Gardena EasyPlus User manual

EN Operator’s manual
Water Control
FR Mode d’emploi
Programmation d’arrosage
IT Istruzioni per l’uso
Unità di controllo per irrigazione
ES Instrucciones de empleo
Control de riego
PT Manual de instruções
Controlador de rega
PL Instrukcja obsługi
Sterowanie nawadnianiem
HU Használati utasítás
Öntözésvezérlés
EL Οδηγίες χρήσης
Σύστημα ελέγχου ποτίσματος
Page 1 width 2 mm less: 146 mm
EasyPlus Art. 1888
EL HU PL PT ES IT FR EN
1888-20.960.01.indb 1 19.11.18 08:21

Fold-out Page width 5 mm less: 143 mm
2
Einstellung Anwendungsempfehlung
Alle 4 – 24 Std. GARDENA Micro-Drip-System
Alle 24 – 72 Std. GARDENA Sprinkler
Blauer Bereich GARDENA Outdoor Sprühnebel Set
Bewässerungsempfehlungen
Setting Application recommendation
Every 4 – 24 hrs GARDENA Micro-Drip-System
Every 24 – 72 hrs GARDENA Sprinkler
Blue area GARDENA Outdoor Cooling Mist Set
Irrigation recommendations
Réglage Recommandation
Toutes les 4 – 24 heures GARDENA Micro-Drip-System
Toutes les 24 – 72 heures GARDENA Sprinkler
Zone bleue Brumisateur GARDENA
Recommandations d'irrigation
1888-20.960.01.indb 2 19.11.18 08:21

Fold-out Page width 5 mm less: 143 mm
3
Run Time
Water Now
30 min
3x
Green
= OK
ABC
E
1x 9V
1x
2x
...
23x
= 1hr
= 2hrs
...
= 23hrs
Red LED
= Low
1.
2. 3.
Frequency
Ø 26,5mm G3/4"
+ Ø 33,3mm G1"
D
1888-20.960.01.indb 3 19.11.18 08:21

Page 2 width 2 mm less: 146 mm
GARDENA Water Control Easy Plus
Translation of the original instructions.
For safety reasons, children and young
people under 16 as well as anyone who is
not familiar with these operating instruc-
tionsshould not use the product. Persons with
reduced physical or mental abilities may use the
product only if they are supervised or instructed by
a responsible person. Children must be supervised
to ensure that they do not play with the product.
Never operate the product when you are tired, ill or
under the influence of alcohol, drugs or medicine.
Intended use:
The GARDENA Water Control is intended for private
use in domestic and hobby gardens, exclusively
for outdoor use, to control sprinklers and watering
systems. The Water Control can be used for auto-
matic watering during holidays.
DANGER! The GARDENA Water Control must
not be used for industrial purposes or in
conjunction with chemicals, foodstuffs, easily
flammable and explosive materials.
4
EN
1888-20.960.01.indb 4 19.11.18 08:21

1. SAFETY
Important!
Read the operator’s manual carefully before use
and keep for future reference.
Battery:
To ensure the Water Control runs safely,
only a 9V alkaline manganese battery
(alkaline) type IEC 6LR61 must be used!
In order to stop the Water Control from failing
because of a weak battery if you are away for
a long time, the battery must be replaced when
the LED flashes red.
Setting up:
The Water Control may only be set up vertically
with the sleeve nut to the top to prevent water
penetrating into the battery compartment.
The minimum water output to ensure that the
Water Control functions correctly is 20 – 30 l/h.
For example, at least 10 x 2-litre Drip Heads are
required to control the Micro-Drip-System.
The max. temperature for the water flow is
40 °C.
Avoid tensile strain.
vDo not pull the hose connected to the
Water Control.
CAUTION! If the control section is
removed when the valve is open, the
valve remains open until the control section
is reattached.
DANGER! Cardiac arrest!
This product makes an electromagnetic
field while it operates. This field may under some
conditions interfere with active or passive medical
implants. To decrease the risk of conditions that
can possibly injure or kill, we recommend persons
with medical implants to speak with their physician
and the medical implant manufacturer before you
operate the product.
DANGER! Risk of suffocation!
Small parts can be easily swallowed. There
is also a risk that the polybag can suffocate tod-
dlers. Keep toddlers away when you assemble the
product.
EN
5
1888-20.960.01.indb 5 19.11.18 08:21

2. INITIAL OPERATION v(Fig. A–C)
3. FUNCTION AND SETTING
4. MAINTENANCE v(Fig. D)
5. STORAGE
To put into storage:
vThe product must be stored away from
children.
vTo preserve the battery, it should be
removed (Fig. B).
vStore the controller and the valve unit in
a dry, enclosed and frost-free place.
Disposal: (in accordance with RL2012/19/EC)
The product must not be disposed of to
normal household waste. It must be dis-
posed of in line with local environmental
regulations.
IMPORTANT!
Dispose of the product through or via your
municipal recycling collection centre.
Disposal of the battery:
vPlease return a flat battery to a GARDENA dealer
or dispose of it properly at your nearest recycling
centre.
Dispose of the battery only when discharged.
v (Fig. E)
Once the duration and frequency have been set,
the values will be applied 5 seconds later. The
green LED will flash three times to confirm this. The
first watering operation commences. This will be
the watering start time from now on. If you want
watering to commence later than this, press the
+1h button repeatedly within the 5-second time
window until the desired start time has been set.
A video of the
commissioning
and setting
processes is
available here:
EN
6
1888-20.960.01.indb 6 19.11.18 08:21

