GCC Technologies Elite XL User manual

i
GCC
TECHNOLOGIES
User’s Manual
G
CC
T
ECHNOLOGIES
Elite XL
808
Elite XL

ii
EPA POLLUTION PREVENTER
030.15218 Rev. B 7/95
FEDERAL COMMUNICATIONS COMMISSION
WARNING: This equipment was tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions in this manual, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. For more
information about radio frequency interference, refer to Appendix G of this manual.
CANADIAN REGULATIONS
ThisequipmentisaClassAdigitalapparatusthatcomplieswiththeRadioInterferenceRegulations,CRC
c. 1374.
IMPORTANT: Changes or modifications to this product not authorized by GCC Technologies Inc.
couldvoidtheFCCCertificationandnegateyourauthoritytooperatethe product. This productwastested
for FCC Compliance under conditions that included the use of shielded cables and connectors between
system components. It is important that you use shielded cables and connectors to reduce the possibility
of causing interference to radios, television sets, and other electronic devices. You can obtain the proper
shielded cables from GCC Technologies or from an Authorized GCC Technologies dealer.
CLASS 1 LASER PRODUCT
LASER SAFETY:Thisprinteriscertifiedas aClass1laserproductundertheU.S.DepartmentofHealth
and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for
Health and Safety Act of 1968. This means that the printer does not emit hazardous radiation. Since
radiationemitted inside the printeriscompletelyconfinedwithinprotectivehousingsand external covers,
thelaserbeamcannotescapefromthemachineduringanyphaseofuseroperation.TheCenterforDevices
andRadiological Health (CDRH) of theU.S. Food and Drug Administration implemented regulationsfor
laserproductson August 1,1976.These regulations apply tolaser products marketed inthe United States.
Thelabelon the printer indicatescompliancewith the CDRH regulationsandmust be attached tothelaser
products marketed in the United States.
Caution - Use of controls, adjustments, or performance of procedures other than those specified in this
manual may result in hazardous radiation exposure.
EPA ENERGY STAR COMPUTERS AWARD
The Elite XL printer is designed to conserve electricity. With
its power-saving design, the Elite XL qualifies for the U.S.
Environmental Protection Energy Star Computers Award.

iii
Contents
Introduction
Quick Start
Quick Start Elite XL printer setup............................................xiii
Quick Start Macintosh software configuration.........................xiii
Quick Start IBM PC and compatible software configuration ..... xiv
Chapter 1 Setting up the Elite XL
Unpacking the printer ...............................................................1-1
The Elite XL Configuration Page ............................................. 1-2
Choosing a location for the printer ...........................................1-3
Installing or replacing a toner cartridge....................................1-4
Adjusting the print density .......................................................1-9
Using the Tabloid/A3 Universal paper tray ............................1-10
Using the multipurpose feeder................................................1-12
Installing the multipurpose feeder extension plate .................1-14
Opening the paper output tray ................................................1-16
Connecting power to the Elite XL .......................................... 1-18
Elite XL interface connections ...............................................1-19
LocalTalk connection ...........................................1-20
Centronics (parallel) connection...........................1-22
Serial connection ..................................................1-22
Ethernet network connection ................................1-23
Direct Ethernet connection .....................................................1-25
Configuring the Macintosh EtherTalk software......................1-28
Configuring IBM-PC and compatible EtherTalk software .......1-28
Network card status LEDs...................................................... 1-28

iv
Contents
Chapter 2 The Elite XL front panel
Introduction to the Elite XL front panel ...................................2-1
Front panel (LCD) display window.......................................... 2-1
Front panel status LEDs ...........................................................2-1
On Line LED ..........................................................2-1
Comm (Communication) LED ...............................2-1
Paper LED .............................................................. 2-2
Service LED ...........................................................2-2
Front panel function keys ......................................................... 2-2
On Line key ............................................................2-2
Manual Feed key ....................................................2-2
Form Feed/Continue key ........................................ 2-3
Cancel/Reset key ....................................................2-3
Menu key ................................................................2-4
Enter key.................................................................2-4
+/– keys...................................................................2-5
The Elite XL menu system .......................................................2-5
Language ................................................................2-5
Print Help Page.......................................................2-5
Print (1) Sample Page(s).........................................2-5
Printer Info..............................................................2-5
Paper Handling ....................................................... 2-7
Emulations ..............................................................2-8
Interfaces ..............................................................2-11
Info Pages ............................................................. 2-12
Energy Save ..........................................................2-12

