Furniture of America CM3323T User manual

1 / 8
MODEL #
CM3323T
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
VERSION # 20-07-21
2 - People
Recommended
VN

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furnitureof America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessorieslisted on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ 8

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ 8

4 / XXXXXXX8

DINING TABLE
CM3323T
5 / 8
#1 1pc #2 1pc
#A 32pcs #B 32pcs
#3 4pcs #4 4pcs
Flat Washer
(5/16” x 19mm) Lock Washer
(5/16”)
Table Top Table Shelf Table Leg Backrest
#C 16pcs
Bolt (5/16” x 3/4”)
#D 16pcs
Bolt (5/16” x 1-1/2”)
#E 1pc
Allen Wrench (5mm)

6 / 8
Exploded View

1
2
7 / 8
Hardware #A x16pcs
Hardware #B x16pcs
Hardware #C x16pcs
Hardware #E x1pc
Part #4 x4pcs
Part #3 x4pcs
Part #2 x1pc
Hardware #A x16pcs
Hardware #B x16pcs
Hardware #C x16pcs
Hardware #E x1pc
Part #4 x4pcs
Part #3 x4pcs
Align brackets (#4) to the legs (#3), then
secure by using bolts (#C) with washers
(#A,B).
Align legs (#3) to the shelf (#2), then
secure by using bolts (#C) with washers
(#B,A).

3
4
8 / 8
Hardware #A x16pcs
Hardware #B x16pcs
Hardware #D x16pcs
Hardware #E x1pc
Align legs (#3) to the top (#1), then
secure by using bolts (#D) with
washers (#B,A).
