GE AEN10 Series Operating instructions

Safety Instructions........................2, 3
Operating Instructions .................4, 5
Care and Cleaning
Air Filter.............................................................6
Outdoor Coils..................................................6
Installation Instructions........7–12
Troubleshooting Tips.....................14
Normal Operating Sounds....................14
Consumer Support
Consumer Support....................................16
Warranty. ......................................................15
49-7730 11-13 GE
AEN10*
AEN12*
Owner’s Manual and
Installation Instructions
Write the model and serial numbers here:
Model # _________________________
Serial # __________________________
Find these numbers on a label on the side of
the air conditioner.
Air Conditioners
GEAppliances.com
Room
As an ENERGY STAR® partner, GE has
determined that this product meets
the ENERGY STAR® guidelines for
energy efficiency.
*ENERGY STAR® labeled product

2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire, electric
shock or personal injury.
Use this appliance only for its intended
purpose as described in this Owner’s
Manual.
This air conditioner must be properly
installed in accordance with the Installation
Instructions before it is used.
Never unplug your air conditioner by pulling
on the power cord. Always grip plug firmly
and pull straight out from the receptacle.
Replace immediately all electric service
cords that have become frayed or otherwise
damaged. A damaged power supply cord
must be replaced with a new power supply
cord obtained from the manufacturer and
not repaired. Do not use a cord that shows
cracks or abrasion damage along its length
or at either the plug or connector end.
 If the receptacle does not match the plug,
the receptacle must be changed out by a
qualified electrician.
 Turn the unit OFF and unplug your air
conditioner before making any repairs
or cleaning.
NOTE: We strongly recommend that any
servicing be performed by a qualified
individual.
For your safety…do not store or use
combustible materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
 All air conditioners contain refrigerants,
which under federal law must be removed
prior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
 These R410A air conditioning systems
require contractors and technicians to use
tools, equipment and safety standards
approved for use with this refrigerant.
DO NOT use equipment certified for R22
refrigerant only.
SAFETY PRECAUTIONS
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
DO NOT use an adapter plug with this
appliance.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall outlet
to minimize the possibility of electric
shock hazard from this appliance.
Power cord includes a current interrupter device.
A test and reset button is provided on the plug
case. The device should be tested on a periodic
basis by first pressing the TEST button and then
the RESET button while plugged into the outlet. If
the TEST button does not trip
or if the RESET button will not stay engaged,
discontinue use of the air conditioner and
contact a qualified service technician.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a 2-prong wall outlet is encountered,
it is your personal responsibility and obligation to
have it replaced with a properly grounded
3-prong wall outlet.
The air conditioner should always be plugged
into its own individual electrical outlet which has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house wiring circuits which
could cause a fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.
HOW TO CONNECT ELECTRICITY

3
GEAppliances.com
WARNING!
RISK OF FIRE. Could cause serious injury or
death.
• DO NOT use an extension cord with this
Window Air Conditioner.
• DO NOT use surge protectors or multi-outlet
adaptors with this Window Air Conditioner.
USE OF EXTENSION CORDS
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

