Printing agPSMaP®4000/5000 SerieS FluSh Mount teMPlate in adobe acrobat
Notes:
(A) Youmustprintthetemplateon11˝x17˝paper.Thisisnormallyselectedinthe‘PrinterProperties’,andwilldifferbymanufacturer.
• Ifyourprinterisnotcapableofprintingon11˝x17˝paper,oryoudonothave11˝x17˝paper,youmustprintthistemplateatanoffice
servicesstoreorsimilarlocationthathastheabilitytoprinton11˝x17˝paper.
(B) Youmustsetthe‘PageScaling’settingto‘None’.
(C)Select‘Auto-RotateandCenter’tomakesurethetemplateprintsinthecorrectorientation.
Important Information:
• Beforecuttingthemountingsurface,measuretheprintouttomakesureitprintedatthecorrectsize.Boththelengthandwidth
measurementsarenotedonthetemplate.Verify both the length and width measurements before cutting.
• WhencuttingtheFlushMounttemplate,cutinside the line,thensandand/orlethemountingsurfacetoensureagoodt.
A
B
C
Adobe Acrobat Print Dialog Box
Printing a Flush Mount Template.1 1 3/23/2007 4:58:23 PM
August 2007 190-00803-04 Rev. A Printed in Taiwan
GPSMAP 5012/5212
Flush Mount Template
10 3/32" (256 mm)
8 3/32" (206 mm)
9"
(229.11 mm)
1
/
2
"
13 mm
Unit Dimensions: 13" (330 mm) wide x 9 1/2" (240.5 mm) high
Pilot Hole
3
/
8
" (9.5 mm)
Trou d’implantation
9,5 mm
Foro guida
9,5 mm (
3
/
8
”)
Vorbohrung
9,5 mm (
3
/
8
”)
Oricio guía
9,5 mm (
3
/
8
pulg.)
Forboring
9,5 mm (
3
/
8
”)
Styrehull
9,5 mm
Rikthål
9,5 mm (
3
/
8
tum)
CUT ON THIS LINE
DECOUPEZ EN SUIVANT CETTE LIGNE
TAGLIARE SEGUENDO QUESTA LINEA
SCHNEIDEN SIE ENTLANG DIESER LINIE
CORTE EN ESTA LÍNEA
SKÆR PÅ DENNE LINJE
SKJÆR LANGSDENNESTREKEN
SÅGA LÄNGS MED DEN HÄR LINJEN
Recommended clearance for
SD card door
Débattement recommandé pour
le cache de la carte SD
Spazio libero consigliato per lo
sportello della scheda SD
Empfohlener Abstand für SD-
Speicherkartenabdeckung
Se recomienda despejar la puerta
de la tarjeta SD
Rekommenderat utrymme för
SD-kortlucka
Anbefalet fri plads til SD-kortlåg
Anbefalt klaring for SD-kortdekselet
USE 4 mm DRILL BIT
UTILISATION d’un FORET de 4 mm
UTILIZZARE UNA PUNTA DA
TRAPANO DA 4 mm
Verwenden Sie einen 4 mm-Bohrer
UTILICE UNA BROCA DE 4 mm
BRUG ET 4 mm BOREHOVED
BRUK EN 4 mm BIT
ANVÄND EN 4 mm BORRSPETS
Dimensions de l’appareil : 330 mm x 240,5 mm (l x H)
Dimensioni unità: L 330 mm x A 240,5 mm
Geräteabmessungen: Breite 330 mm x Höhe 240,5 mm
Dimensiones de la unidad: 330 mm ancho x 240,5 mm alto
Enhetsmått: 330mm B x 240,5mm H
Enhedens mål: 330 mm B x 240,5 mm H
Mål på enheten: 330 mm B x 240,5 mm H
