GE Masoneilan 469 Series User manual

469
Motor Management Relay
GE
Grid Solutions
Instruction Manual
Software Revision: 5.20
Manual P/N: 1601-0122-AJ
Manual Order Code: GEK-106474S
GE Grid Solutions
650 Markland Street
Markham, Ontario
Canada L6C 0M1
TELEPHONE: Worldwide [phone]
Europe/Middle East Africa [phone]
North America toll-free 1 800 547 8629
FAX: [phone]
E-MAIL: Worldwide multilin.t[email protected]
Europe multilin.t[email protected]
HOME PAGE: Internet: http://www.gegridsolutions.com/multilin
*1601-0122-AJ*

© 2016 GE Multilin Incorporated. All rights reserved.
GE Multilin 469 Motor Management Relay instruction manual for revision 5.20.
469 Motor Management Relay, is a registered trademark of GE Multilin Inc.
The contents of this manual are the property of GE Multilin Inc. This documentation is
furnished on license and may not be reproduced in whole or in part without the permission
of GE Multilin. The content of this manual is for informational use only and is subject to
change without notice.
Part numbers contained in this manual are subject to change without notice, and should
therefore be verified by GE Multilin before ordering.
Part number: 1601-0122-AJ (February 2016)

Safety words and definitions
The following symbols used in this document indicate the following conditions:
Note Indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
Note Indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
Note Indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
Note Indicates practices not related to personal injury.
NOTE
Indicates general information and practices, including operational information and
practices, that are not related to personal injury.

TOC TABLE OF CONTENTS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL TOC–I
Table of Contents
1: GETTING STARTED IMPORTANT PROCEDURES .......................................................................................................... 1-1
CAUTIONS AND WARNINGS ............................................................................................... 1-1
INSPECTION CHECKLIST ...................................................................................................... 1-1
MANUAL ORGANIZATION ................................................................................................... 1-2
USING THE RELAY ............................................................................................................................ 1-3
MENU NAVIGATION ............................................................................................................. 1-3
PANEL KEYING EXAMPLE .................................................................................................... 1-7
CHANGING SETTINGS .................................................................................................................... 1-9
INTRODUCTION ..................................................................................................................... 1-9
THE HELP KEY .................................................................................................................... 1-10
NUMERICAL SETTINGS ........................................................................................................ 1-10
ENUMERATION SETTINGS ................................................................................................... 1-11
OUTPUT RELAY SETTINGS .................................................................................................. 1-15
TEXT SETTINGS ..................................................................................................................... 1-15
APPLICATION EXAMPLE ................................................................................................................. 1-17
DESCRIPTION ........................................................................................................................ 1-17
INSTRUMENT TRANSFORMER DATA ................................................................................... 1-25
MOTOR PROTECTION .......................................................................................................... 1-25
S2 SYSTEM SETTINGS ......................................................................................................... 1-30
S3 DIGITAL INPUTS SETTINGS ........................................................................................... 1-32
S5 THERMAL MODEL .......................................................................................................... 1-33
S6 CURRENT ELEMENTS ..................................................................................................... 1-33
S7 MOTOR STARTING ......................................................................................................... 1-35
S8 RTD TEMPERATURE ...................................................................................................... 1-35
OTHER SETTINGS ................................................................................................................. 1-36
INSTALLATION ................................................................................................................................... 1-38
TESTING ................................................................................................................................ 1-38
2: INTRODUCTION OVERVIEW ........................................................................................................................................... 2-1
DESCRIPTION ........................................................................................................................ 2-1
ORDERING INFORMATION ................................................................................................... 2-4
ORDER CODES ..................................................................................................................... 2-5
EXAMPLE ORDER CODES .................................................................................................... 2-5
ACCESSORIES ....................................................................................................................... 2-5
SPECIFICATIONS ............................................................................................................................... 2-6
INPUTS .................................................................................................................................. 2-6
OUTPUTS ...............................................................................................................................2-7
PROTECTION ......................................................................................................................... 2-8
DIGITAL INPUTS ................................................................................................................... 2-11
MONITORING ........................................................................................................................ 2-12
POWER SUPPLY ................................................................................................................... 2-13
CPU ...................................................................................................................................... 2-14
WAVEFORM CAPTURE (TRACE MEMORY) ......................................................................... 2-14
TESTING ................................................................................................................................ 2-14
CERTIFICATION ..................................................................................................................... 2-15
PHYSICAL .............................................................................................................................. 2-16
ENVIRONMENTAL ................................................................................................................. 2-16
LONG-TERM STORAGE ........................................................................................................ 2-16

