Fysic FX-500 User manual

USER’S MANUAL
FX-500

2
1. Outside line input
2. Telephone or extra number dialler connection
3. Program button
4. Keypad for programming
5. Keypad for dialling memories
6. Protective cover for program buttons
1 2
3
4
5
6
FX-500
The Fysic FX-500 is an additional number dialler for memory numbers.
You can assign handy photos or symbols to each button, allowing you to
call the corresponding person or service by simply pressing a single but-
ton. It’s also possible to use the number dialler as a “big button” keypad.
NUMBER DIALLER OVERVIEW

3
INSTALLATION
Remove the (PTT) plug from the PTT socket.
Click the modular plug out of your existing phone and connect it to the
‘LINE’ input ( 1) of the FX-500.
Connect the supplied cable between the connection of your existing
phone that’s now free and the ‘PHONE’ output ( 2) of the FX-500.
You can now put the PTT plug back into the PTT socket.
The FX-500 must be “charged” for at least 2 minutes before you can
start programming.
If your existing phone is not provided with a modular connection but a
fixed connection, we recommend you to use a connector set such as the
Profoon ASN-1.
The FX-500 can also be used as a wall device. Above each other and
at a distance of 10cm, drill two holes in the wall and insert plugs and
screws. Leave the screws protrude for several millimetres.
Suspend the extra number dialler by sliding the cavities at the rear of the
device over the screws in the wall and pressing the FX-500 number dial-
ler downward.
Telephone
Number dialler
Phone
connection

4
PROGRAMMING
To program photo memories:
1. Pick up the receiver of the phone connected
to the FX-500 and place it beside the device
(if using a wireless phone connected to the
FX-500, press the call button of this phone and
place the handset on the table).
2. At the bottom of the FX-500, briefly press the
“set” button and then enter the phone num-
ber you want to save using the keypad at the
bottom of the FX-500.
3. Now press the photo button at the top under
which you like to save the number.
4. Put the receiver back onto the cradle (or press
the end button if connected with a wireless
phone).
Repeat steps 1-4 to program the other phone numbers.
To program as a “big button” keypad:
You can also use the FX-500 as a normal keypad with large buttons. To
do this, you don’t save an entire phone number underneath a photo but-
ton, but only a single digit to be assigned to the corresponding button.
Program the number 1 underneath photo button 1, the number 2 under-
neath photo button 2, etc.
For this application, replace the photo’s under-
neath the buttons with the supplied number pictu-
res (see illustration below).

5
OPERATION
Photo memories:
1. Pick up the receiver of the existing phone (or press the call button when
using a wireless phone) and wait for the dialling tone.
2. Press the desired photo button on the FX-500.
3. The number will be dialled.
Tip: when calling via a home or office switchboard and having to request
the outside line by pressing (for example) the 0 button, pick up the recei-
ver (or press the call button) and use your normal phone to press the 0
button. When you hear the outside line dialling tone, you can press the
photo button to dial the corresponding photo memory.
‘Big Button’ keypad:
1. Pick up the receiver of your existing phone (or press the call button
when using a wireless phone) and wait for the dialling tone.
2. Use the keypad to enter the phone number you want to dial.
3. The number will now be dialled.
EXTRA NUMBER DIALLER CONN ECTION
If a single FX-500 unit is not sufficient, you can connect a second num-
ber dialler to expand the memory capacity.
Refer to the diagram for connecting two number diallers.
The programming procedure for the second number dialler is the same
as using a single number dialler. After connecting to the telephone net-
work, please wait at least two minutes before you start programming.
Telephone
Number dialler 1 Number dialler 2
Phone
connection

6
CHANGING THE BUTTON SYMBOLS
The symbols you see on the button can be replaced with
other symbols or you own personal photos.
These photos should be cut to a dimension of
23.4mm x 29.4mm.
Symbols are added for general applications. For memories
where photos or symbols are not applicable, you can use a
general symbol to which you can assign your own text.
When using the number dialler as a ‘Big Button’ keypad,
please use the large number symbols.
Changing photos or symbols:
Use a sharp object to lift up the protective plastic cover of
the button. Remove the old photo or symbol. Place the new
photo or symbol picture on the button and then replace the
protective plastic cover.
USEFUL TIPS
When all of the memories are programmed and you want to move the
FX-500, please keep in mind that the programmed memories remain
for only several minutes after the telephone connection is interrupted.
You could write the programmed memories down on a separate piece of
paper as a reminder when programming them again.

7
MAINTENANCE
Do not place the number dialler in direct sunlight or in humid spaces.
Only clean the enclosure with a moist cloth, never use any cleaning
agents.
Do not place the FX-500 on surfaces treated with cellulose, the rubber
feet could leave marks.
WARRANTY
For the Fysic FX-500 you have a warranty of 24 months from the date
of purchase. During this period, we guarantee the free repair of defects
caused by material and workmanship errors. All this subjected to the final
assessment of the importer.
HOW TO HANDLE:
If you notice any defect, rst refer to the user’s manual. Please contact
the supplier of this telephone or contact customer service of Fysic on
telephone number 073 6411 355.
THE WARRANTY BECOMES NULL AND VOID:
In case of improper use, incorrect connections, use of unoriginal parts or
accessories, negligence and in case of defects caused by moisture, fire,
flooding, lightning and natural disasters.
In case of unauthorised modifications and/or repairs performed by third
parties. In case of incorrect transportation of the device without adequate
packaging and when the device is not accompanied by this warranty card
and proof of purchase.
All further liability, especially concerning any consequential damages, is
excluded.

8
DISCARDING THE PRODUCT (ENVIRONMENT)
At the end of the product’s life span, it must not be disposed of as
normal domestic waste. You must bring it to a collection point for
the recycling of electric and electronic equipment.
DECLARATION OF NETWORK COMPATIBILITY
The Fysic FX-500 is designed for use on the ‘public switched telephone
networks (analogue single line)’ of telephone service providers within the
European Union.
For each country or provider, a different connecting cable with plug may
be required.
The Fysic FX-500 is in accordance with the essential requirements and
provisions as described in the European Directive 1999/5/EC.
DECLARATION OF CONFORMITY
The declaration of conformity is available on the
website WWW.FYSIC.COM
