GE Mini Field Agent User manual

GFK-2993F
Field Agents*
User Guide
July 2017
For public disclosure

GFK-2993F2
For public disclosure
These instructions do not purport to cover all details or variations in equipment, nor to provide for every possible
contingency
to be met during installation, operation, and maintenance. The information is supplied for informational
purposes only, and GE makes no warranty as to the accuracy of the information included herein. Changes,
modifications, and/or improvements to equipment and specifications are made periodically and these changes may or
may not be reflected herein. It is understood that GE may make changes, modifications, or improvements to the
equipment referenced herein or to the document itself at any time. This document is intended for trained personnel
familiar with the GE products referenced herein.
GE may have patents or pending patent applications covering subject matter in this document. The furnishing
of this document does not provide any license whatsoever to any of these patents.
Public – This document is approved for public disclosure.
GE provides the following document and the information included therein as is and without warranty of
any kind, expressed or implied, including but not limited to any implied statutory warranty of
merchantability or fitness for particular purpose.
For further assistance or technical information, contact the nearest GE Sales or Service Office, or an authorized GE
Sales
Representative.
Revised: June 2017
Issued: Aug 2016
© 2016 – 2017 General Electric Company.
* Indicates a trademark of General Electric Company and/or its
subsidiaries. All other trademarks are the property of their respective
owners.
We would appreciate your feedback about our
documentation. Please send comments or suggestions
to [e-mail]
DocumentUpdates
Location
Description
MFA ImportantProduct Information
Removedthis section — this content has been moved to Mini Field Agent (MFA)
ImportantProductInformation(GFK-2997)
Secure Deployment
Removed this section — this content has been moved to Field Agents Secure
Deployment Guide (GFK-3009)
Power Requirements
Corrected the operating temperaturerange
Configurea Network Proxy
Removedinstructions for Bypass Proxy Server and Test Connection
Create a Device Representationin
EdgeManager
Replacedmultiple screenshotsto reflect Predix* EdgeManager*screen updates,
specifically the dashboardoption Control Panel and related windows were
replaced with Settings
Assignthe Technician to the Field Agent
Obtain EnrollmentInformation
Throughout Document
Revision C: Added Embedded Field Agent (EFA)
Throughout Document
Revision D: Added Virtual Field Agent (VFA)
Throughout Document
Revision E: Added cellular, Wi-Fi hotspot, and Predix Machine 17.1
enhancements for Mini Field Agent (MFA)
Throughout Document
Revision F: Improved documentation for time synchronization, system time, and
Configuration and Application Management and opening ports.

GFK-2993F3
For public disclosure
Safety Symbol Legend
Warning
Indicates a procedure or condition that, if not strictly observed, could result in
personal injury or death.
Caution
Indicates a procedure or condition that, if not strictly observed, could result in damage
to or destruction of equipment.
Attention
Indicates a procedure or condition that should be strictly followed to improve these
applications.

GFK-2993F4
For public disclosure
If you purchased this product through an Authorized Channel Partner, please contact the seller directly.
General Contact Information
Online technical support https://ge-ip.force.com/communities/CC_Contact
Additional information http://www.geautomation.com/contact-us
Solution Provider http://www.geautomation.com/solution-partners
Technical Support
If you have technical problems that cannot be resolved with the information in this manual, please contact us by
telephone or on the web at https://ge-ip.force.com/communities/CC_Contact
Americas
Online Technical Support https://ge-ip.force.com/communities/CC_Contact
Phone [phone]
International Americas Direct Dial 1-780-420-2010 (if toll free 800 option is unavailable)
Technical Support Email [e-mail]
Customer Care Email [email protected]
Primary language of support English
Europe, the Middle East, and Africa
Online Technical Support https://ge-ip.force.com/communities/CC_Contact
Phone + 800-1-433-2682
EMEA Direct Dial + 420-23-901-5850 (if toll free 800 option is unavailable or
dialing from a mobile telephone)
Technical Support Email [email protected]
Customer Care Email [email protected]
Primary languages of support English, French, German, Italian, Czech, Spanish
Asia Pacific
Online Technical Support https://ge-ip.force.com/communities/CC_Contact
Phone + 86-400-820-8208
+ 86-21-3217-4826 (India, Indonesia, and Pakistan)
Technical Support Email support.cn.i[email protected]om (China)
[e-mail] (Japan)
support.in.[email protected]om (remaining Asia customers)
Customer Care Email [email protected]
[email protected] (China)

