-free car kit requires spezial knowledge and special
abilities. We therefore strongly recommend to havethe installation one bya professional.
2. Pe rso nal i njury – Inappropriate places for the installationmay cause personal injuriesin accidents or may disablethe safety equipment. Note the directions in the chapter
“Installation”!
3. Pe rso nal i njury / Material damage – Whenyou remove coverings or armature parts, sharp toolsmay cause personal injuriesor material damage. Removethe parts carefully.
Don’t submit the connecting cables to pressure.
4. Neg ative eects on road safety – Talking whilst driving reduces your concentration.is may cause dangerous situationson the road. Alsoin hands-free mode,you shoulddraw
your attention to the trac. In complextrac situations you should refrainfrom using the mobile phone!
5. Damage of the airbag– A wrong place selected for the installationof the components may cause damage to the air bagor impair the functioningof the air bag. Install the
components out of range of ac tion of the air bag!
6. In sulation dama ge – Damagedinsulations may cause damages of the unit. e cables installed should not be exposed to tensile stress. Install the cables such as they are not
pinched or chafed.
7. Damage caused by polarity reversalor shor t circuiting – Incorrectly connected cables or a short circuit may cause serious damage to the equipment. It is essentialto disconnect
the car battery before youbegin installation.
8. Damage of important veh icle components – Drilling mounting holes ordriving in self-tapping screws maycause damage toimportant vehiclecomponents or to cables. Make sure
there is enough space lealso behind the screws unddrilling holes!
9. E e c t s on the v e h i c l e ’ s electricalsystem – Althoug h the hands-free car k it produces low amounts of radiation, improper installation of the hands-free c ar kit may inuence the
electronic equipment of thecar. Note the directions of the vehicle manufacturer!
10. Proper use– is system is intended for use exclusively with mobile phones in motor vehicles.
11. Damages caused by false replacement parts – Falsereplacement partsmay cause disturbances. Only usethe replacementparts listed in the chapter “Replacement partsand
Accessories”!
12. Negati ve impact on driving safety – For your own safety, please do not per form a pairing procedure while driving!
Thank you for choosing a product from Funkwerk Dabendorf.
This Quick Guide takes you through the initial set-up of EGO
FLASH. We recommend using the operating instructions for
your cellular phone (or similar) to familiarize yourself with
the Bluetooth
®
functions. Please make sure before installation
that the cell phone is compatible with the unit.
More information and detailed operating instructions can be
found on our website at www.fwd-online.de.
If you have any questions, call our hotline at [phone].
- Electronics box
- Control unit with display
- Microphone
- ISO cable for connecting to the vehicle
- Adapter cable
- Adhesive pad
- Quick Guide
- Safety information
Funkwerk Dabendorf GmbH
Märkische Straße
D-15806 Dabendorf
Telephone [phone]
Fax [phone]
E-mail [e-mail]
Internet www.fwd-online.de
QUICK
GUIDE
A Funkwerk AG company.
Welcome
Contents
EG O F LA SH
Connection Concept
129 8011 1.02
Connection
for EGO FL ASH
display
Line out
connection,
e.g. car ra dio
Microphone
connection
Connection,
e.g.
MP3 player
ISO connection
for the vehicl e
cable loom
ISO connection
to car radio
Connection
for the
Stereo Mute Box
Basepla te connector
for mounted c harger
(optional)
Connection
for ISO cab le
EGO FLA SH
Bluetoo th QD ID B012939
8 |9

Installation guide
6.1 Determination of required configuration
Before installation of your EGO FLASH, please note which features and connection options are provided by your car audio system. It
is advantageous when your audio has the following: a muting function, phone input and line-in. You can find out which of these input
options your audio system has in the documentation provided.
6.1.1 Vehicle
The EGO FLASH may only be installed in vehicles with 12 V, with the negative terminal connected to the chassis. If no car audio is
installed, an add-on speaker will be required. For the installation of the optional charging cradle, you will require a model-specific
mounting that may be purchased from a specialist dealer.
6.1.2 Mobile Telephone
Operation of the EGO FLASH requires a Bluetooth®-compatible mobile phone. You can find a list of supported Bluetooth®telephones
online at www.egohandsfree.com .
6.1.3 Muting (radio muting)
The muting function (Radio Muting) ensures that the audio sound is turned off during telephone calls. The system
supports the muting function. Your car`s audio documentation will show whether your car audio has a mute option. If your car audio
is not equipped with a muting option, you can install the optionally available Stereo Mute Box to facilitate speaker muting.
6.1.4 Converting the EGO FLASH into an already-installed Funkwerk hands-free car kit
An adapter cable is available for customers who already own a Funkwerk hands-free car kit (including the Audio 2000, 3000, Audio
blue, Audio com, and Audio compact) and who would like to easily convert the EGO FLASH. The adapter cable connects the ISO cable,
already installed in the vehicle, of your previous Funkwerk handsfree system with the EGO FLASH and is available as an accessory.
NOTE! This simple converting option is only possible when installing the EGO FLASH without a stereo mute box. To install the EGO
FLASH with the stereo mute box, the stereo mute box’s ISO connecting cable should be used to connect to the vehicle.
6.1.5 Add-on speakers / Car audio telephone connection
The car’s loudspeakers are transferred to the system is by means of switch contacts. These are designed for a peak power handling
of 35 W (Sinus). Loudspeaker power handling exceeding 35 W leads to premature wear on the switching contacts. For higher outputs,
use the telephone connection of the car audio or a 5 W / 4-Ohm satellite speaker. This port is only designed for voice reproduction.
6

