GE Profile PV976 Operating instructions

ge.com
Safety Instructions ........ 2,3
Operating Instructions
Light Controls .................... 4
Vent Controls ..................... 4
Care and Cleaning
Grease Filters .................... 5
Hood Lights ...................... 6
Stainless Steel Surfaces ........... 6
Installation Instructions
Installation Preparation ........ 7-13
Vented to the Outside ........ 14-17
Recirculating ................. 18-22
Troubleshooting Tips .... 23,24
Consumer Support
Consumer Support ............. 26
Warrantg ....................... 25
0_
_C
U
Write the model and serial
numbers here:
Model #
Serial #
You can find them on a label
on the inside of the hood.
PV970
PV976
49-80549 12-08JR

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
SAFETYPRECAUTIONS
_tLWARNING- ToREOUCETHERISK
OFFIRE,ELECTRICSHOCKORINJURYTOPERSONS,
OBSERVETHEFOLLOWING:
A. Usethis unit onlg in the manner intended
bg the manufacturer. If you have questions,
contact the manufacturer.
B. Beforeservicing or cleaning unit, switch
power off at service panel and lock the service
disconnecting means to prevent power from
being switched on accidentallg. When the
service disconnecting means cannot be locked,
securely fasten a prominent warning device,
such as a tag, to the service panel.
C. Donot usethis unit with any solid-state speed
control device.
D. This unit must be grounded.
,A CAUTION- Forgeneralventilatinguse
onlg. Donot useto exhaust hazardous or explosive
materials and vapors.
_ZkCAUTION- roreduceriskoffim
and to properly exhaust air,besure to duct air
outside.Do not vent exhaust air into spaces
within walls or ceilingsor into attics, crawl
spacesor garages.
,,&WARNING- TORE_UCE
THERISKOFINJURYTOPERSONSIN THEEVENT
OFA RANGETOPGREASEFIRE,OBSERVE
THEFOLLOWING*:
A. SMOTHERFLAMESwith o close-fitting lid,cookie
sheet or metal trag, then turn off the burner.
BECAREFULTOPREVENTBURNS.Ifthe flames
do not go out immediatelg, EVACUATEANDCALL
THEFIREDEPARTMENT.
B. NEVERPICKUPA FLAMINGPAN-You may
be burned.
C. DONOTUSEWATER,including wet dishcloths
or towels-a violent steam explosion will result.
D. Usean extinguisher ONLYif:
1. You know you have a ClassABCextinguisher,
and you already know how to operate it.
2. Thefire issmall and contained in the area
where it started.
3. Thefire department isbeing called.
4. You can fight the fire with your back
to an exit.
* Based on "Kitchen FireSafety" published
by NFPA.

ge.com
SAFETYPRECAUTIONS
,& WARNING- TORE_UCEThERISK
OFA RANGETOPGREASEFIRE:
A. Never leavesurface units unattended at high
settings. Boil overs cause smoking and greasy
spilloversthat may ignite. Heat oilsslowlg on low
or medium settings.
B. Alwagsturn hood ONwhen cooking on high
heat or when flamb6ing food (i.e.CrepesSuzette,
CherriesJubilee,PeppercornBeefFlamb6).
C Cleanventilating fans frequentlU.Greaseshould
not be allowed to accumulate on fan or filter.
D. Use proper pan size.Always usecookware
appropriate for the size of the surface element.
WARNING- TOREDUCE
THERISKOFFIRE,ELECTRICSHOCKORINJURY
TOPERSONS,OBSERVETHEFOLLOWING:
A. Installation work and electrical wiring must
be done bg qualified person(s)in accordance
with all applicable codes and standards,
including fire-rated construction.
B. Sufficient air is needed for proper
combustion and exhausting of gases through
the flue (chimneg) of fuel burning equipment
to prevent back drafting. Follow the heating
equipment manufacturer's guidelines and
safetg standards such as those published bg
the National FireProtection Association (NFPA),
the American Societg for Heating, Refrigeration
and Air Conditioning Engineers(ASHRAE)
and the localcode authorities.
C. When cutting or drilling into wall or ceiling,
do not damage electrical wiring and other
hidden utilities.
D. Ducted fans must alwags be vented
to the outdoors.
-& WARNING - TOREDUCEThERISK
OFFIRE,USEONLYMETALDUCTWORK.
Do not attempt to repair or replace ang
part of gour hood unless it is specificallg
recommended in this manual. All other servicing
should be referred to a qualified technician.
READAND FOLLOWTHISSAFETYINFORMATIONCAREFULLY.
READ AND SAVE THESE INSTRUCTIONS

