FYC JK1608E-1 User manual

Thank you very much for purchasing our product. Please read
this manual carefully before use it
and keep the manual at proper place.
Electric Folding
Treadmill
JK1608E-1
Thank you very much for purchasing our product. Please read
this manual carefully before useing it
and keep the manual at the proper place.

As shoppers, we're always trying to find the
perfect balance between quality & value. At
FYC, we believe we've achieved that. Our
diverse catalog of everyday essentials is
tailored especially to our customers &
guaranteed to hit that sweet spot of high quality
& low price.
Always

ŸFor safety purpose, do not stand on running belt while start.
ŸPlease stop immediately if you experience any kind pain, including but not limited to chest
pains,nausea, dizziness, or cramp.
ŸPlease speed up slowly if needed.
ŸAdjustment of belt is prohibited during using.
ŸIt is suggested to wear sports shoes and gym suit while using this equipment.
ŸChildren, the elder, the pregnant, and patients are prohibited from using this treadmill.
ŸPlease clip the safety key on your clothing during using.
ŸPlease firmly hold the handle bars during using.
To avoid injury please read this manual carefully before operating this machine
ŸPlease put the treadmill on flat ground. It is unsuitable to put the treadmill at following places:
ŸThe proper power for the treadmill is A.C 110V.
ŸError may appear on display if the power is not stable. Please do not use the same socket
together with computer, air conditioner etc.
ŸIt is suggested to wear sports shoes and gym suit while use the treadmill.
ŸPlease speed up or speed down slowly.
ŸMake sure no child or other object is near while folding or unfolding the treadmill.
ŸThe treadmill should not be located near water or wet object. Error or damage may be caused
if water or other liquids drop into the equipment.
1
SAFETY NOTICE
CAUTION
1
2Slant ground or slant places on balcony.
3Sunlight area or near heater.
4Noisy places.
Outdoors. (The treadmill is specially designed for indoor use only)

ŸIf you do not feel well before using, please consult your doctor or coach.
ŸPlease unplug the equipment when not in use.
ŸPlease unplug the treadmill before cleaning, moving or change parts for the treadmill.
ŸChildren, the elder and the pregnant are prohibited from using the treadmill. Patients should
consult their doctor before starting any exercise routine.
ŸPlease place the treadmill on a level flat surface. There should be 2M of clearance behind
thetreadmill.
ŸDo not start the treadmill when it is folded.
ŸKeep all electrical components, especially motor, power cord and plug, away from water or
other liquids.
ŸDo not wear clothes like long dress, which might catch on any part of the treadmill while using.
ŸDo not place the treadmill in an area that will block any vent or air openings.
ŸDo not put any objects on the treadmill.
ŸPut away the plug from heated place or fire seat.
ŸPlease switch off all functions and unplug after using.
ŸDo not stand on the belt while you're preparing to use the treadmill.
ŸDo not disassemble the treadmill without consulting professional technicians.
ŸPlease make sure the running belt is fastened before using.
CAUTION DURING USE
Keep both the machine and power cord away from heated surfaces.
2

TOOLS REQUIRED
HARDWARE
PRODUCTS MAIN PARTS
3
PAD Holder
Console
2、
Handrail
3、
Safety Key
4、
5、
1、
220
LockKnod
6、
Motor Cover
7、Running Belt
9、
Side Rail
8、
End Cap
10、
Lock Knob Round Washer
2 PCS 2 PCS
12
Safety Key
1 PCS
3
ALLEN WRENCH
(PROVIDED)
SILICONE OIL
(PROVIDED)
1
23
4
5
67
8
910
Rubber Pad

4
PARTS
RUNNINGDECK
PARTS
PARTSPRODUCT ASSEMBLY
1
After taking the treadmill out of the carton, first install washer on the lower end
of the frame, screw the knob
NOTE
DO NOT TIGHTEN THE KNOBS FIRST
2
1
1
2
PAD HOLDER
2

PARTSPRODUCT ASSEMBLY
2
Raise the handrail to the corresponding slot position of the main shaft,
and then tighten the knob.
3
Insert the pad holder, put the safety key, and complete the assembly.
5

