Furrion FMSN09A-BL/2022005805 User manual

0.9 CU.FT. BUILT-IN MICROWAVE OVEN
0,9CU.FT. FOUR MICRO-ONDES ENCASTRABLE
HORNO DE MICROONDAS INTEGRABLE DE 0.9
PIES CÚBICOS
FMSNABL/; FMSNASS/
USER MANUAL/GUIDE D’UTILISATION/MANUAL DE USUARIO
* Product picture for reference only
* Les images du produit sont données à titre indicatif uniquement
* Imagen con fines solamente ilustrativos

English
CCD-0005771 Rev: 09-16-22 - 1 -
Thank you for purchasing this Furrion® product. Before operating your new product,
please read these instructions carefully. This user manual contains information for
safe use, installation and maintenance of the product.
Please keep this user manual in a safe place for future reference. This will ensure safe
use and reduce the risk of injury. Be sure to pass on this manual to new owners of this
product.
The manufacturer does not accept responsibility for any damages due to not
observing these instructions.

English
CCD-0005771 Rev: 09-16-22
- 2 -
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS...................................................................... 
General Safety Instructions ..................................................................................................................3
Grounding Instructions............................................................................................................................5
Electrical Requirements..........................................................................................................................5
Radio or TV Interference ........................................................................................................................5
California Residents Only.......................................................................................................................6
PRODUCT OVERVIEW ...................................................................................................... 
Product Features ........................................................................................................................................7
Control Panel.................................................................................................................................................8
Installation.......................................................................................................................................................9
What’s in the Box.........................................................................................................................................9
Before Installation.......................................................................................................................................9
Microwave Oven Installation ................................................................................................................9
Electrical Connection...............................................................................................................................11
QUICK COOK PROGRAMS ............................................................................................. 
OPERATION .......................................................................................................................... 
COOKING TECHNIQUES................................................................................................. 
UTENSILS GUIDE................................................................................................................ 
CLEANING AND CARE...................................................................................................... 
TROUBLESHOOTING ....................................................................................................... 
SPECIFICATION................................................................................................................... 

English
CCD-0005771 Rev: 09-16-22 - 3 -
IMPORTANT SAFETY INSTRUCTIONS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
1. Do not attempt to operate this oven with the door open since open door operation
can result in harmful exposure to microwave energy. It is important not to defeat
or tamper with the safety interlocks.
2. Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is particularly important that the oven
door closes properly and that there is no damage to the:
a. DOOR (bent)
b. HINGES AND LATCHES (broken or loosened)
c. DOOR SEALS AND SEALING SURFACES
4. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
General Safety Instructions
WARNING - When using electrical appliances basic safety precautions should be
followed, including the following. To reduce the risk of burns, electric shock, fire, injury
to persons or exposure to excessive microwave energy.
1. Read all instructions before using the appliance.
2. Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY” found on page 3.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS” found on page 5.
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. HOT CONTENTS CAN CAUSE SEVERE BURNS. DO NOT ALLOW CHILDREN
TO USE THE MICROWAVE. Use caution when removing hot items.
6. When cleaning surfaces of door and oven that comes together on closing the
door, use only mild, nonabrasive soaps, or detergent applied with a sponge or soft
cloth.
7. Keep cord away from heated surface.
8. Liquids, such as water, coffee, or tea are able to overheat beyond the boiling point
without appearing to be boiling. Visible bubbling or boiling when the container is
removed from the microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk
of injury to persons:
a. Do not overheat the liquid.
b. Stir the liquid both before and halfway through heating it.
c. Do not use straight-sided containers with narrow necks.

