Ganz PIXELPRO SERIES User manual

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A i

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 2
Precaution
Please read this manual carefully before installing the unit.
Never disassemble the camera. Unauthorized disassembly may cause equipment
failure or damage to the unit.
Please do not install the camera in a place exposed to direct sunlight.
Do not operate the camera in environments beyond the specified temperature. Refer
to “Environment Condition”on “APPENDIX (A) : SPECIFICATIONS”in this manual.
Before applying power to the camera, check the power source to ensure that it is
within the specifications. Refer to “Electrical Characteristics”on “APPENDIX (A) :
SPECIFICATIONS”

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 3
Table of Contents
Precaution................................................................................................................ 2
1. FEATURES............................................................................................................. 4
2. PACKAGE CONTENTS............................................................................................. 5
3. PART NAMES ........................................................................................................ 6
4. INSTALLATION ...................................................................................................... 7
4.1. Installing the camera.......................................................................................................... 7
4.2. Setting the Image Attribute ............................................................................................... 8
5. CONNECTIONS...................................................................................................... 9
6. CONFIGURATION ................................................................................................ 11
6.1. Set up network environment ........................................................................................... 11
6.1.1. Generic IP Environment ............................................................................................ 11
6.1.2. Custom IP Environment............................................................................................. 12
6.1.3 .Wireless LAN ............................................................................................................. 13
6.2. View video on web page .................................................................................................. 15
6.2.1. ActiveX Installation.................................................................................................... 15
6.2.2. View video using IPAdmin Tool ................................................................................. 16
6.3. Reset................................................................................................................................. 17
6.4. Factory Default................................................................................................................. 17
6.5. Safe Mode ........................................................................................................................ 18
APPENDIX (A): SPECIFICATIONS .............................................................................. 20
Summary ................................................................................................................................. 20
Functional Features................................................................................................................. 21
Environment Characteristics ................................................................................................... 21
Environment Characteristics ................................................................................................... 21
Mechanical Characteristics ..................................................................................................... 21
APPENDIX (B): DIMENSIONS ................................................................................... 22
APPENDIX (C): HEXADECIMAL-DECIMAL CONVERSION TABLE.................................. 23
REVISION HISTORY ................................................................................................. 24

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 4
1. FEATURES
Camera
1/4”720p CMOS Image Sensor
Digital Day/Night
WDR
Built-in Passive infrared(PIR) motion sensor
Video
H.264 Baseline, Main, High Profile(MPEG-4 Part 10/AVC), MJPEG(Motion JPEG)
Max 30fps in 720p
Text Overlay
Audio
Two-Way Audio Streaming
G.711 µLaw
Built-in microphone and speaker
Network
IEEE 802.11 b/g/n (Internal antenna)
10/100 Base-T Ethernet
Integration
Software Development Kit (SDK) available
ONVIF Compliant(Profile S)
General
microSD slot
Video Content Analysis (VCA)
VCA Presence (Standard)
VCA Surveillance (Optional)

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 5
2. PACKAGE CONTENTS
Please unpack the package carefully and handle the equipment with care.
The package contains:
Camera
DC Power Adaptor
Screws and Anchor Blocks
Terminal Block
Quick Installation Guide
Note
i
The contents above are subject to change without prior notice.
ETHERNET
DO DI
Out In
Com
DC12V
Com

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 6
3. PART NAMES
①Passive Infrared(PIR) sensor
The PIR sensor is used to detect movement of objects.
②PIR sensor indicator LED
The indicator LED glows in red when PIR sensor detects any movement of objects.
③Status LED
LED glows in green when the device is connected.
④Microphone
Built-in microphone
⑤Privacy Shutter
The privacy shutter is used to manually cover the lens to prevent the camera to see and objects.
⑥Reset button
Use the button to restart the device or to reset it to Factory Default. Refer to “6.3. Reset”and
“6.4. Factory Default”for more details.
⑦Speaker
Built-in speaker
⑧LAN Connector (Ethernet)
RJ45 LAN connector for 10/100 Base-T Ethernet.
⑨Power Adaptor Connector
Use the 12VDC adaptor for power supply.
⑩Terminal Connector
Connector for cable connection of digital input & output. Refer to “5. Connections”for more details.
⑪microSD slot
Supports up to 64GB. Recommend Class 4 and higher for HD recordings.
ETHERNET
DO DI
Out In
Com
DC12V
Com
②
* Models herein and their appearance are subject to change without any prior notice.
④
⑤
⑩
ETHERNET
DO DI
Out In
Com
DC12V
Com
⑦
⑧
⑨
⑪
③
④
①
⑥

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 7
4. INSTALLATION
4.1. Installing the camera
1) Drill two holes on the desired position of installation, and insert anchor blocks into
the holes.
2) Position the mount bracket to anchor blocks.
3) Fasten the mount bracket with screws.
4) Manually position the camera to area where it will be monitored.
To prevent products from damage, place the camera on a stable and non-
vibrating surface. If the stability is in doubt, consult safety personnel for
reinforcements, and then proceed with the installation.
Caution
!

