Read in detail for correct use.

Gas & Flame
Detection System
GTL-200
Instruction Manual
www.gastron.com
02_03
When abnormalities occur after purchasing the product,
please contact the following address.
· Address : 23 Gunpo Advanced Industry 1-ro,
Gunpo-si, Gyeonggi-do
· Tel : [phone]
· Fax : [phone]
· URL : www.gastron.com
· e-mail : [email protected]
Thank you very much for purchasing a product from Gastron Co. Ltd.
Our Gastron Co.Ltd. is a company specialized in Gas Detector & Gas Monitoring System and have been
recognized by many customers for the best quality and use convenience. We always seek to help our
customers to find the product they need and we continuously research to develop gas detectors that satisfies
our customers. From now on, you can solve all problems related to gas detectors with the products of
Gastron. We Gastron will be responsible for your satisfaction.
This user manual describes operation and simple maintenance methods etc. for the gas detector. Please read
carefully and store it in a safe place. Using it as a reference will help a lot when you have a question during
use.
The product and manual are subject to change without a notice for the product's functional improvement and ease of use.
■Onlyanindividualspecializedinexplosion-proofdevicesandwarninglightsmaydisassemble
the device.
■Pleasecontactourcompany'stechnicalsupport,e-mail,orwebsiteforinquiriesrelatedto
inspection and calibration of the explosion-proof warning light.
Greetings

6. Drawings and Dimensions········································································································································ 18
6.1. Combination Type ·················································································································································· 18
6.2. Sounder Type·························································································································································· 19
6.3. Beacon Type ··························································································································································· 20
7. Precautions during Installation ································································································································ 21
Appendix A. Sound Tone Table····································································································································· 22
Appendix B Method to Set Tone··································································································································· 24
8. Revision History··························································································································································· 26
www.gastron.com
04_05
ContentsContents
1. Overview ······································································································································································ 6
2. Specification ································································································································································ 6
2.1. Basic Specifications············································································································································ 6
2.2. Mechanical Specifications ································································································································· 7
2.3. Electrical Specifications(DC Type)······················································································································ 7
2.4. Electrical Specifications (AC Type)····················································································································· 8
2.5. Environmental Specifications ···························································································································· 8
3. Name and description of each part ························································································································ 9
3.1. Combination Type Components ······················································································································· 10
3.2. Sounder Type Components······························································································································· 11
3.3. Beacon Type Components································································································································· 12
4. Installation···································································································································································· 14
4.1. Detachment of Cover ········································································································································ 14
4.2. Combination & Sounder Type Terminal Configuration ···················································································· 15
4.2.1. AC Type Terminal Description················································································································· 15
4.2.1. DC Type Terminal Description················································································································· 15
4.3. Beacon Type Terminal Configuration ················································································································ 15
4.3.1. AC Type Terminal Description················································································································· 15
4.3.2. DC Type Terminal Description················································································································· 15
5. Operation Method ····················································································································································· 16
5.1. Operation Status Setting ··································································································································· 16
5.2. External Contact Point Control·························································································································· 16
5.2.1. Dry Contact Configuration ····················································································································· 17
5.2.2. Wet Contact Configuration ···················································································································· 17
GTL-200
Instruction Manual

