GE Kilsen KFP-CF Series User manual

GE
Security
P/N 501-415103-2-10 • REV 1.0 • ISS 01MAY09
Kilsen KFP-CF Series Operation
Manual

Copyright © 2009 GE Security, Inc.
This document may not be copied in whole or in part or otherwise reproduced without prior
written consent from GE Security, Inc., except where specifically permitted under US and
international copyright law.
Disclaimer The information in this document is subject to change without notice. GE Security, Inc.
(“GE Security”) assumes no responsibility for inaccuracies or omissions and specifically disclaims
any liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or
indirectly, of the use or application of any of the contents of this document. For the latest
documentation, contact your local supplier or visit us online at www.gesecurity.eu.
This publication may contain examples of screen captures and reports used in daily operations.
Examples may include fictitious names of individuals and companies. Any similarity to names
and addresses of actual businesses or persons is entirely coincidental.
Trademarks and patents GE and the GE monogram are trademarks of General Electric Company. CleanMe and the Kilsen
KFP-CF Series name and logo are trademarks of GE Security.
Other trade names used in this document may be trademarks or registered trademarks of the
manufacturers or vendors of the respective products.
Intended use Use this product only for the purpose it was designed for; refer to the data sheet and user
documentation for details. For the latest product information, contact your local supplier or visit
us online at www.gesecurity.eu.
Certification and compliance
European Union directives
2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European manufacturers must designate an authorized
representative in the Community. Our authorized manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for specific
battery information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information see: www.recyclethis.info.
Contact information For contact information see our Web site: www.gesecurity.eu.

Kilsen KFP-CF Series Operation Manual I
Content
Introduction 1
Product range 1
Operating modes 1
Sounder and fire routing delays 2
Control panel overview 3
User interface for two- and four-zone control panels 3
User interface for eight-zone control panels 4
Operator controls and indicators 5
Acoustic indicators 7
Summary of status indications 7
Control panel operation 10
Access levels 10
Basic operation 11
Advanced operation 13
Maintenance 17
Fire alarm system maintenance 17
Battery maintenance 18
Product compliance 19

II Kilsen KFP-CF Series Operation Manual

Kilsen KFP-CF Series Operation Manual 1
Introduction
This is the access level 1 and access level 2 operation manual for the Kilsen KFP-CF
series fire alarm control panels. Read these instructions and all related
documentation entirely before operating this product.
Product range
The KFP-CF series includes the models shown below.
Model Description
KFP-CF2 Two-zone fire alarm control panel
KFP-CF4 Four-zone fire alarm control panel with fire routing
KFP-CF8 Eight-zone fire alarm control panel with fire routing
Fire routing on the four- and eight-zone models is not available for all operating
modes. See “Sounder and fire routing delays” on page 2.
Operating modes
Supported operating modes are shown in the table below. The default operating
mode is EN 54-2.
Table 1: Operating modes
Operating mode Region
EN 54-2 (default) European Union
EN 54-2 Evacuation European Union (Spain)
EN 54-2 Scandinavia European Union (Scandinavia)
BS 5839-1 United Kingdom
NBN S21-100 Belgium
NEN 2535 The Netherlands
The choice of operating mode used depends on your location and the specific
regional requirements of your fire alarm system.
As there is no visual indication of the active operating mode, your installation or
maintenance contractor should provide full details of your configuration.

2 Kilsen KFP-CF Series Operation Manual
Sounder and fire routing delays
Sounder and fire routing delays are not available for all operating modes. The table
below shows delay availability for each operating mode.
Table 2: Sounder and fire routing delays
Operating mode Sounder delay Fire routing delay Extended fire routing
delay
EN 54-2 Yes Yes No
EN 54-2 Evacuation Yes No No
EN 54-2 Scandinavia Yes Yes Yes
BS 5839-1 Yes No No
NBN S21-100 Yes No No
NEN 2535 No Yes Yes
Note: Fire routing is not available on any two-zone control panel.