4
About the controls on the air conditioner.
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
Fan Fan
Delay 1–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
Delay
timer
Increase
Auto Fan
on
Fan speed
Increase
Unit power
on/off
Air Conditioner Controls
Controls
Power Pad
Turns air conditioner on and off. When
turned on, the display will show the room
temperature.
Display
Shows the room temperature or time
remaining on the Delay timer. Shows the Set
temperature while setting the temperature in
Cool or Energy Saver modes. The Set light will
turn on while setting.
Temp Increase Ÿ/Decrease źPads
Use to set temperature when in Cool or
Energy Saver mode. The Set light will turn on
while setting.
Delay Timer IncreaseŸ(+) /Decrease
ź(–) Pads
Each touch of the Increase Ÿ/ Decrease ź
pads on the unit or the Increase +/ Decrease
–pads on the remote control will set the delay
time when using the Delay 1–24hr timer. The
Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low, Med, High
or Auto on the unit. NOTE: On the remote
control, use the fan speed Increase + /
Decrease –pads to set the fan speeds to Low,
Med or High. Use the Auto pad to turn Auto
fan on.
Mode Pad
Use to set the air conditioner to Cool, Energy
Saver or Fan Only mode.
Delay Pads/Delay 1-24hr Pad
'HOD\21³When the air conditioner is off, it can
be set to automatically come on in 1 to 24 hours
at its previous mode and fan settings.
'HOD\2))³When the air conditioner is on,
it can be set to automatically turn off in 1 to
24 hours.
How to set:
Press the Delay 1–24hr pad on the unit or the
Delay pad on the remote control. Each touch
of the Increase Ÿ/ Decreaseźpads on the
unit or the Increase + / Decrease –pads on
the remote control will set the timer in 1-hour
intervals. The Set light will turn on while setting.
To review the remaining time on the Delay
1–24hr timer, press the Delay 1–24hr pad on
the unit or the Delay pad on the remote control.
Use the Increase Ÿ/ Decrease źpads on the
unit or the Increase +/ Decrease –pads on the
remote control to set a new time if desired.
To cancel the timer, press the Delay 1–24hr pad
until the light on the Delay 1–24hr pad goes off.
Reset Filter
LED will turn on when fan has accumulated 250
hours of run time as a reminder to clean filter.
Press Reset Filter to turn off the LED and reset
the accumulated run time.
Note: The default temperature reading on the display is degree Fahrenheit ( °F). To change the display to
degree Celcius (°C), press the Temp Increase Ÿand Temp Decrease źbuttons together and hold for 3
seconds. Repeat the process to change back to degree Fahrenheit (°F)
NOTE: The display always shows the room temperature except
when setting the Set temperature or the Delay timer.
Power
On/Off
Fan Mode
Auto
Reset
Filter
High
Med
Low
Cool
Fan Only
Energy Saver
Delay
1-24 Hrs
Set
+
-
8
Light indicates the
delay timer is set.
Light indicates the unit is in the
temperature or delay time Set mode.
Remote Control

5
GEAppliances.com
Cool Mode
Use the Cool mode at Low, Med, High or Auto Fan
Speed for cooling. Use the Temperature Increase Ÿ
/ Decrease źpads to set the desired temperature
between 64°F and 86°F in 1°F increments.
An electronic thermostat is used to maintain the room
temperature. The compressor will cycle on
and off to keep the room at the set level of comfort.
Set the thermostat at a lower number and the indoor
air will become cooler. Set the thermostat at a higher
number and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan
setting to a Cool setting, it may take approximately
3 minutes for the compressor to start and cooling to
begin.
Cooling Descriptions
For Normal Cooling³6HOHFWWKHCool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling³6HOHFWWKH Cool mode
and High fan with a lower set temperature.
For Quieter and Nighttime Cooling³6HOHFWWKH
Cool mode and Low fan with a middle set
temperature.
Fan Only Mode
Use the Fan Only Mode at Low, Med or High fan
speed to provide air circulation and filtering without
cooling. Since fan-only settings do not provide
cooling, a Set temperature cannot be entered. The
room temperature will appear in the display.
NOTE: Auto Fan Speed cannot be used when in the
Fan Only Mode.
Energy Saver Mode
In the case of a power outage or interruption, the
unit will automatically restart in the settings last
used after the power is restored. If the Delay 1–24hr
feature was set, it will resume countdown. You may
need to set a new time if desired.
Power Outage Recovery Feature
Set to Auto fan speed for the fan speed to
automatically set to the speed needed to provide
optimum comfort settings with the set temperature.
If the room needs more cooling, the fan speed
will automatically increase. If the room needs less
cooling, the fan speed will automatically decrease.
NOTE: Auto Fan Speed cannot be used when in the
Fan Only Mode.
Auto Fan Speed
Do Not Operate in Freezing Outdoor Conditions
This cool-only air conditioner was not designed for
freezing outdoor conditions. It must not be used in
freezing outdoor conditions.
 To ensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
 Make sure nothing is between the air conditioner
and the remote control that could block the
signal.
 The remote control signal has a range of
up to 20 feet.
 Make sure batteries are fresh and installed
correctly as indicated on the remote control.
 Remote contains a magnet allowing it to attach
to metal surfaces.
Remote Control
This mode optimizes the cooling power of your air
conditioner, thereby saving you energy. Once the
set point temperature has been reached, the fan
will cycle off to save energy. The fan will cycle back
on periodically to insure all cooling capacity in the
system is used. This mode is the default mode for the
unit. Each time the unit is powered off, it will restart
in Energy Saver mode ON. This includes Delay timer
mode. The first time the unit is turned on, the settings
will be 70° and Low fan. You can adjust the fan
speed and temperature to your personal comfort.
Energy Saver ON³Helps minimize electricity use.
It is normal for the fan to cycle off and then back
on in this mode. This on/off cycle can repeat
multiple times. Because the fan will cycle off, you
may notice a variation in room temperature and
humidity.
Energy Saver OFF³When this mode is not engaged,
the fan will run continuously, and in Cool mode the
compressor will cycle on and off to maintain room
temperature.