English
CCD-0005771 Rev: 09-16-22
- 4 -
d. After heating, allow the container to stand in the microwave oven for a short
time before removing the container.
e. Use extreme care when inserting a spoon or other utensil into the container.
9. This appliance should be serviced only by qualified service personnel. Contact
nearest authorized service facility for examination, repair, or adjustment.
10. To reduce the risk of fire in the oven cavity:
a. Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bag before placing bag in oven.
c. If material inside of the oven ignite, keep oven door closed, turn oven off, and
disconnect the power cord, or shut off power at the fuse or circuit breaker
panel.
d. Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
11. Some products such as whole eggs and sealed containers, for example, closed
glass jars are able to explode and should not be heated in this oven.
12. Do not cover or block any openings on the appliance.
13. Do not store this appliance outdoors. Do not use this product near water - for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar
location.
14. Use this appliance only for its intended use as described in the manual. Do
not use corrosive chemicals or vapors in this appliance. This type of oven is
specifically designed to heat, cook or dry food. It is not designed for industrial or
laboratory use.
15. Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
16. Do not immerse cord or plug in water or any other liquid.
17. Do not let cord hang over edge of table or counter.
18. Do not operate any heating or cooking appliance beneath the appliance.
(Exception: A microwave oven investigated for use above another heating
appliance.)
19. Do not mount unit over or near any portion of heating or cooking appliance.
(Exception: A microwave oven investigated for use above another heating
appliance.)
20. Do not mount over sink.
21. Do not store anything directly on top of the appliance surface when the appliance
is in operation.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY(NOT FOR
COMMERCIAL USE)

English
CCD-0005771 Rev: 09-16-22 - 5 -
CAUTION
●NOTICE: PACEMAKERS
Most pacemakers are shielded from interference from electronic products,
including microwaves. However, patients with pacemakers may wish to consult
their physicians if they have concerns.
●Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the product.
Grounding Instructions
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an escape wire for the electric current.
WARNING - Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly
grounded.
If it is necessary to use an extension cord, use only a 3-wire extension cord that has
a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the
appliance. The marked rating of the extension cord shall be equal to or greater than
the electrical rating of the appliance.
Electrical Requirements
The electrical requirements are a 120 volt, 60 Hz, AC only, 15 amp or 20 amp
dedicated circuit. It is recommended that a separate circuit serving only the oven be
provided. The oven is equipped with a 3-prong grounding plug. It must be plugged
into a wall receptacle that is properly installed and grounded.
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV,
check that the microwave oven is on a different circuit, relocate the radio or TV as far
away from the oven as feasible or check position and signal of receiving antenna.

English
CCD-0005771 Rev: 09-16-22
- 6 -
California Residents Only
WARNING
This product can expose you to chemicals such as Di (2-ethylhexyl) phthalate
(DEHP), which is known to the State of California to cause cancer and birth defects
or other reproductive harm. For more information go to www.P65Warnings.ca.gov
This device complies with part 18 of
the FCC Rules.
SAVE THESE INSTRUCTIONS

English
CCD-0005771 Rev: 09-16-22 - 7 -
PRODUCT OVERVIEW
Product Features
2
1
3 4
7
5
6
8
Item Description
1Door Safety Lock System
2Oven Window
3Roller Ring
4Shaft
5Glass Tray
6Door Release Button
7Control Panel
8Wave Guide (Do not remove the mica plate covering the wave guide)

English
CCD-0005771 Rev: 09-16-22
- 8 -
Control Panel
DISPLAY
Cooking time, power, indicators and
present time are displayed.
TIME COOK
Cook with the setting you
programmed.
TIME DEFROST
Defrost by the time you input.
WEIGHT DEFROST
Defrost by the weight you input.
POWER
Set the cooking power or check power
level during cooking.
CLOCK
Set the time of day.
KICTHEN TIMER
Set a timer to cook.
QUICK COOK BUTTONS
Instant settings to cook popular foods
EXPRESS COOK (1-6)
Press numbers 1 through 6 to quickly
select a time cooked setting from 1 to
6 minutes.
NUMBER BUTTONS (0-9)
Set the time, power or weight
STOP/CANCEL
Stop/cancel a setting.
0/MEMORY
Set and memory a program.
START/+30 SEC
Press to start cooking. During the
cooking process, press to increase the
cooking time.