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 8
4.2. Setting the Image Attribute
Through the camera’s webpage, users can configure image settings. The menu of image
attribute is available under Video Appearance menu in Setup > Video & Audio > Camera.
The following features can be adjusted: Brightness, Contrast, Saturation, Sharpness and
Orientation.
For more detailed information, refer to the provided “PixelPro GXi series Web Page User's
Manual”.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 9
5. CONNECTIONS
①Sensor (DI) connection
Sensor (DI) can be connected to either a voltage type sensor or a relay type sensor like the
following figures. The interface type can be controlled by web user interface.
Refer to the provided “PixelPro GXi series Web Page User's Manual”for more details.
Input voltage range: 0VDC minimum to 5VDC maximum, Max 50mA
Caution
!
Before connecting sensors, check driving voltage and output signal type of the
sensor. Since the connection is different according to sensor type, be careful to
connect the sensor. Do not exceed the maximum input voltage or relay rate.
+5V
DI
COM
DI
COM
+
-
Relay Type
Voltage Type
+
-
Output of
Sensor
Output of
Sensor
Internal
Internal
+
-
ETHERNET
DO DI
Out In
Com
DC12V
Com
ETHERNET
DO DI
Out In
Com
DC12V
Com
①
②
③
④

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 10
②Alarm (DO) connection
Only the relay type is supported.
Relay Rating: Max 24VDC 50mA
Caution
!
Do not exceed the maximum relay rating.
③LAN connection
This is RJ45 LAN connector for 10/100 Base-T Ethernet. Use the Ethernet cable (RJ45) to
connect the device to a hub or a router in the network.
④Power connection
Use 12VDC adaptor for power supply.
DO
COM
Relay Type
Device
Internal

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 11
6. CONFIGURATION
6.1. Set up network environment
The default IP address of the device is 192.168.XXX.XXX. Users can identify the IP address of the
device from converting the MAC address’s hexadecimal numbers, which is attached to the
device. Be sure that the device and PC are on a same area network before running the
installation.
IP address : 192.168.xxx.xxx
Subnet mask: 255.255.0.0
6.1.1. Generic IP Environment
In case of generic private network environment where IP address 192.168.XXX.XXX are used,
users may view the live streaming images on a web page using the device’s default IP address:
1. Convert the device’s MAC address to the IP address. Refer to the Hexadecimal-Decimal
Conversion Chart at the end of the manual.
(The MAC address of the device is attached on the side or bottom of the device.)
2. Start the Microsoft® Internet Explorer web browser and enter the address of the device.
3. Web streaming and device configurations are supported through ActiveX program. When the
ActiveX installation window appears, authorize and install the ActiveX.
MAC address = 00-1C-B8-01-23-45 →IP address = 192.168.35.69
Convert the last two sets of hexadecimal numbers to decimal numbers.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 12
6.1.2. Custom IP Environment
IPAdminTool is a management tool, which automatically scans all of the network products for
users to perform administrative tasks, which includes network configurations, firmware update,
device reboot, and device organizations.
To modify the device’s default IP address for customized network area:
1. Find the device from the IPAdminTool’s list, and highlight the device’s name.
2. Right-click the mouse and select “IP Address”; IP Setup window appears.
3. In the IP Setup’s window, information under “Local Network information”displays the
user/PC’s network area information. Those information need to be incorporated to the IP
Address, Subnet Mask, Gateway, and DNS boxes, except the last 2 sets of IP Address, which
are to be the unique numbers for the device. Refer to the image above for the setting
4. Click “Setup”to complete the modification.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 13
6.1.3 .Wireless LAN
To configure the wireless mode, the device needs to be connected to a wired network for the
first time. Setup > Network Configuration > Wireless Lan
1. From the USB Wireless AP List tab, select the wireless network where the device will be
located under. Provide the network key (password).
2. From Wireless network IP configuration tab, select Obtain an IP address via DHCP or Use
the following IP address.
A. Use Obtain an IP address via DHCP if you want network to provide automatic address.
B. Use Use the following IP address and type specific addresses if you want the device to
use specific designated address.
3. Click Apply button and wait for system to correspond.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 14
4. Disconnect the wired cable from the camera and wait for 10~15 seconds.
5. Use IPAdminTool* to identify the device or type URL in Windows Explorer to access.
Link-Local Address
This is a built-in function that assigns the device an additional IP address, which can be used to
access the unit from other hosts on the same segment of the local network. An IP address is
automatically assigned when the camera boots up.
The camera can have both a Link-Local IP and a static/DHCP-supplied IP address at the same
time. The IP address block is from 169.254.1.0.to 16.254.254.255.
If you want to enable this function, tick the checkbox of Enable Auto-Configuration link-local
address, and click Renew if you want to change the IP address.
Caution
!
* IPAdminTool needs to be started in a same network where wireless device is
operating at.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 15
6.2. View video on web page
Type the proper IP address to view the live streaming images through a web browser.
The default user name and password is root / pass.
6.2.1. ActiveX Installation
1. When the browser asks to install the AxUMF software, click “Install”to proceed.
2. When Setup installation pop-up window appears, click “Install”to proceed with rest of
installations.
Note
i
Depending on system OS and Internet Explorer version, installation experience
may differ from one another. Figures described above are from Windows 7,
Internet Explorer 9 environment.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 16
6.2.2. View video using IPAdmin Tool
IPAdminTool automatically searches all activated network encoders and IP cameras, and shows
the product name, IP address, MAC address and etc.
1. From the IPAdmin Tool’s product list, select the device by highlighting it.
2. Right-click the mouse and select “Web View”.
3. The system’s default web browser opens the device’s address.
Caution
!
Whether directly accessing the streaming video through typing IP address on a
web page or taking steps through IPAdminTool, the ActiveX is needed to be
installed for the Microsoft Internet Explorer to have the complete configuration
privileges.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 17
6.3. Reset
Perform the following procedures to reset your device:
1. Press the reset button for 2 seconds while the device is in use.
2. Wait for the system to reboot.
Caution
!
Please do not hold for more than 2 seconds. Otherwise, the camera may be
switched to its Factory Default settings.
6.4. Factory Default
Resetting the device back to the factory default will initialize all parameters including the IP
address back to the factory defaults. To reset back to the factory default:
1. Press the reset button and hold.
2. Release the Reset button after 10 seconds.
3. Wait for the system to reboot.
Note
i
The factory default settings can be inferred as follows:
IP address: 192.168.xx.yy
Network mask: 255.255.0.0
Gateway: 192.168.0.1
User ID: root
Password: pass

