Furniture of America CM4265DK-C-L User manual

CM4265DK-C-L
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
ASSEMBLY RATING
EASY DIFFICULT
1 / 7
TOOLS REQUIRED
MODEL #
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
Questions?
2 - People
Recommended
VERSION # 20-02-17

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX7

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ 7

4/ 7

#1
COFFEE TABLE
1pc #2 1pc #3 4pcs
#A 12pcs #B 12pcs #C 12pcs #D 1pc
CM4265DK-C-L
Table Top Leg
Shelf
5 / 7
HARDWARE
PARTS
BOLT Ø5/16 X 2" Allen Wrench 4mm
Lock Washer 5/16"
Flat Washer 5/16"

2
1
6 / 7
1. Carefully place the table top (#1) face down onto a protected surface.
2. Prepare 6 bolt assemblies by first inserting a lock washer (#C) onto
the bolt (#A) then a flat washer (#B) onto that same bolt (#A).
3. Align 3 legs (#3) to three corners of the table top (#1). Insert 2 bolt
assemblies into each leg and secure using the Allen wrench (#D).
Carefully remove the drawer.
#1
Part
#3 x 3pcsPart
#A x6pcsHardware
#B
Hardware
#C
Hardware x6pcs
x6pcs
x 1pc
2. Align the shelf (#2) to the holes
along the legs (#3), then insert
a bolt assembly into the holes
and secure using the Allen wrench.
1. Prepare 3 bolt assemblies
by first inserting a lock
washer (#C) onto the bolt
(#A) then a flat washer (#B)
onto that same bolt (#A).
#2 x 1pcPart
#A x3pcsHardware
#B
Hardware
#C
Hardware x3pcs
x3pcs

3
7 / 7
1. Prepare 3 bolt assemblies by first inserting a
lock washer (#C) onto the bolt (#A) then a
flat washer (#B) onto that same bolt (#A).
2. Align the fourth leg
(#3) to the final
corner and insert a
bolt assembly into
each hole. Secure
using the Allen
wrench (#D).
#3 x 1pcPart
#A x3pcsHardware
#B
Hardware
#C
Hardware x3pcs
x3pcs
Carefully turn the completed table upright. Make sure the table is
rested on a flat surface and does not feel loose or wobbly. If it does,
double check that the bolts are secured and properly tightened.
Insert Drawer.
4