Using the hood controls.
0
@
@
Profile O0 O0 0
-- FAN + - LIGHT + MEMORY/
OFF
@ @ 0
MEMORY/OFF.To set the memorg:
A. Pressthe MEMORY/OFFbutton.
B. Set gour desired fan and light settings.
C. Press the MEMORY/OFFbutton again to save
these settings.
With gour desired settings in memorg, press the
MEMORY/OFFbutton to restore the fan and light
levels to their saved settings. These settings will
remain in memory until they are changed or loss
of power occurs.
To turn off the hood, press the MEMORY/OFF
button.
LIGHT. Press + or - to increase or decrease light
level to desired setting. There are 2 light levels
(LOW,HIGH) and OFF.If gou continue to press
the + or - buttons, the light will cgcle back through
the settings.
NOTE:Please check the lamps to ensure onlg 20W
lamps (maximum) are installed.
FAN. Press+ or - to increase or decrease fan
level to gour desired setting. There are 4 fan levels
(LOW,NED, HIGH, BOOST)and OFF.If gou continue
to press the + or - buttons, the fan will cgcle back
through the settings.
NOTE:There is an audible "beep" each time
a button is pressed. This is normal.
NOTE:The collars around the buttons will illuminate
when pressed. This is normal. The collars will
automaticallg turn off if the hood is turned off.
HEATSENSOR:
This hood isequipped with a heat sensor that will turn
on the fan if excessive temperatures are detected
(over 70 °C/158 °F)above the cooking surface. The hood
will return to its normal operation once the heat sensor
detects temperatures below 60 °C/140 °F.
NOTE:If the hood is OFFor on LOW fan speed,
the temperatures above 70 °C/158 °Fare detected;
then the fan will automaticallg adjust to MED speed.
You mag adjust the fan speed to HIGH or BOOST,
but gou will not be able to adjust the fan speed to LOW
or OFFuntil temperatures below 60 °C/140 °Fare detected.
NOTE:The collars around the buttons mag not illuminate
if the heat sensor is activated. This is normal.
4

Care and cleaning of the vent hood.
Be sure electrical power is off and all surfaces are cool before cleaning or servicing ang part
of the vent hood.
ge.com
!
Metal Grease Filter
The metal filter traps grease
released bg foods from the
cooktop. The filter also helps
prevent flames (from food, grease)
from damaging the inside
of the hood.
For this reason, the filter
must ALWAYSbe in place when
the hood is in use.The grease filter
is dishwasher-safe and should be
cleaned every 6 months, or as
needed.
Toremove:
Pull downward on the filter lock
to release the filter.
Toreplace:
Fit the tabs at the end of the filter
into the slots in the left side of the
filter opening. Lift up the right side
of the filter and push gently until
the filter locks into place. Hake
sure the filter lock is in the closed
position to secure the filter.
Toclean, swish the filter in hot
soapy water and rinse in clean
water or wash it in the dishwasher.
Do not use abrasive cleansers.
NOTE:Some discoloration will occur
in the dishwasher.
Lockingtab handle
Lockingtab handle
Charcoal Filter (forrecirculating installation onlg)
If the model is not vented to the
outside, the air will be recirculated
through a disposable charcoal filter
that helps remove smoke and odors.
The charcoal filter should be
replaced when it is noticeablg dirtg
or discolored (usuallgafter 6 to 12
months, depending on hood usage).
NOTE:DONOTrinse, or put charcoal
filter in an automatic dishwasher.
Thecharcoal filter cannot be
cleaned. It must be replaced.
Order Charcoal Filter WBO2N11348.
To inquire about purchasing
replacement charcoa! filters or to find
the location of a dealer nearest you,
pleaseca!!our to!!-free number:
National Parts Center
800.626.2002
To remove:
2. Removethe metal filter-see Metal
grease filter section.
2. Removethe charcoal filter by
pushing in on both locking tab
handles to release.
To replace:
1. Insertthe charcoal filter into the
opening. Pushthe locking tab
handles toward the center and
release to engage the locking tabs.
2. Replacethe metal filter-see Metal
grease filter section.