Kilsen KFP-CF Series Operation Manual 3
Control panel overview
This topic provides an introduction to the control panel interface, operator controls,
and indicators.
User interface for two- and four-zone control panels
Figure 1: User interface for two- and four-zone control panels
1. Zone buttons and LEDs (Z1, Z2, etc.)
2. Supply LED
3. General Fault LED
4. General Fire Alarm LEDs
5. Sounder Fault/Disable/Test button
and LED
6. Sounder Delay button and LED
7. Network Fault LED
8. Service Detector LED
9. Expansion I/O Fault/Disabled LED
10. General Disable button and LED
11. General Test button and LED
12. Configuration controls
13. Reset button and LED
14. Panel Silence button and LED
15. Sounder Start/Stop button and LED
16. System Fault LED
17. Out of Service LED
18. Earth Fault LED
19. Supply Fault LED
20. Fire Routing Delay button and LED
21. Fire Routing Start and
Fault/Disable/Test button and LEDs
Note: Two-zone control panels do not include fire routing.

4 Kilsen KFP-CF Series Operation Manual
User interface for eight-zone control panels
Figure 2: User interface for eight-zone control panels
1. Zone buttons and LEDs (Z1, Z2, etc.)
2. Supply LED
3. General Fault LED
4. General Fire Alarm LEDs
5. Sounder Fault/Disable/Test button
and LED
6. Sounder Delay button and LED
7. Network Fault LED
8. Service Detector LED
9. Expansion I/O Fault/Disabled LED
10. General Disable button and LED
11. General Test button and LED
12. Configuration controls
13. Reset button and LED
14. Panel Silence button and LED
15. Sounder Start/Stop button and LED
16. System Fault LED
17. Out of Service LED
18. Earth Fault LED
19. Supply Fault LED
20. Fire Routing Delay button and LED
21. Fire Routing Start and
Fault/Disable/Test button and LEDs

Kilsen KFP-CF Series Operation Manual 5
Operator controls and indicators
The following table gives an overview of the control panel operator controls and
indicators. Item numbers refer to Figure 1 on page 3 and Figure 2 on page 4.
Operational features described here may not be available to all users. Further
information on control panel operation and access restrictions can be found in the
topic “Control panel operation” on page 10.
Table 3: Operator controls and LED indicators
Item Control/LED LED colour Description
1 Zone button and
LEDs
Red/Yellow Disables or tests a zone (when pressed together with
the general Disable or general Test button).
The red LED indicates an alarm in the corresponding
zone. A flashing red LED indicates that the fire alarm
was activated by a detector. A steady red LED
indicates that the fire alarm was activated by a
manual call point.
The yellow LED indicates a fault, test, or disablement
in the corresponding zone. A flashing yellow LED
indicates a fault. A steady yellow LED indicates that
the zone is disabled or is being tested.
2 Supply LED Green Indicates that the system is powered up correctly.
3 General Fault LED Yellow Indicates a fault. The corresponding zone, device, or
function fault LED also flashes.
4 General Fire Alarm
LEDs
Red Indicates a fire alarm.
Flashing LEDs indicate that the fire alarm was
activated by a detector. Steady LEDs indicate that
the fire alarm was activated by a manual call point.
The corresponding zone alarm LED indicates the
source of fire alarm.
5 Sounder
Fault/Disable/ Test
button and LED
Yellow Disables or tests sounders (when pressed with the
general Disable or general Test button).
A flashing LED indicates a fault with the sounders. A
steady LED indicates that the sounders are disabled
or are being tested.
6 Sounder Delay button
and LED
Yellow Enables or disables a previously configured sounder
delay.
A steady LED indicates that a sounder delay is
configured and enabled.
7 Network Fault LED Yellow Indicates a network fault.
8 Service Detector LED Yellow Indicates that a detector requires servicing (CleanMe
compatible detectors only).
9 Expansion I/O
Fault/Disabled LED
Yellow Indicates that an installed expansion module has a
fault or is disabled.
A flashing LED indicates a fault with an expansion
module. A steady LED indicates that an expansion
module is disabled.

