GE Monogram ZDWR240HBS User manual

Owner’s
Manual
WineReserve
ZDWR240
ZDWI240
monogram.com

Consumer Information
Wine Reserve
2
Introduction
Your new Monogram wine reserve makes an eloquent statement of style, convenience and
kitchen planning flexibility. Whether you chose it for its purity of design or the assiduous
attention to detail, you will find that your Monogram wine reserve’s superior blend of form
and function will delight you for years to come.
The information on the following pages will help you operate and maintain your wine
reserve properly.
If you have any other questions, visit our Website at: monogram.com
Contents
Care and Cleaning........................................11, 12
Consumer Services...............................................19
Controls and Features....................................8–10
Model and Serial Numbers...................................2
Problem Solver................................................13–15
Product Registration...............................................2
Repair Service....................................................3, 19
Safety Instructions.............................................4–7
Warranty................................................Back Cover
Before
using your
wine reserve
Read this manual carefully. It is intended
to help you operate and maintain your
new wine reserve properly.
Keep it handy for answers to your questions.
If you don’t understand something or
need more help, there is a list of toll-free
consumer service numbers included in
the back section of this manual.
OR
Visit our Website at: monogram.com
Write
down the
model
& serial
numbers
You will find them on a label on the ceiling
inside the wine reserve. Please write these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or
service calls concerning your wine reserve.
ATTENTION CONSUMER!
This unit is designed for storing and cooling beverages.
Do not store perishable foods in this unit.
ATTENTION CONSOMMATEUR !
Cet appareil ménager est conçu pour conserver et rafraîchir des boissons.
Ne mettez pas de biens perissables dans cet appareil ménager.

If you
received a
damaged
appliance
The warranty does not cover damage caused
after delivery. Immediately contact the dealer (or builder) that sold you the wine reserve.
Remove
packaging
Before using, be sure all packing materials
and tape have been removed.
To assure no damage is done to the finish of
the product, the safest way to remove the
adhesive left from packaging tape on new
appliances is an application of household
liquid detergent. Apply with a soft cloth and
allow to soak. Wipe dry and then apply an
appliance polish to thoroughly clean and
protect the surface.
If you need
service
To obtain service, see the Consumer Services
page in the back of this manual.
We are proud of our service and want you
to be pleased. If for some reason you are not
happy with the service you receive, here are
steps to follow for further help.
For customers in the USA:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write
DOOWKHGHWDLOV³LQFOXGLQJ\RXUSKRQH
QXPEHU³WR
Manager, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
For customers in Canada:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
GHWDLOV³LQFOXGLQJ\RXUSKRQHQXPEHUWR
Manager, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
After
installation
is completed
• Promptly inspect your new Monogram wine
reserve. If it has been damaged, contact
the Installer or Dealer immediately.
• This wine reserve must be properly leveled
to ensure correct door alignment and door
closure. Contact the Installer if the unit is
not level.
• The unit should be centered in the opening.
The front face of the door should be 1"
forward of adjacent cabinetry. Contact
the installer if clearance is not correct.
• Test the door swing. Carefully open and
close the door. The door should not rub
or catch on adjacent cabinetry. Notify the
installer if the door makes contact with
cabinetry.
Please Contact the Installer or Dealer if you
experience any of these problems.
Your wine reserve is shipped with a black
toekick on the front of the unit. For shipping
purposes, an optional stainless steel toekick
is secured to the back of the unit. That
toekick should have been removed and
installed, or given to you. Keep the unused
toekick and other unused or removed parts
for possible future use. 3
Save time
& money
Before you request service, check the
Problem Solver in the back of this manual. It lists causes of minor operating problems that you can correct yourself.
Consumer Information
Wine Reserve