Care and cleaning of the vent hood.
Be sure electrical power is off and all surfaces are cool before cleaning or servicing ang part
of the vent hood.
Stainless Steel Surfaces
Do not use a steel wool pad;
it will scratch the surface.
To clean the stainless steel
surface, use warm sudsy water
or a stainless steel cleaner or polish.
Always wipe the surface in the
direction of the grain. Follow the
cleaner instructions for cleaning
the stainless steel surface.
To inquire about purchasing
stainless steel appliance cleaner
or polish, or to find the location
of a dealer nearest gou, please call
our toll-free number:
National Parts Center
800.626.2002
ge.com
Light Bulbs
.4,CAUTION:
Allow bulbs to coo!beforetouching.
Tochange the light bulbs:
.Removethe lamp lens cover by
inserting a small flat blade screwdriver
into each of the three slots and gently
prying it free.
NOTE:Do not remove the outer trim ring
(lamp assembly).
2. Wear gloves. Do not touch the bulb
with gour bare fingers. Skin oils can
cause earlg lamp failure.
3. Grasp the bulb and pull it straight out.
4. Replace with the same wattage. Earlg
bulb failure and damage to or failure of
the transformer mag occur if wattage
istoo high.
These 12-volt, 20-watt halogen bulbs
with a G4 base are available at
specialtg lighting stores and home
building centers.
To order replacement bulb no.
WB01×10239, contact the GENational
Parts Center at 1.800.626.2002 or
purchase from gour local retailer.
5. Replace lamp lens cover bg inserting
the three retaining tabs into the three
slots and pressing firmlg in place.
to remove the lamp lens cover.
Bulb
Outer trim ring
(lamp assembly)
Do not remove
Removableinner
lamplenscover
NOTE: Make sure the tabs are inserted into the slots.
6

Istollotio
Istructio Chimneg Vent Hoods
i r_Questions? Coil 800.GE.CARES (800.432.2737) or Visit our Website at: ge.com }
BEFORE YOU BEGIN
Reed these instructions completelg end carefullg.
•IMPORTANT -Soretheseinstructions
for local inspector's use.
•IMPORTANT - Observeollgoverning
codes and ordinances.
• Note to Installer- Be sure to leave these
instructions with the Consumer.
Note to Consumer - Keep these instructions
for future reference.
Skill level - Installation of this vent hood requires
basic mechanical and electrical skills.
Completion time - Approximatelg 1 to 3 hours
Proper installation is the responsibilitg
of the installer.
Product failure due to improper installation
is not covered under the Wurruntg.
*_CAUTION -Duetotheweight
and sizeofthesevent hoods and to reduce
the riskofpersonalinjuryor domoge
tothe product,TWO PEOPLE ARE REQUIRED
FOR PROPER INSTALLATION.
FOR YOUR SAFETY:
WARNING - Beforebeginningthe
instollotion,switchpower offatservicepaneland
lockthe servicedisconnectingmeans toprevent
power from being switchedon occidentally.When
the servicedisconnectingmeans cannot be locked,
securelyfosteno prominent warning device,such
as o tog,tothe servicepanel.
PRODUCT DIMENSIONS
10-7/8"
....
/
*Height
to ,13-1/8"o
Ceiling
_ -Ix ........_:_:___.._........i_i-i_IL_-__ _ 2-I/2"
19-_/4''"_ _ L .......................29-7/8' ....................."
30" Models Requirea 30" Wide Opening
10-7/8"
*Height
to 13-1/8",
Ceiling
2-3/8"
19-3/4" ....................... 35-7/8 ....................
36" Models Requirea 36" Wide Opening
* Forsuppliedduct coverceiling heights for vented installation
and recirculatinginstallation, referto the table on page 13.
Allow 1"overlap
of duct.
17-1/2"

