GBC Auto+200M User manual

S H R E D D E R S
™
Instruction Manual
www.accobrandsasia.com
A U T O + 200X&200M™

7
2min
200X
7
200
200
300X
200
7
200X
7
200
1
200X
200X
200
7
200
200
2
200
200
200
7

7
300X
7
4
7
200
200
300X
7
200X
7
3
200
200
7
200X
7
6
5
200
200
200
200
200
200
200

A U T O + 200X&200M™S H R E D D E R S
autofeed technology
auto-feed chamber and up to 6 - 7 sheets through the manual feed slot. The auto-feed mechanism
The Auto+ 200X and 200M has been designed to automatically shred up to 200 sheets from the
has been designed to handle paper fastened with staples and paper clips and to only pull a few
sheets of paper into the cutting mechanism to minimise the risk of paper jams.
Sheet capacity:
Manual feed slot
7 sheets (80gsm)
Sheet capacity:
Autofeed chamber
200 sheets (80gsm)
Duty Cycle 12 min ON / 40 min OFF
Run time from cold 14 minutes
Volts / Hz UK Version: 230V / 50Hz
EK Version: 220V / 60Hz
Amperage UK Version: 1.2 Amps
EK Version: 1.2 Amps
Motor Watts UK Version: 270 Watts
EK Version: 300 Watts
Sheet capacity:
Manual feed slot
6 sheets (80gsm)
Sheet capacity:
Autofeed chamber
200 sheets (80gsm)
Duty Cycle 5 min ON / 30 min OFF
Run time from cold 15 minutes
Volts / Hz UK Version: 230V / 50Hz
EK Version: 220V / 60Hz
Amperage UK Version: 1.5 Amps
EK Version: 1.5 Amps
Motor Watts UK Version: 350 Watts
EK Version: 350 Watts
technical specifications
GBC Auto+ 200X GBC Auto+ 200M
To guard against injury, the following basic safety precautions must be observed in the set-up of this
product.
• Ensure the machine is plugged into an easily accessible power outlet, and ensure the cable is not
likely to trip up a passer by.
•
supplier.
• Unplug your shredder before moving it or when it is not in use for an extended period of time.
• Do NOT operate with a damaged power supply cord or plug, after it malfunctions, or after it has
been damaged in any manner.
•
• The socket-outlet should be near the equipment and should be easily accessible.
•
• Do NOT use near water.
• Do NOT use aerosol dusters or cleaners.
• Do NOT spray anything into the shredder.
• Do NOT load the auto-feed chamber with unopened junk mail, magazines, bound documents etc.
Although this shredder has been designed to comply with UL 60950-1 EN 60950-1 safety standards
including the “probe accessibility tests”, do not operate the shredder near children or pets.
points to note
5
GB

Cool Down indicator – This means
the machine is cooling down.
warning symbols
This means no aerosols.
This means keep children away
from shredder.
This means you should be careful
because long hair can become
entangled in the cutting head.
This means don’t reach into the
feed opening of the cutting head.
This means be careful of loose
jewellery which could become
entangeld in the cutting head.
This means no oil lubrication,
use Rexel oil sheets only.
This means be careful of ties and
other loose clothing which could
become entangled in the cutting
head.
This means the shredder can
accept small paperclips.
This means the shredder can
accept small staples.
Safety First
Sheet capacity of manual feed
entry slot.
7
control panel and indicators
Continuous Jam BoostReverse Auto
This means the shredder can
accept credit cards.
Bin Full indicator – This means the
bin is full.
Paper Loading Door/Bin Door
Open indicator –
This means either:
• Loading door is open
• Bin is open
Lock indicator – This means the
paper loading door is locked (during
shredding).
Paper jam indicator – This means
there is a paper jam in the auto feed
chamber.
If this symbol is flashing the
shredder is attempting to clear a
paper jam automatically.
If this symbol is permanently
illuminated red please follow the
instructions under ‘Reverse function’
to clear any jammed material.
6
GB