GFK-2993F5
For public disclosure
Contents
1Overview............................................................................................................................................ 8
1.1 Applicable Products......................................................................................................................8
1.2 Related Documentation................................................................................................................ 9
1.3 Field Agent Architecture ............................................................................................................. 10
1.4 Mini Field Agent (MFA)............................................................................................................... 11
1.4.1 MFA Specifications................................................................................................................................................12
1.5 Embedded Field Agent (EFA)..................................................................................................... 14
1.5.1 Mark* VIe IS420UCSCH1A CPU w/ Field Agent ................................................................................................14
1.5.2 PACSystems IC695CPE400 RX3i Rackless CPU w/ Field Agent ........................................................................14
1.6 Virtual Field Agent (VFA)............................................................................................................ 15
2MFA Hardware Instructions............................................................................................................ 16
2.1 Internal Components .................................................................................................................. 16
2.1.1 Installation..............................................................................................................................................................17
2.1.1.1 DIN Rail Mount..................................................................................................................................................18
2.1.1.2 Panel Mount .......................................................................................................................................................19
2.1.1.3 MFA Interface Details........................................................................................................................................20
2.1.1.4 Power Requirements...........................................................................................................................................21
2.1.1.5 Pin Definitions....................................................................................................................................................22
2.1.1.6 Network Configuration.......................................................................................................................................22
2.1.2 Push Button and LEDs ...........................................................................................................................................23
2.2 Push Button Operations.............................................................................................................. 24
2.2.1 Configuration Mode...............................................................................................................................................24
2.2.2 Reboot....................................................................................................................................................................25
2.2.3 Factory Reset..........................................................................................................................................................25
2.3 Field Agent Sales Catalog.......................................................................................................... 26
2.3.1 GE MFA Orderable Items......................................................................................................................................26
2.3.2 MFA Included Items ..............................................................................................................................................26
2.3.3 MFA Accessories...................................................................................................................................................26
2.4 Agency Certifications and Standards.......................................................................................... 27
2.4.1 Federal Communications Commission (FCC)........................................................................................................28
2.5 Replacement and Spares........................................................................................................... 29
2.5.1 Replacement Procedure..........................................................................................................................................29
2.5.2 Renewals and Spares..............................................................................................................................................30
3EFA Hardware Instructions............................................................................................................ 32
3.1 Mark* VIe IS420UCSCH1A CPU w/ Field Agent......................................................................... 32
3.1.1 UCSC EFA – Network Configuration....................................................................................................................32
3.1.2 UCSC EFA – Push Button and LED......................................................................................................................33
3.2 PACSystems IC695CPE400 RX3i Rackless CPU w/ Field Agent............................................... 34
3.2.1 CPE400 EFA -- Network Configuration................................................................................................................34
3.2.2 CPE400 EFA – LED, Display, and Push Buttons ..................................................................................................35
3.3 GE EFA Orderable Items............................................................................................................ 36
4VFA Instructions............................................................................................................................. 37
4.1 Network Configuration................................................................................................................ 37
4.2 Configuration Mode .................................................................................................................... 37
4.3 Virtual Machine Deployment....................................................................................................... 37
4.4 Virtual Machine Snapshots......................................................................................................... 37
4.5 GE VFA Orderable Items............................................................................................................ 37
5Getting Started with the Field Agent ............................................................................................. 38
5.1 What’s the Minimum I Need to Do to Get Going? ....................................................................... 38
5.2 Register the Field Agent............................................................................................................. 38
5.3 Collect Enrollment and Configuration Information....................................................................... 39
5.4 Start the Field Agent................................................................................................................... 39
5.5 Log into the Web Console .......................................................................................................... 40
5.6 Configure the Network................................................................................................................ 42