PREPARE TO INSTALL THE HOOD
INSTALLATION CLEARANCES
These vent hoods are designed to be installed
onto a wall. Theg mag be installed beneath a soffit
or cabinet.
• Install these hoods 24" Min. to 30" Max. above
the cooking surface.
24" Min.
30" Max.
----t
The vent hood must be installed 24" min.
and 30" max. above the cooking surface.
The hood installation height above the cooking
surface depends upon ceiling height and duct
cover limitations. The telescopic duct cover
conceals the ductwork running from the top
of the hood to the ceiling. For supplied duct cover
ceiling heights, see table on page 13.
Recirculation Kit:
Kit includes 1 air deflector and 1 charcoal filter
and is included with the hood.
NOTE: Installation height should be measured
from the cooking surface to the lowest part
of the hood. This hood mag be installed onto a wall
and vented to the outdoors, or it can be installed
for recirculating operation. For recirculation
operation, a Recirculating Kit (included)is required.
ADVANCE PLANNING
Ductwork Planning
• This hood is designed to be vented verticallg
through the ceiling. A duct transition piece is
supplied for vertical exhaust. Use Iocallg supplied
elbows to vent horizontallg through the rear wall.
See page 10.
Determine the exact location of the vent hood.o
o
o
Plan the route for venting exhaust to the outdoors.
Use the shortest and straightest duct route
possible. For satisfactorg performance, duct run
should not exceed 100' equivalent length for ang
duct configurations.
Refer to "Duct Fittings" chart to compute
the maximum permissible length for duct runs
to the outdoors.
• Use metal ductwork onlg.
• A transition piece for 8" round duct is supplied.
Use 8" round duct.
Install a wall cap or roof cap with damper
at the exterior opening. Order the wall or roof cap
and ang transition and length of duct needed
in advance.
Wall Framing for Adequate Support
This vent hood is heavg. Adequate structural
support must be provided. The hood must be
secured to vertical studs in the wall. See page 14.
We stronglg recommend that the vent hood with
duct cover be on site before final framing and
wall finishing. This will also help to accuratelg
locate the ductwork and electrical service.

POWER SUPPLY
IMPORTANT -(Please read carefullg)
&WARNING:
FOR PERSONAL SAFETY,THIS APPLIANCE MUST
BE PROPERLYGROUNDED.
Remove house fuse or open circuit breaker before
beginning installation.
Do not use an extension cord or adapter plug
with this appliance. Follow National Electrical Codes
or prevailing local codes and ordinances.
Electrical supplg
These vent hoods must be supplied with 120V,
60Hz, and connected to an individual, properlg
grounded branch circuit, and protected bg a 15
or 20 amp circuit breaker or time delag fuse.
• Wiring must be 2 wire with ground.
• If the electrical supplg does not meet the above
requirements, call a licensed electrician before
proceeding.
• Route house wiring as close to the installation
location as possible in the ceiling or wall.
See page 14 for details.
• Connect the wiring to the house wiring
in accordance with local codes.
Grounding instructions
The grounding conductor must be connected
to a ground metal, permanent wiring sgstem, or an
equipment-grounding terminal or lead on the hood.
-4,WARNING: The improper connection
of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified
electrician or service representative if gou are in
doubt whether the appliance is properlg grounded.
9

Installation Preparation
DUCT FITTINGS
Use this chart to compute
maximum permissible lengths
for duct runs to outdoors.
NOTE: Do not exceed maximum
permissible equivalent lengths!
Maximum duct length:
i00 feet.
Flexibleducting:
If flexible metal ducting is used,
all the equivalent feet values in
the table should be doubled.
The flexible metal duct should
be straight and smooth and
extended as much as possible.
DO NOT use flexible plastic
ducting.
NOTE: Ang home ventilation
sgstem, such as a ventilation hood,
mag interrupt the proper flow
of combustion air and exhaust
required bg fireplaces, gas
furnaces, gas water heaters and
other naturallg vented sgstems.
To minimize the chance of
interruption of such naturallg
vented sgstems, follow the
heating equipment manufacturer's
guidelines and safetg standards
such as those published bg NFPA
and ASHRAE.
Equivalent
Duct Piece Dimensions Length*
8" Round, 1 ft.
straight (per foot
length)
3-1/4" x 12" i ft.
straight (per foot
length)
8" 90° elbow 17 ft.
8" 45° elbow 10 ft.
3-1/4" x 12"90° elbow 43 ft.
3-!/4" x 12"
45° elbow 26 ft.
Total
Quantitg Equivalent
Used Length
3-!/4" x 12"
90 ° flat elbow 102 ft.
__ 8" round to
3-1/4" x 12" transition 2 ft.
3-1/4" x 12"to 7"
round transition 5 ft.
8" round
to 3-1/4" x 12"
transition 90° elbow 6 ft.
3-1/4" x 12"to 8" round
round transition 90° elbow 13 ft.
8" Round
wall cap
with damper
3-!/4" x 12"wall cap
with damper
52 ft.
75 ft.
(:_ 8" Roundroof cap 44 ft.
Round
roof vent 24 ft.
*Actual length of straight duct plus duct fitting
equivalent. Equivalent length of duct pieces are
based on actual tests conducted bg GE Evaluation
Engineering and reflect requirements for good
venting performance with ang ventilation hood.
Total Duct Run
10