6
PARTS
FOLDING UP AND SETTING DOWN
FOLD:
Take off IPAD holder, unscrew the knob, lie down the handrail.
Then screw the knob with the frame.
TECHNICAL SPECIFICATION
Product name JK1608E-1
Voltage 110V
Frequency 50-60Hz
Speed 0.5-6.5MPH
NOTE: Ensure the Power Switch is in the 'OFF' position and the power cord is unplugged from the electrical outlet.
UNFOLD:
Loosen the knob and uplift the handrail to the certain angle, then insert the pad holder.
5
5

PARTSCONSOLE INSTRUCTON
7
(1). Window shows
1.1 "TIME" window:
hows the running time. Forward travel-time is from 0:00-99:59,
countdown is counted to O from the set time (set cope 5:00~99:00), when count to 0:00,
the treadmill will stop slowly.
"CALORIES" window:
forward count from 0-99, when forward countdown reaches the top point, it will recount.
When calories count down (calories set cope 20.0-990.0), it will count to O from the set
point; when count to 0:00, the treadmill will stop slowly. When in motion state, press "M"
key, the window will switch from Time, Calories, Distance, Step
1.2 "SPEED" window:
shows the current running speed, speed range is 0.5-6.5mph
1.3 "DISTANCE" window:
shows the current movement distance. Forward countdown is from 0.0~99.9.
When forward count down reaches the top point, it will recount. When distance count
down (distance set cope 1.00~99.00) it will count to O from the set point, the treadmill
will stop slowly.
"STEP" window:
Forward step count is from 0-9999. When forward countdown reaches the top point,
it will recount.
(2). Functional instruction
2.1 Sports Mode:
Press "START" key to start the treadmill, SPEED window will count from "3 2 1".
The default speed is 0.5MPH, press "+" or "-" to adjust speed.
2.2 Countdown Mode:
when in standby, press "M" key to choose Time, Distance or Calories countdown.
Press "+" or "-" to set relevant data. After setting, press "START/STOP" to start the treadmill
and it will count down from the set data. When count to O, the machine will stop by itself.
2.3 Pre-set Program (01-P12):
choose one program, then press "+" or "-" to set the running time (time set cope 5:00~99:00
, default time is 30:00). Press "START/STOP" to start the treadmill, it will run based on the pr
e-set speed. Speed changes according to the time "(Time/20)"

TOTAL 12 PROGRAMS AS BELOW
8
1.2
1.2
1.2
1.2
1.9
1.9
1.9
1.9
2.5
2.5
2.5
2.5
1.2
1.9
2.5
3.1
1.9
5
2.5
3.1
4.4
3.1
5
2.5
1.9
2.5
2.5
3.1
3.1
5
3.7
3.7
1.9
1.9
3.7
4.4
2.5
3.1
3.7
3.7
4.4
4.4
3.7
4.4
4.4
5
5
5
3.1
3.7
3.7
3.7
3.7
5
5
5
4.4
5
4.4
1.2
1.9
2.5
2.5
3.7
3.7
3.7
3.7
5
4.4
5
3.7
5
2.5
3.7
4.4
3.7
5
5
5
4.4
5
5
3.7
5
3.1
3.7
4.4
2.5
3.1
3.7
4.4
5
5
5
5
5
3.1
3.7
4.4
2.5
3.1
2.5
3.1
2.5
3.1
2.5
3.1
5
1.9
2.5
2.5
1.2
5
1.2
3.7
4.4
5
5
5
5
2.5
3.1
4.4
1.2
5
3.1
3.7
4.4
5
5
3.7
3.1
1.2
1.2
1.2
1.2
1.9
1.9
1.9
1.9
1.9
1.2
1.2
2.5
1.9
1.9
1.9
2.5
2.5
2.5
3.1
3.1
3.1
3.7
5
5
3.1
3.1
1.9
3.7
3.1
3.7
3.7
4.4
4.4
4.4
5
5
1.9
2.5
3.1
3.7
4.4
5
3.7
5
4.4
5
4.4
5
1.2
1.2
1.2
3.7
3.1
3.7
4.4
4.4
5
4.4
3.7
1.2
2.5
2.5
2.5
3.7
5
3.7
5
5
5
4.4
3.7
5
2.5
2.5
2.5
3.7
3.1
3.7
4.4
4.4
4.4
5
3.7
5
2.5
2.5
2.5
4.4
3.7
4.4
3.7
4.4
3.7
4.4
3.7
4.4
3.1
3.7
4.4
2.5
3.1
2.5
2.5
3.7
4.4
2.5
3.7
5

9
PARTSUSAGE OF SILICONE OIL
PARTSRUNNING BELT ADJUSTMENT
https://youtu.be/MksJIoi8Obo
Foryourconvenience,youcanscanthisQRcodetoseethevideofor
lubricatingtherunningbeltonYouTube,orinputthislinktowatch.