English
CCD-0005771 Rev: 09-16-22 - 9 -
INSTALLATION
What’s in the Box
Make sure all the following items are
included in the packaging. If any item
is damaged or missing, contact your
dealer.
●Microwave oven body x 1
●Glass tray x 1
●Glass tray roller ring x 1
●User manual x 1
●Warranty manual x 1
Before Installation
1. Make sure that all the packing
materials are removed from the oven
cavity.
2. Check the oven for any damage,
such as misaligned or bent door,
damaged door seals and sealing
surface, broken or loose door hinges
and latches and dents inside the
cavity or on the door. If there is
any damage, do not operate the
oven and contact qualified service
personnel.
3. This microwave oven must be
placed on a flat, stable surface to
hold its weight and the heaviest food
likely to be cooked in the oven.
4. Do not place the oven where heat,
moisture, or high humidity are
generated, or near combustible
materials.
5. The oven must have sufficient
airflow. Do not cover or block any
openings on the oven. Do not
remove feet on which oven stands.
6. Do not operate the oven without
glass tray, roller support, and shaft in
their proper positions.
7. Make sure that the power supply
cord is good in condition and does
not run under the oven or over any
hot or sharp surface.
8. The electrical plug or the circuit
breaker must be accessible so that
it can be easily unplugged in an
emergency.
Microwave Oven
Installation
WARNING
For built-in installations, you have
to use the upper and bottom ducts
provided with trim kit FMSN09A-
BL-TK/FMSN09A-SS-TK. Failure to
comply would lead to overheating of
the device.
Cabinet Preparation
1. Select a suitable place that is not
susceptible to moisture.
2. Mark and cutout an opening in the
cabinet according to the dimensions
outlined in the table.
A
B
C
A13⅜" (340mm) Min.
B20" (510mm) Min.
C14⅛" (359mm) Min.

English
CCD-0005771 Rev: 09-16-22
- 10 -
Bottom Duct Installation (sold
together with FMSN09A-BL-
TK or FMSN09-SS-TK trimkit)
1. Mark out the cabinet center line as
shown in the figure below.
Cabinet center line
2. Locate the bottom duct into the
cabinet opening. Ensure the duct
bottom is center aligned to the
cabinet center line. Fix the bottom
duct with four M4 x ⅜” self-tapping
screws.
Bottom duct and cabinet
are aligned as shown.
Trim Kit Installation
(FMSN09A-BL-TK/FMSN09A-
SS-TK, not included)
1. Remove the trim kit from the
packaging. Check to make sure it is
not damaged.
2. Fit the trim kit over the oven front
panel and fix with four M4 x ⅝” self-
tapping screws on side.
Upper Duct Installation (sold
together with FMSN09A-BL-
TK or FMSN09-SS-TK trimkit)
Install the upper duct on the top of the
oven and fix it with four M4 x ⅝” self-
tapping screws.
Oven Installation
Slide the microwave oven into the
cabinet opening and fix it to the cabinet
with four M4 x ⅜” self-tapping screws.

English
CCD-0005771 Rev: 09-16-22 - 11 -
Turntable Installation
Glass Tray
Hub (underside)
Turntable ring assy.
Turntable shaft
●Never place the glass tray upside
down. The glass tray should never
be restricted.
●Both the glass tray and turntable
ring assembly must always be used
during cooking.
●All food and containers of food are
always be placed on the glass tray
for cooking.
●If glass tray or turntable ring
assembly cracks or breaks, contact
your nearest authorized service
center.
Electrical Connection
Connect the microwave oven to a 120
volt, 60 Hz, AC only, 15 amp or 20 amp
dedicated circuit. It is recommended
that an individual circuit serving only the
microwave oven be provided.
QUICK COOK PROGRAMS
The Quick Cook programs allow you
to cook or reheat food automatically
without selecting power level and time.
POPCORN
1. Press “POPCORN” repeatedly, the
number “1.75”, “3.0”, “3.5” will be
displayed in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number indicates the weight
of food.
POTATO
1. Press “POTATO” repeatedly, the
number “1”, “2”, “3” will be displayed
in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number displayed indicates
the number of potatoes. Approximate
weight of a single potato is 8 oz.
PIZZA
1. Press “PIZZA” repeatedly, the
number “4.0”, “8.0”, “14.0” will be
displayed in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.