6 Kilsen KFP-CF Series Operation Manual
Item Control/LED LED colour Description
10 General Disable
button and LED
Yellow Disables a zone, sounders, fire routing, or expansion
I/O module (when pressed with the corresponding
button).
A steady general Disable LED and the corresponding
zone, sounders, or fire routing Fault/Disable/Test
LED indicates a disablement.
11 General Test button
and LED
Yellow Tests a zone, sounders, or fire routing (when pressed
with the corresponding button).
A steady general Test LED and the corresponding
zone, sounders, or fire routing Fault/Disable/Test
LED indicates a test.
12 Numeric keypad and
Enter button
N/A Used to enter the access level 2 password. The Enter
button is also used to disable expansion I/O modules
(when pressed with the general Disable button).
13 Reset button Yellow Resets the control panel and clears all current
system events (except expansion I/O module fault
communication).
A steady LED indicates that access level 2 is active
(see “Access levels” on page 10).
14 Panel Silence button
and LED
Yellow Silences the internal buzzer and acknowledges all
current events.
A steady LED indicates that all current events were
acknowledged.
15 Sounder Start/Stop
button and LED
Red Stops (silences) all active sounders. Pressing the
button again restarts them.
A flashing LED indicates that sounders activate
when a configured delay elapses. A steady LED
indicates that the sounders are active (sounding).
16 System Fault LED Yellow Indicates a control panel CPU failure.
17 Out of Service LED Yellow Indicates that the control panel is not operational.
18 Earth Fault LED Yellow Indicates an earth fault.
19 Supply Fault LED Yellow Indicates a fault with the power supply.
A flashing LED indicates a battery or battery fuse
fault. A steady LED indicates a mains or mains fuse
fault.
20 Fire Routing Delay
button and LED
Yellow Enables or disables a previously configured fire
routing delay.
A steady LED indicates that a fire routing delay is
configured and enabled.
21 Fire Routing Start
button and LED
Red Cancels a previously configured delay and activates
fire routing.
A flashing LED indicates that fire routing activates
when the configured delay elapses. A steady LED
indicates that fire routing is active.

Kilsen KFP-CF Series Operation Manual 7
Item Control/LED LED colour Description
21 Fire Routing
Fault/Disable/Test
button and LED
Yellow Indicates that fire routing is in a fault condition, is
disabled, or is being tested.
A flashing LED indicates a fault. A steady LED
indicates that the function is disabled or is being
tested.
Acoustic indicators
The control panel uses the following acoustic indicators to highlight system events.
Indication Description
The internal buzzer sounds
constantly
Indicates a fire alarm or a system
fault
The internal buzzer sounds
intermittently
Indicates all other faults
Summary of status indications
This section includes a summary of the control panel status indications.
Standby (normal status)
Standby, or normal status, is indicated as follows:
• The Supply LED is steady.
• If a sounder delay was enabled, the Sounder Delay LED is steady.
• If a fire routing delay was enabled, the Fire Routing Delay LED is steady.
• There are no acoustic indications.
Fire alarm
Fire alarm status is indicated as follows:
• The general Fire Alarm LEDs are flashing if the alarm was activated by a detector
or steady if the alarm was activated by a manual call point.
• The corresponding zone alarm LEDs are flashing if the alarm was activated by a
detector or steady if the alarm was activated by a manual call point.
• If a sounder delay was enabled, the Sounder Delay LED is steady. The Sounder
Start/Stop LED flashes while the delay is active. When the sounders are active
(sounding), the LED is steady.
• If a fire routing delay was enabled, the Fire Routing Delay LED is steady. The Fire
Routing Start LED flashes while the delay is active. When fire routing is active, the
LED is steady.
• The internal buzzer sounds constantly.
Alarms activated by a manual call point always take priority over alarms activated by
a detector. If an alarm is activated by both devices, the Fire Alarm LEDs and zone
alarm LEDs are steady.