www.gastron.com
06_07
2. Specication
GTL-200 explosion-proof warning light uses semi-permanent LED light source and has aluminum housing. It is an
explosion-proof product with excellent durability and safety.
With Gastron's unique lens-type lighting system, it has high emission effect of optical signal. Using built-in switches,
sound type, speaker volume, and rotation speed of reflector can be adjusted, thus they can be changed in accordance to
installation condition.
LED has 4 colors; Red, Yellow, Green, and Blue and the max. volume of the speaker is 120 dB. 64 different sound tones
can be selected and external contact is operated by Dry & Wet Contact Method.
3 types of product are available; combination type with speaker and LED combined together, sounder type with speaker
operation only, and beacon type with LED operation only.
GTL-200 explosion-proof warning light has explosion-proof enclosure and is a product that can be used in combination
of stand-alone beacon, speaker, and combination types, etc.
2.2. Mechanical Specifications
ITEMS SPECIFICATION
Explosion-Proof Type Explosion-Proof Enclosure
Cable Inlet 3/4" PF ( 1/2" or 3/4" NPT )
Mounting Holes Ø 7 ±0.1
Size (Dimension) (mm)
Sounder 164(W) * 139(H) * 322(177)(D)
Beacon 164(W) X 278.5(H) X177(D)
Combination 164(W) * 278.5(H) * 322(177)(D)
Weight
Sounder App. 5.0kg
Beacon App. 5.0kg
Combination App. 6.2kg
Body Material Lamp Cover Explosion-Proof Tempered Glass
Body ALDC12
2.3. Electrical Specifications(DC Type)
ITEMS SPECIFICATION
Input Voltage
※CustomersuppliedPSUmustmeetrequirements
IEC1010-1 and CE Marking requirements.
Absolute min:
Nominal:
Absolute max:
Ripple maximum allowed:
18V
24V
30V
0.1V pk-pk
Sounder Wattage Max. wattage:
Max. current:
17.8W@+24VDC
0.74A@+24VDC
Beacon Wattage Max. wattage:
Max. current:
5.1W@+24VDC
0.21A@+24VDC
Combination Wattage Max. wattage:
Max. current:
19.2W@+24VDC
0.8A@+24VDC
EMC Protection: CE
2. Specication
1. Overview
GTL-200
Instruction Manual
2.1. Basic Specifications
ITEMS SPECIFICATION
Display Method LED light source with a rotating reflector
Display Color Option Red, Yellow, Green, Blue
Sound Maximum output Normal 110dB@1meter(1.2KHz)
Max 120dB@1meter(1.2KHz)
Tone Selection 64 user selectable tones
Approvals Classification ExdⅡCT4~T6
EN 61000-6-2 , EN 61000-6-4
Ingress Protection IP66
Product Type
Sounder
Beacon
Combination
Warranty 2Year

www.gastron.com
08_09
3. Name and Description of Each Part
3.1. Combination Type Components
[Figure 1. Combination Type Configuration]
2. Specication
GTL-200
Instruction Manual
2.4. Electrical Specifications (AC Type)
ITEMS SPECIFICATION
Input Voltage
※CustomersuppliedPSUmustmeetrequirements
IEC1010-1 and CE Marking requirements.
Absolute min:
Nominal:
Absolute max:
Ripple maximum allowed:
210V
220V
230V
0.1V pk-pk
Sounder Wattage Max. wattage:
Max. current:
19.7W@+220VAC
0.17A@+220VAC
Beacon Wattage Max. wattage:
Max. current:
4.7W@+220VAC
0.05A@+220VAC
Combination Wattage Max. wattage:
Max. current:
22W@+220VAC
0.2A@+220VAC
EMC Protection: CE
2.5. Environmental Specifications
ITEMS SPECIFICATION
Operation Temperature T5 -40to70℃
T6 -40to60℃
Storage Temperature -40to70℃
Operation Humidity 5 to 99% RH (Non-condensing)
No ITEMS SPECIFICATION
1Case Body Protects internal PCB and other parts by body.
2Case cover Protects internal parts by body.
3Case Glass Cover Protects internal glass and other parts by body.
4Explosion Light Glass It is an explosion-proof case made of glass material and disperse light to outside.
5Case Glass Ring Prevents diversion during explosion light glass fastening.
6Gasket Prevents diversion during explosion light glass fastening.
7O-Ring/1 Inhibits inlet of dust, particles, water, gas
8Reflector Diffracts LED light to emit.
9Reflector troll plate Works as rotating plate that rotates reflector.
10 Motor troll plate Works to deliver rotating speed of motor.
11 Motor Works to rotate reflector.