English
CCD-0005771 Rev: 09-16-22
- 12 -
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number indicates the weight
of food in oz.
FROZEN VEGETABLE
1. Press “FROZEN VEGETABLE”
repeatedly, the number “4.0”, “8.0”,
“16.0” will be displayed in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number indicates the weight
of food in oz.
BEVERAGE
1. Press “BEVERAGE” repeatedly, the
number “1”, “2”, “3” will be displayed
in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number indicates the cup of
beverage, one cup is about 120ml.
DINNER PLATE
1. Press “DINNER PLATE” repeatedly,
the number “9.0”, “12.0”, “18.0” will be
displayed in order.
2. Once the number you desired is
displayed, press “START/+30 SEC”
to start cooking, the buzzer will
sound once.
3. When the cooking is finished, the
buzzer will sound five times then
return to standby mode.
NOTE: The number indicates the weight
of food in oz.
OPERATION
POWER LEVEL
There are 11 power levels available to
select:
Number
button
Power
Level
Cooking
Power
Screen
Display
1,0 10 100% PL10
9990% PL9
8880% PL8
7770% PL7
6660% PL6
5550% PL5
4440% PL4
3330% PL3
2220% PL2
1110% PL1
000% PL0

English
CCD-0005771 Rev: 09-16-22 - 13 -
CLOCK SETTING
1. Press “CLOCK “once, the “00:00” will
be displayed.
2. Use the number buttons to enter the
current time. For example, the time
is 12:10 now, press “1, 2, 1, 0” buttons
accordingly.
NOTE: It is a 12-hour clock system,
the clock range allowed to be set is
1:00--12:59.
3. Press “CLOCK” to finish the clock
setting.
4. Repeat steps 1 to 3 to reset the clock
if you want to reset it.
NOTE: In the process of clock setting, if
the “STOP/CANCEL” button is pressed
or if there is no operation within 1 minute,
the oven will return to the previous
setting automatically.
KITCHEN TIMER
1. Press “KITCHEN TIMER” once, the
“00:00” will be displayed.
2. Use the number buttons to set the
timer. The maximum timer allowed to
set is 99 minutes and 99 seconds.
3. Press “START/+30SEC.” to confirm
the setting.
4. When the timing is finished, the
buzzer will sound five times, then
return to the clock displaying.
NOTE: You are not allowed to change
the program setting during the timing
process.
TIME COOK
1. Press “TIME COOK” once, the
screen will display “00:00”.
2. Use the number buttons to input
the cooking time. The maximum
cooking time is 99 minutes and 99
seconds.
3. Press “POWER” once, the screen
will display “PL10”. Press the number
button to adjust the power level.
NOTE: The default power is 100%
power.
4. Press “START/+30SEC.” to start
cooking. The remaining cooking
time is displayed and start counting
down.
For example, if you want to cook the
food with 50% microwave power for 15
minutes.
1. Press “TIME COOK” once.
2. Press “1”, “5”, “0”, “0” in order.
3. Press “POWER” once, then press “5”
to select 50% cooking power.
4. Press “START/+30SEC.” to start
cooking.
NOTES:
●In the process of setting, if the
“STOP/CANCEL” button is pressed
or if there is no operation within 1
minute, the oven will return to the
previous setting automatically.
●If the “PL0” power level is selected,
the oven will work with fan mode
only.
NOTE: You can use the “PL0” level
to remove the odor of the oven.
●During the cooking process, you
are allowed to change the cooking
power by pressing the “POWER”
button. Once the “POWER” button is
pressed, the current power will flash
for 3 seconds, then you can press
the number button to change the
power.
EXPRESS COOKING
●In standby mode, press the number
buttons 1 to 6 to select 1 to 6 minutes
of cooking at instantly 100% power
level. Press “START/+30SEC.” to
increase the cooking time during
the cooking process, each press

