Furious FPV RACEPIT User manual

Please contact us if you need further assistance:
Tech support: [e-mail]
Sales support: [e-mail]
Website: http://furiousfpv.com/
RACEPIT
Flight Controller
USER MANUAL

1
CONTENTS
Features .................................................................................................................................................. 2
Pinouts.................................................................................................................................................... 2
Dimensions ............................................................................................................................................. 3
Connections Overview ........................................................................................................................... 3
Connections............................................................................................................................................ 4
Connect with Receivers ............................................................................................................ 4
Spektrum Rx:........................................................................................................................... 4
FrSky XSR Rx: ........................................................................................................................... 5
FrSky R-XSR Micro Rx: ............................................................................................................. 6
TBS Crossfire Nano Rx:............................................................................................................ 8
Connect with Video Transmitters.............................................................................................. 9
Build-in power switch for VTX:................................................................................................ 9
Stealth Long Range 5.8GHz VTX:............................................................................................. 9
Using Tramp HV VTX: ............................................................................................................ 10
Using TBS Unify Pro 5G8 HV SE VTX:.....................................................................................10
Using TBS Unify Pro Nano 5G8 VTX: ..................................................................................... 11
Using TBS Unify Pro 5G8 HV Race 2 VTX:.............................................................................. 11
Camera Connections............................................................................................................... 12
Bluetooth Connection ............................................................................................................ 13
Connect with ESC 4 in 1 .......................................................................................................... 14
Hobbywing XRotor Micro 45A 3-6S: .....................................................................................15
AIKON AK32 55A 3-6S: ..........................................................................................................16
DALRC ENGINE 40A Pro 3-5S:................................................................................................ 17
T-Motor F45A 32bit 6S:......................................................................................................... 18
Holybro Tekko32 35A 3-6S:................................................................................................... 19
Holybro Tekko32F3 Metal 65A 4-6S: ....................................................................................20
Anniversary Special Edition Racerstar REV35 35A 3-6S:....................................................... 21
SucceX 60A V2 Plus 4-5S: ......................................................................................................22
Tips........................................................................................................................................................23

2
Features
STM32F405 main chip
MPU6000 Gyroscope
Built-in connector for 4-in-1 ESC as well as solder pads
Built-in power switch for VTX, support 5V & Vbat
Built-in Camera switcher
Built-in 16MB Blackbox flash
Full 6 UARTs for Simultaneous Connections of Runcam Device, GPS, CRSF Rx,
Bluetooth and others
Work with 5V or Vbat input
High quality 5V 2A BEC w/2S –6S voltage input range
Built-in Inverter for S.BUS & S.PORT
Integrated Silicone Damper for maximum FC functionality
Pinouts

3
Dimensions
Connections Overview

4
Connections
*WARNING: FC can support up to 6S, but make sure that other devices connected
to VBAT also supports it.
Connect with Receivers
Spektrum Rx:

5
FrSky XSR Rx:
Note: If telemetry is not working with the FC, please update the firmware for the Rx
SBUS protocol

6
FrSky R-XSR Micro Rx:
Note: If telemetry is not working with the FC, please update the firmware for the Rx
SBUS protocol

7
F.Port protocol
*Note: Make sure your Rx is running F.Port protocol firmware, R-XSR Firmware:
190311
Link download Firmware:
https://www.frsky-rc.com/wp-content/uploads/Downloads/Firmware/R- XSR/FW-
RXSR-FPORT-190311.zip

8
TBS Crossfire Nano Rx:

9
Connect with Video Transmitters
Build-in power switch for VTX:
Note: From factory, the VTX power jumper is set to always ON, desolder the
jumper to use the power switch.
Stealth Long Range 5.8GHz VTX:

10
Using Tramp HV VTX:
Using TBS Unify Pro 5G8 HV SE VTX:

11
Using TBS Unify Pro Nano 5G8 VTX:
Using TBS Unify Pro 5G8 HV Race 2 VTX:

12
Camera Connections
Built-in Camera switcher:
Note: When USER2 is not enabled, the VTX will get the video signal from
Camera 1, and when using dual cameras they need to be powered from VBat (not
on 5 volt)
Using with FOXEER (Arrow Mini, Arrow Micro, Monster)

13
Using with Caddx SDR2 Plus Race
Bluetooth Connection

14
How to use Speedy Bee App
Step 1: Open Speedy Bee App.
Step 2: Tap to start scanning.
Step 3: Select the Bluetooth name.
Step 4: Configure the Flight Controller.
Connect with ESC 4 in 1
*WARNING: FC can support up to 6S, but make sure that other devices connected
to VBAT also supports it.
JST SH 1.0mm with 10 or 8 pin connectors is included. Insert the wires in the order
that matches your ESC.

15
Hobbywing XRotor Micro 45A 3-6S:

16
AIKON AK32 55A 3-6S:

17
DALRC ENGINE 40A Pro 3-5S:

18
T-Motor F45A 32bit 6S:

19
Holybro Tekko32 35A 3-6S:
