Furniture of America CM1738F-2 User manual

Assembly Instructions
EASY DIFFICULT
Page 1 of 5
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
Rev: 18-12-21
CM1738F-1/2/3
2 PERSONS RECOMMENDED
Tools Required For Assembly:
Allen Wrench (Included)
Phillips Screwdriver (Not Included)
For more information contact our team: [email protected]

Page 2 of 5
BASIC ASSEMBLY TECHNIQUES
FOR YOUR FURNITURE TO LAST,CORRECT ASSEMBLY AND PROPER MAINTENANCE ARE NECESSARY.
PLEASE FOLLOW THE INFORMATION PROVIDED BELOW TO FULLY ENJOY YOUR FURNITURE.
FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
IT IS THE USER'S RESPONSIBILITY TO MAINTAIN THE FURNITURE.THE HARDWARE MAY
LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO
SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE
SERIOUS INJURY.
When lock or spring washer is used in
an assembly, please make sure the
lock or spring washer is placed
between the larger flat washer and the
head of the screw or bolt.
Some furniture comes with height
adjusetment knobs underneath each
leg. To lower or to raise each leg, you
need to turn clockwise or
counterclockwise, respectively.
FURNITURE OF AMERICA.ALL RIGHTS RESERVED.
Make sure all parts are properly
aligned, then use the appropriate
hand tool to completely tighten the
bolts or screws. Do not use power
tools and do not overtighten.
Position each part correctly and insert
screws or bolts into their respective
holes by hand tighten or using the
proper hand tool. Only tighten when
step is completed or when instructed
to do so.
Save the instructions and store the Allen
wrench or any supplied tool for later
maintenance. After two weeks, check and
tighten any loose hardware and repeat
again every six months thereafter.
Use cardboard or carpet area when
assembling furniture to prevent
scratches .Make sure the furniture
rests on a flat and level surface with
each leg evenly touching the floor.
No dragging of products/parts.

Parts List
Hardware List
Before you begin, please read Page 2
of "Assembly and Care Advice".
And remember, do not tighten until
each step is completed or instructed.
Page 3 of 5
#A x 8pcs
Bolt Ø1/4" x 3-1/8"
#B x 8pcs
#C x 12pcs
Screw #4 x 30mm
#D x 3pcs
Barrel Nut Ø1/4" x 1/2"
#2 x 1pc
#3 x 2pcs
#4 x 1set
Full Slat Kit (10pcs)
#1 x 1pc
Side Rail
Footboard
Headboard Bookcase
#5 x 1pc
Center Support Rail
#6 x 3pcs
Support Leg 300x40x40mm
#E x 1pc
Allen Wrench 4mm
Screw #4 x 40mm

#A x 8pcs
#B x 8pcs
#A
#E
#B
#2
Page 4 of 5
#2
#1
#3
#3
#4
#5
#6
#3
#1
#3
Exploded View
Insert barrel nuts (#B) to the side holes of the side rails (#3). Align side rails (#3) to the
holes of the headboard (#1) and footboard (#2), then secure by tightening bolts (#A) onto
barrel nuts (#B).

Page 5 of 5
#D x 3pcs
#C x 12pcs
#6
#5
#C
#D
#4
#3
#3
Align support legs (#6) to the slat (#5), then secure by using screws (#D). Adjust the
bottom levelers on the support legs (#6) according to ground level.
Align slats (#4) to the side rails (#3) and center slat (#5), then
secure by using screws (#C).

Assembly Instructions
EASY DIFFICULT
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
CM1738F-4
2 PERSONS RECOMMENDED
Tools Required For Assembly:
Allen Wrench (Included)
Phillips Screwdriver (Not Included)
Page 1 of 7
For more information contact our team: [email protected]
Rev: 18-12-21