8 Kilsen KFP-CF Series Operation Manual
Fault
Fault status is indicated as follows:
• General faults are indicated by the general Fault LED and the corresponding zone,
function, or device fault LED indicator flashing.
• Mains power faults and mains fuse faults are indicated by a flashing general Fault
LED and a steady Supply Fault LED.
• Battery power and battery fuse faults are indicated by a flashing general Fault
LED and a flashing Supply Fault LED.
• Earth faults are indicated by a flashing general Fault LED and a steady Earth Fault
LED.
• The internal buzzer sounds intermittently.
WARNING: Contact your installation or maintenance contractor to investigate the
cause of all reported faults.
Disabled
Disabled zones are indicated as follows:
• The general Disable LED and the corresponding zone Fault/Disable/Test LEDs are
steady.
• There is no acoustic indicator.
Disabled sounders are indicated as follows:
• The general Disable LED and the Sounder Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
Disabled fire routing is indicated as follows:
• The general Disable LED and the Fire Routing Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
Disabled expansion modules are indicated as follows:
• The general Disable LED and the I/O Fault/Disabled LEDs are steady.
• There is no acoustic indicator.
Test
A zone test is indicated as follows:
• The general Test and the corresponding zone Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
A sounder test is indicated as follows:
• The general Test and the Sounder Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.
A fire routing test is indicated as follows:
• The general Test and the Fire Routing Start Fault/Disable/Test LEDs are steady.
• There is no acoustic indicator.

Kilsen KFP-CF Series Operation Manual 9
Out of service
WARNING: When the control panel indicates Out of Service, your fire alarm system is
inactive and your site is not protected. Contact your installation or maintenance
contractor immediately to investigate the problem.
The control panel is out of service when there is insufficient or no mains and/or
battery power. In this state there is no further fire alarm or fault warning and all panel
operation stops.
Out of service is indicated as follows:
• The Supply LED flashes if there is no mains power and the battery voltage is
insufficient.
• The Supply LED is steady if the mains power is insufficient and no battery power is
detected.
• The Out of Service LED is steady.
• The internal buzzer sounds intermittently.
When power is re-established the control panel returns to its former status.
Caution: To avoid damage to batteries, we recommended that you disconnect them
when the control panel is out of service.

10 Kilsen KFP-CF Series Operation Manual
Control panel operation
Access levels
For your safety, operation of some features of this product are restricted by access
level.
Access level 1
Access level 1 is the default access level and allows basic operational access only,
such as responding to a fire alarm or fault warning at the control panel.
The tasks you can perform at this access level are detailed in the topic “Basic
operation” on page 11.
Access level 2
Access level 2 allows advanced operational access. It is reserved for authorized users
who have been trained to operate the control panel. The default access level 2
password is 2222.
The tasks you can perform at this access level are detailed in the topic “Advanced
operation” on page 13.
Entering access level 2
To enter access level 2:
1. Enter the access level 2 password using the numeric keypad.
2. Press Enter.
A long beep and a steady Reset LED indicate that the correct password was entered
and access level 2 is active.
Note: Three short beeps accompanied by a flashing general Fault LED indicate that
an incorrect password was entered.
Exiting from access level 2
The control panel automatically exits from access level 2 and reverts to access level 1
after five minutes if no button is pressed.