4
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you
and others. All safety messages will follow the safety alert symbol and the word “DANGER”, “WARNING”,
or “CAUTION”. These words are defined as:
Indicates a hazardous situation which, if not avoided,will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,could result in minor or moderate injury.
WARNING
DANGER
CAUTION
Thisrefrigerator mustbe properlyinstalled inaccordance with
theInstallation Instructionsbefore itis used.
Unplug therefrigeratorbefore makingrepairs, replacinga
light bulb,orcleaning.
Note: Power totherefrigerator cannotbe disconnectedby
any settingon thecontrolpanel.
Note: Repairs mustbeperformed bya qualifiedService
Professional.
Do nottryto replacea burned-outLED light.An authorized
technicianwill needto replacethe LEDlights.
Replaceall partsandpanels beforeoperating.
Do notstoreor usegasoline orother flammablevapors and
liquidsin thevicinity ofthis orany otherappliance.
Because ofpotentialsafety hazardsunder certainconditions,
we stronglyrecommendagainst theuse ofan extensioncord.
However, ifyoumust usean extensioncord, itis absolutely
necessary thatitbe aUL-listed (inthe UnitedStates) ora
CSA certified(inCanada), 3-wiregrounding typeappliance
extensioncord havinga groundingtype plugand outletand
that theelectricalrating ofthe cordbe 15amperes (minimum)
and120 volts.
Do notallowchildren toclimb, standor hangon the
refrigerator. Theycoulddamage therefrigerator andseriously
injurethemselves.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, explosion, electric shock, or injury when using your
refrigerator follow these basic safety precautions:
WARNING
WARNING Explosion Hazard.
Keep flammable materials and vapors, such as gasoline, away from refrigerator. Failure to do so can
result in fire, explosion, or death.
INSTALLATION
Do not clean glass shelves or covers with warm water when
they are cold. Glass shelves and covers may break if exposed
to sudden temperature changes or impact, such as bumping
or dropping. Tempered glass is designed to shatter into many
small pieces if it breaks.
Keep fingers out of the “pinch point” areas; clearances
between the doors and between the doors and cabinet are
necessarily small. Be careful closing doors when children are in
the area.
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of injury when using your refrigerator, follow these basic
safety precautions.
CAUTION
REFRIGERATOR SAFETY INFORMATION