v
Contents
Chapter 3 Using the Elite XL with a Macintosh
Software installation .................................................................3-1
Installing application-specific PDF files ................3-2
The Elite XL printer drivers .....................................................3-4
Selecting the LaserWriter 8 printer driver ................................3-4
Selecting the PDF files (LaserWriter 8 only) ......... 3-5
Printing documents using the LaserWriter 8 printer driver ...... 3-7
Selecting Page Setup options (LaserWriter 8)..........................3-8
Paper .......................................................................3-8
Edge-to-edge printing .............................................3-8
Layout.....................................................................3-8
Reduce or Enlarge ..................................................3-8
Orientation ..............................................................3-9
Options ...................................................................3-9
Selecting Print options (LaserWriter 8).................................. 3-10
Copies ...................................................................3-10
Pages.....................................................................3-10
Paper Source .........................................................3-10
Destination............................................................3-11
Options .................................................................3-12
Saving print files (LaserWriter 8)...........................................3-14
Selecting the Elite XL printer driver ...................................... 3-16
Printing documents using the Elite XL printer driver ............3-16
Selecting Page Setup options (Elite XL driver)......................3-17
Paper option..........................................................3-17
Reduce or Enlarge ................................................3-18
Orientation ............................................................3-18
Printer Effects .......................................................3-18

vi
Options .................................................................3-19
Selecting Print options (Elite XL driver)................................3-20
Copies ...................................................................3-20
Pages.....................................................................3-20
Cover Page ............................................................3-20
Print ......................................................................3-20
Destination............................................................3-21
Paper Source .........................................................3-21
Printing with the Custom option...........................3-22
Manual feed printing ..............................................................3-24
Naming the Elite XL...............................................................3-25
Chapter 4 Using the Elite XL withWindows and
DOS
Windows 3.1
Installing Windows 3.1 printing software.................................4-1
Setting Windows 3.1 printing options ......................................4-4
Paper Source ...........................................................4-4
Paper Size ...............................................................4-5
Edge-to-edge printing .............................................4-5
Orientation ..............................................................4-5
Copies .....................................................................4-5
Options ...................................................................4-6
Advanced Options ..................................................4-7
Port assignment – Windows 3.1................................................4-8
Installing the Windows 3.1 printer description files ............... 4-10
Printing from Windows 3.1 applications ................................ 4-11
Selecting Print Setup options................................4-11
Selecting Print options..........................................4-12
Contents

vii
Contents
Windows 95
Using a GCC printer with Windows 95 .................................. 4-13
Windows 95 printing software overview ..............4-13
Installing a PPD for your GCC printer .................4-13
Before starting ......................................................4-13
Installing Windows 95 printing software..............4-14
Exploring the Properties dialog box .......................................4-24
Printing a Windows 95 test page .......................... 4-26
The Device Options panel ....................................4-27
The Details panel ..................................................4-29
The Paper panel ....................................................4-30
The Graphics panel...............................................4-31
The Fonts panel ....................................................4-32
The PostScript panel.............................................4-32
Printing from Windows 95 applications ................................. 4-33
Selecting print options ..........................................4-33
The Print Properties dialog box ............................4-34
DOS
Using a GCC Printer with DOS..............................................4-35
Setup and printing from the DOS command line.....4-35
Setup and printing from a DOS application .........4-35
Port configuration – DOS .....................................4-36
Selecting a printer driver ......................................4-37
Using the Copy command ....................................4-38
Installing Printer Description files..........................................4-39

viii
Contents
Chapter 5 QuickDraw GX
Introduction ...........................................................................5-1
QuickDraw GX compatibility ................................5-1
Installing GCC QuickDraw GX PostScript printer drivers ......5-2
Installing GX drivers for a new printer................... 5-2
Installing GX drivers from an upgrade disk ........... 5-2
Choosing a GX printer driver (creating a printer icon) ............5-3
Configuring a desktop printer...................................................5-4
Background printing ...............................................5-4
Setting default printer .............................................5-4
Determining input tray paper size(s) ......................5-5
Selecting printer extensions....................................5-6
Configuring printer extensions ...............................5-6
QuickDraw GX Page Setup (GX aware applications)..............5-7
The General page setup panel.................................5-8
The Options panel...................................................5-9
QuickDraw GX Print dialog box (GX aware applications).... 5-10
The General print panel ........................................5-11
Other print panels .................................................5-12
Page Setup and Print dialog boxes (unadopted applications) . 5-13
Page Setup dialog box ..........................................5-13
Print dialog box ....................................................5-14
Turning off QuickDraw GX printing ......................................5-14
Substituting LaserWriter 7.1.2 or LaserWriter 8
for LaserWriter 7.2 ...............................................5-15

