Gardenline 22466 User manual

User Manual
Manual
del usuario
English.... Page 3
Español.... Página 21
GAZEBO WITH NETTING
GLORIETA CON MALLA

AFTER SALES SUPPORT 3
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA
Geng Started .................................. 3
Warnings & Cauons .......................... 4
Pack Contents .................................... 5
Parts List ............................................ 6
Hardware List ..................................... 7
Assembly Instrucons ........................ 8
Warranty ............................................ 13
Contents • Contenido
Para comenzar .................................. 21
Advertencias y precauciones ............. 22
Contenido de la caja .......................... 23
Lista de piezas .................................... 24
Lista de hardware .............................. 25
Instrucciones de ensamblaje .............. 26
Garana ............................................ 35
Geng Started
Ensure all parts packaged in carton match the parts list.
Remove all protecve materials and place parts on a
non-abrasive surface to avoid scratching. If any parts are
missing or damaged, DO NOT aempt to assemble. Please
contact our customer service center (Monday-Friday
9:00am – 5:00pm EST) at 1-800-599-8898.
Cauon
Read all the instrucons before assembly. Failure to
comply with instrucons may result in faulty assembly and
potenal injury! Assemble product on a so, non-abrasive
surface such as a carpet or cardboard to avoid damaging
the item. Seek assistance to assemble bulky or heavy items.
Aer nal alignment, make sure all bolts and nuts are
securely ghtened with screw covers pressed in place.
Cleaning & Maintenance
Wash canopy with a mild soluon of soap and water; rinse
thoroughly. Dry completely.
Getting Started

4 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 5
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Pack Contents / Parts
Pack contents / parts
ARight Panel
BLe Panel
CCorner Canopy Rib
DCanopy Middle Rib
ECross Beam
FCross Beam Connector
GCorner Connector
HCanopy Two-Tier Ribs
IConnector
JMain Canopy
KSmall Canopy
LNeng Panel
MCorner Shelf
NPlasc Ring
ORope
PM6 x 14mm Screws
QM6 x 30mm Screws
RStake
Warnings & Cauons
1. When storing, do not re-pack your gazebo unl completely dry.
2. This gazebo must be assembled by two or more adults.
3. The gazebo canopy must not be le aached in windy or extreme
condions.
4. Loading limit of the hook is 10 lbs.
5. Steel components for garden accessories and furniture are treated with
rust-inhibing paint. However, due to the nature of steel, surface oxidaon
(rusng) will occur if this protecve coang is scratched. This is a natural
process. To minimize this condion, it is recommended that care be taken
when assembling and handling the product in order to prevent the paint
from being scratched. If scratching or damage occurs, it is recommended
that the area be touched-up immediately with rust-inhibing paint. Surface
rust can be removed easily using a very light applicaon of common
cooking oil. If surface oxidaon (rusng) occurs and no measures are taken
to correct it, the oxidaon may start dripping onto the deck or pao, which
may cause damaging stains that can be dicult to remove.
WARNING
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT
FABRIC. This tent is made with fabric that meets CPAI-84 specicaons
for ame resistance. It is not re proof. The fabric will burn if le in
connuous contact with any ame source. The applicaon of any
foreign substance to the tent fabric may render the ame-resistant
properes ineecve.

6 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 7
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Parts List
H
C
I
K
J
M
R
B
A
D
GE F
O P Q
N
L
Descripon Qty Descripon Qty
ARight Panel 4 J Main Canopy 1
B Le Panel 4 K Small Canopy 1
C Corner Canopy Rib 4L Neng Panel 4
D Canopy Middle Rib 4M Corner Shelf 4
ECross Beam 8N Plasc Ring 32
F Cross Beam Connector 4O Rope 4
GCorner Connector 4 P M6 x 14mm Screws 16
HCanopy Two-Tier Ribs 4 Q M6 x 30mm Screws 28
I Connector 1 R Stake 12
Hardware List
A
B
H
G
F
E
D
C
B
A
R
NP
I
J
Q
O
K
L
M

8 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 9
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Assembly Instructions
STEP 1:
At the top corner, first place the Corner Connector (G) into the corner
of the attached panels, then connect Left Panel (B) and Right Panel (A)
with Screws M6x30 mm (Q). Follow this step to assemble remaining A’s
with B’s. See Fig. 1.
GG
A
Q
A
G
A
B
Part A should always be
on the right side.
Part B should always be
on the left side.
When Part A and B are
in the correct order,
Part G will face inward.
Facing a corner
outside of your gazebo.
Fig. 1
Q
(12) Screw
(M6x30 mm)
Assembly Instructions
STEP 2:
Use Screws M6x30 mm (Q) to connect Cross Beam (E) to Left Panel (B)
and Right Panel (A). See Fig. 2.
Use Screws M6x14 mm (P) to connect two Cross Beams (E) and Cross
Beam Connector (F). See Fig. 3.
Put the Corner Shelf (M) on Left Panel (B) and Right Panel (A) as
illustrated above. Fasten all screws to assemble the frame. See Fig. 4.
G
F
E
BA
EF
Fig. 2 Fig. 3
Fig. 4
Q
(16) Screw
(M6x30 mm)
P
(12) Screw
(M6x14 mm)
Q
A
E
Q
Q
E
B
Q
EE
P
F
M
Fig. 3 Fig. 4
Fig. 2