Installation Preparation
TOOLS AND MATERIALS REQUIRED
(NOT SUPPLIED)
Penciland tape measure
Spirit level
Safety glasses
Phillips screwdriver
LI _{C]D
Flashlight
Metal snips
Electric drill with 3/16" bits,
#2 Phillips and flat head
Ste ladder
Pliers
Wire cutter/stripper
UL listed wire nuts©
Aluminized Strain relief for
Duct tape junction box
Sabersaw or KeyHolesaw
8" round metal
duct, length to
suit installation
120V60Hz.15 or 20 Amp,
2-wire with ground, properly
grounded branchcircuit
REMOVE THE PACKAGING
CAUTION: Wearg,ovestoprotect
against sharp edges.
• Remove the duct covers.
• Remove the hardware bag, literature package
and other boxed parts.
• Remove and properlg discard the protective
plastic wrapping and other packaging materials.
• Remove packing foam from behind the blower.
11

Installation Preparation
CHECK INSTALLATION HARDWARE
Locate the hardware package packed with the hood and check contents.
/
L/'Z
d3
6 wood screws
(#10 13/4' long)
HARDWAREPACKAGE
Locate and count
screws
f
4 wall fasteners
(5/16")
(screw with
wall anchor)
8 duct cover
and air deflector
screws
(#8 thread forming
screw 3/8" long)
_AtLVEmlS27_/4""IN
ABOVET"EI"S_TIO_
"EIO"T
_+ IIo I/_,, 'l
I
F REAR WALL
MOUNTING TEMPLATE
i1 _
t
Tf ..............H i
I _+ .................
12_Z" 'I OFTHE_OOD
JHor_onlolLine " .... _i . J "Lla_onH _ [ ..... _J J
Wall mount template
Stainless steel filter
Duct cover bracket
2-piece decorative
duct cover
RECIRCULATING KIT (Included)
Air deflector Charcoalfilter
12

Installation Preparation
DETERMINE INSTALLATION HEIGHT
• Telescopic duct covers are provided to conceal
the ductwork running to the ceiling.
• This hood can be installed for recirculating
operation. Recirculating Kit included with hood.
NOTE: Installation height should be measured from
the cooking surface to the straight portion of the
hood.
The vent hood must be installed 24" min. and
30" max. above the cooking surface. The hood
installation height, from the cooking surface to the
bottom of the hood, depends upon ceiling height
and duct cover limitations.
PV970, PV976
Upper Duct Cover | 25.81
Lower Duct Cover [ 27.56
Counter to Hood Heiqbt
Actual
Ceiling *Possible VENTED
Height Installetion Hei ht
7' 11"
8' 0"
8' 1"
8' 2"
8' 3"
8'4"
8' 5"
8'6"
8' 7"
8' 8"
8' 9"
8' 10"
8' 11"
9' 0"
9' 1"
9' 2" 25" to 30"
9' 3" 26" to 30"
9' 4" 27" to 30"
9' 5" 28" to 30"
9' 6" 29" to 30"
9'7" 30"
9'8"
9'9"
9' i0"
9'11"
i0' 0"
i0' i"
i0' 2"
10' 3"
*Possible
RECIRCULATING
Installation Height
24"
24" to 25"
24" to 26"
24" to 27"
24" to 28"
24" to 29"
25" to 30"
26" to 30"
27" to 30"
28" to 30"
29" to 30"
30"
*Based on 36" countertop height
13