TOC–II 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
TABLE OF CONTENTS
3: INSTALLATION MECHANICAL INSTALLATION ...................................................................................................... 3-1
DESCRIPTION ........................................................................................................................ 3-1
PRODUCT IDENTIFICATION .................................................................................................. 3-2
INSTALLATION ....................................................................................................................... 3-3
UNIT WITHDRAWAL AND INSERTION ................................................................................ 3-5
ETHERNET CONNECTION .................................................................................................... 3-7
DEVICENET CONNECTION .................................................................................................. 3-8
TERMINAL LOCATIONS ........................................................................................................ 3-9
TERMINAL LIST ..................................................................................................................... 3-9
ELECTRICAL INSTALLATION ......................................................................................................... 3-11
TYPICAL WIRING .................................................................................................................. 3-11
DESCRIPTION ........................................................................................................................ 3-12
CONTROL POWER ................................................................................................................ 3-12
CURRENT INPUTS ................................................................................................................. 3-13
VOLTAGE INPUTS ................................................................................................................. 3-17
DIGITAL INPUTS ................................................................................................................... 3-18
ANALOG INPUTS .................................................................................................................. 3-19
ANALOG OUTPUTS .............................................................................................................. 3-19
RTD SENSOR CONNECTIONS ............................................................................................ 3-20
OUTPUT RELAYS .................................................................................................................. 3-22
DRAWOUT INDICATOR ........................................................................................................ 3-24
RS485 COMMUNICATIONS PORTS ................................................................................... 3-24
DIELECTRIC STRENGTH ....................................................................................................... 3-25
2-SPEED MOTOR WIRING .................................................................................................. 3-27
4: INTERFACES FACEPLATE INTERFACE ................................................................................................................. 4-1
DESCRIPTION ........................................................................................................................ 4-1
DISPLAY ................................................................................................................................. 4-1
LED INDICATORS ................................................................................................................. 4-2
RS232 PORT ....................................................................................................................... 4-3
KEYPAD ................................................................................................................................. 4-4
SETTINGS ENTRY .................................................................................................................. 4-6
DIAGNOSTIC MESSAGES ..................................................................................................... 4-7
SELF-TEST WARNINGS ....................................................................................................... 4-8
FLASH MESSAGES ................................................................................................................ 4-9
ENERVISTA 469 SETUP SOFTWARE INTERFACE ................................................................. 4-10
OVERVIEW ............................................................................................................................ 4-10
HARDWARE ........................................................................................................................... 4-11
INSTALLING THE ENERVISTA 469 SETUP SOFTWARE .................................................... 4-13
CONNECTING ENERVISTA 469 SETUP TO THE RELAY ...................................................... 4-16
CONFIGURING SERIAL COMMUNICATIONS ....................................................................... 4-16
USING THE QUICK CONNECT FEATURE ............................................................................ 4-17
CONFIGURING ETHERNET COMMUNICATIONS ................................................................. 4-18
CONNECTING TO THE RELAY .............................................................................................. 4-19
WORKING WITH SETTINGS AND SETTINGS FILES ............................................................. 4-22
ENGAGING ADEVICE ........................................................................................................... 4-22
ENTERING SETTINGS ............................................................................................................ 4-22
FILE SUPPORT ...................................................................................................................... 4-23
USING SETTINGS FILES ....................................................................................................... 4-23
UPGRADING RELAY FIRMWARE ................................................................................................. 4-35
DESCRIPTION ........................................................................................................................ 4-35
SAVING SETTINGS TO AFILE .............................................................................................. 4-35

