Furniture of America CM2672 User manual

EASY
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
Assembly Instructions
Tools Required for Assembly
Rev.14-11-06
Page 1 of 5
DIFFICULT
ASSEMBLY RATING
CM2672
Phillips Screwdriver (Not Included)
2 PERSONS RECOMMENDED
Allen Wrench (Included)

Page 2 of 5

Parts List
#1 x 1 pc
Futon
#2 x 4 pcs
Leg
#A x 16 pcs
Screw
Before you begin, please read Page 2
of “Assembly and Care Advice”.
And remember, do not tighten until
each step is completed or instructed.
MD
Page 3 of 5
#B x 8 pcs
Bolt 1/4”x1”
#C x 8 pcs
Lock Washer
#D x 8 pcs
Flat Washer
#E x 1 pc
Allen Wrench
Due to the size and/or weight of this product, it is highly
recommended that the assembly should be done near
the area of its intended location. Make sure you have
enough space to move around during the assembly.
ALWAYS have at least two people to help with
transporting and assembling the product to avoid any
potential injury and/or damage.

Page 4 of 5
I. Align the leg (#2) with the pre-
drilled holes on the corner of
the futon (#1).
II. Secure 4 screws (#A) into the
leg (#2) using a Phillip
screwdriver to tighten.
III. Prepare 2 bolt assemblies by
inserting FIRST the lock
washer (#C) onto the bolt (#B)
and the flat washer (#D) onto
the SAME bolt (#B), in that
order.
IV. Insert the bolt assemblies
through the pre-drilled holes of
the leg (#2) and secure those
bolts using the Allen wrench
(#E) to lock them with the
futon (#1).
V. Repeat the process above to
assemble the remaining 3 legs
(#2) onto the futon (#1).
With the help of another person, carefully place the futon
(#1) facing down on a protective surface. Remove 4 legs
(#2) located inside the futon (#1).
#A x 16 pcs
#B x 8 pcs
#C x 8 pcs
#D x 8 pcs
Turn right (clockwise) to tighten

Page 5 of 5
ASSEMBLY IS COMPLETED
Carefully turn the futon upright. Make sure the futon is rested on a
flat surface and does not feel loose or wobbly. If it does, double
check that the screws are secured and properly tightened.