GFK-2993F6
For public disclosure
5.6.1 IP Addresses...........................................................................................................................................................42
5.6.1.1 To Identify/Change an IP Address .....................................................................................................................42
5.6.2 Configure a Network Proxy....................................................................................................................................44
5.6.3 Configure the Cellular Network.............................................................................................................................45
5.6.3.1 Enabling the Cellular Modem ............................................................................................................................45
5.6.3.2 Configure the Access Point Name......................................................................................................................46
5.6.3.3 View the Cellular Status.....................................................................................................................................46
5.6.3.4 Cellular Plan and SIM Diagnostics ....................................................................................................................46
5.7 Configure Time Synchronization................................................................................................. 47
5.7.1 Using NTP Time Synchronization .........................................................................................................................47
5.7.2 Using HTTPS Time Synchronization.....................................................................................................................48
5.8 Update the Field Agent............................................................................................................... 49
5.8.1 Access the Field Agent Updater.............................................................................................................................49
To access the Field Agent Updater.....................................................................................................................................49
5.8.2 Method 1: Manual Local Update Using a Local Area Network.............................................................................51
To manually initiate a local update using a Local Area Network connection....................................................................51
5.8.3 Method 2: Manual Cloud Update over the Internet................................................................................................52
To manually initiate a cloud update over the Internet........................................................................................................52
5.8.4 Method 3: Automatic Cloud Update over the Internet...........................................................................................53
To configure automatic cloud updates over the Internet....................................................................................................53
5.8.5 Upgrade Predix Machine If Applicable..................................................................................................................54
5.9 Configure EdgeManager Access ................................................................................................ 55
5.9.1 Create Accounts for Operator and Technician Roles .............................................................................................55
5.10 Enroll Field Agent in Predix Cloud........................................................................................... 56
5.10.1 Enroll using EdgeManager.....................................................................................................................................56
5.10.1.1 Create a Device Representation in EdgeManager ..........................................................................................57
5.10.1.2 Obtain Enrollment Information......................................................................................................................58
5.10.1.3 Log into Predix Cloud Enrollment Page in Field Agent Web Console..........................................................59
5.10.1.4 Enter Enrollment Information and Trigger Enrollment..................................................................................59
5.10.1.4.1 Using Certificate Enrollment .....................................................................................................................60
5.10.1.4.2 Using OAuth Authentication Code Enrollment .........................................................................................62
5.10.1.5 Verify the Field Agent is Online in EdgeManager.........................................................................................63
5.10.2 Enrolling Mini Field Agent Using iPhone App......................................................................................................64
6Using the Field Agent..................................................................................................................... 66
6.1 Device Management................................................................................................................... 66
6.1.1 Field Agent Status..................................................................................................................................................66
6.1.1.1 Using Edge Manager - Field Agent Health Status and Resource Usage ............................................................66
6.1.1.2 Using Web Console – Status Information ..........................................................................................................66
6.1.2 Field Agent Commands..........................................................................................................................................68
6.1.2.1 Using Edge Manager - Supported Field Agent Commands................................................................................68
6.1.2.2 Using Web Console – Sending Commands........................................................................................................69
6.1.2.3 When might a Factory Reset be required ...........................................................................................................69
6.1.3 Configuration Management....................................................................................................................................70
6.1.3.1 EdgeManager Configuration Management.........................................................................................................70
6.1.3.2 Compression Utilities.........................................................................................................................................71
6.1.3.3 Predix Machine Web Console Configuration Management...............................................................................72
6.1.4 Application Management .......................................................................................................................................74
6.1.4.1 EdgeManager Application Management............................................................................................................74
6.1.4.2 Predix Machine Web Console Application Management...................................................................................74
6.1.5 How to Open Ports on a Field Agent......................................................................................................................76
6.1.5.1 The Ports Configuration File..............................................................................................................................76
6.1.5.2 Activating the Ports Configuration.....................................................................................................................76
6.2 Configuring Data Collection and Sending Data to the Cloud....................................................... 77
6.2.1 Determine the Data Source and Data to Consume .................................................................................................77
6.2.2 Field Agent Configuration Tool.............................................................................................................................77
6.2.3 Configure the Field Agent Data Source .................................................................................................................77
6.2.3.1 Configure an OPC UA Data Source...................................................................................................................78
6.2.3.2 Configure a Modbus TCP Data Source..............................................................................................................79
6.2.4 Configure Sending Data to the Predix Cloud .........................................................................................................80
6.2.5 Guidelines for Maximum Configured Variables....................................................................................................81
6.2.5.1 Using the OPC UA Machine Adapter without Store and Forward.....................................................................81