TOC TABLE OF CONTENTS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL TOC–III
LOADING NEW FIRMWARE ................................................................................................. 4-35
ADVANCED ENERVISTA 469 SETUP FEATURES ................................................................... 4-38
TRIGGERED EVENTS ............................................................................................................. 4-38
WAVEFORM CAPTURE (TRACE MEMORY) ......................................................................... 4-38
PHASORS .............................................................................................................................. 4-40
TRENDING (DATA LOGGER) ................................................................................................ 4-42
EVENT RECORDER ............................................................................................................... 4-44
MODBUS USER MAP ........................................................................................................... 4-46
VIEWING ACTUAL VALUES ................................................................................................. 4-46
USING ENERVISTA VIEWPOINT WITH THE 469 ................................................................... 4-49
PLUG AND PLAY EXAMPLE ................................................................................................. 4-49
5: SETTINGS OVERVIEW ........................................................................................................................................... 5-1
SETTINGS MESSAGE MAP ................................................................................................... 5-1
TRIPS, ALARMS, AND BLOCKS ............................................................................................ 5-6
RELAY ASSIGNMENT PRACTICES ........................................................................................ 5-7
S1 469 SETUP .................................................................................................................................... 5-8
PASSCODE ............................................................................................................................ 5-8
PREFERENCES ....................................................................................................................... 5-9
COMMUNICATIONS .............................................................................................................. 5-11
REAL TIME CLOCK ............................................................................................................... 5-13
DEFAULT MESSAGES ........................................................................................................... 5-14
MESSAGE SCRATCHPAD ...................................................................................................... 5-15
CLEAR DATA ......................................................................................................................... 5-16
INSTALLATION ....................................................................................................................... 5-16
S2 SYSTEM SETUP ............................................................................................................................ 5-18
CURRENT SENSING .............................................................................................................. 5-18
VOLTAGE SENSING .............................................................................................................. 5-20
POWER SYSTEM ................................................................................................................... 5-20
COMMUNICATIONS CONTROL ............................................................................................ 5-21
REDUCED VOLTAGE ............................................................................................................. 5-22
PRESET MOTOR VALUES ..................................................................................................... 5-24
S3 DIGITAL INPUTS .......................................................................................................................... 5-26
DESCRIPTION ........................................................................................................................ 5-26
STARTER STATUS ................................................................................................................. 5-27
ASSIGNABLE INPUTS 1(4) ................................................................................................... 5-27
S4 OUTPUT RELAYS ......................................................................................................................... 5-36
DESCRIPTION ........................................................................................................................ 5-36
RELAY RESET MODE ............................................................................................................ 5-36
FORCE OUTPUT RELAY ....................................................................................................... 5-37
S5 THERMAL MODEL ...................................................................................................................... 5-38
MOTOR THERMAL LIMITS ................................................................................................... 5-38
THERMAL MODEL ................................................................................................................ 5-40
OVERLOAD CURVE SETUP .................................................................................................. 5-41
S6 CURRENT ELEMENTS ............................................................................................................... 5-60
SHORT CIRCUIT TRIP ........................................................................................................... 5-60
OVERLOAD ALARM .............................................................................................................. 5-61
MECHANICAL JAM ............................................................................................................... 5-61
UNDERCURRENT .................................................................................................................. 5-62
CURRENT UNBALANCE ....................................................................................................... 5-63
GROUND FAULT ................................................................................................................... 5-65
PHASE DIFFERENTIAL .......................................................................................................... 5-66
S7 MOTOR STARTING ..................................................................................................................... 5-68

