Gasmate CH205HTODS User manual

03371 04/16
Important: Retain these instructions for future use.
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the appliance.
2. Extinguish any open flame.
3. If odour continues, immediately call
your gas supplier.
Do not store or use gasoline or other flammable
vapour and liquids in the vicinity of this or any other
appliance.
FOR OUTDOOR USE ONLY
PROPANE GAS
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Read the instructions thoroughly before installing or
servicing this equipment.
COLUMN HEATER
Model No. CH205HTODS
The ideal solution for extending the season of
outdoor entertaining
Creates a stylish and attractive ambience
Rotary piezo ignition
Includes a safety ‘tip-over’ switch that halts supply of
gas to the unit should it be accidently knocked over
Oxygen depletion system for enhanced safety
Stainless steel burner for extra long-term reliability
Complete with hose and POL regulator
Efficient and powerful 35MJ/h output
Adjustable heat output
Operates for approximately 10 hours on a properly
filled 9Kg Propane cylinder
For outdoor use only
Gas certified to Australian standards

2 32 2
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS
This appliance must only be used in a well
ventilated area.
1. This appliance shall not be installed or
used indoors, in buildings, garages or
any other enclosed area.
2. DO NOT place articles on or against this
appliance.
3. DO NOT use or store flammable
materials near this appliance.
4. Children and adults should be
alerted to the hazards of high surface
temperatures, burns and clothing
ignition.
5. Children should be carefully supervised
when they are in the area of the
appliance.
6. NEVER hang anything including
clothes or other flammable items on the
appliance.
7. DO NOT operate this appliance unless
it is fully assembled with burner guard in
place.
8. DO NOT SPRAY AEROSOLS IN THE
VICINITY OF THIS APPLIANCE WHILE
IT IS IN OPERATION.
9. Installation and repair should be done
by a qualified service person. The
appliance must be inspected before
use and at least annually by a qualified
service person. It is imperative that
control compartment, burners and
circulating air passages of the heater be
kept clean.
IMPORTANT SAFETY RULES
Prior to assembling your appliance, the following
must be reviewed. Compliance with the following
should result in satisfactory heater operation.
This instruction manual should be retained for
future reference. The installation must conform
with local codes or authority having jurisdiction.
1. The appliance is intended for heating
residential and non-residential outdoor
spaces. The installation must conform with
local codes or, in the absence of local codes,
with the Australian Standard AS 5601.
2. Adequate clearance around air openings
into the combustion chamber, clearances
from combustible materials, provisions for
accessibility and for combustion and
ventilating air supply must be maintained at
all times when the appliance is operating.
3. Proper clearance from combustible materials
must be maintained at all times.
The minimum clearances are as follows:
Minimum Clearance from Combustibles
Side 500mm Rear 500mm
Ceiling 500mm Below 500mm
Combustible materials are considered to be
wood, compressed paper, plant fibres, plastic,
plexiglas or other materials capable of being
ignited and burned. Such materials shall be
considered combustible even though flame
proofed, fire-retardant treated or plastered.
Additional clearance may be required for glass,
painted surfaces and other materials which may
be damaged by radiant or convection heat.
4. Heaters must be placed on a level and
adequate footing and be readily accessible.
5. The gas manifold supply pressure must
be regulated at 2.75 kPa utilising an AGA
approved regulator (supplied with heater).
6. The appliance must be inspected before
each use, and at least annually by a qualified
service person.
a. The appliance area must be kept clear
and free of combustible materials,
gasoline and other flammable vapours
and liquids.
b. Gas orifices and burner must be kept
clear of dirt and cobwebs. Flow of and
ventilation air through the perforated
portions of the heater must not be
obstructed. Cleaning with a soft brush
before use and at least every six months
is recommended.
c. All gas connections should be checked
for leaks utilising a soap solution. NEVER
use a flame for this purpose.

2 32
INSTALLATION, OPERATION & MAINTENANCE INSTRUCTIONS INSTALLATION - OUTDOOR USE ONLY
d. The flame pattern at the emitter grid
should be visually checked whenever
heater is operated. If flames extend
beyond surface of the emitter grid or
black spot is accumulating on the emitter
grid or reflector, the heater should be
turned off immediately. The heater should
not be operated again until the unit is
serviced and or repaired.
e. Any cleaning agent used on the heater
should be of a non-combustible and non-
corrosive nature.
f. The stainless steel emitter grid normally
does not require cleaning and should
NEVER be painted.
7. The hose must be protected from contact
with hot or sharp surfaces both during use
and while in storage. The hose assembly
should be visually inspected prior to each
use of the heater. If excessive abrasion or
wear is evident, or the hose is cut, it must
be replaced prior to operating the heater.
The replacement hose assembly may be
obtained from the manufacturer.
8. DO NOT use any pressure regulator or hose
assembly other than those supplied with the
appliance. Replacement pressure regulator
and hose assembly must be those specified.
Replacement parts may be obtained from
the manufacturer or your local sales
representative.
9. Installation and use of this heater must
conform with local codes or, in the
absence of local codes, with the Standards
of Storage and Handling of Liquefied
Petroleum Gases.
10. This heater is designed to operate with
a standard 9Kg propane cylinder with
Approved Cylinder Connection.
11. The valve outlet must be maintained in good
condition. When the cylinder is not in
use, be sure to cover it with a dust cap. A
leak test should be performed with soapy
water whenever connecting a new cylinder.
NEVER use a match to test for leaks.
12. The gas cylinder must be turned off
whenever the heater is not in use. When
the heater is to be stored indoors, the
propane cylinder and the heater must be
disconnected and the cylinder stored in
accordance with the Standard for Storage
and Handling of Liquefied Gases.
13. The heater has been designed with several
safety features which include a tip over
switch.
Screw the coupling nut of regulator into the
cylinder valve outlet.
POL CYLINDER CONNECTION DEVICE
Type of Gas Propane
Consumption 35 MJ/h
Operating Pressure 2.75 kPa
Injector Size 1.9 mm
Heater specifications can be found on the data
label.
Any modification to the heater not described in
the installation instructions may compromise the
safety of this appliance. Special concern is as
follows:
(1) DO NOT shorten post length;
(2) DO NOT bypass thermocouple safety;
(2) DO NOT operate heater without the reflector;
Clothing or other flammable materials should not
be hung from the heater, or placed on or near
the heater. The area above the burner may be
extremely hot. Direct contact with these metal
surfaces should be avoided in order to prevent
burns or clothing ignition.

