Garmin GMX 200 User manual

GMX 200 STC Installation
STC Master Data List
Garmin Ltd. or its subsidiaries
c/o Garmin International, Inc.
1200 E. 151st Street
Olathe, Kansas 66062 USA
Dwg. Number:
005-C0315-00 Rev. A
Confidential
This drawing and the specifications contained herein
are the property of GARMIN Ltd. or its subsidiaries
and may not be reproduced or used in whole or in part
as the basis for manufacture or sale of products
without written permission.
Record of Revision
Rev. Date Description of Change
1 6/02/06 Initial Release
2 6/16/06 Add documents to Table 1 & 2
A 7/25/06 Update Table 1 & 2 revisions for initial STC issue. Add FT Report.

GMX 200 STC Installation 005-C0315-00 Rev A
STC Master Data List Page 2 of 6
1. INTRODUCTION...................................................................................................................3
1.1 Purpose.................................................................................................................3
1.2 Scope....................................................................................................................3
1.3 Document Revision...............................................................................................3
1.4 Definitions.............................................................................................................3
2. DATA AND EQUIPMENT LIST REQUIRED FOR INSTALLATION .....................................3
2.1 Data Required for Installation...............................................................................3
2.2 Substantiating Data ..............................................................................................4
2.3 Equipment List......................................................................................................5
3. GENERAL INSTALLATION REQUIREMENTS....................................................................5
4. GENERAL.............................................................................................................................5
4.1 Mechanical............................................................................................................5
4.2 Hardware ..............................................................................................................5
4.3 Wiring....................................................................................................................6
4.4 Circuit Protection ..................................................................................................6
4.5 Electrical Load Analysis........................................................................................6
5. SPECIAL INSTALLATION INSTRUCTIONS........................................................................6
Table 1 STC Data.......................................................................................................................4
Table 2 Related Data (Substantiating Data)...............................................................................4
Table 3 Required Equipment List...............................................................................................5

GMX 200 STC Installation 005-C0315-00 Rev A
STC Master Data List Page 3 of 6
1. INTRODUCTION
1.1 Purpose
The purpose of this document is to list the data required to support STC installation of the Garmin
GMX 200 Multi-Function Display in accordance with STC requirements, and to list other data associated
with the STC which is not required for installation.
1.2 Scope
This document applies to the installation of the GMX 200 units when installed IAW the data listed in this
document on the Approved Model List aircraft as defined for this STC. This document includes general
installation requirements, special installation instructions, and it provides an index of STC data including
both data required for installation and data associated with the STC, but not required for installation.
1.3 Document Revision
This document shall be released, archived, and controlled in accordance with Garmin document control
system. As such when this and other documents are revised, the entire document is revised and the
new revision nomenclature is changed on each page of the revised document.
1.4 Definitions
The following terminology is used within this document:
1) AC: Advisory Circular
2) AML: Approved Model List
3) DER: Designated Engineering Representative
4) FAA: Federal Aviation Administration
5) FARs: Federal Aviation Regulations
6) IAW: In accordance with
7) STC: Supplemental Type Certificate
8) TIA: Type Inspection Authorization
2. DATA AND EQUIPMENT LIST REQUIRED FOR INSTALLATION
2.1 Data Required for Installation
2.1.1 GMX 200 Installation Data
All documents listed in Table 1 are required for installation purposes for new installations of the
GMX 200 equipment. All documents must be of the revision listed or later FAA approved revisions.