English
CCD-0005771 Rev: 09-16-22
- 14 -
will increase cooking time by 30
seconds. The maximum cooking
time is 99 minutes and 99 seconds.
●In standby mode, press
“START/+30SEC” to start 30
seconds of cooking at instantly
100% power level. During
microwave cooking and time
defrost ,time can be added by
pressing “START/+30EC”button
The maximum cooking time is 99
minutes and 99 seconds.
WEIGHT DEFROST
1. Press “WEIGHT DEFROST” once,
the screen will display “dEF1”.
2. Use the number buttons to input the
food weight to be defrosted. The
valid weight range is 4~100 Oz.
3. Press “START/+30SEC.” to start
defrosting. The defrosting time will
be displayed and start counting
down.
TIME DEFROST
1. Press “TIME DEFROST” once, the
screen will display “dEF2”.
2. Use the number buttons to input the
defrosting time. The valid time range
is 0:01~99:99.
3. Press “START/+30SEC.” to start
defrosting. The defrosting time will
be displayed and start counting
down.
NOTE: The default defrosting power is
level 3. If you want to change the power
level, press “POWER” once, then press
the number button to choose a desired
defrosting power level.
MEMORY FUNCTION
If a program has been memorized in the
system.
1. Press “0/MEMORY” repeatedly, the
number “1”, “2”, “3” will be displayed
in order.
2. Once the number where the
program to be saved is displayed,
press “START/+30 SEC” to start
cooking by using the saved program.
For example, to set a new program of
“To cook the food with 80% microwave
power for 3 minutes and 20 seconds.”
as the second memory, the steps are as
follows:
1. In standby mode, press “0/
MEMORY” twice, the number “2” will
be displayed.
2. Press “TIME COOK” once, then
press “3”, “2”, “0” in order.
3. Press “POWER” once, the screen will
display “PL10”. Press “8” to change
the power level to “PL8”.
NOTE: The default power is 100%
power.
4. Press “START/ +30 SEC” once to
save the program. The buzzer will
sound once and the screen displays
“2”.
NOTE: The memory will not be cleared
unless the power is cut off. Or you need
to reset the program.
MULTISTAGE COOKING
At most 2 multi-stage programs can be
set for cooking.
For example, if you want to cook with
80% microwave power for 5 minutes and
60% microwave power for 10 minutes.
The cooking program can be set as
follows:
1. Press “TIME COOK” once, then
press “5”, “0”, “0” to set the cooking
time.
2. Press “POWER” once, then press “8”
to select 80% microwave power.
3. Press “TIME COOK” once, then

English
CCD-0005771 Rev: 09-16-22 - 15 -
press “1”, “0”, “0”, “0” to set the
cooking time.
4. Press “POWER” once, then press “6”
to select 60% microwave power.
5. Press “START/ +30 SEC” to start
cooking.
NOTE: If the defrosting stage is included
in multi-stage cooking, the defrosting will
be set as the first stage automatically.
The auto cooking function is unusable
during multi-stage cooking.
CHILD LOCK
The child lock function prevents
unsupervised operation by children.
To lock: In standby mode, press and
hold “STOP/CANCEL” for 3 seconds, a
long “beep” will be heard indicating the
oven has entered into the lock mode, the
screen displays “ ”.
To unlock: Press and hold “STOP/
CANCEL” for 3 seconds, a long “beep”
indicating the oven is unlocked, the “
” disappeared from the screen.
INQUIRING FUNCTION
●In cooking mode, press “CLOCK”,
the clock will be displayed for 3
seconds and then disappeared.
●In cooking mode, press “POWER”
the current power level will be
displayed for 3 seconds and then
disappeared.
COOKING END REMINDING
When the cooking is finished, the buzzer
will beep 5 times to alert the user the
cooking is finished.
COOKING TECHNIQUES
Your microwave makes cooking easier
than conventional cooking, provided you
keep these considerations in mind:
STIRRING
Stir foods such as casseroles and
vegetables while cooking to distribute
heat evenly. Food at the outside of the
dish absorbs more energy and heats
more quickly, so stir from the outside to
the center. The oven will turn off when
you open the door to stir your food.
ARRANGEMENT
Arrange unevenly shaped foods, such
as chicken pieces or chops, with the
thicker, meatier parts toward the outside
of the turntable where they receive
more microwave energy. To prevent
overcooking, place delicate areas, such
as asparagus tips, toward the center of
the turntable.
SHIELDING
Shield food with narrow strips of
aluminum foil to prevent overcooking.
Areas that need shielding include poultry
wing tips, the ends of poultry legs, and
corners of square baking dishes. Use
only small amounts of aluminum foil.
Larger amounts can damage your oven.
TURNING
Turn foods over midway through cooking
to expose all parts to microwave energy.
This is especially important with large
foods such as roasts.
STANDING