www.gastron.com
10_11
3.1. Combination Type Components
No NAME DESCRIPTIONS
12 Led assy plate(bracket) Fastens LED Assy to the body.
13 lens Lens for light source that emits LED light.
14 Heat sinking plane Heat-proof body that decreases LED temperature and increases lifetime.
15 Bearing washer Washer for bearing that operates rotating plate to decrease friction.
16 Heat sinking plane-Net Net that fastens heat-proof plate to LED assy plate (bracket)
17 Speaker Cover Protects internal Driver unit and other parts by body
18 FlameArrester∮25x2 Prevents entrance of debris and delivers buzzer sound to outside.
19 Driver unit Speaker that emits PCB signal sound.
20 Horn set Horn that enhances output of driver unit and prevents water from entering.
21 Cage Protective mesh for explosion light glass
22 Terminal PCB AC/DC Power Supply
23 Main PCB Operates by receiving signal upon an error in LED/speaker/motor
24 Led PCB PCB with LED
No NAME DESCRIPTIONS
1Case Body Protects internal PCB and other parts by body
2Case cover Protects internal parts by body
3O-Ring/1 Inhibits inlet of dust, particles, water, gas
4Speaker Cover Protects internal Driver unit and other parts by body
5FlameArrester∮25x2 Prevents entrance of debris and delivers buzzer sound to outside.
6Driver unit Speaker that emits PCB signal sound.
7Horn set Horn that enhances output of driver unit and prevents water from entering.
8Terminal pcb AC/DC Power Supply
9Main pcb Operates by receiving signal upon an error in LED/speaker/motor
10 Name plate lavel Label for Authentication
[Table 1. Combination Type Configuration Description]
GTL-200
Instruction Manual
3.2. Sounder Type Configuration
[Figure 2. Sounder Type Configuration]
[Table 2. Sounder Type Configuration Description]
3. Name and Description of Each Part3. Name and Description of Each Part

www.gastron.com
12_13
GTL-200
Instruction Manual
[Table 4. Beacon Type Configuration Description]
No NAME DESCRIPTIONS
1Case Body Protects internal PCB and other parts by body
2Case cover Protects internal parts by body
3Case Glass Cover Protects internal Glass and other parts by body
4Explosion Light Glass It is an explosion-proof case made of glass material and disperse light to outside.
5Case Glass Ring Prevents diversion during explosion light glass fastening.
6Gasket Prevents diversion during explosion light glass fastening.
7O-Ring/1 Inhibits inlet of dust, particles, water, gas
8Reflector Diffracts LED light to emit.
9Reflector troll plate Works as rotating plate that rotates reflector.
10 Motor troll plate Works to deliver rotating speed of motor.
11 Motor Works to rotate reflector.
12 Led assy plate(bracket) Fastens LED Assy to the body.
13 lens Lens for light source that emits LED light.
14 Heat sinking plane Heat-proof body that decreases LED temperature and increases lifetime.
15 Bearing washer Washer for bearing that operates rotating plate to decrease friction.
16 Heat sinking plane-Net Net that fastens heat-proof plate to LED assy plate (bracket)
17 Cage Protective mesh for Explosion Light Glass
18 Terminal pcb AC/DC Power Supply
19 Main pcb Operates by receiving signal upon an error in LED/Speaker/Motor
20 Led pcb set PCB with LED
3.3. Beacon Type Components
[Table 3. Beacon Type Configuration]
3. Name and Description of Each Part3. Name and Description of Each Part

www.gastron.com
14_15
4. Install4. Install
GTL-200
Instruction Manual
■Itisprohibitedforanindividual,otherthananapproveduseroratechnicianresponsibleforinstallationandrepair
from the head office, to install an explosion-proof warning light on site or open the cover of the installed warning
light and manipulate it. This may cause serious loss of life and property from fire, explosion, and etc.
■Inaddition,pleasecheckwhetherthereisanyremainingexplosivegasorcombustiblematerialinthe
surroundings. Power must be turned off before performing work.
4.1. Detachment of Cover
■Turntheslottedsetscrew(M4)fixingthecoverpartofmainbody3~4turnscounterclockwise(ccw)usingahex
wrench (M2) then turn the cover of gas leak detector ccw to detach the cover.
■Whenthebottomcoverisdetached,terminalboardforexternalwiringappears.Performcablewiringasshown
in the terminal configuration below.
[Figure 3. Slotted Set Screw Configuration]
No PCB SILK DESCRIPTION NOTE
1L1 AC Power (Live)
2L2 AC Power (Natural)
3S1 External Signal Line 1
Operates upon connecting "COM" terminal to a
desired signal line.
(Only supports Dry Contact Operation)
4S2 External Signal Line 2
5S3 External Signal Line 3
6COM Digital Ground
4.2.1. AC Type Terminal Description
4.2. Combination & Sounder Type Terminal Configuration
No PCB SILK DESCRIPTION NOTE
1 + DC + Power
2 - DC - Power
3S1 External Signal Line 1 For Dry Contact Operation, connect to "DC -"
power to run. For Wet Contact Operation, run
"S1~S3"and"DC-"
4S2 External Signal Line 2
5S3 External Signal Line 3
4.2.2. DC Type Terminal Description
4.3. Beacon Type Terminal Configuration
4.3.1. AC Type Terminal Description
No. PCB SILK DESCRIPTION
1L1 AC Power (Live)
2L1
3L2 AC Power (Natural)
4L2
4.3.2. DC Type Terminal Description
No. PCB SILK DESCRIPTION
1 + DC + Power
2 + DC + Power
3 - DC - Power
4 - DC - Power