BASIC ASSEMBLY TECHNIQUES
FOR YOUR FURNITURE TO LAST,CORRECT ASSEMBLY AND PROPER MAINTENANCE ARE NECESSARY.
PLEASE FOLLOW THE INFORMATION PROVIDED BELOW TO FULLY ENJOY YOUR FURNITURE.
FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
IT IS THE USER'S RESPONSIBILITY TO MAINTAIN THE FURNITURE.THE HARDWARE MAY
LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO
SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE
SERIOUS INJURY.
When lock or spring washer is used in
an assembly, please make sure the
lock or spring washer is placed
between the larger flat washer and the
head of the screw or bolt.
Some furniture comes with height
adjusetment knobs underneath each
leg. To lower or to raise each leg, you
need to turn clockwise or
counterclockwise, respectively.
FURNITURE OF AMERICA.ALL RIGHTS RESERVED.
Make sure all parts are properly
aligned, then use the appropriate
hand tool to completely tighten the
bolts or screws. Do not use power
tools and do not overtighten.
Position each part correctly and insert
screws or bolts into their respective
holes by hand tighten or using the
proper hand tool. Only tighten when
step is completed or when instructed
to do so.
Save the instructions and store the Allen
wrench or any supplied tool for later
maintenance. After two weeks, check and
tighten any loose hardware and repeat
again every six months thereafter.
Page 2 of 7
Use cardboard or carpet area when
assembling furniture to prevent
scratches .Make sure the furniture
rests on a flat and level surface with
each leg evenly touching the floor.
No dragging of products/parts.

Before you begin, please read Page 2
of "Assembly and Care Advice".
And remember, do not tighten until
each step is completed or instructed.
#1 x 1pc
#2 x 1pc
Top Panel
Side Panel (Left)
#4 x 1pc
#3 x 1pc
#5 x 2pcs
#6 x 2pcs
#7 x 2pcs
Support Rail
#8 x 1pc #H x 1pc
Allen Wrench 4mm
Side Panel (Right)
Horizontal Panel
Center Vertical Panel
Horizontal Bar Cabinets
Back Panel
#A x 4pcs
Bolt Ø1/4" x 3-1/8"
#B x 8pcs
Barrel Nut Ø1/4" x 1/2"
#C x 4pcs
Bolt Ø1/4" x 2-1/4"
#D x 12pcs
Bolt Ø1/4" x 1-3/8"
#E x 22pcs
#F x 8pcs
Dowel Ø7/16" x 1-9/16"
Dowel Ø7/16" x 1-3/16"
Screw #4 x 15mm
#G x 36pcs
Parts List
Hardware List
Page 3 of 7

Page 4 of 7
#1
#3
#5
#4
#2
#8
#6
#7
Exploded View
#C x 4pcs
#B x 4pcs #1
#4
#5
#5
#E
#E
#B
#H
#C
#E x 6pcs
Insert dowels (#E) to center vertical panels (#5), then align center
vertical panels (#5) to the holes of the top panel (#1).
Insert dowels (#E) and barrel nuts (#B) to center vertical panels (#5),
then align center vertical panels (#5) to the holes of the horizontal
panel (#4). Secure by using bolts (#C).

Page 5 of 7
#D x 8pcs
#E x 8pcs
#E
#E
#H
#H
#D
#D
#2
#3
#6
#H
#A
#E
#B
#A x 4pcs
#B x 4pcs
#E x 8pcs
#6
#2
#3
#1
#4
Insert dowels (#E) to top and horizontal panels (#1,4),
then insert dowels (#E) to horizontal bar cabinets (#6)
from step 3. Align and attach side panels (#2,3) to the
top, horizontal panels (#1,4) and bar cabinets (#6).
Secure top and horizontal panels (#1,4) by using bolts
(#D).
Insert barrel nuts (#B) to horizontal bars (#6), then secure by
tightening bolts (#A) to barrel nuts (#B).

Page 6 of 7
#G x 32pcs
#G
#8
#H
#D
#F
#D x 4pcs
#F x 8pcs
#7
#2
#3
#6
#4
Align back panel (#8) to the back of the unit, then
secure by using screws (#G).
Insert dowels (#F) to the support rails (#7), then
attach support rails (#7) to unit. Secure by using
bolts (#D).

Page 7 of 7
#G x 4pcs
#G
#G
Secure both bed and shelves together by
using screws (#G).
