Monogram.
™
Specification Created 12/01
ZEU769BC/SC/TC—GE Monogram Ribbon Cooktop
Dimensions and Specifications (in inches)
Cutout Dimensions:
W 33-7/8" (860 mm)
L 19-1/8" (484 mm)
Note: 9.4 KW rating at 240 volts.
7.1 KW rating at 208 volts.
Note: Use template provided with installation
instructions to obtain required 1/2" radius cut or
angle cut in each corner.
* Depth of unit at conduit location (left rear): 4-3/4”.
Requires 5” min. clearance below the cooktop bottom
to combustible materials.
Reference pub. no. 49-8800, GE Monogram Halogen
and Ribbon Cooktop Installation Instructions,
before installing for current dimensional data.
Electrical junction box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at front
1-3/4" MIN.
clearance to
side wall
from cut-out
1-1/2" MIN.
clearance to
side wall
from cut-out
18" MIN.
to cabinet
1-3/4" to
rear wall
13" MAX.
depth
Cooktop
2-1/2"
Required
33-7/8
19-1/8"
36" 20-3/8"
3-1/4"
16" Min
Junction
Box
For answers to your Monogram,
® GE Profile™or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories

Monogram.
™
Specification Created 12/01
ZEU769BC/SC/TC—GE Monogram Ribbon Cooktop
Monogram.
L
O
O
F
F
H
I
1
2
3
4
5
6
7
8
9
L
O
O
F
F
H
I
1
2
3
4
5
6
7
8
9
L
O
O
F
F
H
I
1
2
3
4
5
6
7
8
9
L
O
O
F
F
H
I
1
2
3
4
5
6
7
8
9
L
O
O
F
F
H
I
1
2
3
4
5
6
7
8
9
ON
HOT SURFACE
Features and Benefits
•36”Ribbon Electric Cooktop
•Two 7”Ribbon, One 6”Ribbon and One Dual
6”/9”Ribbon Heating Element
•Ribbon Bridge Burner Links 7”Elements
•Upfront Controls with Ten-Step Rotary
Controls for Halogen Elements
•Five Hot Surface Indicator Lights
•Frameless Glass Cooktop
•Model ZEU769SCSS—Black with
Stainless steel trim
•Model ZEU769TCWW—White on white
•Model ZEU769BCBB—Black on black