6
Air Direction
Use the lever to adjust the air direction left and right
only.
About the controls on the air conditioner
Additional important information.
Turn the air conditioner off and remove the plug from
the wall outlet before cleaning.
To clean, use water and a mild detergent. Do not use
bleach or abrasives.
Grille and Case
Care and cleaning of the air conditioner.
Outdoor Coils
The coils on the outdoor side of the air conditioner
should be checked regularly. If they are clogged with
dirt or soot, they may be professionally cleaned.
1Remove the battery cover by sliding it according
to the arrow direction.
2Insert new batteries, making sure that the (+)
and (–) of battery are installed correctly.
3Reattach the cover by sliding it back
into position.
NOTES:
 Use 2 “AAA” (1.5 volt) alkaline batteries. Do not
use rechargeable batteries.
 Remove the batteries from the remote control if
the system is not going to be used for a long time.
 Do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc) or rechargeable
(ni-cad, ni-mh, etc) batteries.
How to Insert the Batteries in the Remote Control
Air Filter
The air filter behind the front grille should be checked
and cleaned at least every 30 days or
more often if necessary.
To remove:
Open the inlet grille by pulling downward on the tabs
at the top upper corners of the inlet grille until the
grille is in a 45º position. Remove the filter.
Clean the filter with warm, soapy water. Rinse and let
the filter dry before replacing it. Do not clean the filter
in a dishwasher.
CAUTION:DO NOT operate the air
conditioner without a filter because dirt and lint will
clog it and reduce performance.
Tab Tab

BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT ³Save these instructions
for local inspector’s use.
•IMPORTANT ³Observe all governing
codes and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Approximately 1 hour
• We recommend that two people install
this product.
• Proper installation is the responsibility
of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
• You MUST use all supplied parts and use proper
installation procedures as described in these
instructions, and any separate kit instructions,
when installing this air conditioner.
Installation
Air Conditioner
Instructions
Some models require a 115/120-volt AC,
60 Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
Some models require 230/208-volt AC,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for best
performance and to prevent overloading
house or apartment wiring circuits, which
could cause a possible fire hazard from
overheating wires.
ELECTRICAL REQUIREMENTS
CAUTION:
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
SUREOHPV³FRQVXOWDTXDOLILHGHOHFWULFLDQ
If the sill support bolts do not contact the
window sill, or if you have a window without
a sill, you must order accessory kit RAK87
to properly install this air conditioner. Call
800.626.2002 or visit GEAppliances.com.
Power cord includes a current interrupter
device. A test and reset button is provided on the
plug case. The device should be tested on a periodic
basis by first pressing the TEST button and then the
RESET button while plugged into the outlet. If the
TEST button does not trip or
if the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
7
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measure
Pencil
Level Scissors or knife
Adjustable wrench
Flat-blade screwdriver
Questions? Call 800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com

8
Installation Instructions
Type A (6) Type B (7)
Right
accordion
panel
Window sash seal
(thin, adhesive-backed)
Foam top
window gasket
Window locking
bracket (2)
Left accordion
panel
Top mounting rail
PARTS INCLUDED
(appearance may vary)
Type C (6)
Type D (3)
Top mounting rail
seal strip
Sill support (2)
Nut (2)
Bolt (2)