EGO FLASH

10 |11
6.1.6 Car audio line-in input
A car audio with a line-in input option is required for music reproduction in stereo. As an alternative to line-in, the car audio may
have a mini-ISO port (block connector C), a 0.14 in jack socket or a RCA input socket. An appropriate adapter lead is required for
the connection between the EGO FLASH line-out and the line-in version of your audio system. If your car audio system has no
line-in option, you can employ the optionally available Stereo Mute Box for stereo reproduction in combination with your car’s front
speakers.
6.2 Verbauorte
INSTALLATION LOCATIONS! Unsuitable installation locations may become a source of injury in an accident (or emergency braking)
situation, or may inhibit the correct functioning of essential safety equipment!
6.2.1 Checking cable lengths
Before you’ve securely installed the components, check that the instal-
lation locations have been selected in such a way that the cable length
is sufficient to connect the individual components.
6.2.2 Selection of the installation location for the electronics box
The Bluetooth®antenna for the connection to the mobile phone is
installed in the electronics box. The antenna transmits directionally
towards the front. For this reason, during installation, ensure that the
antenna faces into the passenger cell (see Fig. 02). Vertical mounting is
ideal. Metallic screening between the front panel and the passenger cell, such as metal or metallised plastic panels, are unsuita-
ble and may interfere with the Bluetooth®connection. Locations behind the dashboard or in a metal-lined glove compartment are
also unsuitable.
A covering in plastic, fabric or wood presents no problems whatsoever.

Fig. 02:
Signal
transmission of
the Bluetooth®
antenna

Suitable locations for the electronics box:
Passenger side, next to the middle console under the paneling,
model-specific installation console (dealer).
Our suggested installation locations are shown in the illustration on
the right.
Further unsuitable locations are:
Leg and knee height, potential head impact zone, airbag inflation
space, engine compartment
6.2.3 Selection of the point of installation for the microphone
Suitable for the microphone:
Where voice can reach the microphone unhindered (distance between
the speaker and the microphone should be approx. 13.78 in), on the
A-column (between windshield and driver’s side window), next to the
driver‘s sun visor, on the dashboard
Unsuitable for the microphone:
Close to the speakers (less than 31 in), under the dashboard, in the air
stream from open windows or air vents
6.2.4 Selection of site for installing the control unit with integrated display
Suitable for the control console:
In the space above the DIN installation shaft, close to the steering wheel (in an easily accessible and visible position)
Unsuitable for the control console:
Airbag inflation space, potential head impact zones, out of reach of driver’s reach
Fig. 03:
Installation
locations
for the elec-
tronics box
Fig. 04:
Installation
location for
microphone
The illustration
shows one of
the potential mi-
crophone moun-
ting locations.
Alternatively,
the microphone
may be attached
to the sun visor
with the clip
provided.
EGO FLASH