ix
Chapter 6 Fonts
Introduction ..............................................................................6-1
Resident PostScript fonts..........................................................6-1
PostScript resident font catalog ................................................6-2
PCL resident font catalog .........................................................6-4
Font compatibility.....................................................................6-5
Type 1 fonts ............................................................6-5
TrueType fonts........................................................6-5
Downloading fonts from a Macintosh ......................................6-6
Additional LaserWriter Utility functions .................................6-8
File menu functions ................................................6-8
Utilities menu functions..........................................6-9
Downloading Type 1 fonts from Windows............................... 6-9
Using an external hard disk with the Elite XL .......................6-10
Initializing an external hard disk ............................................6-12
Initializing hard disks from a Macintosh..............6-12
Initializing hard disks from a PC..........................6-13
Chapter 7 Maintenance and troubleshooting
Routine maintenance ................................................................7-1
The Elite XL toner cartridge...................................7-1
Handling the toner cartridge ...................................7-1
Storing the toner cartridge ......................................7-1
Replacing a toner cartridge..................................... 7-1
Cleaning the printer ................................................7-2
Transporting the printer ............................................................7-2
Troubleshooting........................................................................7-3
Contents

x
Chooser problems .....................................................................7-3
LocalTalk problems ..................................................................7-4
Serial and parallel communication problems ...........................7-5
Ethernet communication problems...........................................7-5
Macintosh system crashes ........................................................7-6
Macintosh font problems ..........................................................7-7
PostScript problems.................................................................. 7-7
PCL problems ...........................................................................7-8
Front panel messages................................................................ 7-8
Clearing paper jams ................................................................7-11
Poor quality output .................................................................7-14
Appendixes
Elite XL specifications ............................................................ A-1
Paper specifications and recommendations ............................. B-1
Upgrading the printer’s memory.............................................. C-1
Configuring optional sheet feeders.......................................... D-1
PCL: additional information.................................................... E-1
Interface connections and pinouts ............................................F-1
Radio and television interference ............................................ G-1
Service and Support................................................................. H-1
Optional accessories ..................................................................I-1
Ordering information................................................................ J-1
Glossary ................................................................................... K-1
License and warranties ............................................................ L-1
Contents

xi
Congratulations on your purchase of a GCC Technologies® Elite™ XL laser printer. The Elite
XL family of printers consists of 8 and 16 page-per-minute printers which offer a wide variety of
options that enable you to tailor your Elite XL to your printing needs.
Using this manual
This manual is intended to be used in conjunction with the Elite XL User’s Manual supplied on
the Elite XL Software and Documentation CD-ROM provided with your product. The informa-
tion contained in this guide will allow you to quickly setup your printer and install either the
Macintosh® or Windows™ drivers. Once you have completed the Quick Installation of your
printer, please review the Elite XL User’s Manual for a more comprehensive description of the
features and functions of your printer.
Elite XL highlights
Fast processing power
The Elite XL608 uses an AMD29030 RISC processor running at 25MHz. All other products use
an AMD29040 RISC processor running at a blazing 50MHz!
Multiple resolution printing
All Elite XL models deliver 600 dot per inch (dpi), and 300 dpi “draft” mode printing for fast
proofing. Additionally, the Elite XL1208 and 1208S models print at 1200 dpi.
Full support for mixed platform environments
All Elite XL models provide outstanding cross-platform printing compatibility allowing the
printer to be easily integrated into the most demanding workgroup environments. The Elite XL’s
PostScript®Level 2 and PCL®5/HP-GL/2 interpreters (with TrueType and Type 1 font support)
accept print jobs from Macintosh®, Windows™, MS-DOS®, and Unix® based computers.
WebAdmin®Remote Printer Management
WebAdmin is an innovative solution to remote printer management. Using a World Wide Web
browser, you can monitor and control the status and configuration settings of any Elite XL
printer on your Ethernet network.
Introduction