After installation video tutorial
1
2
3
RUNNING BELT SKEWS TO THE LEFT
RUNNING BELT SKEWS TO THE RIGHT
RUNNING BELT IS IN THE LOGJAM
Then make the machine running without loading 1-2 minutes.Please
Please adjust the belt like this to the middle position.
Please adjust the belt like this to the middle position.

10
https://youtu.be/uoXqZXk1Bx8
Foryourconvenience,youcanscanthisQRcodetoseethevideoon
YouTube,orinputthislinktowatch.

https://youtu.be/LGKKCk-yivM
Foryourconvenience,youcanscanthisQRcodetoseethevideo
onYouTube,orinputthislinktowatch.

PARTSDAILY MAINTAINANCE
STEP1:https://youtu.be/Xqri9ug5J7c
Foryourconvenience,youcanscanthisQRcodetosee
thevideoonYouTube,orinputthislinktowatch.

STEP2:https://youtu.be/nyZ75WFTZZw
（STEP1） （STEP2）
1
2
3
1. Please disconnect power before checking the machine or cleaning.
2. Clear belt and dial plate after use, at least once a week.
3. Check and tighten screws and spines at fixing point.
4. Do not hang clothes or other objects on the machine.
RUNNING BELT DEVIATE TO LEFT
RUNNING BELT DEVIATE TO RIGHT
RUNNING BELT LOGJAM

11
PARTSEXERCISE GUIDE
Warm-up
Start each workout with of stretching and some light exercises. A proper warm-up5 to 10 minutes
Increase your body temperature, heart rate and circulation in preparation for exercise. Easy into
your exercise.
Training Zone Exercise
After warming up, increase the intensity to your desired exercise program. Be sure to maintain your
Intensity for maximum performance. Breathe regularly and deeply as you exercise-never hold
you breathe.
Cool Down
Finish each workout with a light jog or walk for at least 1 minute. Then complete of 5 to 10 minutes
stretching to cool down. This will increase the flexibility of your muscles and will help prevent
post- exercise problems.
PLEASE NOTE: Before beginning any exercise program, consult your physician.
This is important especially if you are over the age of 45 or individuals with pre-existing health problem.

12
MAXIMUM
85%
70%
COOL DOWN
HEART RATE
200
180
160
140
120
100
80
20 25 30 35 40 45 50 55 60 65 7570 AGE
THIS IS HOW YOUR PULSE SHOULD BEHAVE DURING GENERAL FITNESS
EXERCISE. REMEMBER TO WARM UP AND COOL DOWN FOR A FEW MINUTES
The most important factor here is the amount of effort you put in. The harder and longer you work the more calories
you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal.
MADE IN CHINA

PARTSTROUBLE SHOOTING
If you are not sure about how to do that, please contact our customer service and we will provide the best solution for you.
13

1
One year warranty Product Inquiry Orders FAQ Product Assembly Returns & Refunds
Dear Sir/Madam:
★★★★★Great products so far
February 24, 2018
Great product so far. Fast delivery, easy setup, and working without any issues.
With your inspiring rating, FYC will be more consistent to offer you
EASY SHOPPING EXPERIENCE, GOOD PRODUCTS and EFFICIENT SERVICE!
WARRANTY
If you have any issues with your orders, logistics,
items, etc, please contact us bythe following way.
Whatsapp: [phone]
Telephone: [phone] 83096029
Email: [email protected]
Your purchase includes a hassle-free Money Back Guarantee and a free replacement exchange for one year.
Within the warranty period, we provide the FREE replacement parts. If caused by incorrect assembly, incorrect
use or change of parts failures, our company takes no responsibility. You should show our products series no. and
relative pictures or videos or concern information before getting the warranty.