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 18
6.5. Safe Mode
What is Safe Mode?
Your IP camera or encoder could encounter an unexpected occasion such as broken firmware
file or uncompleted loading of firmware file during system booting. To restore the device from
the occasions, the device provides the emergency firmware as a factory default. Your device
will get restarted with safe mode when there is any error on your booting system files.
Why does your IP camera or encoder boot in Safe Mode?
Normally, the cause of ‘safe mode’ is classified into two types.
* When the power supply is unplugged in the middle of system booting.
* When the firmware files required for system booting are damaged.
IMPORTANT: Your device will turn into the safe mode when it fails to boot certain times.
How to recover your system from Safe Mode
The messages above will appear on the webpage when your device has been rebooted in ‘safe
mode’. Then, you should follow the instructions on the webpage according to the steps in a
row.
Note
i
There are two types of firmware files when you receive a firmware folder from
your vendor. When you need to update the firmware as the final resolution in case
your device is in safe mode like above, ensure that the firmware means the
firmware file for the device with the file name as GXi-V.1.X.X.X-~~~.enc.
Browse

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 19
Note
i
There is another method to update firmware, which is using IPAdminTool.
Please refer to ‘IPAdminTool User’s Manual.pdf’for the detailed procedure.
Note
i
If your device is still at safe mode after trying to update firmware, please contact
your local agency to get further assistance.
* Firmware update for safe mode itself: If you want to update the firmware for safe mode, you
should upload a firmware file with the following file name: GXi-SAFEMODE.~~~.enc.

PixelPro GXi Series ZN1-Q3FN2 Installation Guide
03-2014-A 20
APPENDIX (A): SPECIFICATIONS
Summary
Camera Module
Image Sensor
1/4”720p CMOS
Effective Pixels
1280 x 720
Scanning System
Progressive scanning
AGC Control
Auto
Minimum Illumination
Color:1.0 Lux
B/W 0.001 Lux (DSS ON)
Lens
2.7mm F2.0
Field of View
91° (Horizontal)
Day & Night
Digital Day & Night
WDR
Digital WDR
2D-DNR
Supported
DSS (Sens-up)
2X ~ 16X
White Balance
ATW1 / ATW2 / Push / Manual
BLC
On(possible to designate zone) / Off
Video
Compression Format
H.264 and MJPEG Selectable per Stream
Number of Streams
Dual Stream, Configurable
Resolution
1280 x 720, 1120 x 630, 960 x 540, 800 x 450,
640 x 360, 480 x 270, 320 x 180
Compression FPS
30fps@720p
Motion Detection
Built-in
Burnt-in Text
Video stream overlay text
Audio
Input
1 Built-in Mic.
Output
1 Built-in Speaker
Compression Format
G.711