TOC–IV 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
TABLE OF CONTENTS
ACCELERATION TIMER ......................................................................................................... 5-68
START INHIBIT ...................................................................................................................... 5-68
JOGGING BLOCK .................................................................................................................. 5-69
RESTART BLOCK ................................................................................................................... 5-71
S8 RTD TEMPERATURE ................................................................................................................... 5-72
RTD TYPES ........................................................................................................................... 5-72
RTDS1 TO 6 ....................................................................................................................... 5-73
RTDS7 TO 10 ..................................................................................................................... 5-74
RTD 11 ................................................................................................................................ 5-75
RTD 12 ................................................................................................................................ 5-76
OPEN RTD SENSOR ............................................................................................................ 5-77
RTD SHORT/LOW TEMP .................................................................................................... 5-77
S9 VOLTAGE ELEMENTS ................................................................................................................ 5-78
UNDERVOLTAGE ................................................................................................................... 5-78
OVERVOLTAGE ...................................................................................................................... 5-80
PHASE REVERSAL ................................................................................................................. 5-80
FREQUENCY .......................................................................................................................... 5-81
S10 POWER ELEMENTS ................................................................................................................. 5-82
POWER MEASUREMENT CONVENTIONS ........................................................................... 5-82
POWER FACTOR ................................................................................................................... 5-83
REACTIVE POWER ................................................................................................................ 5-84
UNDERPOWER ...................................................................................................................... 5-85
REVERSE POWER ................................................................................................................. 5-86
TORQUE SETUP .................................................................................................................... 5-86
OVERTORQUE ....................................................................................................................... 5-87
S11 MONITORING ............................................................................................................................ 5-88
TRIP COUNTER ..................................................................................................................... 5-88
STARTER FAILURE ................................................................................................................ 5-88
DEMAND ...............................................................................................................................5-89
PULSE OUTPUT .................................................................................................................... 5-91
LOSS OF COMMUNICATIONS .............................................................................................. 5-92
S12 ANALOG INPUTS/OUTPUTS ................................................................................................ 5-94
ANALOG OUTPUTS 1 TO 4 ................................................................................................. 5-94
ANALOG INPUTS 1 TO 4 ..................................................................................................... 5-96
ANALOG INPUT DIFF 1-2 ................................................................................................... 5-98
ANALOG INPUT DIFF 3-4 ................................................................................................... 5-99
S13 469 TESTING ............................................................................................................................. 5-101
SIMULATION MODE ............................................................................................................. 5-101
PRE-FAULT SETUP ............................................................................................................... 5-102
FAULT SETUP ........................................................................................................................ 5-103
TEST OUTPUT RELAYS ......................................................................................................... 5-104
TEST ANALOG OUTPUTS ..................................................................................................... 5-104
COMM PORT MONITOR ....................................................................................................... 5-105
GR MULTILIN USE ONLY .................................................................................................... 5-105
S14 TWO-SPEED MOTOR .............................................................................................................. 5-106
DESCRIPTION ........................................................................................................................ 5-106
SPEED2 UNDERCURRENT ................................................................................................... 5-110
SPEED2 ACCELERATION ...................................................................................................... 5-110
6: ACTUAL VALUES OVERVIEW ........................................................................................................................................... 6-1
ACTUAL VALUES MAP ......................................................................................................... 6-1
DESCRIPTION ........................................................................................................................ 6-3
A1 STATUS ........................................................................................................................................... 6-4