12 |13
6.3 Installation
DAMAGE TO ESSENTIAL VEHICLE COMPONENTS! Essential vehicle components or wiring can be damaged when drilling mounting
holes or screwing in self-threading screws. Please make sure there is always sufficient space behind the screw holes and drilled
holes!
6.3.1 Mounting the electronics box
Installation consoles for a number of car models
are available from your dealer. These are designed
to contain all the system components, including
the electronics box. When it is not possible to use
an installation console, please proceed as follows:
Define the mounting points
Making sure that there is at least 2.8 in space for
the plug and socket connectors. Mark the positions
for the fixing screws.
Mounting the electronics box
For mounting the electronics box, use four self-threading screws and appropriate washers. We recommend size “ST 2,9x25 DIN
7981” self-threading screws. These are ideal for the fixing of the electronics box. Pre-drill the holes with a 0.08 in drill.
6.3.2 Mounting the microphone
Define the mounting location
The microphone holder has a self-adhesive strip on the back. The mounting location should have the same form and area as the
self-adhesive strip on the microphone holder. The location selected must allow the microphone cable to reach the electronics box!
Position the microphone with the head facing towards the direction of speech.
Cleaning and degreasing the mounting location
The mounting location must be clean and free from grease and dirt/dust. Prior to installation, clean the area with a cleansing product
containing ethyl alcohol. Only use products that do not damage plastics or varnished wood finishes and are themselves free of oils or
grease. Unsuitable cleansers are, for example, lighter fluid, acetone, turpentine, trichloroethylene and similar products.
Attaching the microphone holder
Peel off the protective backing from the self-adhesive strip. Hold the microphone holder at a distance of several millimetres (about a
quarter of an inch) above the desired mounting location. Re-check the positioning. Re-positioning after mounting is no longer possi-
ble. Place the microphone holder on the mounting location and fix by applying short and light pressure.

Fig. 05:
Electronics box
dimensions

Attaching the microphone
Attach the microphone by sliding it into the holder and position the microphone head towards the direction of speech.
6.3.3 Mounting the control unit with integrated display
Define the mounting location
The control console is mounted on a smooth service by means of the self-adhesive pad provided. Make sure that the location is within
easy reach of the intended user.
Cleaning and degreasing the mounting location
The mounting location must be clean and free from grease and dirt/dust. Prior to installation, clean the area with a cleansing product
containing ethyl alcohol. Only use cleansing products that do not damage plastics or varnished wood finishes and are themselves free
of oils or grease. Unsuitable cleansers are, for example, lighter fluid, acetone, turpentine, trichloroethylene and similar products.
Attaching the control unit with integrated display
After defining the appropriate cable direction on the back of the console, fix it by covering it with the self-adhesive pad. Hold the con-
trol console at a distance of several millimetres (about a quarter of an inch) above the desired mounting location. Re-check the posi-
tioning. Re-positioning the console after mounting is no longer possible. Apply the control console to the proposed mounting location
and fix by applying short and light pressure.
6.4 Connection scheme
Installation for call reception for a car audio system with a mute input but without a phone input
With this connection option, voice playback is is emitted from the front right car speaker. During calls, the mute input blocks the car
audio signal.
NOTE: Please observe the information in section “6.5.1 Checking the mute inputs” on con-
necting the mute lead of the ISO connecting cable.
Installation for voice playback with a car audio system with phone and mute input options
With this connection option, voice playback comes through the car audio system speakers.
During calls, the car radio output is switched to the phone input by the mute input In order
to access the phone input of your car audio system, the speaker output of your EGO FLASH
must be connected to the phone input of your car audio system. The purple and green leads
of the ISO cable must be connected to the car audio phone input for this option. The purple
and green leads must be disconnected from the ISO connector. The green lead (pin 14 of

Fig. 06:
Connection for the mini
ISO connection cable
EGO FLASH

14 |15
the 14-pin plug) should be connected to „Phone Out“, and the purple lead (pin 7 of the 14-pin plug) to „Phone In +“ of the Mini-ISO
socket.
For information on the phone connection options of your car audio system, please consult the manufacturer‘s user manual.
NOTE: If your car audio system has different phone connection options from those mentioned here, please consult a qualified pro-
fessional for installation of the system. Furthermore, please read the section with information on connecting the mute lead of the
ISO connection cable, “6.5.1 Checking the mute input”.
6.5 Installation of the ISO connecting cable
The battery must be disconnected before starting cable installation. Disconnect the grounding cable from the negative pole of the
battery. The cable installation procedure is shown in the illustrations.
When the installation is completed,
reconnect the grounding cable to the
negative pole of the battery.

Fig. 07:
Installation
procedure
1
2
3
4
Connect 14-pin ISO
connecting cable to
EGO FLASH
Disconnect car wiring
harness from car radio
Connect EGO FLASH ISO
connector to car radio
Connect EGO FLASH ISO connectors to car
wiring harness ISO connectors
Connect yellow mute lead to
one of the three mute inputs
(see table)
Car audio
Car audio
Electronics box