xii
Introduction
Multiple network solutions
In addition to Elite XL’s built-in AppleTalk software and interface, all Elite XL printers are shipped
standard with Ethernet to allow connection on an Ethernet Network. The Elite XL printers are also
shipped with EtherTalk, NetWare®and TCP/IP®protocols.
All ports active feature
All Elite XL’s support simultaneously active LocalTalk®, Centronics®Parallel, and Ethernet interfaces.
Superior halftone reproduction with AccuGray
Some Elite XL models incorporate GCC’s exclusive AccuGray®technology for PostScript printing.
AccuGray is a sophisticated software algorithm that ensures that halftones are accurately printed, regard-
less of the line frequencies used.
SCSI interface
All Elite XL’s come standard with a built-in SCSI port for attachment of hard drives allowing additional
font storage. All Elite XL printers may also be upgraded to allow for the installation of an internal hard
drive.
Flexible paper handling
The Elite XL offers an excellent set of paper handling options and the software to effortlessly control
them. The printer includes a 250-sheet Tabloid/A3 universal paper tray and an adjustable multipurpose
feeder that provides an additional paper feed source for up to 50 sheets of paper, or 5 envelopes.
Low operational costs
Incorporating a low cost one-piece toner cartridge and an “Energy Star” compliant, low power consump-
tion print engine, the Elite XL is an extremely cost-effective workgroup laser printer.
Full featured front panel display
The Elite XL includes a simple-to-understand front panel that makes it easy to configure the printer for
your operating environment. The easy-to-read LCD display keeps you informed about the status of the
printer at all times.
Fast and easy ordering of upgrades and consumables
Spare toner cartridges, lower paper tray upgrades, and interface cables are all just phone call away. Call
your local GCC Distributor or GCC direct at 1-617-275-5800 or visit our Web Home page at
http://www.gcctech.com.

xiii
The following Quick Start procedures are intended for users who are experienced in the
setup and configuration of network laser printers in the Macintosh and Windows (3.1)
environments. If you are unsure about any of these steps, please skip this section and
begin reading Chapter 1, “Setting up the Elite XL.”
Quick start Elite XL printer setup
1. Install the toner cartridge.
2. Insert paper into the paper tray and insert the paper tray into the
printer.
3. Plug the AC power cord into the back of the Elite XL and then into a
grounded AC outlet.
4. Connect the Elite XL to your network system or directly to your
computer using the appropriate cables.
5. Switch on the Elite XL and the computer.
After about one minute, the start page prints, the On Line LED on the
front panel of the printer is solid, and a message in the display window
indicates that the Elite XL is ready for printing.
Quick Start Macintosh software configuration
1. Install the Elite XL Macintosh software for your Elite XL model, from
the Elite XL Software and Documentation CD-ROM.
2. Use the Chooser to select a printer driver and the Elite XL printer
name.
3. Use the Chooser’s Setup function (LaserWriter 8 only) to select the
appropriate Elite XL PPD.
4. Repeat steps 1-3 on each Macintosh that will use the printer.
You are now set to print to the Elite XL from a Macintosh. Turn to Chapter 3, “Using
the Elite XL with a Macintosh,” for more information.
Quick Start

xiv
Quick Start
Quick Start IBM PC and compatible software configuration
1. Install the GCC Elite XL Windows driver for your Elite XL model,
from the Elite XL Software and Documentation CD-ROM.
2. Select the Elite XL as the default printer.
3. Assign the printer to the appropriate (LPT#, COM#) printer port.
4. Repeat steps 1-3 on each PC that will use the printer.
The Elite XL is now set to print from an IBM PC or compatible.Turn to Chapter 4, “Using
the Elite XL with a PC,” for more information.

