Garden Furniture Direct WINDERMERE OCTAGONAL TABLE User manual

1
Before you commence the assembly process we recommend that you read these instructions
thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have
the correct components. If for any reason you need assistance, you can find our contact details on the
final page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible and that you
use another person to assist you if necessary.
Package contents
Tools required
1 x Table top
4 x Seats
2 x A-frames
M8 Coach Screws
Cover Caps
10mm socket or spanner
Windermere octagonal table
GaGarden
rnitu reFuu
Direct
T: 03333 448 121
ASSEMBLY
INSTRUCTIONS
Windermere
octagonal/circular Table

Windermere octagonal/circular table
2
Step 1
Step 2
Ensure that you have all of the correct parts as listed
on the front page of these instructions, including any
fixings.
On a flat, level surface take the bottom A-frame,
which is identified by the slots being on TOP of the
cross piece...
Step 3
Step 4
...and slot the top A-frame onto it as shown.
Now secure the 2 frames together using 4 of the
coach screws, where the 2 frames intersect as shown.

Windermere octagonal/circular table
3
Step 5
Step 6
Carefully lower the table top onto the frame
assembly and centre it on the legs...
...and then confirm the correct alignment by looking
directly down through the parasol hole.
Step 7
Step 8
Now attach the table top to the leg assembly using 2
coach screws per leg.
Lower one of the seat panels onto the frame as
shown above...

Windermere octagonal/circular table
4
Step 9
Step 10
...and attach it to the leg using a coach screw...
...noting the clearance between the seat and the
upper surface of the frame assembly. Repeat steps 8 -
10 for the remaining seat units.
Step 10
Your Windermere table is now complete.
GardenFurniture.Direct i a trading tyle of LTK Sco Limited
Regi tered in England & Wale - Regi tered No. 6282947
We hope that you found your product quick and ea y to a emble.
However, if you require any further a i tance or have any que on you can
contact u by telephone on: 03333 448 121 or vi it www.gardenfurniture.direct