Installation Instructions
INSTALLATION--VENTED TO THE OUTSIDE
DUCTWORK, WIRING LOCATIONS
Determine the exact location of the vent hood.
• Locate the template packed with the literature.
- Measure :36"from the floor to the top of the cooking
surface. Add hood installation height determined on
pages 8 and 13. Mark that location.
- Use a level to draw a straight pencil line on the wall.
- Tape the template in position along the penciled
line. CHECKTO BESURETHE TEMPLATEISLEVEL.
5" centerline to wall---. ,z Ceiling
I
Wallvent
HouseWiring 27-3/4"min.
Location ._._ CL ....above
........................................installation
t>'_ ........ height
I
18"
Min.
Ceiling ducting:
If ductwork will vent straight up to the ceiling:
• Use a level to draw a line straight up, from
the centerline on the template to the ceiling.
• Measure 5" from the back wall to the centerline
of an 8-1/2" hole on the ceiling.
NOTE:If drgwall is not present, add drgwall thickness
to the 5" dimension.
Wall Ducting:
If ductwork will vent to the rear:
• Use a level to draw a line straight up from
the centerline on the template.
• Measure at least 27-3/4" above the pencil line
that indicates the bottom installation height,
to the centerline of an 8-1/2" dia. duct hole.
(Hole mag be elongated for duct elbow.)
HOUSEWIRING LOCATION:
• Thejunction box is located on the top left side
of the hood.
• Wiring should enter the back wall at least 18" above
the bottom of the hood and within 5" of the left side
of the centerline.
INSTALL FRAMING
FOR HOOD SUPPORT
IMPORTANT- F omingmustbecapable
of supporting i00 Ibs.
8-1/2" min. opening for ductwork
I_ Centerline of
installation
I space
View from
rear cleats
l"x 12"min.
mounting
support
h--A:] :L
:r
If drgwall is present, mark the screw hole locations
for the top mounting brackets. Remove the template.
• Cut awag enough drywall to expose 2 vertical studs
at the bracket location indicated on the template.
• Install a horizontal support at least l"x 12"
between two wall studs at the mounting screw
location. The horizontal support must be flush with
the room side of the studs. Use cleats behind both
sides of the support to secure to wall studs.
NOTE: 2 horizontal supports will be needed ifthere
is a stud located between the horizontal screw
locations (seefigure).
IMPORTANT: Reinstall drgwall for an even mounting
surface.
14

Installation Instructions
[-_ INSTALL HOOD MOUNTING SCREWS
Thetwo upper mounting screws must enter the horizontal
support or wall studs.
• With the template taped in place, usea punch to mark
mounting bracket screw locations.
• Drill1/8" pilot holesin 4 of the punched locations
in the lower bracket. Ifthe bottom 2 pilot holesdo not enter
wood, enlarge the holesto S/8"and install metal wall
fastener anchors (provided).
• Removethe template.
• Installthe 2 top mounting screws,leave 1/4"gap between
the screw head and the wall.Thiswill allow the keghole
slot on the hood frame to engage the screw head.
...... _2 9
---+ i +
I i I
,}
I' REAR WALL
MOUNTING TEMPLATE
I
i
o_ILL2_ol _/t_ PILo_HOL_STH,OUGH_uosO__A,_ALLS_O_
.__..........'-_ .................... ".tr._t']_.1'.L.nt................................ . ........................................................ _';'t2t;';=:rt;='...:: t f... i.
u
IMPORTANT:Usethe mounting screws provided.
DONOTUSEDRYWALLSCREWS.
• Checkto be surethe mounting screws are horizontallg level.
INSTALL DUCT BRACKET
Theduct bracket shouldbe installed against the back wall
and flush with the ceiling;the point where the ceiling meets
the wall should be levelfor the bracket and duct cover to fit
flush.Thisbracketwill holdthe duct cover in placeat thetop.
Securethe bracket to the wall:
• Align the diamond centerline cutout on the bracket
with the penciledcenterline on the wall.
• Hark 2 screwhole locationsin the wall.
• Drill1/8" pilot holesinthe marked locations.
• If pilot holesdo not enter wood studs, enlargethe holes
to 3/8" and install metal wall fastener anchors (provided).
• If mounting directlg to amasonrg wall, obtain appropriate
#10 masonrg screw anchors.Drilland install per the
fastener supplier's instructions.
• Drivescrews bg hand,into the fasteners to allow anchors
to expand. Removethe screws.
• Securethe bracketto thewall with wood screws and/or
fasteners.
Centerline cutout
e'
F4-] MOUNT THE HOOD
_4,WARNING:2peopleare requiredto lift
and position the hood ontothe mounting screws.
• Liftthe hood onto the mounting screws.
• If usinga wall fastener,make surethe washer isinfront
of the flange and not behind it. Checkwith a levelbefore
tightening the screws.
• Installlower screwsto pull the hood tight against the wall.
Tighten
screws
Bottom Install
screw screws
location
15