4 54 4
Gaurd
Flexible hose
assembly
M5 screw 10mm long
M8 screw 20mm long
M4 screws
6mm long
Gaurd cap
M5 nuts
Cylinder
house body
Cylinder
house door
Lock
M6 screw
15mm long
M6 nuts
Base
Burner head (upper)
Burner head (lower)
Pilot lighting hole
M4 screw 6mm long
Tools Required
Phillips head screwdriver
2 adjustable spanners
STEP 1
Secure the base to the cylinder
house body with five M6 x
15mm long screws, washers
and nuts.
STEP 2
Secure the burner head lower
to the cylinder house body
with four M5 x 10mm long
screws, washers and nuts.
Attach the burner head upper
using four M4 x 6mm long
screws.
STEP 3
Locate the guards into the
burner head support ensuring
the pilot lighting hole is aligned
with the hole in the burner tube
and attach together using ten
M4 screws 6mm long.
STEP 4
Position the guard cap over
the guards and secure using
six M4 screws 6mm long and
to the burner head upper using
an M8 x 20mm long screw.
STEP 5
Securely attach the hose to the
burner head and the regulator
to a gas cylinder, check the
connections for leaks using a
soap solution.
STEP 6
Sit the cylinder house door into
the hinge, close and lock.
COLUMN HEATER ASSEMBLY

4 54
COLUMN HEATER - FOR OUTDOOR USE ONLY
Minimum Clearance from Combustible Surfaces*:
500mm
1888mm
760mm
540mm
*Combustible materials are considered
to be wood, compressed paper, plant
fibres, plastic or other materials that are
capable of being ignited and burned.

6 76 6
White smoke may appear around the emitter grid during
the first minute of initial firing.
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Any modifications or adjustments made to product without prior
authority from the manufacturer will void any warranty claims. Read the installation, operating and
maintenance instructions thoroughly before installing or servicing this equipment.
WARNING
TEST FIRING HEATER
Test fire heater, following the lighting instructions. Leak test all gas connections with soapy water. Soap
bubbles indicate gas leakage. DO NOT use a match to test for gas leaks.
TROUBLE SHOOTING
Problem Possible Causes
Pilot won’t light
Air in gas line
Low gas pressure
Gas line turned ‘OFF’
Blockage in gas line
Ignitor did not spark
Pilot won’t stay lit
Suspect thermocouple
Corrosion of thermocouple contact
Suspect valve
Wind exceeding 16 kph
Main burner will not light
No gas
Low gas pressure
Blockage in orifice
Manual valve not in ‘LIGHT’ position
Note: If the appliance cannot be adjusted to perform correctly it should not be used until serviced or repaired.
LIGHTING INSTRUCTIONS
1. Ensure that the control knob is off. Slowly open the gas
cylinder valve.
2. Press and turn the control knob to ‘LIGHT’ position, the
rotary piezo will make a clicking sound.
3. Check for pilot flame through pilot lighting hole. If pilot does
not light turn control knob to ‘OFF’ position and try again
from the start. Several attempts may be necessary.
4. With the pilot alight keep control knob depressed for 15
seconds then turn the control knob to ‘LOW’.
5. For maximum heat turn control knob to ‘HIGH’.
6. To turn heater off, turn control knob to ‘OFF’.
Note: Allow one minute to purge air through to pilot after
connection to a new cylinder.

6 76
SAFE APPLIANCE LOCATIONS
This appliance shall only be used in an above ground open-air situation with natural ventilation,
without stagnant areas, where gas leakage and products of combustion are rapidly dispersed by
wind and natural convection.
Any enclosure in which the appliance is used shall comply with one of the following:
An enclosure with walls on all sides, but at least one permanent opening at ground level and
no overhead cover (see Example 1).
Within a partial enclosure that includes an overhead cover and no more than two
walls (see Example 2 & 3).
Within a partial enclosure that includes an overhead cover and more than two walls,
the following will apply:
at least 25% of the total wall area is completely open, and
at least 30% of the remaining wall area is open and unrestricted (see Example 4 & 5).
In the case of balconies, at least 20% of the total wall area shall be and remain open and
unrestricted.
The following figures are diagrammatical representations of outdoor areas. Rectangular areas have been
used in these figures - the same principles apply to any other shaped area.

88
For any queries or assistance call
Customer Service
(Australia Only)
1300 174 876
Hours of operation:
Monday to Friday 8.30am - 5.30pm EST
Do not return to place of purchase.
Keep your purchase receipt, this will be required to
make any claims under the 12 month warranty.