TOC TABLE OF CONTENTS
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL TOC–V
MOTOR STATUS ................................................................................................................... 6-4
LAST TRIP DATA ................................................................................................................... 6-4
ALARM STATUS .................................................................................................................... 6-6
START BLOCKS ..................................................................................................................... 6-8
DIGITAL INPUTS ................................................................................................................... 6-8
REAL TIME CLOCK ............................................................................................................... 6-9
LOSS OF COMMUNICATIONS .............................................................................................. 6-9
NETWORK STATUS .............................................................................................................. 6-9
A2 METERING DATA ........................................................................................................................ 6-11
CURRENT METERING ........................................................................................................... 6-11
TEMPERATURE ...................................................................................................................... 6-12
VOLTAGE METERING ........................................................................................................... 6-13
SPEED .................................................................................................................................... 6-13
POWER METERING .............................................................................................................. 6-14
DEMAND METERING ............................................................................................................ 6-15
ANALOG INPUTS .................................................................................................................. 6-15
PHASORS .............................................................................................................................. 6-16
A3 LEARNED DATA .......................................................................................................................... 6-27
MOTOR STARTING ............................................................................................................... 6-27
AVERAGE MOTOR LOAD ..................................................................................................... 6-27
RTD MAXIMUMS ................................................................................................................. 6-28
ANALOG INPUT MIN/MAX ................................................................................................. 6-29
A4 MAINTENANCE ........................................................................................................................... 6-30
TRIP COUNTERS ................................................................................................................... 6-30
GENERAL COUNTERS .......................................................................................................... 6-31
TIMERS .................................................................................................................................. 6-32
A5 EVENT RECORDER ..................................................................................................................... 6-33
EVENT 01 TO EVENT 256 .................................................................................................. 6-33
A6 PRODUCT INFO .......................................................................................................................... 6-36
469 MODEL INFORMATION ............................................................................................... 6-36
CALIBRATION INFORMATION .............................................................................................. 6-36
DIAGNOSTICS .................................................................................................................................... 6-37
DIAGNOSTIC MESSAGES ..................................................................................................... 6-37
FLASH MESSAGES ................................................................................................................ 6-38
7: TESTING OVERVIEW ........................................................................................................................................... 7-1
TEST SETUP .......................................................................................................................... 7-1
HARDWARE FUNCTIONAL TESTING ......................................................................................... 7-3
PHASE CURRENT ACCURACY TEST .................................................................................... 7-3
VOLTAGE INPUT ACCURACY TEST ..................................................................................... 7-3
GROUND AND DIFFERENTIAL ACCURACY TEST ............................................................... 7-4
GE DIGITAL ENERGY 50:0.025 GROUND ACCURACY TEST ......................................... 7-5
RTD ACCURACY TEST ......................................................................................................... 7-5
DIGITAL INPUTS AND TRIP COIL SUPERVISION ................................................................ 7-7
ANALOG INPUTS AND OUTPUTS ........................................................................................ 7-8
OUTPUT RELAYS .................................................................................................................. 7-10
ADDITIONAL FUNCTIONAL TESTING ....................................................................................... 7-11
OVERLOAD CURVE TEST ..................................................................................................... 7-11
POWER MEASUREMENT TEST ............................................................................................ 7-11
UNBALANCE TEST ................................................................................................................ 7-12
VOLTAGE PHASE REVERSAL TEST ...................................................................................... 7-13
SHORT CIRCUIT TEST .......................................................................................................... 7-14

TOC–VI 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
TABLE OF CONTENTS
8: APPENDIX TWO-PHASE CT CONFIGURATION ............................................................................................ 8-1
DESCRIPTION ........................................................................................................................ 8-1
COOL TIME CONSTANTS ............................................................................................................... 8-4
SELECTION OF COOL TIME CONSTANTS ........................................................................... 8-4
CURRENT TRANSFORMERS .......................................................................................................... 8-6
GROUND FAULT CTSFOR 50:0.025 A CT .................................................................... 8-6
GROUND FAULT CTSFOR 5ASECONDARY CT ............................................................. 8-8
PHASE CTS........................................................................................................................... 8-8
EU DECLARATION OF CONFORMITY ........................................................................................ 8-10
EU DECLARATION OF CONFORMITY ................................................................................. 8-10
CHANGE NOTES ................................................................................................................................ 8-11
REVISION HISTORY .............................................................................................................. 8-11
CHANGES TO THE 469 MANUAL ...................................................................................... 8-11
GE WARRANTY .................................................................................................................................. 8-16
WARRANTY ........................................................................................................................... 8-16
I: INDEX

469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–1
469 Motor Management Relay
Chapter 1: Getting Started
GE
Grid Solutions
Getting Started
1.1 Important Procedures
1.1.1 Cautions and Warnings
Please read this chapter to guide you through the initial setup of your new relay.
Note Before attempting to install or use the relay, it is imperative that all WARNINGS and
CAUTIONS in this manual are reviewed to help prevent personal injury, equipment
damage, and/or downtime.
Note
1.1.2 Inspection Checklist
• Open the relay packaging and inspect the unit for physical damage.
• View the rear nameplate and verify that the correct model has been ordered.
• Ensure that the following items are included:
– Instruction Manual
– GE EnerVista CD (includes software and relay documentation)
– mounting screws
• For product information, instruction manual updates, and the latest software updates,
please visit the GE Grid Solutions website at http://www.gegridsolutions.com.
NOTE
Note If there is any noticeable physical damage, or any of the contents listed are missing, please
contact GE Grid Solutions immediately.