Installation Instructions
WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to modify
them for other types of windows.
CAUTION: If the sill support
bolts do not contact the window sill, or
if you have a window without a sill, you
must order accessory kit RAK87 to
properly install this air conditioner.
Call 800.626.2002 or visit GEAppliances.com.
• The air conditioner can be installed without
the accordion panels if needed to fit in a
narrow window. See the window opening
dimensions.
• All supporting parts must be secured
to firm wood, masonry or metal.
• The electrical outlet must be within reach of
the power cord.
1
16.4” min.
25.25sto 38s
(With accordion panels)
STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will keep
it from draining properly. To adjust for this, attach
a piece of wood to the sill.
WOOD PIECES –
WIDTH: 2s
LENGTH: Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place a
piece of wood on the sill to make it 1/2shigher
than the top of the storm window frame or the
vinyl frame.
Attach securely with nails or screws provided
by the installer.
2
1/2shigher
than storm
window
frame
Storm window
frame
Wood
Sill
1/2shigher
than vinyl frame
(on some windows)
Vinyl frame
REMOVE THE AIR CONDITIONER
FROM THE CASE
Remove and save the 2 screws from the lower
sides of the front grille.
Grasp the lower corners of the grille while
pressing in on the case sides with your finger
tips. Pull out to release and lift it up.
NOTE: Do not pull the bottom edge toward you
more than 3sor you may damage the tabs of
the grille.
Remove the ground screw from each side
of the case. Keep them in a safe location.
NOTE: Be sure to save these screws. You
will need them later in the installation.
Slide the air conditioner from the case by
gripping the base pan handle and pulling
forward while bracing the case. Do not pull
or lift on the styrofoam discharge area.
3
A
C
FRONT
D
FRONT
Do not
pull or
lift in this
DUHD³
damage
to the
unit may
result
FRONT
FRONT
B
9

Installation Instructions
10
INSTALL THE TOP MOUNTING RAIL
ONTO THE CASE
Attach the top mounting rail onto the top of the
case with 3 Type B screws.
5
Type B
screws
Top
mounting
rail
INSTALL THE
SIDE ACCORDION PANELS
Slide the left and right accordion panels into
the top and bottom mounting rails.
Attach the accordion panels to the case using 3
Type A screws on each side.
6
A
B
Type A
screws
Top mounting rail
Bottom mounting rail
Accordion
panel
PREPARE THE WINDOW
• Cut the window sash seal to the window
width and stick the adhesive side to the
bottom of the sash.
7
Window sash
seal
BACK
INSIDE
4ATTACH THE TOP MOUNTING RAIL
SEAL STRIP
Remove the backing from the top mounting rail
seal strip and attach the seal strip to the bottom
of the top maounting rail, along the front edge.
Allow the seal strip to overlap 3/8” on each end.
Top mounting rail
Remove
backing
from seal
strip
3/8”
3/8”
3/8” overlap 3/8” overlap
Top mounting rail
Seal strip
FRONT VIEW

Installation Instructions
11
INSTALL THE CASE IN THE WINDOW
Open the window and mark the centerline of
the window sill.
Carefully place the case on the window stool
and align the center mark on the bottom front
with the centerline of the sill.
Pull the window down behind the top mounting
rail.
NOTE: Do not shut the window so tightly that
movement of the accordion panels is
restricted.
Select the position that will place the sill
supports near the outermost point on the sill.
Place the short side of the sill supports, on the
case bottom, toward the window. Attach the sill
supports to the case track hole in relation to the
selected position using 2 Type B screws in each
support.
CAUTION: Do not install this air
conditioner in a window if the bolts do not contact
the window sill.
Adjust the bolt and the nut in each support so
that the case is installed with a slight tilt to the
outside. Use a level; no more than 1/2 bubble
will be the correct case slant to the outside.
CAUTION: If the sill support bolts do
not contact the window sill or if you have a window
without a sill you must order accessory kit RAK87 to
properly install this air conditioner. Call 800.626.2002
or visit GEAppliances.com.
8INSTALL THE CASE IN THE WINDOW
(CONT.)
Secure the case to the window sill by using 3
Type D screws.
Pull the accordion panels to each window sash
track. Attach them on each side to the window
sash and the window sill using
4 Type C screws.
8
A
B
C
F
G
D
Long side of
sill supports
OUTSIDE
E