5
IMPORTANTESINSTRUCTIONS DESÉCURITÉ
LIREETCONSERVERCESINSTRUCTIONS
Ce symbole représente une alerte de sécurité. Ce symbole vous avise de dangers possibles pouvant causer la
mort, des blessures ou autres. Tous les messages de sécurité seront précédés du symbole d’alerte de sécurité ainsi
que des mots « DANGER », « AVERTISSEMENT » ou « MISE EN GARDE ». Ces messages sont les suivants :
Signale une situation qui présente un danger imminent et qui, si elle n’est pas évitée, entraînera des blessures
graves, voire la mort.
Signale une situation qui présente un danger imminent et qui, si elle n’est pas évitée, peut entraîner des
blessures graves, voire la mort.
.
Signale une situation qui présente un danger imminent et qui, si elle n’est pas évitée, peut entraîner des
blessures mineures ou graves.
AVERTISSEMENT
DANGER
MISE EN GARDE
IMPORTANTES CONSIGNES DE SÉCURITÉ
Pour réduire le risque d’incendie, d’explosion, de choc électrique ou de blessures
lorsque vous utilisez votre réfrigérateurde , veuillez suivre ces consignes de sécurité :
AVERTISSEMENT
Ce réfrigérateurdoitêtre correctementinstallé conformément
auxConsignes d’Installationavant touteutilisation.
Débranchez leréfrigérateuravant d’effectuerune réparation,
de remplacerune ampouleou dele nettoyer.
Remarque: L’alimentationdu réfrigérateurne peutêtre
déconnectée paraucunedes fonctionssur lepanneau de
commande.
Remarque :Les réparationsdoivent êtreeffectuées parun
professionnel qualifié.
Ne tentezpasde remplacerune ampouleà DELgrillée. Le
remplacement desampoulesà DELdoit êtreeffectué parun
technicienautorisé.
Remettez touteslespièces etpanneaux enplace avant
d’utiliserl’appareil.
Ne stockezpasou n’utilisezpas d’essenceou d’autresvapeurs
et liquidesinflammablesà proximitéde cetappareil oude tout
autreappareil électroménager.
Nous déconseillonsfortementl’utilisation d’unerallonge
àcause desrisques potentielsdans certainesconditions.
Cependant, sil’utilisationd’un cordonprolongateur est
nécessaire, cedernierdoit obligatoirementêtre homologué
UL (auxUSA)ou CSA(au Canada),à troisbrins avecmise àla
terre pourappareilélectroménager etdoit êtreéquipé d’une
fiche etd’uneprise femelleavec terre.Les caractéristiques
électriques ducordonprolongateur doiventêtre de15
ampères(minimum) etde 120volts.
Ne laissezpasles enfantsgrimper, semettre deboutou se
suspendreaux poignéesde portesdans leréfrigérateur
ou auxclayettesdu réfrigérateur.Ils pourraientse blesser
gravement.
Ne nettoyezpasles clayettesou lescouvercles enverre avec
de l’eautièdequand ceux-cisont froids.Les clayetteset
couvercles enverrepeuvent secasser s’ilssont exposésà des
changements soudainsdetempérature ousi vousles cognez
oules faitestomber. Leverre trempéest conçupour sebriser
enpetits morceauxen casde casse
Éloignez lesdoigtsdes partiesdu congélateuroù l’onpeut
facilement sepincer: lesespaces entreles portes,et entre
les portesetles placardssont toujoursétroits. Soyezprudent
lorsquevous fermezles portesen présenced’enfants.
IMPORTANTES CONSIGNES DE SÉCURITÉ
Pour réduire le risque de blessures lorsque vous utilisez votre réfrigérateurde , veuillez
suivre ces consignes de sécurité.
ATTENTION
CONSIGNES DE SÉCURITÉ POUR LE RÉFRIGÉRATEUR
INSTALLATION
AVERTISSEMENT Risque d’explosion.
Conservez les matériaux et vapeurs inflammables tels que l’essence à l’écart de votre réfrigérateur. Une
explosion, un incendie voire la mort pourrait en résulter.

6SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
CONNECTING ELECTRICITY
REFRIGERANTS
WARNING RISK OF CHILD ENTRAPMENT
Child entrapmentandsuffocation arenot problemsof
the past.Junkedor abandonedrefrigerators arestill
dangerous evenifthey willsit for“just afew days.”If
you aregettingrid ofyour oldrefrigerator, pleasefollow
theinstructions belowto helpprevent accidents.
Before You Throw Away Your Old Refrigerator:
Takeoff thedoor/drawers.
Leave theshelvesin placeso thatchildren maynot
easilyclimb inside.
All refrigeration products contain refrigerants, which
under federal law must be removed prior to product
disposal.
If you are getting rid of an old refrigeration product,
check with the company handling
the disposal about what to do.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord. For personal
safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the
possibility of electric shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
The appliance should always be plugged into its own
individual electrical outlet which has a voltage rating
that matches the rating plate. This provides the best
performance and also prevents overloading house
wiring circuits which could cause a fire hazard from
overheated wires.
Never unplug an appliance by pulling on the power cord.
Always grip the plug firmly and pull straight out from the
outlet.
Repair or replace immediately all power cords that have
become frayed or otherwise damaged. Do not use a cord
that shows cracks or abrasion damage along its length
or at either end.
When moving the appliance, be careful not to roll over or
damage the power cord.
WARNING Electrical Shock Hazard.