GFK-2993F7
For public disclosure
6.2.5.2 Using Store and Forward with the OPC UA Machine Adapter..........................................................................82
6.2.5.3 Using the Modbus TCP Machine Adapter..........................................................................................................83
6.2.5.4 Using Store and Forward When Internet Connectivity is Disrupted and Restored ............................................84
6.2.6 Reconfigure the Field Agent ..................................................................................................................................85
6.2.6.1 First Time Configuration....................................................................................................................................85
6.2.6.2 Reconfiguration for Production Environment....................................................................................................85

1 Overview
1.1 Applicable Products
Product Family
Catalog
Number Description Provisioning Connection Data Source Connection Cloud Connection
Mini Field Agent (MFA)
ICMFA000000 Field Agent as a standalone appliance for
connecting to external data sources.
•Ethernet LAN •Ethernet LAN •Ethernet WAN
ICMFA002US0
ICMFA002EU0 Field Agent as a standalone appliance for
connecting to external data sources.
Includes optional Wi-Fi hotspot for
provisioning.
•Ethernet LAN
•Wi-Fi hotspot with U.S./Canada
or European country code and
frequencies per catalog number
•Ethernet LAN •Ethernet WAN
ICMFA001US1
ICMFA001EU1 Field Agent as a standalone appliance for
connecting to external data sources.
Includes optional Wi-Fi hotspot for
provisioning and optional private cellular
cloud connection on AT&T®.
•Ethernet LAN
•Wi-Fi hotspot with U.S./Canada
or European country code and
frequencies per catalog number
•Ethernet LAN •Ethernet WAN
•AT&T private cellular
network in the
U.S./Canada or
European Union per
catalog number
ICMFA001US0
ICMFA001EU0 Field Agent as a standalone appliance for
connecting to external data sources.
Includes optional Wi-Fi hotspot for
provisioning and optional cellular cloud
connection on customer-
provided network.
•Ethernet LAN
•Wi-Fi hotspot with U.S./Canada
or European country code and
frequencies per catalog number
•Ethernet LAN •Ethernet WAN
•Cellular network in the
U.S./Canada or
European Union per
catalog number using
customer-provided SIM
Embedded Field Agent (EFA)
IC695CPE400 Field Agent embedded in an Industrial
Internet Control System running
PACSystems*.
•Ethernet WAN in Configuration
Mode only •
Virtual LAN through
hypervisor
•Ethernet WAN
•Ethernet WAN
IS4200UCSCH1A Field Agent embedded in an Industrial
Internet Control System running Mark*
VIe.
•Ethernet WAN in Configuration
Mode only •
Virtual LAN through
hypervisor
•Ethernet WAN
•Ethernet WAN
Virtual Field Agent (VFA)
117T6408Gxxxx Field Agent as a virtual machine image in
a Control Server. •Virtual LAN1 through hypervisor
•Virtual LAN2 through hypervisor
•Virtual LAN1
through hypervisor
•Virtual LAN2
through hypervisor
•Virtual WAN through
hypervisor

GFK-2993F9
For public disclosure
1.2 Related Documentation
Product Landing Pages
Product
URL
Mini Field Agent
https://digitalsupport.ge.com/communities/en_US/Article/ICMFA000000-Landing-Page
CPE400 with
Embedded Field
Agent
https://digitalsupport.ge.com/communities/en_US/Article/IC695CPE400-Landing-Page
Virtual Field Agent
https://digitalsupport.ge.com/communities/en_US/Article/ICVFA000000-Landing-Page
Other Documentation
Document ID
Document Title
GFK-3009
Field Agents Secure Deployment Guide
GFK-3017
Mini Field Agent Upgrade Guide
GFK-3018
Field Agents Registration Guide
GFK-3019
Field Agent Machine Adapters User Guide
GFK-2830
PACSystems* RXi, RX3i, and RX7i Controllers Secure Deployment Guide
GFK-2222
PACSystems CPU Reference Manual
GFK-2314
PACSystems RX3i System Manual
GFK-2224
TCP/IP Ethernet Communications for PACSystems User’s Manual
GFK-2225
TCP/IP Ethernet Communications for PACSystems Station Manager Manual
GFK-2571
PACSystems RX3i PROFINET Controller Manual
GFK-2572
PACSystems RX3i PROFINET Controller Command Line Interface Manual
GFK-2904
PROFINET IO Devices Secure Deployment Guide
GEH-6721 Vol I
Mark* VIe and Mark* VIeS Control Systems Volume I: System Guide
GEH-6721 Vol II
Mark* VIe and Mark* VIeS Control Systems Volume II: General-purpose Applications
GEH-6721 Vol III
Mark* VIe and Mark* VIeS Control Systems Volume III: For GE Industrial Applications
GEH-6839
Mark* VIe Control Systems Secure Deployment Guide
GEH-6700
ToolboxST* User Guide for Mark* Controls Platform
GEH-6767
Security Baseline Information for Mark* VIe Control
GEA-S1289
Cyber Security Management System for Mark* VIe Control
GFA-2120B
Mark* VIe UCSC Outcome Optimizing Control for Power Generation Applications
GEH-6851
Control Server – High Availability (HA) Maintenance Guide