Kilsen KFP-CF Series Operation Manual 11
Basic operation
Basic operation includes those tasks that can be performed when the control panel is
in access level 1, the default access level.
Basic operation in access level 1 lets you:
• Acknowledge a system event and silence the internal buzzer
• Cancel an active sounder delay
• Cancel an active fire routing delay
• Perform a control panel LED and internal buzzer test
No other system controls are available at access level 1.
Acknowledging a system event and silencing the internal buzzer
To acknowledge a system event and silence the internal buzzer, press the Panel
Silence button.
A steady Panel Silence LED indicates that the internal buzzer was silenced and that all
current events were acknowledged.
Cancelling an active sounder delay
If a sounder delay is enabled and active, press the Sounder Start/Stop button to
cancel the delay and activate sounders immediately.
A sounder delay is indicated as follows:
• A steady Sounder Delay LED indicates that a delay is enabled.
• A flashing Sounder Start/Stop LED during a fire alarm indicates that the
configured delay is active (sounders are activated when the configured delay
elapses or when the delay is cancelled).
A fire alarm activated by a manual call point overrides any configured delay and
activates sounders immediately.
Cancelling an active fire routing delay
If a fire routing delay is enabled and active, press the Fire Routing Start button to
cancel the delay and activate fire routing immediately.
A fire routing delay is indicated as follows:
• A steady Fire Routing Delay LED indicates that a delay is enabled.
• A flashing Fire Routing Start LED during a fire alarm indicates that the configured
delay is active (fire routing is activated when the configured delay elapses or
when the delay is cancelled).
A fire alarm activated by a manual call point overrides any configured delay and
activates fire routing immediately.

12 Kilsen KFP-CF Series Operation Manual
Performing a control panel LED indicator and internal buzzer test
To perform a control panel LED indicator and internal buzzer test, press and hold the
Test button for three seconds or more.
The test is indicated as follows:
• The general Fault and System Fault LEDs flash.
• All other LEDs are steady.
• The internal buzzer sounds constantly.
The test continues for as long as the Test button remains pressed (with an automatic
timeout of twelve seconds). When the test is completed the control panel returns to
its former state.

Kilsen KFP-CF Series Operation Manual 13
Advanced operation
Advanced operation includes those tasks that can be performed when the control
panel is in access level 2.
This access level is password-protected and is reserved for authorized users who
have been trained to operate the control panel. The default access level 2 password
is 2222.
Those tasks included in the topic “Basic operation” on page 11 are also available at
access level 2.
Resetting the control panel
To reset the control panel and clear all current system events, press the Reset button.
System events that have not been resolved continue to be highlighted when the reset
process ends.
Caution: Investigate all fire alarms and system faults before resetting the control
panel.
Stopping sounders or restarting stopped sounders
To stop sounders, press the Sounder Start/Stop button. To restart stopped sounders,
press the button again.
A steady Sounder Start/Stop LED indicates that the sounders are active (sounding). A
flashing Sounder Start/Stop LED indicates that a configured sounder delay is active
(to cancel an active sounder delay, see “Cancelling an active sounder delay” on page
11).
Note: Sounder functionality is defined by your system configuration settings and
stopped sounders may restart automatically if another alarm event is detected.
Contact your fire system installation or maintenance contractor to confirm your
configuration details.
Enabling or disabling a configured sounder delay
To enable a configured sounder delay, press the Sounder Delay button. To disable the
delay, press the button again.
Note: Availability of this feature is subject to configuration and its functionality may
vary for each zone. Contact your fire system installation or maintenance contractor
to confirm your configuration details.
Enabling or disabling a configured fire routing delay
To enable a configured fire routing delay, press the Fire Routing Delay button. To
disable the delay, press the button again.
Note: Availability of this feature is subject to configuration and its functionality may
vary for each zone. Contact your fire system installation or maintenance contractor
to confirm your configuration details.