5.1. Operation Status Setting
■Byusing#1to#6internaldipswitch,operatingtonecanbeselected.Fortypesoftone,refertothetonetablein
Appendix A.
■Byusing#7to#8internaldipswitch,operatingmodecanbechanged.
5.2.1. Dry Contact Configuration
■UsingCOMterminal,controlcontactstatusofS1~S3.
www.gastron.com
16_17
GTL-200
Instruction Manual
[Figure 4. Dry Contact Configuration]
5.2.2. Wet Contact Configuration
■UsingDC+power,selectS1~S3signal.
[Figure 5. Wet Contact Configuration]
5.2. External Contact Point Control
■Inordertoselectproductoperationandoutputtone,internalcontactpoints(S1~S3)ofwarninglightmustbe
controlled.
■Byusingapplicablecontactpoint,itcancontroloperationstatusandtoneoutput.Refertotheoperationstatus
setting table above for control mode.
■ForconfigurationofS1~S3fortoneoutput,refertoMethodforSettingToneinAppendixB.
■ContactpointcontrolconfigurationcanbesetinDryContactandWetContact.Operationconfiguration
depending on Contact Type is set to internal Jumper configuration and related items are as follows.
■ForMode1,performbasicwarninglightconfiguration.
■ForMode2,itisusedwhenpowerisinputtedregularlyandwhenitiscontrolledonlyusingexternalcontactpoints.
■ForMode3,itisamodetomanuallystoptoneoutputandusedduringsetting.
[Table 5. Operation Description]
Mode Dip Switch Setting Power On Input External Contact Point
(S1, S2, S3)
#7 #8
Mode1 OFF OFF Beacon operation and
set tone output N/A
Mode2 OFF ON No Operation Beacon operation and
set tone operation
Mode3 ON OFF Beacon Operation Set tone Operation
5. Operation Method5. Operation Method

www.gastron.com
18_19
GTL-200
Instruction Manual
6.1. Combination Type 6.2. Sounder Type
[Figure 6. Combination Type Drawing] [Figure 7. Sounder Type Drawing]
6. Drawings and Dimensions6. Drawings and Dimensions

www.gastron.com
20_21
GTL-200
Instruction Manual
■Avoidareaswithelectricalbarrierssuchasrainwater,etc.Itisrecommendedtobeinstalledinareasthatareeasierto
work in since regular maintenance is needed. Avoid areas with vibration or shock since they can affect output values.
■Thisequipmenthasexplosion-proofconstructionforinternalpressureandbelongstoGROUPIIforgasandvaporin
general work sites and chemical plants. It can be used in ZONE 1 (ONE) and ZONE 2 (TWO) hazardous sites.
■Allowabletemperatureis85Corbelow,whichcorrespondstoT6.
■Surroundingtemperatureisinarangeof-40°C~70°C.
■RelativeHumidity:5%~99%
■InstallationSite:IndoorandOutdoor
■ExplosionIgnitionGradefortheGasorVapor:ExdIICT6
■Duringwiringwork,useexplosion-proofcableglandatcableinletortightlysealcableconduitduringmetalcable
wiring construction to prevent spread of flames in case of explosion or movement of gas, etc. through the cable
conduit within 50 mm.
■Whenconnectingtheequipmentwithcable,screwthreadmustbetightened5threadsormore.
■Workinconditionssatisfyingother[StandardsforSelection,Installation,andMaintenance,etc.ofExplosion-proof
Electric Machine and Equipment Wiring, etc. at Work Site]
■Allmaterialsusedforcableinletsuchascableglandandsealingfitting,etc.andusedassealingunusedinletsmust
pass the verification!
6.3. Beacon Type
[Figure 8. Beacon Type Drawing]
7. Precautions before Installation6. Drawings and Dimensions
[Figure 9. High-Pressure Packing Type] [Figure 10. Y Sealing Compound]
Cable Cable
Inside Inside
Outside Outside
Lead-in unit connector
Lead-in unit connector
Charging compound
Cable-fixing device
Pipe for piping
Cable-fixing device
Sealing ring
Sealing
ring
Connector
Pipe for piping
Compressed
element
Connector for fixing
compressed element