Installation Instructions
12
INSTALL THE AIR CONDITIONER
IN THE CASE (CONT.)
Replace the 2 ground screws removed earlier,
one on each side of the case.
IMPORTANT: The ground screws must be
reinstalled to ensure a proper ground.
Attach the front grille to the case by inserting
the tabs on the grille into the slots on the front
top of the case. Push the grille in.
Secure the front grille to the case by replacing
the 2 screws removed earlier. Press on the top
of the grille to help with side screw installation.
Connect power.
10
B
C
INSTALL THE AIR CONDITIONER
IN THE CASE
Slide the air conditioner into the case by the base
pan. Do not push on the controls, styrofoam air
discharge housing or the finned coils. Make sure
the air conditioner is firmly seated.
10
A
E
D
Do not press on
WKHVHDUHDV³
damage to the
unit may result
Base Pan
9
INSTALL SUPPORT BRACKET AND
FOAM TOP WINDOW GASKET
Attach the support bracket
with one Type C screw.
Cut the foam top window gasket to the window
width.
Stuff the foam
between the glass
and the window
to prevent air and
insects from getting
into the room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
ACAUTION:
To prevent broken glass or
damage to windows, on
vinyl or other similarly
constructed windows,
attach the support bracket
to the window side jam.
B
C
Wood
Vinyl

Normal Operating Sounds
 You may hear a pinging noise caused by
water being picked up and thrown against the
condenser on rainy days or when the humidity
is high. This design feature helps remove
moisture and improve efficiency.
 You may hear the thermostat click when the
compressor cycles on and off.
 Water will collect in the base pan during
high humidity or on rainy days. The water
may overflow and drip from the outdoor side
of the unit.
 The fan may run even when the compressor
does not.
Troubleshooting Tips.
13
Problem Possible Causes What To Do
Air conditioner The air conditioner • Make sure the air conditioner plug is pushed
does not start is unplugged. completely into the outlet.
The fuse is blown/circuit • Check the house fuse/circuit breaker box and replace
breaker is tripped. the fuse or reset the breaker.
Power failure. • The unit will automatically re-start in the settings last
used after the power is restored.
•There is a protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. For this reason, the unit may not start
normal cooling for 3 minutes after it is turned
back on.
The current interrupter • Press the RESET button located on the power cord plug.
device is tripped. •If the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does Airflow is restricted. • Make sure there are no curtains, blinds or furniture
not cool as it should blocking the front of the air conditioner.
The temp control may • In the Cool mode, press the Decrease dpad.
not be set correctly.
The air filter is dirty. •Clean the filter at least every 30 days.
See the Care and Cleaning section.
The room may have been hot. • When the air conditioner is first turned on, you need
to allow time for the room to cool down.
Cold air is escaping. • Check for open furnace registers and cold air returns.
Cooling coils have iced up. •See “Air conditioner freezing up” below.
Air conditioner Ice blocks the air flow • Set the controls at High Fan or High Cool and set the
freezing up and stops the air conditioner thermostat to a higher temperature.
from cooling the room.
The remote control The batteries are inserted • Check the position of the batteries. They should be
is not working incorrectly. inserted in the opposite (+) and (–) direction.
The batteries may be dead. • Replace the batteries.
Water drips outside Hot, humid weather. • This is normal.
Water drips indoors The air conditioner is not • For proper water disposal, make sure the air conditioner
tilted to the outside. slants slightly from the case front to the rear.
Water collects in Moisture removed from air • This is normal for a short period in areas with little
base pan and drains into base pan. humidity; normal for a longer period in very humid areas.

14
Notes.

15
Staple your receipt here.
Proof of the original purchase
date is needed to obtain
service under the warranty.
*($LU&RQGLWLRQHU³2QH<HDU/LPLWHG:DUUDQW\.
For The Period Of: GE Will Replace:
One Year Any part of the air conditioner which fails due to a defect in materials or workmanship.
From the date of the During this limited one-year warranty, GE will also provide, free of charge, all labor and related
original purchase service to replace the defective part.
All warranty service provided by our Factory Service Centers,
or an authorized Customer Care®technician. To schedule
service, visit us on-line at GEAppliances.com, or call 800.
GE.CARES (800.432.2737). Have serial number and model
number available when calling for service.
Service trips to your home to teach you how to
use the product.
Improper installation, delivery or maintenance. If you
have an installation problem, or if the air conditioner
is of improper cooling capacity for the intended use,
contact your dealer or installer. You are responsible
IRUSURYLGLQJDGHTXDWHHOHFWULFDOFRQQHFWLQJIDFLOLWLHV
Failure of the product resulting from modifications to
the product or due to unreasonable use including failure
to provide reasonable and necessary maintenance.
In commercial locations, labor necessary to move the
unit to a location where it is accessible for service
by an individual technician.
Replacement of house fuses or resetting of circuit
breakers.
Failure due to corrosion on models not corrosion-
protected.
Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of God.
,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\SRVVLEOH
defects with this air conditioner.
Damage caused after delivery.
What Is Not Covered:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is
not available, you may be responsible for a trip charge or you may be required to bring the product to an
Authorized GE Service location for service. In Alaska, the warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know
what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
(;&/86,212),03/,(':$55$17,(6³<RXUVROHDQGH[FOXVLYHUHPHG\LVSURGXFWUHSDLUDVSURYLGHGLQ
this Limited Warranty. Any implied warranties, including the implied warranties of merchantability or
fitness for a particular purpose, are limited to one year or the shortest period allowed by law.