Installation Instructions
INSTALLATION--VENTED TO THE OUTSIDE
I-_ CONNECT DUCTWORK
• Remove shipping tape from the damper.
• Install ductwork, making connections
in the direction of airflow as illustrated.
• Push duct over the exhaust outlet and damper.
• Secure joints in ductwork with sheet metal screws.
• Wrap all duct joints and the flange connections
with aluminized duct tape for an airtight seal.
Airflow
Ducttape _
over seam ___ Screw
and screw _ ]
-&CAUTION: Do mot use sheet metal
screws atthe hood flangeconnection.Doing so will
preventproper damper operation.Sealconnection
withtape only.
CONNECT ELECTRICAL
Verify that power is turned off at the source.
-&WARNING:lfhousewiring isnot2-wire
with a ground wire, a ground must be provided
by the installer. When house wiring is aluminum,
be sure to use U.L. approved anti-oxidant compound
and aluminum-to-copper connectors.
• Remove the 6 screws on the junction box cover
and the knockout on the top left side.
Knockout
Juncti°n a" _ iJ\ ::X
boxcover--____ I\ !\
• Secure the house wiring to the junction box with
a strain relief (not provided).
• Connect the white lead to the branch circuit white lead.
• Connect the black lead to the branch circuit black lead.
Connect the green/yellow lead to the branch
circuit green lead or bare ground lead.
Secure all the connections with wire nuts on each
electrical connector.
Push the wires into the junction box and replace
the cover. Be sure the wires are not pinched.
Secure the junction box cover with the 6 original
screws.
16

Installation Instructions
INSTALL DUCT COVERS
• Remove protective plastic
covering. Mounting
screws
• Assemble duct covers
according to application.
NOTE: The inside duct cover has vent
holes on one end. The holes are intended
for use when the hood is installed for
recirculating purposes. Slide the upper duct cover
into the folded ends of the lower duct cover.
• Place the decorative duct covers on top of the hood.
Duct cover bracket
/
Upperduct " _.
cover
II
Lower duct
cover
Lower duct
cover seat
Duct cover
attachment tabs
• Extend the inner duct cover upward to the ceiling
bracket.
• Secure with 2 screws to the duct cover bracket.
• Remove the packing material from the filter
opening.
Locate the screw holes on the inside front edge
of the opening. Install 2 screws to secure the lower
duct cover to the hood.
[_] INSTALL METAL GREASE FILTER
• Remove the protective film on the grease filter.
NOTE: The charcoal filter is not required for this
installation.
• Fit the tabs at the end of the filter into the slots
in the left side of the filter opening. Lift up the
right side of the filter and push gentlg until the
filter locks into place. Make sure the filter lock
is in the closed position to secure the filter.
To remove the filter, pull downward on the filter
lock to release.
[_ FINALIZE INSTALLATION
• Check to be sure all tape and packaging materials
have been removed.
• Refer to the Operating Instructions in this manual
to operate the hood.
17