www.gastron.com
22_23
GTL-200
Instruction Manual
Appendix A. Tone Table
■Operatingtonesconsistof64differenttypesandisaccordingtothetablebelow.
TONE OUTPUT SIGNAL FORM OF SIGNAL
Tone1 300Hz Continues
Tone2 340Hz Continues
Tone3 440Hz Continues
Tone4 554Hz Continues
Tone5 660Hz Continues
Tone6 800Hz Continues
Tone7 1000Hz Continues
Tone8 1200Hz Continues
Tone9 2000Hz Continues
Tone10 2400Hz Continues
Tone11 2850Hz Continues
Tone12 420Hz at 625msec on/off
Tone13 544Hz at 875msec on/off
Tone14 660Hz at 150msec on/off
Tone15 660Hz at 1800msec on/off
Tone16 745Hz at 500msec on/off
Tone17 800Hz at 250msec on/off
Tone18 800Hz at 250msec on / 1000msec off
Tone19 1000Hz at 250msec on/off
Tone20 1000Hz at 500msec on/off
Tone21 1000Hz at 250msec on / 1000msec off
Tone22 1000Hz at 1000msec on/off
Tone23 2400Hz at 250msec on/off
Tone24 2400Hz at 500msec on/off
Tone25 2850Hz at 1000msec on/off
Tone26 2850Hz at 150msec on / 100msec off
Tone27 700Hz at 2000msec on/off
Tone28 700Hz at 125msec on/off
Tone29 720Hz at 700msec on/ 300msec off
Tone30 970Hz at 500msec on/off, 1500msec off
Tone31 2850Hz at 500msec on/off, 1500msec off
TONE OUTPUT SIGNAL FORM OF SIGNAL
Tone32 Reserved
Tone33 Reserved
Tone34 544Hz / 440Hz at 1000msec
Tone35 800Hz / 1000Hz at 125msec
Tone36 2400Hz / 2900Hz at 125msec
Tone37 800Hz / 1000Hz at 250msec
Tone38 800Hz / 1000Hz at 500msec
Tone39 1000Hz / 2000Hz at 500msec
Tone40 2400Hz / 2900Hz at 250msec
Tone41 500Hz - 1000Hz at 6Hz
Tone42 500Hz - 1200Hz at 0.3Hz
Tone43 660Hz - 1200Hz at 1Hz
Tone44 800Hz - 1000Hz at 1Hz
Tone45 800Hz - 1000Hz at 7Hz
Tone46 2400Hz - 2900Hz at 1Hz
Tone47 2400Hz - 2900Hz at 7Hz
Tone48 800Hz - 1000Hz at 50Hz
Tone49 2400Hz - 2900Hz at 50Hz
Tone50 1200Hz - 500Hz at 1Hz
Tone51 1400Hz - 1600Hz at 1000msec up / 500msec down
Tone52 500Hz - 1200Hz at 2500msec up, 500msec off
Tone53 500Hz - 1200Hz at 5000msec up, 250msec off
Tone54 800Hz / 660Hz at 1500msec off
Tone55 800Hz / 1000Hz at 180msec off
Tone56 250Hz - 1200Hz at 3sec up, 6sec, 3sec down
Tone57 250Hz - 800Hz at 3sec up, 6sec, 3sec down
Tone58 250Hz - 2400Hz at 6sec up, 6sec, 6sec down
Tone59 Simulated Bell
Tone60 wave-1
Tone61 wave-2
Tone62 wave-3
Tone63 wave-4
Tone64 wave-5
7. Precautions before Installation7. Precautions during Installation