GFK-2993F10
For public disclosure
1.3 Field Agent Architecture
The goal of Field Agent technologyis to connect industrial machines to the Predix* Cloud, so that asset owners can receive
insights and optimization for their equipment. Field Agents connect and transmit this data securely. Operators can then
visualize the performance of their assets and enable predictive analytics. Armed with this valuable information, operators can
optimize equipment uptime. OEMs can proactively maintain and service their equipment fleet, improving operations, growing
service revenues and winning new business. Asset owners can evolve past a break-fix model and implement predictive
analytics to minimize unplanned downtime.
GE has developed a family of Field Agent devices to address the challenges of communicating equipment data. A Field
Agent has two primary functions:
• Collecting and transmitting machine data securely
• A platform for running applications at the edge
Once a Field Agent is up and running, data is transferred from the plant to the cloud over encrypted channels, preserving its
time stamp, quality, and fidelity. It also provides a rich domain application environment for edge processing, so logic can be
executed at the most appropriate place in the architecture — locally on the machine or in the cloud.
HTTPS
Customer Access
Using
Laptop or Mobile
Device
HTTPS
OPC
UA,
Modbus
TCP, etc.
Control System at Customer Site Field Agent at Customer Site
Predix Cloud

GFK-2993F11
For public disclosure
1.4 Mini Field Agent (MFA)
The GE Mini Field Agent* (MFA) module is a Machine to Cloud collector that securely forwards data to a Predix* Time
Series Database Service. The MFA is based on the ARM architecture and designed to meet low power, harsh environment
specifications for industrial use. It runs an embedded Linux® operating system and comes with Predix Machine pre-integrated
and ready to enroll in Predix EdgeManager. The Field Agent ecosystem enables end users ease of developing Predix solutions
using the MFA platform. The following figure depicts the typical installation of a MFA. The section Configure the Network
provides defaults IP addresses.
Features
• Predix Machine
• One Wide Area Network (WAN) Ethernetport
• Three Local Area Network (LAN) Ethernetports with
built-in switch
• RS-485 hardwareinterface
• RS-232 hardwareinterface
• CAN bus hardware interface
• One discrete input
• One relay contact
• Optional cellular modem
• Optional Wi-Fi hotspot
Discrete
Input/Relay
Switched 10/100 Mbps
Ethernet Ports
Power Supply
RS-485 and CAN bus
Serial Com Ports
RS-232 Serial
Com Ports