English
CCD-0005771 Rev: 09-16-22
- 16 -
Foods cooked in the microwave build
up internal heat and continue to cook
for a few minutes after heating stops.
Let foods stand to complete cooking,
especially foods such as cakes and
whole vegetables. Roasts need this
time to complete cooking in the center
without overcooking the outer areas. All
liquids, such as soup or hot chocolate,
should be shaken or stirred when
cooking is complete. Let liquids stand a
moment before serving. When heating
baby food, stir well at removal and test
the temperature before serving.
ADDING MOISTURE
Microwave energy is attracted to water
molecules. Food that is uneven in
moisture content should be covered
or allowed to stand so that the heat
disperses evenly. Add a small amount of
water to dry food to help it cook.
UTENSILS GUIDE
This section lists which utensils can
be used in the microwave, which ones
have limited use for short periods, and
which ones should not be used in the
microwave.
RECOMMENDED
Microwave browning dish - Use to
brown the exterior of small items such as
steaks, chops, or pancakes. Follow the
directions provided with your browning
dish.
Microwaveable plastic wrap - Use
to retain steam. Leave a small opening
for some steam to escape and avoid
placing it directly on the food.
Paper towels and napkins - Use for
short-term heating and covering; these
absorb excess moisture and prevent
spattering. Do not use recycled paper
towels, which may contain metal and
could ignite.
Glass and glass-ceramic bowls and
dishes - Use for heating or cooking.
Paper plates and cups - Use for short-
term heating at low temperatures. Do not
use recycled paper, which may contain
metal and could ignite.
Wax paper - Use as a cover to prevent
spattering.
Thermometers - Use only those
labeled “Microwave Safe” and follow all
directions. Check the food in several
places. Conventional thermometers may
be used on microwave food once the
food has been removed from the oven.
LIMITED USE
Aluminum foil - Use narrow strips of
foil to prevent overcooking of exposed
areas. Using too much foil can damage
your oven, so be careful. You should
keep distance of 1 inch (25.4mm)
between aluminum foil and cavity.
Ceramic, porcelain, and stoneware -
Use these if they are labeled “Microwave
Safe”. If they are not labeled, test them to
make sure they can be used safely.
Plastic - Use only if labeled “Microwave
Safe”. Other plastics can melt.
Not Recommended
Glass jars and bottles - Regular glass
is too thin to be used in a microwave.
It can shatter and cause damage and
injury.
Paper bags - These are a fire hazard,