www.gastron.com
24_25
GTL-200
Instruction Manual
Appendix B Method to Set Tone
■Tosetoutputtone,when#7and#8ofdipswitchesareturnedOFF,itisoutputtedbysettingfrom#1~6ofdip
 switchesafterturningpowerON,regardlessofoperationstatusofexternalcontactpoints(S1~S3).
■When#8ofdipswitchisturnedon,theoutputtoneisdecidedbycombinationof#1~6settingofdipswitchand
 externalcontactpoint(S1~S3)asshowninthetablebelow.
No. DIP Switch
DIP S/W
#7,8 OFF DIP S/W #8 ON
Stage1 Stage2 Stage 3 Stage 4 Stage 5 Stage 6 Stage 7 Stage 8
123456 S1 S2 S1+S2 S3 S1+S3 S2+S3 S1+S2+S3
1Tone1 Tone1 Tone10 Tone45 Tone22 Tone 60 Tone 61 Tone 5
2Tone2 Tone2 Tone10 Tone45 Tone22 Tone 60 Tone 61 Tone 5
3Tone3 Tone3 Tone10 Tone25 Tone39 Tone 60 Tone 61 Tone 5
4Tone4 Tone4 Tone10 Tone45 Tone22 Tone 60 Tone 61 Tone 5
5Tone5 Tone5 Tone10 Tone39 Tone45 Tone 60 Tone 62 Tone 6
6Tone6 Tone6 Tone10 Tone39 Tone45 Tone 60 Tone 62 Tone 5
7Tone7 Tone7 Tone22 Tone9 Tone45 Tone 60 Tone 62 Tone 5
8Tone8 Tone8 Tone22 Tone10 Tone45 Tone 60 Tone 62 Tone 5
9Tone9 Tone9 Tone22 Tone7 Tone39 Tone 60 Tone 63 Tone 5
10 Tone10 Tone10 Tone5 Tone45 Tone22 Tone 60 Tone 63 Tone 6
11 Tone11 Tone11 Tone5 Tone45 Tone22 Tone 60 Tone 63 Tone 6
12 Tone12 Tone12 Tone10 Tone39 Tone45 Tone 60 Tone 63 Tone 5
13 Tone13 Tone13 Tone4 Tone9 Tone45 Tone 61 Tone 62 Tone 5
14 Tone14 Tone14 Tone10 Tone45 Tone22 Tone 61 Tone 62 Tone 5
15 Tone15 Tone15 Tone10 Tone22 Tone39 Tone 61 Tone 62 Tone 5
16 Tone16 Tone16 Tone10 Tone22 Tone39 Tone 61 Tone 62 Tone 5
17 Tone17 Tone17 Tone10 Tone45 Tone35 Tone 62 Tone 63 Tone 5
18 Tone18 Tone18 Tone10 Tone22 Tone45 Tone 62 Tone 63 Tone 5
19 Tone19 Tone19 Tone10 Tone22 Tone45 Tone 62 Tone 63 Tone 5
20 Tone20 Tone20 Tone10 Tone22 Tone45 Tone 62 Tone 63 Tone 5
21 Tone21 Tone21 Tone10 Tone45 Tone22 Tone 63 Tone 64 Tone 5
22 Tone22 Tone22 Tone10 Tone45 Tone39 Tone 63 Tone 64 Tone 5
23 Tone23 Tone23 Tone5 Tone45 Tone22 Tone 63 Tone 64 Tone 6
24 Tone24 Tone24 Tone5 Tone45 Tone38 Tone 63 Tone 64 Tone 6
25 Tone25 Tone25 Tone5 Tone45 Tone38 Tone 64 Tone 60 Tone 6
26 Tone26 Tone26 Tone5 Tone45 Tone38 Tone 64 Tone 60 Tone 6
27 Tone27 Tone27 Tone10 Tone22 Tone45 Tone 64 Tone 60 Tone 5
No. DIP Switch
DIP S/W
#7,8 OFF DIP S/W #8 ON
Stage1 Stage2 Stage 3 Stage 4 Stage 5 Stage 6 Stage 7 Stage 8
123456 S1 S2 S1+S2 S3 S1+S3 S2+S3 S1+S2+S3
28 Tone28 Tone28 Tone10 Tone22 Tone45 Tone 64 Tone 60 Tone 5
29 Tone29 Tone29 Tone10 Tone22 Tone45 Tone 61 Tone 63 Tone 5
30 Tone30 Tone30 Tone10 Tone 22 Tone 45 Tone 61 Tone 63 Tone 5
31 Tone31 Tone31 Tone5 Tone 45 Tone 22 Tone 61 Tone 63 Tone 6
32 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
33 Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved
