Furniture of America CM3663T User manual

EASY
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
CM3663T
Allen Wrench (Included)
Assembly Instructions
Tools Required for Assembly:
Page 1 of 5
DIFFICULT
ASSEMBLY RATING
2 PERSONS RECOMMENDED
For more information contact our team: [email protected]
Rev:18-07-25

BASIC ASSEMBLY TECHNIQUES
FOR YOUR FURNITURE TO LAST,CORRECT ASSEMBLY AND PROPER MAINTENANCE ARE NECESSARY.
PLEASE FOLLOW THE INFORMATION PROVIDED BELOW TO FULLY ENJOY YOUR FURNITURE.
FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
IT IS THE USER'S RESPONSIBILITY TO MAINTAIN THE FURNITURE.THE HARDWARE MAY
LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO
SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE
SERIOUS INJURY.
When lock or spring washer is used in
an assembly, please make sure the
lock or spring washer is placed
between the larger flat washer and the
head of the screw or bolt.
Some furniture comes with height
adjustment knobs underneath each
leg. To lower or to raise each leg, you
need to turn clockwise or
counterclockwise, respectively.
FURNITURE OF AMERICA.ALL RIGHTS RESERVED.
Make sure all parts are properly
aligned, then use the appropriate
hand tool to completely tighten the
bolts or screws. Do not use power
tools and do not overtighten.
Position each part correctly and insert
screws or bolts into their respective
holes by hand tighten or using the
proper hand tool. Only tighten when
step is completed or when instructed
to do so.
Save the instructions and store the Allen
wrench or any supplied tool for later
maintenance. After two weeks, check and
tighten any loose hardware and repeat
again every six months thereafter.
Use cardboard or carpet area when
assembling furniture to prevent
scratches .Make sure the furniture
rests on a flat and level surface with
each leg evenly touching the floor.
No dragging of products/parts.
Page 2 of 5

Parts List
#1 x 1 pc
Table Top
#2 x 1 pc
Leaf
#3 x 1 pc
Pedestal
#A x 12 pcs
Bolt 5/16”x2”
Before you begin, please read Page 2
of “Assembly and Care Advice”.
And remember, do not tighten until
each step is completed or instructed.
Page 3 of 5
Hardware List
#D x 1 pc
Allen Wrench
#C x 12 pcs
Flat Washer
#B x 12 pcs
Lock Washer
#4 x 1 pc
Pedestal Base
#5 x 2 pcs
Table Base

Page 4 of 5
Turn right (clockwise) to tighten
#A x 4 pcs
#B x 4 pcs
#C x 4 pcs
#A x 8 pcs
#B x 8 pcs
#C x 8 pcs
I. Align the 2 table bases (#5) with
the pre-drilled holes on the
pedestal (#3).
II. Prepare 4 bolt assemblies by
inserting FIRST the lock washer
(#B) onto the bolt (#A) and then
the flat washer (#C) onto the
SAME bolt (#A), in that order.
III. Insert the bolt assemblies through
the 2 table bases (#5) and secure
those bolts using the Allen wrench
(#D) to lock them with the pedestal
(#3).
I. With the help of another person, carefully
place the table top (#1) facing down on a
protected surface.
II. Align the assembled table bases (#5) with
the pre-drilled holes on the bottom of the
table top (#1)
III. Prepare 8 bolt assemblies by inserting
FIRST the lock washer (#B) onto the bolt
(#A) and then the flat washer (#C) onto
the SAME bolt (#A), in that order.
IV. Insert 4 bolt assemblies through the pre-
drilled holes of the 2 table bases (#5) and
secure those bolts using the Allen wrench
(#D) to lock them with the table top (#1).
V. Align the pedestal base (#4) with the pre-
drilled holes on the bottom of the pedestal
(#3)
VI. Insert 4 bolt assemblies through the pre-
drilled holes of the pedestal base (#4) and
secure those bolts using the Allen wrench
(#D) to lock them with the pedestal (#3).
Turn right (clockwise) to tighten
#5

Page 5 of 5
I. Carefully turn the completed table upright. Make sure the table is
rested on a flat surface and does not feel loose or wobbly. If it
does, double check that the bolts/screws are secured and
properly tightened.
II. To insert the table leaf (#2) unlock the latches located under the
table top (#1).
III. Once unlocked, slide outward on both ends of the outer-piece
table until there is sufficient opening to place the table leaf (#2).
Then slide inward on both ends of the outer-piece table until they
are touching and sitting flush with the table leaf (#2).
IV. Secure the parts together by locking the latches located under
the table top (#1).
ASSEMBLY IS COMPLETED