Auto+ 200X/200M shredding capability
Auto+ 200X/200M CAN shred the following:
•200 sheets
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small sized paper loaded centrally
•200 sheets
• Paper clip paper, 25mm within the corner.
• Capable of shredding small/medium paper clips (max. wire thickness = 0.9 mm)
• >80/100gsm paper (through manual feed slot ONLY)
• A3 folded in half max. 2 sheets
• 200 sheets
• 80 gsm paper
- A4 - 210mm x 297mm
- A5 - 148mm x 210mm
- A3 single sheet folded in half to make A4
Auto+ 200X/200M CAN shred (through the manual feed slot):
Thick paper or
card.
Multiple folded
sheets (e.g. A3
sheets folded in
half).
Unopened mail
(e.g. junk mail).
Glossy paper or
a sheet covered
with print on both
sides.
Auto+ 200X/200M CANNOT shred the following:
Large clips.
Check the length
of the paperclip
is not longer than
32mm.
Heavy duty
staples. Check
the staple leg
length is not
greater than
6mm.
Bound
documents
Bulldog clips
Magazines or
other documents
bound by multiple
staples or clips.
Adhesive labels.
Plastic sheets,
laminated
documents,
plastic folders.
A U T O + 200X&200M™S H R E D D E R S 7
GB

intelligent help
1In the unlikely event of the shredder jamming, the Auto+ 200X & 200M will stop shredding,
and the jam icon will blink in orange.
2The shredder will illuminate the FWD ( ) and REV ( ) buttons in the sequence necessary
to clear the jam.
3If the jam cannot be intelligentally cleared, the jam icon ( ) will illuminate in red. At this
point follow the reverse function instructions to clear any jammed material.
bin or loading door open safety function
As a safety precaution, if the bin or loading door is opened during shredding, the shredder will stop
and the bin full indicator will illuminate ( ).
8
GB
automatic jam clearance
Intelligent Jam Clearance: In the unlikely event of the shredder jamming, the Auto+ 200X and 200M
will automatically reverse and forward the engine three times to clear a jam. During this operation
the Paper Jam indicator will flash ( ).
1. operation
1After unpacking the product, remove the CD shard tray which sits inside the shredder bin.
Store this tray on the product as shown and use when you shred CDs.
2Connect the shredder to mains supply.
3Ensure the ON/OFF button on the back of the machine is in the ON position, which will
illuminate the blue standby symbol ( ).
4To commence shredding, press the Auto button ( ), which sets the shredder into auto mode.
You are now ready to shred.
5To load the shredder, simply lift the loading door handle to open the loading door and insert
documents. You can open the door further to 90 degrees for easier access if required. Load up
to 200 sheets at a time into the feed chamber. Do not fill above the 200 MAX level, this could
damage the shredder.
6The shredder will start the shredding cycle automatically ONLY after closing the loading door.
If there is still paper in the Autofeed chamber after first attempt, open and re-close the paper
loading door a second time.
7If you only have up to 6/7 sheets to shred, you can use the manual feed slot, provided the auto
feed chamber is empty.
8Insert paper to be shredded into the feed area.The shredder will detect the paper and start
automatically.
9If the shredder is left in auto mode for more than 2 minutes without being used, the shredder will
automatically turn back to sleep mode in order to save power.
10 The shredder will automatically ‘wake up’ from sleep mode when paper is inserted into the
shred mouth or you open the loading door. There is no need to press the Auto button ( ).

A U T O + 200X&200M™S H R E D D E R S
9
GB
2. reverse function
1Should you wish to reverse paper out whilst shredding, a reverse button ( ) has been fitted for
your convenience.
2Reverse the paper out then turn the machine off using the ON/OFF switch at the rear of the
shredder. Remove the paper from the manual feed slot (if being used) or open the loading door,
remove the remaining stack of paper, then pull the jammed paper free of the cutting mechanism.
3To resume shredding, turn the shredder on using the ON/OFF switch at the rear of the shredder.
Return the switch to the auto position ( ).
5. bin full
The shredder will not function when the bin is full and the bin full symbol ( ) is illuminated.
You should empty the bin.
• Pull open the bin slowly to empty.
• Push the empty bin back into place and press the auto button to resume shredding.
3. CD/DVD shredding
A separate CD/DVD tray is provided to collect the shredded CD/DVD shards, ensure that this is
correctly mounted onto the bin before shredding.
1Lift up the paper loading door.
2Always insert CDs/DVDs in the CD/DVD slot. Only shred one CD/DVD at a time.
3Close the paper loading door.
4Empty the CD/DVD bin after 8 CDs/DVDs to avoid waste spilling over into the paper waste bin.
5Remove the CD/DVD tray before recommencing to shred paper and store on the back of the
shredder.
GBC encourages customers to recycle shredded paper.
Please note that shredded paper cannot be recycled if mixed with credit card shards.
If recycling, please separate shredded paper and credit cards.
4. credit card shredding
The Auto+ 200X and 200M can shred credit cards. Switch the shredder to auto mode, then;
1Lift up the paper loading door.
2Insert the credit card into the roller as shown. Only shred one credit card at a time.
3Close the paper loading door.