GMX 200 STC Installation 005-C0315-00 Rev A
STC Master Data List Page 4 of 6
Table 1 STC Data
Mfg. Doc No. Rev Description
Garmin 005-C0315-00 A GMX 200 Master Data List (this document)
Garmin 190-00607-00 A GMX 200 Instructions for Continued Airworthiness
Garmin 190-00607-01 A GMX 200 AFMS
Garmin 190-00607-02 A GMX 200 Pilot’s Guide
Garmin 190-00607-04 B GMX 200 Installation Manual
2.1.2 Continued Airworthiness
Instructions for continued airworthiness are found in Garmin document number 190-00607-00
Instructions for Continued Airworthiness. See Table 1 for document revision.
2.2 Substantiating Data
The documents listed in Table 2, or later FAA-approved revisions, contain information related to this STC
but are not required for follow-on installations.
Table 2 Related Data (Substantiating Data)
Doc No. Rev Description
005-00315-00 1 Project Specific Certification Plan (PSCP) for Installation of GMX
200 unit in STC AML
005-00315-01 2 GMX 200 STC System Accomplishment Summary
005-00315-02 1 GMX 200 Flight Test Plan
005-00315-03 1 GMX 200 Ground Test Plan
005-00315-04 2 GMX 200 Flight Test Report
005-00315-06 1 GMX 200 FHA & System Safety Assessment
005-00315-07 1 GMX 200 Model Qualification Process for STC AML
005-00315-08 2 GMX 200 Acceptance Analysis for STC AML
005-00315-20 1 GMX 200 Environmental Qualification Form (EQF)

GMX 200 STC Installation 005-C0315-00 Rev A
STC Master Data List Page 5 of 6
2.3 Equipment List
All equipment must have the Part Numbers and Software Versions contained in the following table, or
later FAA Approved revisions or versions.
Table 3 Required Equipment List
Model Description Part
Number Mfg. Software Ver.
(or later FAA
approved version)
OR
GMX 200, Black
GMX 200, Gray
GMX 200 I/O Traffic, Black
GMX 200 I/O Traffic, Gray
GMX 200 I/O Radar/TAWS, Black
GMX 200 I/O Radar/TAWS, Gray
GMX 200 I/O Traffic/Radar, Black
GMX 200 I/O Traffic/Radar, Gray
011-01271-00
011-01271-10
011-01465-00
011-01465-10
011-01466-00
011-01466-10
011-01467-00
011-01467-10
Garmin 2.02
Mounting Tube 115-00746-00 Garmin n/a
Database data card 010-10820-00 Garmin n/a
Connector Kit
Connector Kit, I/O (see note 1) 011-01283-00 011-01283-01 Garmin n/a
Configuration Module 011-00979-02 Garmin n/a
Note 1: I/O Connector Kit required for I/O models only.
3. GENERAL INSTALLATION REQUIREMENTS
4. GENERAL
The installation must be done in accordance with all applicable FARs. The installation shall conform to
the data listed in Section 2.1, Data Required for Installation with exception of special instructions as
defined in Section 5 Special Installation Instructions, which shall have precedence over the data listed in
Section 2.1.
4.1 Mechanical
Mechanical installation, wiring, cable bundling and routing, and connections to existing aircraft systems
must conform to those specific instructions or requirements found in the STC data. Those aspects of the
STC where specific installation instructions or requirements are not provided in the STC data, the
installer shall conform to the recommended practices and procedures found in AC 43.13-2A, Chapter 2,
Radio Installations, and AC 43.13-1B, Chapter 11, Electrical Systems, Section 3, 4 and 7.
4.2 Hardware
Hardware not supplied with the equipment, or otherwise specified in the appropriate installation manuals
or other STC data (ie screws, nuts, tie wrap, etc) shall be from standard aircraft hardware as described
by AC 43.13-1B, Chapter 5, Aircraft Hardware.

GMX 200 STC Installation 005-C0315-00 Rev A
STC Master Data List Page 6 of 6
4.3 Wiring
All wire used in the installation shall be of appropriate standard aircraft quality grade and size as
described in AC 43.13-1B, Chapter 11, Sections 5-20.
4.4 Circuit Protection
All GMX 200 unit modification circuits shall be protected in accordance with AC 43.13-1B, Chapter 11,
Section 4, Circuit Protection Devices.
4.5 Electrical Load Analysis
An electrical load analysis shall be performed on each aircraft, as described in AC 43.13-1B, Chapter 11
Section 3. The document P/N 190-00607-04 GMX 200 Installation Manual provides specifications on the
GMX 200 power requirements.
5. SPECIAL INSTALLATION INSTRUCTIONS
None