7
CONSERVEZCESDIRECTIVES
IMPORTANTESINSTRUCTIONS DESÉCURITÉ
BRANCHEMENTS ÉLECTRIQUES
Tous les appareils de réfrigération contiennent des
refrigerants qui, conformément aux lois fédérales,
doivent être enlevés avant toute élimination de
l’appareil.
Si vous vous débarrassez de vieux appareils de
réfrigération, vérifiez, auprès de la société qui
s’occupe de leur élimination, ce que vous devez
faire.
RACCORDEMENTÉLECTRIQUE
Ne coupez ni retirez en aucun cas la troisième broche
(mise à la terre) de la fiche du cordon d’alimentation.
Pour votre sécurité, cet appareil doit être
correctement mis à la terre.
Le cordon d’alimentation de cet appareil est muni
d’une fiche à 3 broches (mise à la terre) qui se branche
dans une prise mural ordinaire à 3 alvéoles (mise à la
terre) pour réduire au minimum les risques du chocs
électriques.
Faites examiner la prise de courant et le circuit par un
électricien qualifié pour vous assurer que la prise est
correctement mise à la terre.
Si la prise murale est du type standard à 2 alvéoles, il
vous incombe de la faire remplacer par une prise à 3
alvéoles correctement mise à la terre.
Le appareil doit toujours être branché dans sa propre
prise de courant, dont la tension nominale est identique
à celle indiquée sur la plaque signalétique.
Cette précaution est recommandée pour garantir un
rendement optimum et éviter une surcharge des circuits
électriques de la résidence, ce qui pourrait créer un
risque d’incendie par surschauffe des fils.
Ne débranchez jamais l’appareil en tirant le cordon
d’alimentation. Saisissez fermement la fiche du cordon et
tirez droit pour la retirer de la prise.
Réparez ou remplacez immédiatement tout cordon
effiloché ou endommagé.N’utilisez pas un cordon
fendillé ou présentant des signes d’usure.
Lorsque vous déplacez l’appareil du mur, faites attention
de ne pas la faire rouler sur le cordon d’alimentation afin
de ne pas l’endommager.
AVERTISSEMENT RISQUESPOURLESENFANTS
Les enfants pris au piège ou morts d’asphyxie
sont toujours d’actualité.
Les appareils de réfrigération abandonés sont
toujours aussi dangereux, même
si on n’attend que “quelque jours” pour
s’en débarasser. Si vous ne gardez pas
votre ancien appareil, veuillez suivre
les directives ci-dessous afin de prévenir
les accidents.
Avant de vous débarasser de votre vieux
appareil de réfrigération :
•Démontez les portes.
•Laissez les clayettes en place afin
d’empêcher les enfants de grimper
à l’intérieur.
AVERTISSEMENT Risque de choc électrique.
RÉFRIGÉRANTS

8
Controls and Features
Wine Reserve
Temperature
control
The temperature range of the wine reserve is
from 40°F to 65°F.
Do not install the wine reserve where the
temperature will go below 55°F or above
90°F.
The temperature display shows the actual
temperature of the wine reserve. The actual
temperature may vary slightly from the
set temperature based on factors such as
door openings, amount of wine and room
temperature. After making adjustments,
allow 12 to 24 hours for the wine reserve
to reach the temperature you have set and
before making any further adjustments. The
factory setting is the REDWINE setting (55°F).
Note: On all three temperature selections,
the light beside the pad will remain lit,
indicating the selection made.
The REDWINE setting will provide a storage
temperature of approximately 55ºF, which is
optimum for the storage of red wine. Press
the REDWINE pad to display 55°F. Several
seconds after the REDWINE pad is pressed,
the actual temperature will be displayed
while the wine reserve temperature moves
toward 55°F.
The WHITEWINE setting will provide a
storage temperature of approximately
45ºF, which is optimum for white wine.
Press the WHITEWINEpad to display 45°F.
Several seconds after the WHITEWINE
pad is pressed, the actual temperature
will be displayed while the wine reserve
temperature moves toward 45°F.
The CUSTOM setting will provide a storage
temperature range of 40°F to 65°F. This
setting provides the ability to customize the
temperature to the optimum setting for the
particular wine. To change the temperature
setting, press and hold the CUSTOMpad
until the display begins to flash the set
temperature. Then press the + or – pads until
you reach the desired set temperature. Once
you reach the desired temperature, stop
pressing the pads. After several seconds, the
display will return to the actual temperature.
The actual temperature will be displayed
while the wine reserve moves toward the set
temperature.
In general, temperatures at the bottom
of the cabinet will be cooler than
temperatures at the top of the cabinet.
Position your wine inventory accordingly
(i.e., white wines in the cooler zones and red
wines in the warmer zones).
Child control
lockout
This child control lockout feature prevents
unwanted changes to your temperature
settings.
After the desired temperature is set, the
temperature can be locked. To lock, press
both the +and –pads at the same time for
five seconds. To unlock, press both +and –
pads for five seconds.

