Furious FPV Radiance DSHOT User manual

Please contact us if you need further assistance:
Tech support: [e-mail]
Sales support: [e-mail]
Website: http://furiousfpv.com/
RADIANCE DSHOT VERSION
Flight controller
USER MANUAL

Introduction
The Furious FPV Radiance FC (Flight Controller) provides a blaze of feature packed brilliance that
equates to the perfect fit for models utilizing their own PDB (power distribution board).
Functionality is the key, but innovation is our specialty. The Radiance FC stacks with 4 in 1 ESC’s
for perfect CG, allowing optimized acro flight. When utilising your own PDB, weight and cost are
minimised.
High performance and user friendly, the Radiance FC features cutting edge F3 chip (MPU6000)
processing power, a built in BEC, integrated LC filter, iLap transponder, and a current sensor
input, just to name a few. With this feature packed insanity, the Radiance shadows all other
FC's, providing everything that's needed in one perfect package.
Step into the light with unworldly levels of capability & functionality, all at ultra-budget friendly
pricing. Simply put, this is the way we do it at Furious FPV.
WHAT’S NEW RADIANCE DSHOT VERSION?
Remove PPM pin and add TX2 pin
Ready support ESC Dshot protocol
New component for BEC better
New red color for PCB
Feature
Latest Generation F3 Processor Chip
High Performance, User Friendly F3 MPU6000 Chip
Integrated LC Filter for Perfect Clarity
Designed for Acro Precision via CG Perfection
Heavy Duty 1A BEC @ 5V Output and 0.8A BEC @12V Output
Included Spektrum Satellite Port
2S-5S Lipo Ready
Support DSHOT protocol
Inrush Voltage Protection Input by Transient Voltage Suppressor
Gold Plated Pads for the Very Best Connectivity
Weight: 5gr

Board Layout
Dimensions

Connection
* Warning: Radiance DShot Version can support up to 5s Lipo battery but make sure other
devices also support it.
Connect with Receiver:
Using XSR FrSky Receiver

Using SPD15 Receiver
Using Spektrum Satellite Receiver

Connect with Video Transmitter:
Using Tramp HV
With Piggy V2 OSD

With Only Camera

Using TBS Unify Pro
With Piggy V2 OSD

With Only Camera

Using FX FX799T
With Piggy V2 OSD

With Only Camera

Connect with other devices:

Connect with ESC 4 in 1 Aikon SEFM 30A:
You can buy ESC Aikon SEFM 30 4 in 1 right here: https://goo.gl/IOYBEr

Connect with ESC 4 in 1 Cicada 35x4 35A:
You can buy ESC Sunrise Cicada 35x4 35A right here: https://goo.gl/s08OaI

Basic setup
Please, follow carefully these next steps, and always remove your propellers when you’re
configuring your quad
Step 1: Plug USB cable and connect Radiance with the computer then open BetaFlight
Step 2: Configure Ports.
(1) Turn on MSP of UART 1 to use OSD.
(2) Turn on Serial Rx of UART 2 to use Receiver Mode
(3) Select SmartPort of UART 3 to use S.Port of Receiver.
* Note: Please check in connection to correct select for this function.
Step 3: Go to Configuration and choose ESC/Motor protocol in ESC/Motor Features

Step 4: Select Serial- based receiver in Receiver Mode
If you are using SBus, iBus or a Spektrum Satellite, you will need to pick your Serial Receiver
Provider. Follow this table:
RX Type
Serial Receiver Provider
DSM2 Satellite
SPEKTRUM1024
DSMX Satellite
SPEKTRUM2048
FrSky RX
SBUS
Futaba RX
SBUS
FlySky RX
IBUS
Turnigy RX
IBUS
Ex: If you use SPD15 or XSR Receiver then you choose SBUS in Serial Receiver Provider.
Go to CLI and type the following commands:
set sbus_inversion = ON
save
If you use LR1000D Receiver please type:
set sbus_inversion = ON
save

Step 5: Go to Receiver tab to configure the receiver and select the channel mapping
compatible with your transmitter.
Ex: Choose 3rd mapping (JR/ Spektrum/ Graupner) if you use FrSky Receiver.
Step 6: Go to Modes to set ARM range and choose auxiliary functions Aux.
* Note: the Aux number associated with the switch you will use for arming, other modes
function

Tips
How to configure your Spektrum RX with your flight controller:
In Betaflight Configurator:
Go to the Ports tab
Enable “Serial RX” on the UART 2
Click “Save”.
Then go to the Configuration tab. Under the section labeled “Receiver”, pick
SPEKTRUM2048.(Note: If you are using a DSM2 receiver, pick SPEKTRUM1024.)
Click “Save”.

Finally, go to the Receiver tab. Pull down the drop down that says “Channel Map” and select
the “JR / Spektrum / Graupner” option.
Once again, click “Save”.
How to turn on bind mode
Safety warning: never plug battery to the quad during setup.
Connect quadcopter to the computer and go to Command-line interface (CLI) tab.
Remember to type “save” and hit enter after these commands have been executed.
Type in the commands as pictured above, or copy and paste them from below:
set spektrum_sat_bind=9
set spektrum_sat_bind_autorst=0
save

Note –if you are using a DSM2 receiver, change “set spektrum_sat_bind=9” to
“set spektrum_sat_bind=5”
Reboot your flight controller by unplugging the flight controller from your PC then plugging it
back in.
Your RX should go into bind mode by now as the LED on the RX will be blinking rapidly.
How to set up OSD via BetaFlight Serialpassthrough:
Note:
UART 1 is typically reserved for the USB so if you have connected anything
you want to access on that UART, this will not work
Depending on your setup you may need to power the device you are trying
to connect to access it.
How to set up OSD with BetaFlight via Serialpassthough:
Step 1: Connect your flight controller to the USB on your computer.
Step 2: Open Betaflight and connect to the flight controller while noting the com
port it’s using.
Step 3: Go to the Ports tab and verify what UART you’ve connected to your device.