1–2 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
1.1.3 Manual Organization
Reading a lengthy instruction manual on a new product is not a task most people enjoy. To
speed things up, this introductory chapter provides a step-by-step tutorial for a simple
motor application. Important wiring considerations and precautions discussed in Electrical
Installation on page 3–11 should be observed for reliable operation. Detailed information
regarding accuracy, output relay contact ratings, and so forth are detailed in Specifications
on page 2–6. The remainder of this manual should be read and kept for reference to
ensure maximum benefit from the 469 Motor Management Relay. For further information,
please consult your local sales representative or the factory. Comments about new
features or modifications for your specific requirements are welcome and encouraged.
settings and actual values are indicated as follows in the manual:
A3 LEARNED DATA  AVERAGE MOTOR LOAD AVERAGE MOTOR LOAD LEARNED
This ‘path representation’ illustrates the location of an specific actual value or settings with
regards to its previous menus and sub-menus. In the example above, the AVERAGE MOTOR
LOAD LEARNED actual value is shown to be an item in the AVERAGE MOTOR LOAD sub-
menu, which itself is an item in the A3 LEARNED DATA menu, which is an item of ACTUAL
VALUES.
Sub-menu levels are entered by pressing the MESSAGE or ENTER key. When inside a
submenu, the MESSAGE or ESCAPE key returns to the previous sub-menu. The
MESSAGE and MESSAGE keys are used to scroll through the settings in a sub-menu.
The display indicates which keys can be used at any given point.

CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–3
1.2 Using the Relay
1.2.1 Menu Navigation
The relay has three types of display messages: actual value, settings, and target messages.
A summary of the menu structure for settings and actual values can be found at the
beginning of chapters 5 and 6, respectively.
Settings are programmable settings entered by the user. These types of messages are
located within a menu structure that groups the information into categories. Navigating
the menu structure is described below.
Actual values include the following information:
1. Motor and System Status:
a. Motor status either stopped, starting, or running. It includes values such as motor
load, thermal capacity used, motor speed, and instantaneous values of power
system quantities.
b. The status of digital inputs.
c. Last trip information, including values such as cause of last trip, time and date of
trip, motor speed and load at the time of trip, pre-trip temperature measure-
ments, pre-trip analog inputs values, and pre-trip instantaneous values of power
system quantities.
d. Active alarms.
e. Relay date and time.
f. Present blocking conditions.
g. General system status indication including the status of output relays, active
pickup, alarm and trip conditions.
2. Metering Data:
a. Instantaneous current measurements including phase, differential, unbalance,
ground, average, and motor load.
b. RTD Temperatures including hottest RTDs.
c. Instantaneous phase to phase and phase to ground voltages (depending on the
VT connections), average voltage, and system frequency.
d. Motor Speed
e. Power Quantities including apparent, real and reactive power.
f. Current and power demand including peak values.
g. Analog inputs
h. Vector information.
3. Motor Learned Data:
a. Learned and last acceleration time.
b. Learned and last starting current.