6. TROUBLESHOOTING
Problem Possible Cause Remedy
Manual watering is
not possible using the
button
Low battery is continuously displayed:
LED next to start delay lights up red.
vInsert a new (alkaline) battery.
Tap is turned off. vTurn the tap on.
Controller is not connected. vMount the controller on housing.
Watering program is
not being undertaken
(no watering)
Program entry/modification during or
just before the start pulse.
vMake program entry / modification
outside the programmed start times.
Valve was opened manually previously. vAvoid possible program overlaps.
Tap is turned off. vTurn the tap on.
Controller is not connected. vMount the controller on housing.
Low battery is continuously displayed:
LED next to start delay lights up red.
vInsert a new (alkaline) battery.
Minimum pressure of 0.5 bar not available. vEnsure a pressure of at least 0.5 bar.
LED lights up orange. vPay careful attention to the blue and
grey settings and keep them com-
pletely separate.
Water Control does
not close
Minimum quantity of water drawn is less
than 20 l/h.
vConnect more drip heads.
Valve soiled. v Flush in the opposite direction to the
normal flow direction.
EN
7
1888-20.960.01.indb 7 19.11.18 08:21

7. TECHNICAL DATA
8. ACCESSORIES
Water Control Value /Unit
Min./ max. operating
pressure 0.5 bar /12 bar
Operating temperature
range 5 °C to 50 °C
Flow medium Clear fresh water
GARDENA Anti-theft device Art.1815-00.791.00 from the GARDENA Service
Water Control Value /Unit
Max. liquid temperature 40 °C
Battery required 1 x 9V alkaline
manganese
Typ IEC 6LR61
Operating time of the
battery
approximately
1 year
NOTE: For any other malfunctions please contact the GARDENA service department.
Repairs must only be done by GARDENA service departments or specialist dealers
approved by GARDENA.
EN
8
1888-20.960.01.indb 8 19.11.18 08:21

9. SERVICE/WARRANTY
Service:
Please contact the address on the back page.
Warranty:
In the event of a warranty claim, no charge is levied
to you for the services provided.
GARDENA Manufacturing GmbH offers a 2-year
warranty for this product (from the date of pur-
chase) if the product has been used exclusively for
private purposes. This manufacturer’s warranty
does not apply to used products purchased from
a secondary market. This warranty includes all
significant defects of the product that can be
proved to be material or manufacturing faults. This
warranty is fulfilled by supplying a fully functional
replacement product or by repairing the faulty
product sent to us free of charge; we reserve the
right to choose between these options. This
service is subject to the following provisions:
• The product was used for its intended purpose
as per the recommendations in the operating
instructions.
• Neither the purchaser nor a third party has
attempted to repair the product.
• Only original GARDENA spare and wear parts
were used.
Normal wear and tear of parts and components,
optical changes, as well as wear parts and con-
sumables, are excluded from the warranty.
This manufacturer’s warranty does not affect
warranty entitlements against the dealer/retailer.
If problems arise with this product, please con-
tactour Service department. In the event of a war-
ranty claim, please send the defective product
together with a copy of the purchase receipt and
a description of the defect, sufficiently stamped, to
the GARDENA service address on the back page.
Consumables:
Faults which occur as a result of incorrectly
installed or leaking batteries are not covered by
the guarantee.
Damage caused by frost is not covered by the
warranty.
EN
9
1888-20.960.01.indb 9 19.11.18 08:21

Programmation d’arrosage GARDENA EasyPlus
Traduction des instructions originales.
Pour des raisons de sécurité, les enfants,
les jeunes de moins de 16 ans et les per-
sonnes n’ayant pas lu et compris ce mode
d’emploi ne doivent pas utiliser ce produit. Les per-
sonnes présentant des capacités physiques ou
mentales réduites ne doivent utiliser le produit que
sous la surveillance d’une personne responsable ou
instruite. Surveillez les enfants pour vous assurer
qu’ils ne jouent pas avec le produit. Ne jamais utiliser
le produit si vous êtes fatigué ou malade, ou si
vous êtes sous l’influence d’alcool, de drogues ou
de médicaments.
Utilisation conforme:
La Programmation d’arrosage GARDENA est
réservée à l’utilisation privée dans les jardins de
maison et de loisir en vue d’un usage exclusif
à l’extérieur pour le pilotage d’arroseurs et de sys-
tèmes d’arrosage. La programmation d’arrosage
peut être utilisée pour l’arrosage automatique
pendant les vacances.
DANGER! La Programmation d’arrosage
GARDENA ne doit pas être utilisée comme
application industrielle et en relation avec
des produits chimiques, des aliments et des
matières facilement inflammables ou explo-
sives.
FR
10
1888-20.960.01.indb 10 19.11.18 08:21