6.5.1 Checking the mute inputs
Picture 5 of Fig. 07 shows mute inputs 1–3. The yellow mute lead of the hands-free system should be connected to one of these
inputs. Which mute input should be selected is shown in the tables:
Fig. 08:
Type-dependent
pin allocation
Fig. 10:
Connection system
Fig. 09:
Plug wiring scheme
Socket contact housing Wiring of power supply connectors
Radio model Pin Wire colour Function
Audi,
Volkswagen,
Grundig
1
2Mute
3
4blue Ignition (15)
7red Permanent positive (30)
8brown Ground (31)
Socket contact housing
Radio model Pin Wire colour Function
Ford,
Mercedes,
Porsche,
Becker
1
2
3Mute
4red Permanent positive (30)
7blue Ignition (15)
8brown Ground (31)
Socket contact housing
Radio model Pin Wire colour Function
Blaupunkt
1
2Mute
3
4red Permanent positive (30)
7blue Ignition (15)
8brown Ground (31)
Socket contact housing
Radio model Pin Wire colour Function
Philips
1Mute
2
3
4red Permanent positive (30)
7blue Ignition (15)
8brown Ground (31)
Socket wiring from
the rear (see table)
Plug wiring from
the rear
Car audio
Electronics box
Vehicle wiring harness
EGO FLASH

16 |17
6.5.2 Checking the installation
When the ISO connection cable is correctly installed, a call remains active until the call is ended, even if the ignition has already
been turned off beforehand. The system switches off automatically when the call has been ended. If the system switches to off
immediately switches off,then exchange the ignition lead (blue) with the power supply lead (red) as shown in Fig. 11b
PLEASE NOTE, the fuses should remain in place when opening the fuse compartment, make sure that they are not inadvertently
exchanged!
6.5.3 Additional external speakers
In the following cases, additional speakers (4 Ω, min. 5 W) must be used:
→ when the car audio system speakers should not be used
→ when the output rating of the speaker channel is greater than 35 W (Sinus) and the car audio
system has no phone connection option
→ when the car audio system is used with active speakers and has no phone connection option
Feedback interferes with the clarity of calls. Mount additional speakers at a distance of at least 31 in from the microphone. When
mounting additional speakers, please observe the manufacturer‘s installation instructions. Speakers can be connected to the
green (pin 14) and the purple (pin 7) leads of the connection cable. First of all, the purple and green leads must be disconnected
from the ISO connector (see Fig. 12).
1
2A
1A 2A
1A
+12V
2
2A
1A
2A
1A
+12V
2A
1A
2A
1A
3
+12V

Fig. 11a:
View of original
connection
Fig. 11b:
View after
changing cables
red
blue red
red
red
red
red blue
blue
blue
blue
blue

6.6 Connecting the components to the electronics box
The individual components are connected to the electronics box as follows :
[1] Plug the microphone jack into the jack socket with the microphone symbol
[2] The electronic box line-in can be used to connect an optional MP3 player with line-out. To do so, a connection
cable 0.14 in stereo jack plug to 0.14 in stereo jack plug (l = 4.92 ft) is required.
IMPORTANT: Only connect the device (MP3 player, iPod™, etc.) to the electronics box line-in with a jack cable when it
is being powered by battery alone (without the recharger), as interfering impulses may otherwise cause damage to the
electronic box line-in.
Fig. 12:
Additional external
loudspeakers

Pin Colour Function View of the plug side,
from which the wiring is
fed in the plug housing
(with pin allocation)
Connection option for additional speakers on pin 7
(purple lead) and pin 14 (green lead) of the 14-pin plug
1Brown Ground (31)
2Yellow Radio mute
3
4
5
6White
Car audio speaker
output +
(front right)
7Purple Speaker lead +
(front right)
8Red Permanent positive (30)
9Blue Ignition (15)
10
11
12
13 Black
Car audio speaker
output -
(front right)
14 Green Speaker lead -
(front right)
EGO FLASH

18 |19
[3] The electronics box line-out must be connected to the car audio line-in. Depending on the car audio line-in
configuration, one of the following cables is required:
→ Connection cable 0.14 in stereo jack to 0.14 in stereo jack (l = 4.92 ft)
→ Connection cable 0.14 in stereo jack to RCA plug (l = 4.92 ft)
→ Connection cable 0.14 in stereo jack to Mini-ISO (l = 4.92 ft)
[4] The control unit with display must be connected to the port.
[5] The 14-pin plug of the ISO connecting cable must be connected with the electronics box.
[6] The base plate for the charging cradle may also be connected to the “charger” output socket.
Fig. 13:
Electronics box
connection
[1]
[2] [4]
[3] [5] [6]

6.7. Connection of the EGO iDapter to the electronics box
Before the EGO iDapter is connected to the Ego Look/Flash, a Bluetooth update to software version 7.0 or
higher must be performed. Following this, the EGO iDapter can be attached to the Ego Look/Flash as
described in the connection diagram.
i
Pod Pla
y
e
r
Abb. 13a:
Connection
EGO iDapter
EGO FLASH