1–4 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
c. Learned and last starting capacity.
d. Average motor load.
4. Maintenance data. This is useful statistical information that may be used for
preventive maintenance. It includes:
a. Trip counters
b. General counter such as number of motor starts, number of emergency restarts,
number of starter operations, digital counter for other purposes not listed above.
c. Timers such as motor running hours, time between starts timer, and five start
timers used to calculate the average start time of the motor.
5. RTD Learned Data, which includes the maximum temperature measured by each of
the 12 RTDs.
6. Event recorder downloading tool.
7. Product information including model number, firmware version, additional product
information, and calibration dates.
8. Oscillography downloading tool.
Alarm, trip conditions, diagnostics, and system flash messages are grouped under Target
Messages.
Press the MENU key to access the header of each menu, which will
be displayed in the following sequence:
To access settings,
Press the MENU key until the display shows the header of the
Settings menu.
Press the MESSAGE or ENTER key to display the header for the
first Settings page.
The Settings pages are numbered, have an ‘S’ prefix for easy
identification and have a name which provides a general idea of the
settings available in that page.
Pressing the MESSAGE and MESSAGE keys will scroll through
all the available Settings page headers. Settings page headers look
as follows:
1. SETPOINTS
Press [] for more
2. ACTUAL VALUES
Press [] for more
3. TARGET MESSAGES
Press [] for more
SETPOINTS []
S1 469 SETUP

CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–5
To enter a given Settings page,
Press the MESSAGE or ENTER key.
Press the MESSAGE or MESSAGE keys to scroll through sub-
page headers until the required message is reached.
The end of a page is indicated by the message END OF PAGE. The
beginning of a page is indicated by the message TOP OF PAGE.
To access actual values,
Press the MENU key until the display shows the header of the actual
values menu.
Press the MESSAGE or ENTER key to display the header for the
first actual values page.
The actual values pages are numbered, have an ‘A’ prefix for easy
identification and have a name, which gives a general idea of the
information available in that page.
Pressing the MESSAGE or MESSAGE keys will scroll through all
the available actual values page headers. Actual values page
headers look as follows:
To enter a given actual values page,
Press the MESSAGE or ENTER key.
Press the MESSAGE or MESSAGE keys to scroll through sub-
page headers until the required message is reached.
The end of a page is indicated by the message END OF PAGE. The
beginning of a page is indicated by the message TOP OF PAGE.
Similarly, to access additional sub-pages,
Press the MESSAGE or ENTER key to enter the first sub-page,
Press the MESSAGE or MESSAGE keys to scroll through the
available sub-pages, until the desired message is reached.
The process is identical for both settings and actual values.
The following procedure illustrates the key sequence to access the Current Demand actual
values.
Press the MENU key until you reach the actual values main menu.
Press MESSAGE or ENTER key to enter the first actual values
page.
Press the MESSAGE or MESSAGE key to scroll through pages,
until the A2 METERING DATA page appears.
ACTUAL VALUES []
A1 STATUS
ACTUAL VALUES []
A2 METERING DATA

1–6 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
Press the MESSAGE or ENTER key to display the first sub-page
heading for the Metering Data actual values page:
Pressing the MESSAGE or MESSAGE keys will scroll the display up and down
through the sub-page headers.
Pressing the MESSAGE or ESCAPE key at any sub-page heading will return the
display to the heading of the corresponding settings or actual value page.
Pressing it again, will return the display to the main menu header.
Press the MESSAGE key until the DEMAND METERING sub-page
heading appears.
At this point, pressing MESSAGE or ENTER key will display the messages under this
sub-page. If instead you press the MESSAGE key, it will return to the previous sub-
page heading. In this case,
When the symbols and []appear on the top line, it indicates that additional sub-
pages are available and can be accessed by pressing the MESSAGE or ENTER key.
Press MESSAGE or ENTER while at the Demand Metering sub-
page heading to display the following:
Press MESSAGE key to return to the Demand Metering sub-page
heading.
Press the MESSAGE key to display the next actual value of this
sub-page.
Actual values and settings messages always have a colon
separating the name of the value and the actual value or settings.
This particular message displays the current demand as measured
by the relay.
The menu path to this value is shown as A2 METERING DATA  DEMAND METERING
CURRENT DEMAND. Settings and actual values messages are referred to in this
manner throughout the manual.
For example, the A3 LEARNED DATA MOTOR STARTING LEARNED ACCELERATION
TIME path representation describes the following key-press sequence:
Press the MENU key until the actual value header appears on the
display, MESSAGE or ENTER key,
CURRENT []
METERING
DEMAND []
METERING
POWER []
METERING
CURRENT
DEMAND: 0 Amps

CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–7
Press the MESSAGE key until the A3 LEARNED DATA message is
displayed.
Press the MESSAGE or ENTER key to display MOTOR STARTING
message.
Press the MESSAGE or ENTER key to reach the LEARNED
ACCELERATION TIME message and the corresponding actual value.
Press the MESSAGE key to display the next actual value message
as shown below:
Press the MESSAGE or MESSAGE keys to scroll the display up
and down through all the actual value displays in this corresponding
sub-page.
Press the MESSAGE key to reverse the process described above
and return the display to the previous level.
Press the MESSAGE key twice to return to the A3 LEARNED DATA
page header.
1.2.2 Panel Keying Example
The following figure gives a specific example of how the keypad is used to navigate
through the menu structure. Specific locations are referred to throughout this manual by
using a ‘path representation’. The example shown in the figure gives the key presses
required to read the learned starting current denoted by the path A3 LEARNED DATA 
MOTOR STARTING  LEARNED STARTING CURRENT.
Press the menu key until the relay displays the actual values page.
LEARNED STARTING
CURRENT: 0 A
MOTOR []
STARTING
ACTUAL VALUES []
A3 LEARNED DATA

1–8 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
ACTUAL VALUES []
Press the MESSAGE or ENTER key
ACTUAL VALUES []
A1 STATUS
Press the MESSAGE key
ACTUAL VALUES []
A2 METERING DATA
Press the MESSAGE key
ACTUAL VALUES []
A3 LEARNED DATA MESSAGE MOTOR STARTING []MESSAGE LEARNED ACCELERATION TIME: 0.0 s
MESSAGE LEARNED STARTING
CURRENT: 0 A

CHAPTER 1: GETTING STARTED
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 1–9
1.3 Changing Settings
1.3.1 Introduction
There are several classes of settings, each distinguished by the way their values are
displayed and edited.
The relay's menu is arranged in a tree structure. Each setting in the menu is referred to as a
settings, and each settings in the menu may be accessed as described in the previous
section.
The settings are arranged in pages with each page containing related settings; for
example, all the Short Circuit Trip settings are contained within the same page. As
previously explained, the top menu page of each setting group describes the settings
contained within that page. Pressing the MESSAGE keys allows the user to move between
these top menus.
All of the 469 settings fall into one of following categories: device settings, system settings,
digital input settings, output relay settings, thermal model settings, current element
settings, motor starting settings, RTD temperatures settings, voltage element settings,
power element settings, monitoring settings, analog input/output settings, two speed
motor settings, and testing settings.
NOTE
Note IMPORTANT: Settings are stored and used by the relay immediately after they are
entered. As such, caution must be exercised when entering settings while the relay is in
service. Modifying or storing protection settings is not recommended when the relay is
in service since any incompatibility or lack of coordination with other previously saved
settings may cause unwanted operations.
Now that we have become more familiar with maneuvering through messages, we can
learn how to edit the values used by all settings classes.
Hardware and passcode security features are designed to provide protection against
unauthorized settings changes. Since we will be programming new settings using the front
panel keys, a hardware jumper must be installed across the settings access terminals (C1
and C2) on the back of the relay case. Attempts to enter a new settings without this
electrical connection will result in an error message.
The jumper does not restrict settings access via serial communications. The relay has a
programmable passcode settings, which may be used to disallow settings changes from
both the front panel and the serial communications ports. This passcode consists of up to
eight (8) numeric characters.
The factory default passcode is “0”. When this specific value is programmed into the relay it
has the effect of removing all settings modification restrictions. Therefore, only the settings
access jumper can be used to restrict settings access via the front panel and there are no
restrictions via the communications ports.
When the passcode is programmed to any other value, settings access is restricted for the
front panel and all communications ports. Write Access via keypad is not permitted until
the passcode is entered via the keypad. Write access via communication port is not
permitted until the passcode is entered via that port. That is, the passcode must be
entered via the port from which access is desired.

1–10 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 1: GETTING STARTED
Entering the passcode on any communication port automatically restricts the other ports,