10 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 11
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Assembly Instructions
STEP 3:
Insert Corner Canopy Rib (C) into Canopy Two-Tier Rib (H). See Fig. 5.
Insert Corner Canopy Rib (C) into Corner Connector (G). See Fig. 6.
Insert Canopy Two-Tier Rib (H) into Connector (I). See Fig. 7.
Insert Canopy Middle Rib (D) into Connector (I). See Fig. 8.
Lock up Canopy Middle Rib (D) to Cross Beam Connector (F) with Screws
M6x14 mm (P). See Fig. 9.
H
Fig. 5
C
I
D
Fig. 6
Fig. 7
Fig. 8
Fig. 9
P
(4) Screw
(M6x14 mm)
Fig. 5
C
G
Fig. 6
H
C
I
H
H
H
I
D
DD
F
P
Fig. 8 Fig. 9
Fig. 7
STEP 3:
Assembly Instructions

12 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 13
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Assembly Instructions
STEP 4:
Put Small Canopy (K) on small top. Then fully spread the Main Canopy (J).
See Fig. 10.
Use Plastic Ring (N) to hang Netting Panel (L) to Cross Beams (E). See
Fig. 11.
Use Stake (R) to fix the assembled gazebo to ground. See Fig. 12.
To ensure stability, tie Rope (O) to loop found at the corner of the Main
Canopy (J) and tie the other end to a Stake (R). Repeat on all corners.
See Fig. 13.
KJ
L
E
Fig. 10 Fig. 11
K
Fig. 10
J
O
L
Fig. 11
Fig. 12 Fig. 13
Fig. 10
STEP 4:
RR
A
B
O
R
Fig. 12 Fig. 13
Assembly Instructions

14 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
AFTER SALES SUPPORT 15
1800 599 8898 [email protected]
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA USA
Step 1:
Elastic bands can be found in the
center of each netting panel, one
on either side. Run your left hand
through the elastic band that has a
plastic latch attached to it. Run your
right hand through the elastic band
on the opposite side of the netting.
Step 2:
Gather the netting panel into a
bundle and hold it in place with your
right hand. Keep the elastic band
with latch in your left hand from
being pulled into the bundle.
Step 3:
Bring the elastic band with latch in
your left hand around the bundle
counter-clockwise.
Tying Netting
Step 4:
Once the elastic band with latch has
been brought around full circle, pull
the latch through the other elastic
band.
Step 5:
Gently release both elastic bands.
The latch placed through the second
elastic band should prevent the
netting panel from unwinding.
Tying Netting

16 AFTER SALES SUPPORT
[email protected] 1800 599 8898
MODEL: 22466 PRODUCT CODE: 7884 04/2019
USA
Note: In case of adverse weather condions or strong wind, please
remove the Main Canopy (J) from the gazebo.
The gazebo is designed to provide shade only. Do not use this gazebo
in strong wind and rain. Wind and rain can damage the gazebo and
could result in injury to you and others. The canopy is not waterproof
and not intended for use in the rain. The water will sit easily on top of
the canopy fabric and severely damage the gazebo. Do not use or set
up in rainy, windy, or stormy condions.
This product is designed for leisure use only and is not a shelter against
adverse weather condions.
Assembly Instructions
Your details:
Date of purchase
Name
Address
E mail
Locaon of purchase
Descripon of malfuncon:
Return your completed
warranty card with the faulty
product to:
TDC USA, Inc.
5 Industrial Road
Fairfield, NJ 07004
United States of America
[email protected]
* We recommend that you keep the receipt with this warranty card. You must include a copy of your receipt.
WARRANTY CARD
GAZEBO WITH NETTING
Phone lines available
Monday to Friday
9am - 5pm EST.
[email protected]
1800 599 8898
USA
MODEL:
22466-19 04/2019
7884
YEAR WARRANTY
2

ALDI INC. FULL WARRANTY CONDITIONS
Dear Customer:
The ALDI warranty is a full warranty oering you the following benets:
Warranty period: 2 years* from date of purchase.
Costs: Free repair, exchange, or refund.
No transport costs.
ADVICE Please contact our service hotline by phone, email, or
fax before sending the device. This allows us to provide
support in the event of possible operator errors.
In order to make a claim under the warranty, please send us:
The faulty item with all component parts, the original receipt, and the
warranty card properly completed.
The warranty does not cover damage caused by:
Accident or unancipated events to frame [metal parts] (e.g. wind,
snow, lighng, re).
Deterioraon, fading, sagging, or unancipated events to canopies
and neng panels (e.g. wind, sun, rain, pets/animals).
Improper use or transport.
Failure to follow safety and maintenance instrucons.
Other improper treatment or modicaon.
Aer the expiraon of the warranty period, you may have your product
repaired at your own expense. You will be noed of the repair costs in
advance.
This warranty gives you specic legal rights, which may vary from state to state,
that are not intended to exceed statutory minimum requirements beyond what
is included above.
This warranty does not limit the statutory obligaon of the seller arising
from any implied warranes. The period of warranty can only be extended in
accordance with applicable law.
.