14 Kilsen KFP-CF Series Operation Manual
Enabling or disabling a configured extended fire routing delay
If configured, the extended fire routing delay is enabled or disabled at the same time
as the standard fire routing delay.
In NEN 2535 operating mode, the extended fire routing delay becomes the active
delay when sounders are stopped (by pressing the Sounder Start/Stop button) and
remain stopped when the standard fire routing delay time has elapsed.
In EN 54-2 Scandinavia operating mode, the extended fire routing delay becomes the
active delay when an extended fire routing delay switch is activated while the
standard fire routing delay elapses.
Testing a zone
To test a zone, press the general Test button, and then press the corresponding Zone
button. The maximum number of zones that may be tested at the same time is four.
A zone in test is indicated as follows:
• The general Test LED is steady.
• The Zone Fault/Disable/Test LED is steady.
When an alarm is activated in a zone in test:
• The general Fire Alarm LEDs and Zone alarm LED are steady or flashing,
depending on the source of the alarm.
• Fire routing and other zone-dependent functions are not activated.
• Unless configured otherwise, the sounders are activated for five seconds and the
Sounder Start/Stop LED is steady (see note).
• Unless configured otherwise, the internal buzzer sounds constantly (see note).
• The control panel will reset automatically after five seconds and clear alarms for
the zone in test.
To end the test, press the Test button, and then press the Zone button again.
If there is a fire alarm in another zone not in test, the control panel responds to the
alarm event as configured.
Note: The internal buzzer and sounders may be configured not to sound when an
alarm is activated in a zone being tested. Contact your fire system installation or
maintenance contractor to confirm your configuration details.
Disabling a zone or enabling a disabled zone
To disable a zone, press the general Disable button, and then press the
corresponding Zone button.
A disabled zone is indicated as follows:
• The general Disable LED is steady.
• The zone Fault/Disable/Test LED is steady.
To enable the zone, press the general Disable button, and then press the Zone button
again.

Kilsen KFP-CF Series Operation Manual 15
WARNING: No fire alarm or faults are indicated for disabled zones.
Testing sounders
To test sounders, press the general Test button, and then press the Sounder
Fault/Disable/Test button. Sounders can only be tested when the control panel is in
standby.
The test is indicated as follows:
• The general Test LED is steady.
• The Sounder Fault/Disable/Test LED is steady.
• The sounders emit the audible test signal (three seconds on, five seconds off) for
the duration of the test, without any configured delay.
To end the test, press the general Test button, and then press the Sounder Start/Stop
button again.
If there is a fire alarm the fire panel will exit the test immediately and respond to the
alarm as configured.
Disabling sounders or enabling disabled sounders
To disable sounders, press the general Disable button, and then press the Sounder
Fault/Disable/Test button. Sounders can only be disabled when the control panel is in
standby.
Disabled sounders are indicated as follows:
• The general Disable LED is steady.
• The Sounder Fault/Disable/Test LED is steady.
To enable the sounders, press the general Disable button, and then press the
Sounder Fault/Disable/Test button again.
WARNING: Disabled sounders do not indicate a fault or operate if there is a fire
alarm.
Testing fire routing
Caution: Always notify the fire brigade of any planned fire routing tests.
To test fire routing, press the general Test button, and then press the Fire Routing
Start button.
The test is indicated as follows:
• The general Test LED is steady.
• The Fire Routing Fault/Disable/Test LED is steady.
• The Fire Routing Start LED flashes and the test signal (three seconds on/five
seconds off) is activated without any configured delay for the duration of the test.
To end the test, press the general Test button, and then press the Fire Routing Start
button again.

16 Kilsen KFP-CF Series Operation Manual
If there is a fire alarm the fire panel will exit the test and respond to the alarm as
configured.
Disabling fire routing or enabling disabled fire routing
To disable fire routing, press the general Disable button, and then press the Fire
Routing Start button.
Disabled fire routing is indicated as follows:
• The general Disable LED is steady.
• The Fire Routing Fault/Disable/Test LED is steady.
To enable fire routing, press the general Disable button, and then press the Fire
Routing Start button again.
WARNING: Disabled fire routing does not indicate a fault or operate if there is a fire
alarm.
Disabling expansion modules or enabling disabled expansion modules
To disable expansion modules, press the general Disable button, and then press
Enter.
Disabled expansion modules are indicated as follows:
• The general Disable LED is steady.
• The Expansion I/O Fault/Disabled LED is steady.
To enable the expansion modules, press the general Disable button, and then press
Enter again.
WARNING: Disabled expansion modules do not indicate a fault or operate if there is a
fire alarm.