Installation Instructions
INSTALLATION--RECI RCULATING
DUCTWORK, WIRING LOCATIONS
• Determine the exact location of the vent hood.
• Locate the template packed with the literature.
• Measure 36" from the floor to the top of the cooking
surface. Add hood installation height determined on
pages 8 and 13. Mark that location.
• Tape the template in position along the penciled line.
CHECKTO BE SURETHE TEMPLATEISLEVEL.
• Use a level to draw a line straight up, from
the centerline on the template to the ceiling.
5" centerline to wall .... _1
House Wiring _..6_ _Ceiling
Lii:tiln......................................!................................................................................
18"
Min.
--+ II
in REARWALL
MOUNTING TEMPLATE
I
HOUSEWIRING LOCATION:
• Thejunction box is located on the top left side
of the hood.
• Wiring should enter the back wall at least 18"
above the bottom of the hood, and within 5"
of the centerline.
INSTALL FRAMING
FOR HOOD SUPPORT
IMPORTANT: Framing must be capable
ofsupportingi00 Ibs.
View from
rear cleats
l"x 12" min.
mounting
support
If drgwall is present, mark the screw hole locations
for the top mounting brackets. Remove the template.
• Cut awag enough drgwall to expose 2 vertical studs
at the bracket location indicated on the template.
• Install ahorizontal support atleast l"x 12"
between two wall studs at the mounting screw
location. The horizontal support must be flush with
the room side of the studs. Use cleats behind both
sides of the support to secure to wall studs.
NOTE: 2 horizontal supports will be needed ifthere
is a stud located between the horizontal screw
locations (seefigure).
IMPORTANT: Reinstall drLIwall for an even mounting
surface.
18

Installation Instructions
[_ INSTALL HOOD MOUNTING SCREWS
The mounting screws must enter the horizontal
support or wall studs.
• With the template taped in place, use a punch
to mark mounting bracket screw locations.
• Drill 1/8" pilot holes in 4 of the punched locations
in the lower bracket. If the bottom 2 pilot holes do
not enter wood, enlarge the holes to 3/8" and install
metal wall fastener anchors (provided).
• Remove the template.
• Install the 2 top mounting screws; leave 1/4" gap
between the screw head and the wall. This will allow
the keyhole slot on the hood frame to engage the
screw head.
u
T................................................................................. y................................................................................. _-
I i /
io REAR WALL
HOUNTING TEHPLATE
£
i
.........
IMPORTANT: Use the mounting screws provided.
DO NOT USEDRYWALLSCREWS.
,,Check to be sure the mounting screws are
horizontally level.
[-_ INSTALL DUCT BRACKET
AND DEFLECTOR
The duct bracket should be installed against the back
wall and flush with the ceiling; the point where the
ceiling meets the wall should be level for the bracket
and duct cover to fit flush. This bracket will hold
the duct cover in place at the top.
Secure the bracket to the wall:
• Align the diamond centerline cutout on the bracket
to the penciled centerline on the wall.
• Mark 2 screw hole locations in the wall.
• Drill 1/8" pilot holes in the marked locations.
• If pilot holes do not enter wood studs, enlarge
the holes to 3/8" and install metal wall fastener
anchors (provided).
• If mounting directly to a masonry wall, obtain
appropriate #10 masonry screw anchors. Drill
and install per the fastener supplier's instructions.
• Drive screws, by hand, into the fasteners to allow
anchors to expand. Remove the screws.
• Secure the bracket to the wall with wood screws
and/or fasteners.
Centerline cutout
• Assemble the air deflector accessory to the duct
cover bracket with the 4 assembly screws provided.
DO NOT tighten screws. This is a temporary
installation.
19

Installation Instructions
INSTALLATION--RECI RCULATING
MOUNT THE HOOD
.4,WARNING: 2peoplearerequiredtolift
and position the hood onto the mounting screws.
• Lift the hood onto the mounting screws.
• If using a wall fastener, make sure the washer
is in front of the flange and not behind it. Check
with a level before tightening screws.
• Install lower screws to pull the hood tight against
the wall.
Tighten
Bottom Install
screw screws
location
[-_ SIZE AND CUT DUCT PIECE
• Measure from the bottom of the air deflector
to the top of the hood as shown. Reduce that
dimension bg 1" to facilitate installation.
The duct will cover and overlap the deflector
and the exhaust outlet in the hood.
• Remove the air deflector from the duct cover
bracket.
Measure Duct
length length
• Cut the duct piece to size and slip onto the bottom
of the deflector.
• Place the assembled deflector and duct over
the exhaust outlet.
• Hold the assemblg against the duct bracket.
• Drive 2 screws into each side of the bottom
of the deflector and into the bracket.
• Use duct tape to seal duct to the deflector
and at the exhaust outlet.
Deflector
2O