6. self-cleaning cutters
After emptying and replacing a full bin, the shredder will run in forward for 4 seconds, stop for
2 seconds and then reverse for 4 seconds to clear away any remaining paper from the cutter
mechanism. This unique ‘self-cleaning’ mechanism is additional jam prevention technology
from GBC.
over heating
If the Auto+ 200X and 200M is used continuously for over 14-15 minutes the shredder may overheat
and the cool down incicator will flash red ( ). Please allow the shredder to cool down. When
the shredder is ready to be used the thermometer symbol will no longer illuminate. If the shredder
needs to cool down while shredding, no action is needed. The shredder will automatically restart
shredding paper once it has cooled down after periods of continuous use. All you need to do is
ensure paper is loaded into the chamber and the bin is empty when the machine is cooling down.
lubrication of the shredder
Only use Rexel Oil Sheets (2101948) to lubricate. ACCO Brands accepts no liability for
product performance or safety when other types or brands of lubricants are used on any part(s) of
this machine. GBC recommend using an oil sheet after the bin has been emptied three times (and
for ongoing three bin cycle thereafter). Insert the oil sheet into the manual feed slot and NOT in the
auto-feed chamber. Using an oil sheet in the auto-feed chamber will contaminate the feed rollers
preventing the auto-feed mechanism shredding. Follow the maintenance instructions if the rollers
become contaminated.
10
7. maintenance
The rollers on the auto-feed mechanism may become dirty over time, please wipe clean with a
dry cloth to maintain maximum product performance.
The auto-start infra-red sensor, located in the paper feed entry-slot, can occasionally become
covered in paper-dust causing the shredder to run despite no paper being fed into the machine.
Switch the shredder off at the rear of the machine and carefully clean the sensor using a cotton-
swab.
service
We recommend these machines are serviced every 6 to 12 months by a GBC service engineer –
see back of this booklet for the contact details of our service centre and for enquiries about
maintenance contracts.
GB

Only use Rexel Oil Sheets* (2101948) to
lubricate.
Oil Sheets
shredder accessories
Accessory Part Number Quantity
2101948 12 sheets/pack
ACCO Brands (ACCO) warrants its products and their parts against defects in materials and workmanship under normal
use for a period of 12 months from the original date of purchase. During this period, ACCO will, at its discretion, in
accordance with law, either repair the shredder using new or refurbished parts, or replace the shredder with a new or
refurbished shredder that is equivalent to the shredder being replaced. The warranty applies only to defects in materials
and workmanship under normal use and does not extend to damage to the product or parts which result from:-
- alteration, repair, modification or service carried out by anyone other than an authorised ACCO service centre.
- accident, neglect, abuse or misuse owing to failure to comply with the normal operating procedures of the product.
Please note that the cutter blades will be progressively worn down by shredding fastened sheets (staples and paperclips)
- this is not covered in the warranty. The Auto+ 200X has been design to shred up to 25 credit cards and 25 CD/DVDs in
the standard 1 year warranty period. Any excessive credit card or CD/DVD shredding will invalidate the cutter warranty.
guarantee
A U T O + 200X&200M™S H R E D D E R S
* ACCO Brands accepts no liability for product performance or safety when other types or brands of lubricants are used on
any part(s) of this machine.
11
GB

ACCO BRANDS ASIA PTE LTD
47 Ayer Rajah Crescent
#05-08/17 Singapore 139947
Tel: [phone]
Fax: [phone]
[email protected]
Ref:AUTO+200X-200M/SG/V1/270913