Setting up the Elite XL 1-1
Unpacking the printer In addition to the printer, the Elite XL box contains the following items:
IMPORTANT: Save all packing materials and shipping boxes in case you ever
need to transport the printer and toner cartridge.
In addition to the contents of the Elite XL box, you will need the appropriate
cables to connect your computer to the printer. The Elite XL offers LocalTalk,
serial (RS-422), and Centronics (parallel) interfaces as standard. Ethernet is
also standard on all Elite XL models.
To unpack the Elite XL:
1. Remove the Universal paper tray and the software and documen-
tation package from the shipping box.
2. Remove the two pieces of packing foam from the top of the
printer.
3. Lift the printer out of the box and place it on a flat surface.
4. Remove the plastic bag surrounding the printer.
5. Remove the plastic and cardboard surrounding the universal
paper tray.
G CC
T ECHNOLOGIES
Elite™XL 808
Configuration Page
Printer Information
Interfaces
Paper Handling
Language: English
AppleTalkName: Model
PageCount: 20
RAMInstalled: 8MB
Harddisk: No disk
OSVersion: 2.3
PostScriptLevel 2 Version: 2.3
ROMVersion: 2.3
H/WVersion: 1.0
AccuGray: Enabled
PrintDarkness: Normal
DefaultSource: Upper Tray
DefaultSize: Letter
JamRecovery: Disabled
PaperReserve: Enabled
ManualFeed Timeoutt: 5 Minutes
8-pinSerial: LocalTalk
RS422Serial (Inactive)
BaudeRate: 9600
DataBits: 8
StopBits: 1
Parity: None
FlowControl: Xon/Xoff
RS232Serial (Active)
BaudeRate: 9600
DataBits: 8
StopBits: 1
Parity: None
FlowControl: Xon/Xoff
ParallelPort (Active)
PS/PCLSensing: PostScript Only
PortEmulation
ParallelPort: Auto Switch
RS232Port: Auto Switch
RS422Port: Auto Switch
LocalTalkPort: PostScriptOnly
PostScript
DefaultResolution: 800
JobCancel: Enabled
StartPage: Disabled
WaitTimeout: 300Seconds
PCLResolution: 600
Copies: 1
FontSource: Internal
FontNumber: 1
Pitch: 10.0
PointSize: 12.0
Orientation: Portrait
PageLength: 60
SymbolSet: Roman-8
WaitTimeout: 120Seconds
LineWrap: Disabled
LineTermination: Normal
Emulations
1) Set Cleaning Paper with its face down in a cassette.
2) Start print.
Cleaning Paper
User’s manual Multipurpose feeder extension
Universal
paper tray
Configuration page
AC power cord
Toner cartridge
(in box)
Cleaning
page
Elite XL CD-ROM
G CC
T ECHNOLOGIES
EliteXL
G
CC
T
ECHNOLOGIES
User’s Manual
Elite XL
Bitstream fonts
Chapter 1Setting up the Elite XL

Setting up the Elite XL
Chapter 1
1-2 Chapter 1
Printer Information
Configuration Page
GCC
T ECHNOLOGIES
For more information or the dealer nearest you, contact:
UNITED STATES 209 Burlington Road, Bedford, MA 01730-9143, U.S.A., Tel: [phone], Fax: [phone]
UNITED KINGDOM Unit #3, Maple Grove Business Centre, Lawrence Road, Hounslow, Middlesex, England TW4 6DR,
Tel: [phone], Fax: [phone]
GERMANY Vertriesburo Deutschland, Hahnbuschweg 2-4, 24147 Klausdorf, Germany,
Tel. Sales: 0431-79-97-610+611, Technical Support: (49) 79 97 620 + 621, Fax: [phone]
The GCC Technologies logo is a registered trademark of GCC Technologies, Inc. Elite is a trademark of GCC Technologies, Inc.
PhoenixPage and the PhoenixPage logo are trademarks of Phoenix Technologies Ltd. registered in the U.S.A.
LocalTalk is a registered trademark ofApple Computer, Incorporated. PCL is a registered trademark of Hewlett-Packard Company.
Elite
™
XL808
Language: English
AppleTalk Name: Elite XL
Page Count: 20
RAM Installed: 12MB
Hard Disk: No disk
OS Version: 2.3
PostScript Level 2 Version: 2.3
ROM Version: 2.3
H/W Version: 1.0
Serial Number: 45200059BHN
Default Source: Tray 1
Paper Group: U.S.
Default Size: Letter
Jam Recovery: Disabled
Paper Reserve: Enabled
MPFeeder Orientation: Long-Edge Feed
Paper Thickness: Normal
Manual Feed Timeout: 300 Seconds
Energy Save: 15 Minutes
Paper Handling
8-pin Serial: LocalTalk
RS422 Serial (Inactive)
Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: None
Flow Control: Xon/Xoff
Parallel Port (Active)
GCIO Card (Active)
Card Installed: GCIO Enet 1.0
Ethernet Address: 00:C0:B0:02:09:6B
Interfaces
PS/PCL Sensing: PostScript Only
Port Emulation
Parallel Port: Auto Switch
RS422 Port: Auto Switch
LocalTalk Port: Auto Switch
EtherTalk Port: Auto Switch
PostScript
Default Resolution: 800
AccuGray: Disabled
Job Cancel: Enabled
Start Page: Disabled
Wait Timeout: 120 Seconds
PCL
Resolution: 300
Copies: 1
Font Source: Internal
Font Number: 1
Pitch: 10.0
Point Size: 12.0
Orientation: Portrait
Page Length: 60
Symbol Set: Roman-8
Wait Timeout: 120 Seconds
Line Wrap: Disabled
Line Termination: Normal
Emulations
The model number of your
printer will appear here.
The Elite XL Configuration Page
Each Elite XL package includes a Configuration Page. It was printed on your printer,
at GCC’s manufacturing facility, prior to shipment. The configuration page displays
the software and hardware versions of the printer, factory default settings, and the
hardware configuration of your Elite XL. The page shown below is a facsimile, it
does not represent a configuration page for a specific Elite XL model. However, most
of the items shown will be on your Configuration Page.