16
Consumer Support.
GE Appliances Website GEAppliances.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
order parts or even schedule service on-line.
Schedule Service GEAppliances.com
Expert GE repair service is only one step away from your door. Get on-line and schedule your service at your
convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal business hours.
Real Life Design Studio GEAppliances.com
*(VXSSRUWVWKH8QLYHUVDO'HVLJQFRQFHSW³SURGXFWVVHUYLFHVDQGHQYLURQPHQWVWKDWFDQEHXVHGE\SHRSOHRI
all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and mental abilities
and impairments. For details of GE’s Universal Design applications, including kitchen design ideas for people with
disabilities, check out our Website today. For the hearing impaired, please call 800.TDD.GEAC (800.833.4322).
Extended Warranties GEAppliances.com
Purchase a GE extended warranty and learn about special discounts that are available while your warranty is still
in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours. GE Consumer Home
Services will still be there after your warranty expires.
Parts and Accessories GEAppliances.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or by phone at
800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally should
be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause unsafe
operation.
Contact Us GEAppliances.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including
your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225
Register Your Appliance GEAppliances.com
5HJLVWHU\RXUQHZDSSOLDQFHRQOLQH³DW\RXUFRQYHQLHQFH7LPHO\SURGXFWUHJLVWUDWLRQZLOODOORZIRUHQKDQFHG
communication and prompt service under the terms of your warranty, should the need arise. You may also mail
in the pre-printed registration card included in the packing material.
Printed in China

Instrucciones de seguridad........... 2,3
Instrucciones de operación........... 4,5
Cuidado y limpieza
Bobinasparaexteriores.......................6
Filtrodeaire...................................6
Instrucciones de instalación........7–12
Solucionar problemas ...................14
Sonidosdeoperaciónnormales..............14
Servicio al consumidor
Garantía......................................15
Servicio al consumidor .......................16
49-7730 11-13 GE
AEN10*
AEN12*
Acondicionador de aire
GEAppliances.com
Habitación
Escriba los números de modelo
y serie aquí:
# de Modelo_________________
# de Serie___________________
Puede encontrar estos números
en una etiqueta en el costado
del acondicionador de aire.
Como socio de ENERGY STAR®,
GE ha confirmado que este
producto cumple las directrices
de ENERGY STAR®relativas al
rendimiento energético.
* Producto etiquetado *ENERGY STAR®
Manual del
propietario y las
instrucciones de
instalación

