Furniture of America CM7561CK User manual

Assembly Instructions
EASY DIFFICULT
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
Rev: 18-07-17
2 PERSONS RECOMMENDED
Tools Required For Assembly:
Allen Wrench
(Included)
CM7561CK
Phillips Screwdriver
(Not Included)
Wrench
(Included)
For more information contact our team: [email protected]
Page 1 of 7

BASIC ASSEMBLY TECHNIQUES
FOR YOUR FURNITURE TO LAST,CORRECT ASSEMBLY AND PROPER MAINTENANCE ARE NECESSARY.
PLEASE FOLLOW THE INFORMATION PROVIDED BELOW TO FULLY ENJOY YOUR FURNITURE.
FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
IT IS THE USER'S RESPONSIBILITY TO MAINTAIN THE FURNITURE.THE HARDWARE MAY
LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO
SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE
SERIOUS INJURY.
When lock or spring washer is used in
an assembly, please make sure the
lock or spring washer is placed
between the larger flat washer and the
head of the screw or bolt.
Some furniture comes with height
adjusetment knobs underneath each
leg. To lower or to raise each leg, you
need to turn clockwise or
counterclockwise, respectively.
FURNITURE OF AMERICA.ALL RIGHTS RESERVED.
Make sure all parts are properly
aligned, then use the appropriate
hand tool to completely tighten the
bolts or screws. Do not use power
tools and do not overtighten.
Position each part correctly and insert
screws or bolts into their respective
holes by hand tighten or using the
proper hand tool. Only tighten when
step is completed or when instructed
to do so.
Save the instructions and store the Allen
wrench or any supplied tool for later
maintenance. After two weeks, check and
tighten any loose hardware and repeat
again every six months thereafter.
Use cardboard or carpet area when
assembling furniture to prevent
scratches .Make sure the furniture
rests on a flat and level surface with
each leg evenly touching the floor.
No dragging of products/parts.
Page 2 of 7

Before you begin, please read Page 2
of "Assembly and Care Advice".
And remember, do not tighten until
each step is completed or instructed.
Page 3 of 7
Parts List
#A x 14pcs
#1 x 1pc
Headboard panel
#3 x 1pc
Foot board
#B x 14pcs
#C x 14pcs
#D x 1pc
#4 x 2pcs
Side Rail
#5 x 4pcs
Bed slat
#6 x 8pcs Ø1/4"
Support Leg 28x28x210mm
#2 x 2pcs
Headboard legs (L+R)
#7 x 1pc
Headboard Support
#E x 8pcs
#F x 8pcs
#G x 8pcs
#H x 1pc
Bolt Ø5/16"x1-3/4"
Lock washer Ø5/16"
Flat Washer Ø5/16"
Allen Key 4mm
Threaded Pins Ø5/16"x3-1/2"
Hex Nut Ø5/16"
Nut Ø5/16"
Wrench 14mm
#8 x 2pcs
Top Bed Rail

#1
#2L
#2R
#3
#4
#4
#5
#6
#7
Before you begin, please read Page 2
of "Assembly and Care Advice".
And remember, do not tighten until
each step is completed or instructed.
#J x 12pcs
#K x 12pcs
Bolt Ø1/4"x1-3/4"
Lock washer Ø1/4"
#L x 12pcs
Flat Washer Ø1/4"
Page 4of 7
#I x 8pcs
Screw #4x1-3/16"
Hardware List

#1
#E
#F
#G
#H
#3
#4
#4
#E x 8pcs
#F x 8pcs
#G x 8pcs
#A x 14pcs
#B x 14pcs
#C x 14pcs
Page 5 of 7
#1
#2R
#7
#C #B #A
#D
#C
#B
#A
#D
#2L
Align HB legs (#2R/L) to the holes of the
headboard (#1) and HB support (#7),
then secure by using bolts (#A) with
washers (#B,C).
Attach threaded pins (#E) to the headboard (#1) and footboard
(#3), then align the side rails (#4) to the threaded pins (#E). Secure
by using hex nut (#F) with washer (#G).

Page 6 of 7
#5
#6
x 4
#I x 8pcs
#I
#4
#4
#5
Attach support legs (#6) to the bed slats (#5). Adjust leveler of the
support legs (#6) according to ground level.
Align slats (#5) to the side rails (#4), then secure by using screws (#I).

Page 7 of 7
ASSEMBLY IS COMPLETED
#L #K #J
#D
#J x 12pcs
#K x 12pcs
#L x 12pcs
Align top bed rails (#8) to the side rails, then secure
by using bolts (#J) with washers (#K,L).