Setting up the Elite XL 1-3
Choosing a location for the printer
Place the Elite XL on a flat, level surface in a well-ventilated area away from
direct sunlight and areas where the air temperature and humidity can vary. Do
not place objects on top of the printer. Do not obstruct the fan vent located on
the right side of the printer. Keep the printer away from areas where ammonia
fumes and excessive dust are present, and do not use ammonia-based cleaners
near the printer.
Place the printer with enough space (at least 12.5 inches) in front of it to allow
for the extension of the multipurpose feeder.
OnLine Comm Paper Service
OnLine
Menu
Manual
Feed FormFeed
Continue
Enter
Cancel
Reset
Elite XL
G CC
T ECHNOLOGIES
230mm
(9 inches)
180mm
(7 inches)
50mm
(2 inches)
320mm
(12.5 inches)
200mm (8 inches)
minimum overhead
clearance.
Choosing a location for the printer

Setting up the Elite XL
Chapter 1
1-4 Chapter 1
Installing or replacing a toner cartridge
The toner cartridge contains powdered ink, called toner, that the printer uses to form
images on paper. The cartridge also contains a light sensitive imaging drum that is
covered by a protective flap. Do not lift the flap when handling the cartridge.
Each toner cartridge box also includes a Cleaning Page that is used to clean the
printer’s fusing roller. Instructions for using the cleaning paper are detailedlater in
this section.
Important toner cartridge reordering note:If you are using an 8 ppm Elite XL
model, use either part number AC15246 or AC15616 when reordering toner. If
you are using a 16 ppm Elite XL model, use only part number AC15616 when
reordering toner. (See page J-1 for ordering information.)
To install or replace a toner cartridge:
1. Close the multipurpose feeder.
See page 1-12 for information about the multipurpose feeder.
2. Open the printer access door.
Press the release button on the front of the printer and pull the access
door forward. If you are installing a cartridge for the first time, go to
step
G
CC
T
ECHNOLOGIES
Elite XL
608
Release button
Printer access door

Setting up the Elite XL 1-5
3. If you are replacing a cartridge, remove the empty cartridge and
discard it.
Grasp the yellow handle on each end of the toner cartridge and pull the
cartridge straight out.
4. Remove the protective sheet from the toner cartridge.
The toner cartridge is shipped with a protective paper sheet inserted
between its rollers. Remove the sheet by pulling it downwards. Do not
remove the sheet by pulling it upwards. This will lift the protective
flap, allowing light into the cartridge which could cause damage to the
photosensitive drum.
Before inserting
the toner cartridge
in the printer,
detach the tape
and pull this sheet
out in the direction
indicated.
NOTICE
Bevor Sie die
tonerkartusche in
den Drucker
einsetzen, lösen
Sie das Band und
ziehen das Blatt in
die angegebene
Richtung heraus.
ACHTUNG
Décoller le ruban
et retirer cette
feuille dans la
direction indiquée
avant d’insérter la
cartouche toner
dans l’imprimante.
AVERTISSEMENT
Installing or replacing a toner cartridge
Protective flap, do not lift

Setting up the Elite XL
Chapter 1
1-6 Chapter 1
5. Distribute the toner.
Unpack the new toner cartridge and gently shake it back and forth
a few times, to distribute the toner evenly through the cartridge.
6. Remove the toner seal tape from the toner cartridge.
Place the toner cartridge on a flat surfacewith the yellow handles
facing you. Pull the green tab straight out from the right side of the
cartridge, removing the attached toner seal completely.
Yellow
handles