2
INFORMACIÓN IMPORTANTE DE SEGURIDAD.
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.
¡ADVERTENCIA!
Por su seguridad, se debe seguir la información en este manual para minimizar el riesgo de incendios,
descargas eléctricas o lesiones personales.
Use este electrodoméstico solamente para
el propósito determinado según se describe
en el Manual del propietario.
Este acondicionador de aire debe instalarse
correctamente de acuerdo con las
Instrucciones de instalación antes de su uso.
Nunca desenchufe su acondicionador de
aire tirando del cable eléctrico. Siempre agarre
firmemente el enchufe y tire de
él directamente hacia afuera.
Reemplace inmediatamente todos los cables
eléctricos que se hayan pelado o que se
hayan dañado de alguna otra manera.
Un cable de corriente dañado no debe
repararse, sino que debe ser sustituido por
uno nuevo que se adquiera del fabricante. No
use un cable eléctrico que muestre evidencias
de deterioro, o daños de abrasión en su
superficie en alguno de sus extremos.
Si el receptáculo no coincide con el enchufe,
un electricista calificado debe reemplazar el
receptáculo.
Apague la unidad (OFF) y desenchufe el
acondicionador de aire antes de efectuar
reparaciones o la limpieza.
NOTA: Recomendamos enfáticamente que
un técnico calificado realice las reparaciones.
Por su seguridad…no almacene ni use
materiales combustibles, gasolina u
otros vapores o líquidos inflamables
en la proximidad de éste o algún otro
electrodoméstico.
Todos los acondicionadores de aire contiene
refrigerantes, los que por Ley Federal deben
ser removidos antes de desecharlos. Si usted
planea deshacerse de algún producto que
contenga refrigerantes, póngase en contacto
con la compañía que se encarga de recoger
su basura para que le indiquen qué hacer.
Estos sistemas de acondicionadores de
aire R410A requieren quelos contratistas
y técnicos usen herramientas, equipos
y estándares de seguridad aprobados
para su uso con estere frigerante. NO
use equipamiento certificado sólo para
refrigerante R22.
PRECAUCIONES DE SEGURIDAD
Bajo ninguna circunstancia, corte o remueva la
tercera púa (tierra) del cable eléctrico. En pos
de la seguridad personal, este electrodoméstico
debe siempre conectarse a tierra.
NO use un enchufe adaptador con este
electrodoméstico.
El cable eléctrico de este electrodoméstico está
equipado con un enchufe de tres púas (tierra)
que combina con un tomacorriente estándar
de tres tomas de pared para minimizar la
posibilidad de una descarga eléctrica.
El cable de alimentación incluye un
dispositivo para interrupción de corriente.
Se incluye un botón de prueba y de reinicio
en el dispositivo. El dispositivo debe ponerse
a prueba periódicamente: primero se presiona
el botón de TEST (prueba) y luego RESET
(reinicio) mientras se encuentra enchufado al
tomacorriente. Si el botón TEST no se dispara
o si el botón RESET no queda enganchado,
deje de utilizar el acondicionador de aire y
comuníquese con un técnico calificado.
Pida a un técnico que inspeccione el
tomacorriente y el circuito para cerciorarse
de que el tomacorriente está conectado a
tierra de la manera apropiada.
Donde exista un tomacorriente de dos
tomas, es su responsabilidad y obligación
personal hacer que dicho tomacorriente
sea reemplazado por uno de tres tomas
con conexión a tierra.
El acondicionador de aire debería siempre estar
conectado a un tomacorriente individual con su
circuito de voltaje correspondiente.
Esto proporciona el mayor rendimiento y
además evita que los circuitos del resto de
la casa se sobrecarguen, lo cual podría causar
incendios por el sobrecalentamiento del
cableado.
Ver las Instrucciones de instalación, en la
sección Requisitos Eléctricos para los requisitos
específicos de conexión.
CÓMO CONECTAR LA ELECTRICIDAD

3
GEAppliances.com
¡ADVERTENCIA!
USO DE PROLONGADORES
RIESGO DE INCENDIO. Podría ocasionar
lesiones graves o la muerte.
• NO use un prolongador con este
Acondicionador de Aire de Ventana.
• NO use protectores contra picos de tensión ni
adaptadores para múltiples tomacorrientes
con este Acondicionador de Aire de Ventana.
LEA Y SIGA ESTAS INSTRUCCIONES DE SEGURIDAD
CUIDADOSAMENTE.
GUARDE ESTAS INSTRUCCIONES