GFK-2993F12
For public disclosure
1.4.1 MFA Specifications
Note For the latest information, refer to the webpage at http://www.geautomation.com/products/field-agent
Item
Description
Processor TI AM3352 32-bit ARMprocessor,800MHz
Memory 512MB DDR3 RAM
2GB on-board flash
Ambient Temperature,
Humidity
-40°C to 70°C (0°C to 70°C ATEX), 5 to 95% non-condensing
Use above 55°C requires installation in a restricted access location
Real Time Clock Battery Battery backup for RTC, 6 years
USB Port USB 2.0
SD Card Slot One MicroSD card slot
Wi-Fi (Optional) 2.4GHz Wi-Fi, regional settings determined by catalog number
Cellular (Optional) LTE Cellular Modem, regional settings determined by catalog number
Region
4G LTE Bands
3G WCDMA Bands
U.S./Canada 2, 4, 5, 7, 12, 13, 25, 26 2 (1900 MHz), 5 (850 MHz)
EU
1, 3, 7, 8, 20
1 (2100 MHz), 8 (850 MHz)
EthernetPorts One unswitchedEthernetport,10/100 Mbps
Three switched Ethernet ports, 10/100 Mbps
RS-232
One RS–232 Serial Port (pluggablescrew terminal)
Maximum cable distance is 15m
Maximum communicationrate is 115.2 kbps
RS-485
One RS–485 Serial Port (pluggablescrew terminal)
Maximum cable distance: 305 m (1000 ft)
Maximum communicationrate: 115.2 kbps
CAN bus
One CAN port (pluggable screw terminal)
Maximum cable distance is 40 meters
Maximum communicationrate is 1 Mbps
Discreteinput
1 x 24 V opto-coupled/ isolated input, 10 mA nominal
Minimum ON = 1.4µs
Maximum OFF = 28 µs
Hipot tested to 1202 V DC (equivalent of 925 V rms)
Relay contact
1 x Output relay, DC (Form A normally open relay contact,30W switching power)
30 V DC, 1A
Hipot tested to 1202 V DC (equivalent of 925 V rms)
Operating System EmbeddedLinuxbuilt using the Yocto Toolchain
Operating voltage 9 to 30 V DC, nominal 24 V DC
Power consumption 4 Watts (167mA@24V DC) without cellular modem (ICMFA000000, ICMFA002xxx)
8.4 Watts (350mA@24V DC) with cellular modem (ICMFA001xxx)
3-pin power plug
Wire sizes: 22 to 16 AWG; Screw torque: 2 in-Ib
Temperature rating for copperwire: 80 °C
Wiring to power input terminalsshall be limited to 30 meters in length

GFK-2993F13
For public disclosure
Item Description
Housing dimensions 5.53 x 5.33 x 1.55 Inches (140.5 x 135.3 x 39.4 mm)
Mounting DIN rail or panel mount
Certifications Refer to the section Agency Certificationsand Standards
Operational Vibration IEC 600068-2-6
10-57Hz, 0.012"ppk displacement
57-500HZ,2.0g acceleration
Operational Shock IEC 60068-2-27
15g, 11ms (sine wave)
Mean Time Between Failures ICMFA000000: 415,750 hours (47.46 years)
ICMFA001xxx: 396,295 hours (45.24 years)
ICMFA002xxx: 404,734 hours (46.20 years)
Security Features On-board Trusted Platform Module
Protocols Modbus TCP, OPC UA (built in)
Other protocols can be added using the Predix Machine SDK.

GFK-2993F14
For public disclosure
1.5 Embedded Field Agent (EFA)
The GE Embedded Field Agent (EFA) is available in two physical form factors: the Mark* VIe controller, which is part of the
ControlST family of products, and the CPE400 controller, which is part of the PACSystems* family of products. The EFA resides in
one of the virtual machines on the controller and uses the Ubuntu® operating system. It comes with Field Agent software including
Predix Machine pre-integrated and ready to enroll in Predix EdgeManager. While the EFA is essentially configured the same way
as an MFA, there are different Application and Configuration templates provided for the EFA. For instance, because the EFA has
more memory and a higher-performance CPU compared to the MFA, it can retain more “Store and Forward” buffered data in the
event of temporary loss of communications to the cloud. Therefore, the Store and Forward configuration files for the MFA and EFA
are different.
1.5.1 Mark* VIe IS420UCSCH1A CPU w/ Field Agent
The Mark* VIe UCSC EFA uses the IICS Cloud Port (found on the bottom of the UCSC) to both communicate to controllers to gather
data, as well as to connect to the Predix Cloud. For more information about the UCSC itself, please see GEH-6721_Vol_II Mark* VIe
and Mark* VIeS Control Systems, Volume II: General-purpose Applications.
1.5.2 PACSystems IC695CPE400 RX3i Rackless CPU w/ Field Agent
The CPE400 EFA uses the EFA Port (found on the bottom of the CPE400) to connect to the Predix Cloud. It uses an internal virtual NIC
to communicate with the controller to gather data. The CPE400 also contains a display, which is described in the EFA HW Instructions
portion of this document. For more information about the CPE400 itself, please see PACSystems RX7i & RX3i CPU Reference Manual,
GFK-2222Y or later.