34 Tone 34 Tone 34 Tone 4 Tone 45 Tone 22 Tone 61 Tone 64 Tone 5
35 Tone 35 Tone 35 Tone 10 Tone 22 Tone 45 Tone 61 Tone 64 Tone 5
36 Tone 36 Tone 36 Tone 10 Tone 22 Tone 45 Tone 61 Tone 64 Tone 5
37 Tone 37 Tone 37 Tone 10 Tone 22 Tone 45 Tone 62 Tone 64 Tone 5
38 Tone 38 Tone 38 Tone 10 Tone 22 Tone 45 Tone 62 Tone 64 Tone 5
39 Tone 39 Tone 39 Tone 22 Tone 7 Tone 45 Tone 62 Tone 64 Tone 5
40 Tone 40 Tone 40 Tone 10 Tone 22 Tone 39 Tone 62 Tone 64 Tone 5
41 Tone 41 Tone 41 Tone 10 Tone 45 Tone 39 Tone 64 Tone 61 Tone 5
42 Tone 42 Tone 42 Tone 10 Tone 45 Tone 39 Tone 64 Tone 61 Tone 5
43 Tone 43 Tone 43 Tone 10 Tone 45 Tone 22 Tone 64 Tone 61 Tone 5
44 Tone 44 Tone 44 Tone 10 Tone 45 Tone 22 Tone 64 Tone 61 Tone 5
45 Tone 45 Tone 45 Tone 10 Tone 22 Tone 39 Tone 64 Tone 63 Tone 5
46 Tone 46 Tone 46 Tone 10 Tone 22 Tone 45 Tone 64 Tone 63 Tone 5
47 Tone 47 Tone 47 Tone 10 Tone 22 Tone 45 Tone 64 Tone 63 Tone 5
48 Tone 48 Tone 48 Tone 10 Tone 39 Tone 45 Tone 64 Tone 63 Tone 5
49 Tone 49 Tone 49 Tone 10 Tone 22 Tone 39 Tone 64 Tone 62 Tone 5
50 Tone 50 Tone 50 Tone 35 Tone 9 Tone 22 Tone 64 Tone 62 Tone 5
51 Tone 51 Tone 51 Tone 10 Tone 45 Tone 22 Tone 64 Tone 62 Tone 5
52 Tone 52 Tone 52 Tone 10 Tone 45 Tone 22 Tone 64 Tone 62 Tone 5
53 Tone 53 Tone 53 Tone 10 Tone 45 Tone 22 Tone 60 Tone 64 Tone 5
54 Tone 54 Tone 54 Tone 6 Tone 22 Tone 39 Tone 60 Tone 64 Tone 5
55 Tone 55 Tone 55 Tone 6 Tone 22 Tone 45 Tone 60 Tone 64 Tone 5
56 Tone 56 Tone 56 Tone 10 Tone 45 Tone 39 Tone 60 Tone 64 Tone 5
57 Tone 57 Tone 57 Tone 10 Tone 45 Tone 22 Tone 62 Tone 60 Tone 5
58 Tone 58 Tone 58 Tone 10 Tone 39 Tone 22 Tone 62 Tone 60 Tone 5
59 Tone 59 Tone 59 Tone 6 Tone 39 Tone 22 Tone 62 Tone 60 Tone 5
60 Tone 60 Tone 60 Tone 10 Tone 45 Tone 22 Tone 61 Tone 62 Tone 5
61 Tone 61 Tone 61 Tone 10 Tone 45 Tone 22 Tone 60 Tone 62 Tone 5
62 Tone 62 Tone 62 Tone 10 Tone 45 Tone 22 Tone 60 Tone 61 Tone 5
63 Tone 63 Tone 63 Tone 5 Tone 22 Tone 39 Tone 61 Tone 62 Tone 6
64 Tone 64 Tone 64 Tone 5 Tone 22 Tone 39 Tone 62 Tone 63 Tone 6
7. Precautions before Installation7. Precautions during Installation

www.gastron.com
26_27
GTL-200
Instruction Manual
Version Contents Date
0.0 * Manual Initial Revision 2013. 03. 14
1.0 * Changed Tone Selection Method and External Contact Point Function 2013. 09. 19
2.0 * Added Tone Table and Contents for Each Product Type 2014. 01. 20
3.0 * Added Case body mount hole size 2014. 04. 04
4.0 * Corrected tone table 2014. 05.04
5.0 * Changed Sound Bracket
* Manual Version Modify 2013. 01. 28
5.1 * Added Dip Switch Function Stetting 2016. 06. 16
6.0 * Changed Font 2016. 11. 09
7.0 *ChangedExplosion-proofEquipmentCableEntryInstallationRegulation45cm→50mm 2017. 01. 20
8. Revision History