4
Acerca de los controles en el acondicionador de aire
Controles
Tecla de Power (Encendido)
Apaga y prende el acondicionador de aire.
Al encenderse, la pantalla mostrará la
temperatura ambiente.
Pantalla
Muestra la temperatura ambiente o
el tiempo restante en el Sincronizador de
retardo. Muestra la temperatura Definida al
configurar la temperatura en los modos Cool
(Frío) o de Energy Saver (Ahorro de energía).
La luz de Ajuste se encenderá durante la
configuración.
Teclas de Temp Aumento s /Reducción t
Usado para ajustar la temperatura cuando
se encuentre en el modo Cool (Frío) o Energy
Saver (Ahorro de energía). La luz de Ajuste se
encenderá durante la configuración.
Teclas de Sincronizador de retardo Aumento
Ÿ(+) / Reducciónź(–)
Cada vez que toque las teclas Aumento Ÿ/
Reducción źde la unidad o las teclas Aumento
+ / Reducción – en el control remoto definirá
el tiempo de retardo al utilizar el Delay 1–24hr
timer (Sincronizador de retardo 1–24 h).
La luz de Ajuste se encenderá durante la
configuración.
Teclas de Fan Speed (Velocidad del ventilador)
Usado para ajustar la velocidad del ventilador
a Low (Bajo), Med (Medio), High (Alto) o
Auto (Automática) en la unidad. NOTA: en el
control remoto, utilice las teclas Aumento +
/ Reducción – velocidad de ventilador para
ajustar la velocidad del ventilador en Low (Bajo),
Med (Medio) o High (Alto). Utilice la tecla Auto
para activar el ventilador automático.
Tecla de MODO
Usado para ajustar el acondicionador de aire
al modo Cool (Frío), Energy Saver (Ahorro de
energía) o Fan Only (Solo ventilador).
Teclas de Delay (Retardo)/ Delay 1–24hr
(Retardo 1–24h)
Delay ON (ENCENDIDO Retardo)³&XDQGR
el acondicionador de aire está apagado,
puede ajustarse para que se encienda
automáticamente dentro de 1 a 24 horas en el
modo y configuración de ventilador anterior.
Delay OFF (APAGADO Retardo)³&XDQGRHO
acondicionador de aire está encendido, puede
ajustarse para que se apague automáticamente
dentro de 1 a 24 horas.
Cómo realizar el ajuste:
Pulse la tecla Delay 1–24hr (Retardo 1–24h) en
la unidad o Delay pad (Retardo) del control
remoto. Cada toque de las teclas Aumento Ÿ/
Reducciónźen la unidad o las teclas Aumento
+ / Reducción – en el control remoto definirá el
temporizador en intervalos de 1 hora. La luz de
Ajuste se encenderá durante la configuración.
Para revisar el tiempo restante en el Sincronizador
de retardo 1–24 h, pulse la tecla de Delay
1–24hr (Retardo 1–24h) en la unidad o Delay pad
(Retardo) en del control remoto. Utilice las teclas
Aumento Ÿ/ Reducciónźen la unidad o las
teclas Aumento + / Reducción – en el control
remoto para definir un nuevo tiempo, si lo
desea.
Para cancelar el sincronizador, pulse la tecla
Delay 1–24hr (Retardo 1–24h) hasta que la luz
de dicho control se apague.
Reinicio del Filtro
La luz LED se encenderá cuando el ventilador haya
acumulado 250 horas de funcionamiento, como
recordatorio para la limpieza del filtro. Presione
Reset Filter (Reiniciar el Filtro) para apagar la
luz LED y reiniciar el tiempo de funcionamiento
acumulado.
Funciones y el aspecto pueden variar.
Las luces al lado de las teclas de toque en el panel de control del acondicionador de aire indicarán los ajustes seleccionados.
Nota: La temperatura por defecto que figura en la pantalla está en grados Fahrenheit (°F). Para modificar
la pantalla a grados Celsius (°C), mantenga presionados los botones Temp Increase (Incremento
de Temperatura) ŸTemp Decrease (Disminución de Temperatura) źal mismo tiempo y durante 3
segundos. Repita el proceso para volver a modificar la pantalla a grados Fahrenheit (°F).
Fan Fan
1–24 h de retardo
Reducción de
sincronizador de
retardo
Selección de modo
Reducción de
velocidad del
ventilador
Aumento y reducción
de ajuste de
temperatura
Aumento de
sincronizador de
retardo
Encendido automático
del ventilador
Aumento de velocidad
del ventilador
Encendido/apagado de
la unidad
Controles del acondicionador de aire
NOTA: La pantalla muestra siempre la temperatura ambiente, excepto al configurar
la temperatura Definida o el Sincronizador de retardo.
Power
On/Off
Fan Mode
Auto
Reset
Filter
High
Med
Low
Cool
Fan Only
Energy Saver
Delay
1-24 Hrs
Set
+
-
8
La luz indica que la unidad está en el
modo de Ajuste de temperatura o de
Tiempo de retardo.
La luz indica que el
temporizador de retardo
está configurado.
Control Remoto