English
CCD-0005771 Rev: 09-16-22 - 17 -
except for popcorn bags that are
designed for microwave use.
Styrofoam plates and cups - These
can melt and leave an unhealthy residue
on food.
Plastic storage and food containers
- Containers such as margarine tubs can
melt in the microwave.
Metal utensils - These can damage
your oven. Remove all metal before
cooking.
NOTE: Should you wish to check if a
dish is safe for microwaving, place the
empty dish in the oven and microwave
on HIGH for 30 seconds. A dish which
becomes very hot should not be used.
CLEANING AND CARE
1. Turn off the oven and remove the
power plug from the wall socket
before cleaning.
2. Keep the inside of the oven clean.
When food splatters or spilled liquids
adhere to oven walls, wipe with a
damp cloth. Mild detergent may
be used if the oven gets very dirty.
Avoid the use of spray and other
harsh cleaners as they may stain,
streak or dull the door surface.
3. The outside surfaces should be
cleaned with a damp cloth. To
prevent damage to the operating
parts inside the oven, water should
not be allowed to seep into the
ventilation openings.
4. Wipe the window on both sides with
a damp cloth to remove any spills or
spatters.
5. Do not allow the control panel to
become wet. Clean with a soft,
damp cloth. When cleaning the
control panel, leave oven door open
to prevent oven from accidentally
turning on.
6. If steam accumulates inside or
around the outside of the oven door,
wipe with a soft cloth. This may
occur when the microwave oven
is operated under high humidity
conditions. In such case, it is normal.
7. It is occasionally necessary to
remove the glass tray for cleaning.
Wash the tray in warm sudsy water
or in a dishwasher.
8. The roller ring and oven floor should
be cleaned regularly to avoid
excessive noise. Simply wipe the
bottom surface of the oven with
mild detergent. The roller ring may
be washed in mild sudsy water
or dishwasher. When removing
the roller ring from cavity floor for
cleaning, be sure to replace in the
proper position.
9. Remove odors from your oven by
combining a cup of water with the
juice and skin of one lemon in a deep
microwaveable bowl, microwave for
5 minutes. Wipe thoroughly and dry
with a soft cloth.
10. When it becomes necessary to
replace the oven light, please
consult a dealer to have it replaced.
11. The oven should be cleaned
regularly and any food deposits
removed. Failure to maintain the
oven in a clean condition could lead
to deterioration of the surface that
could adversely affect the life of the
appliance and possibly result in a
hazardous situation.
12. Please do not dispose this appliance
into the domestic rubbish bin;
it should be disposed to the
particular disposal center provided
by the municipalities.

English
CCD-0005771 Rev: 09-16-22
- 18 -
TROUBLESHOOTING
Check your problem by using the chart below and try the solutions for each problem.
If the microwave oven still does not work properly, contact the nearest authorized
service center.
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Oven will not
start
–Electrical cord for oven is not plugged in.
–Door is open.
–Wrong operation is set.
–Plug into the outlet.
–Close the door and try again.
–Check instructions.
–Check circuit breaker
Arcing or
sparking
–Materials to be avoided in microwave
oven were used.
–The oven is operated when empty.
–Spilled food remains in the cavity.
–Use microwave-safe cookware only.
–Do not operate with oven empty.
–Clean cavity with wet towel.
Unevenly
cooked foods
–Materials to be avoided in microwave
oven were used.
–Food is not defrosted completely.
–Cooking time, power level is not suitable.
–Food is not turned or stirred.
–Use microwave-safe cookware only.
–Completely defrost food.
–Use correct cooking time, power level.
–Turn or stir food.
Overcooked
foods
–Cooking time, power level is not suitable. –Use correct cooking time, power level.
Undercooked
foods
–Materials to be avoided in microwave
oven were used.
–Food is not defrosted completely.
–Oven ventilation ports are restricted.
–Cooking time, power level is not suitable.
–Use microwave-safe cookware only.
–Completely defrost food.
–Check to see that oven ventilation ports
are not restricted.
–Use correct cooking time, power level.
Improper
defrosting
–Materials to be avoided in microwave
oven were used.
–Cooking time, power level is not suitable.
–Food is not turned or stirred.
–Use microwave-safe cookware only.
–Use correct cooking time, power level.
–Turn or stir food.
SPECIFICATION
Technical Specification
Rated Input Power 120V/60Hz, 1350W (MICROWAVE)
Rated Output Power (Microwave) 900 W
Product Dimensions (W×D×H) 19⅛" x14¾" x 13⅜" (485 x 375 x 340mm)
Oven Capacity 0.9 cu. ft.
Turntable Diameter Ø10.6" / Glass
Net Weight Approx. 27.6 lbs.

CCD-0005771 Rev: 09-16-22 - 19 -
Français
Nous vous remercions d’avoir acheté ce produit Furrion®. Avant d’utiliser votre nouveau produit,
il faut lire attentivement ce manuel. Ce guide d’utilisation contient des informations pour une
utilisation, une installation et une maintenance sûres du produit.
Il faut conserver ce guide d’utilisation dans un endroit sûr pour toute référence future. Cela garantit
une utilisation en toute sécurité et réduit tout risque de blessure. Assurez-vous de transmettre ce
guide d’utilisation aux nouveaux propriétaires de ce produit.
Le fabricant décline toute responsabilité en cas de dommages dus au non-respect de ces
instructions.