GFK-2993F15
For public disclosure
1.6 Virtual Field Agent (VFA)
The GE Virtual Field Agent (VFA) is a Virtual Machine that uses the Ubuntu operating system. It contains Predix Machine to allow
streaming data to the cloud or running applications locally. It also incorporates User Interfaces for configuring networks and time
synchronization, getting Field Agent Product and Linux OS Updates, and checking status and running commands. While the VFA is
essentially configured the same way as an MFA or VFA, there are different Application and Configuration templates provided for the
VFA, because these templates are associated with a specific version of Predix Machine. Currently the Virtual Field Agent is normally
distributed as one of the possible Virtual Machines on a Control Server. To learn more about Control Servers, please see GEH-6851
Control Server – High Availability (HA) Maintenance Guide and GEH-6852 Control Server – Simplex Maintenance Guide.

GFK-2993F16
For public disclosure
2 MFA Hardware Instructions
2.1 Internal Components
Caution
The only user-serviceablecomponents in the Mini Field Agent are the Real Time Clock
Batteryand cellular SIM card. Do not remove or alter any other components on the Mini
Field Agent.
The MFA module is shipped with a battery pre-installed. The battery holder is located below the Supercap, and can be
replaced by opening the top cover.
To replace the battery
1. Power OFF the MFA Module.
2. Wait for 1 minute.
3. Open the top cover by loosening the four screws on the edges.
4. Use a small flat-head screw driver to gently pry out the old battery.
5. Insert the new battery.
Replace battery only with Rayovac BR2032 or part IC690ACC001Bor later. Use of
another battery may present a risk of fire or explosion.
Warning Battery may explode if mistreated. Do not recharge, disassemble, heat above 100 °C
(212 °F) or incinerate.
The MFA module has an optional cellular modem. The SIM is available as a pre-installed option or may be installed by the
customer. The SIM card holder is located underneath the cellular modem and can be installed by opening the top cover and
removing the cellular modem.
To install aSIM Card
1. Power OFF the MFA Module.
2. Wait for 1 minute.
3. Open the top cover by loosening the four screws on the edges.
4. Remove the cellular modem by removing the two screws, tilt the modem up and slide out of the connector.
5. Slide the SIM card holder latch toward the Open position and flip it open.
6. Slide the SIM card into the holder so that the contacts will face down when closed and with the notched end extending out
of the holder.
7. Close the SIM card holder and slide the latch to the Locked position.

GFK-2993F17
For public disclosure
2.1.1 Installation
There are two different mounting options for the MFA: DIN Rail Mount or Panel Mount. The ICMFAACC001 MFA Panel
Mounting Kit is required to use the Panel Mount option. After mounting the MFA, connect it to the facility network using
standard Ethernet cables. The LAN interface should be connected to the local area network containing one or more industrial
devices. The WAN interface should be connected to a network with access to the Internet.

GFK-2993F18
For public disclosure
2.1.1.1 DIN Rail Mount
The MFA comes equipped with a DIN Rail mounting clip as displayed in the following figure. For DIN Rail mounting, pull
the clip down and lock it in place. Place the unit on the DIN rail, and then push the clip up to secure it. The optional panel
mounting plate should not be attached because it will prevent DIN rail mounting.

GFK-2993F19
For public disclosure
2.1.1.2 Panel Mount
To panel mount the MFA module, attach the ICMFAACC001 panel mount plate to the side of the MFA module using the four
M3 screws included with the mounting kit. Attach the panel mount plate in the orientation as displayed in the following
figure. The screw size for each panel mount tab is recommended to not exceed M5.

GFK-2993F20
For public disclosure
2.1.1.3 MFA Interface Details
Note Refer to Mini Field Agent (MFA) Important Product Information (GFK-2997) for version-specific interface details.
The following figure displays all four sides of the MFA module with details for connections.
Front View
Top View
Cellular Antenna
Connections
(on applicable models)
MicroSD slot
(for GE internal use only)
Local Field I/O
DIN Rail
Mounting Clip
RS-232
RS-485
Termination Jumper for CAN
(rightmost 2 contacts)
Wi-Fi Antenna
Connection
(on applicable models)
Ground
Connection
Rear View
Bottom View
USB
Interface
Ethernet
Interfaces
Push
Button
Status
LEDs