Removing
full extension
drawers
All of the full extension drawers pull out
so bottles can be conveniently added or
removed.
Any of the full extension drawers can be
removed to store larger bottles.
To remove:
1. Pull the full extension drawer out to the
STOPposition.
2. Push the tab on right drawer guide down
while pulling the tab on left guide up, and
pull the drawer out.
To replace:
1. Push the drawer slide arm back into the
unit.
2. Pull the small slide sub-assembly
completely forward.
3. Insert the sides of the drawer back into the
guides.
4. Push until the tabs lock into place.
Tab (push tab down on
right drawer guide, pull
tab up on left drawer
guide)
NOTE: Make sure the tabs on the full
extension drawer guides are fully engaged
before loading any bottles. Pull the drawers
out all the way to the STOP position and push
back in several times to make sure locking
tabs are properly engaged.
To replace, push drawer
slide arm back into unit Pull smallslide sub-assembly completely forward
9
Interior light
and light pad
The interior light makes it easy to view your
wine labels and enhances the display of your
collection.
When the light pad is pressed and the word
ON is displayed, the light will remain on for
one hour before automatically turning off.
When the light pad is pressed and the word
OFF is displayed, the light will come on only
when the door is opened.
For best viewing, do not store a bottle on the
top shelf directly under the light. Remember
to turn off the light when it is no longer
needed.
Appearance may vary
Controls and Features
Wine Reserve
Sub-assembly Sub-assembly

10
Controls and Features
Wine Reserve
Insert wine
bottles
The top five full extension drawers each
hold eight bottles, two deep with the necks
alternating front to back or nine bottles,
alternating with necks pointing inward.
The bottom two full extension drawers hold
six bottles each and are loaded with necks
facing the rear. Tall bottles should not be
loaded on the bottom drawer because
they may prevent the door from closing.
8 bottle arrangement 9 bottle arrangement Bottom drawer
Loading
tips and
suggestions
•The bottles on the top full extension
drawer, directly under the light, will be
exposed to a slightly higher temperature
when the light is on. Position your wines
accordingly and remember to turn off the
light when it is no longer needed.
•Keep wines that you plan to use for
everyday drinking and entertaining on
the front half of the full extension drawers
where labels are completely visible. Place
wines for aging or longer term storage in
the rear.
•Do not allow children to climb, stand or
hang on the wine reserve full extension
drawers. They could seriously injure
themselves and possibly cause damage to
the wine reserve.
•In general, temperatures at the bottom
of the cabinet will be cooler than
temperatures at the top of the cabinet.
•Position your wine inventory accordingly
(i.e., white wines in the cooler zones and
red wines in the warmer zones).
Wood drawer
fronts
The full extension drawer fronts on the wine
reserve are unfinished cherry wood. During
use, oil from hands may accumulate and
stain the wood.
•The drawer fronts may be stained and
sealed to match adjacent cabinetry. The
tinted glass will make the stained wood
appear darker. A true color match can be
seen only when the door is opened.
•Apply the stain and sealer according to
the manufacturer’s instructions. To avoid
unpleasant odor, keep the door open to
ventilate and allow the stain/sealer to dry
completely before using the product.
NOTE: Natural wood may vary slightly in
grain and color.
