Geemarc CL7400 User manual

CL7400
Amplified Wireless Digital TV Headset
User Guide
CL7400

CONTENTS 1
INTRODUCTION 2
Unpacking the CL7400 3
INSTALLATION 4
Setting Up –Connecting Charging Base to TV 4
SCART Users 6
RCA Users 6
Neither SCART nor RCA Users 6
USING THE CL7400 10
Turning the CL7400 On 10
SETTINGS 11
Volume Setting 11
Balance Setting 12
Tone Setting 13
Stereo/Mono Setting 14
PAIRING 15
ECO MODE 17
WIRED MODE 18
CL7400 with Hi Fi or MP3 18
TROUBLESHOOTING 19
SAFETY INFORMATION 21
GENERAL INFORMATION 23
GUARANTEE 24
RECYCLING DIRECTIVES 25
Congratulations on purchasing your Geemarc CL7400. The CL7400 is a
pair of stylish top quality headphones together with a charging base that
can be plugged into the TV, Laptop, Audio, MP3 and iPods. The
headphones provide high quality CD sound and the volume can be
increased up to 125dB. The CL7400 is useful for the hard of hearing
person, allowing them to listen to the TV or such like at a desired volume
without the need to turn up the volume on the TV. Or, if one person likes
to read in bed and the other likes to watch TV, simply wear this
comfortable, lightweight and adjustable headset.
The headset also has built-in tone control, volume control, balance control
and stereo or mono selection. It has a built in rechargeable battery which
self charges when placed back on the charging base. The Geemarc
CL7400 has an indoor range of up to 50 meters from the transmitter and
works digitally through walls.
This easy to use stylish device will allow you to hear the beauty of the
sound with amazing sound quality transmission.
The CL7400 is also foldable for easy transportation.
Its is important that you read the instructions below in order to use your
Geemarc CL7400 to its full potential. Keep this user guide in a safe place
for future reference.
CONTENTS
INTRODUCTION
1
2

Unpacking the CL7400
When unpacking the CL7200, you should find the following in the box:
CL7400 Radio Controlled Headphones
Charging Base
AC Power Adaptor
3.5mm Male jack to 2 RCA plugs adaptor cable
3.5 mm Female jack to 2 RCA plugs adaptor cable
1 User Guide
For product support and help visit our website at www.geemarc.com
Telephone [phone]
Or fax [phone]
Setting Up –Connecting Base to TV (or other device)
.
1. Insert the AC adaptor connector into the ‘DC IN 5V’ socket found on the
back of the Charging Base.
2. Insert the RCA plugs of the male lead into the back of the charging base
as per the colour coding i.e. red lead into red socket, white lead into white
socket.
3. Insert the other end of this lead (the male jack) into the female jack.
INSTALLATION
1
4
5
INTRODUCTION
33

A SCART Users
Insert the other side of the female 3.5mm jack to RCA Adaptor into your
SCART connector.
5. Insert the SCART connector into your TV.
B RCA Users
Insert the RCA Adaptors into your TV RCA sockets as per the colour
coding i.e. red lead into red socket, white lead into white socket.
C Neither SCART nor RCA Users
Insert one end of the 3.5 mm jack cable into the base of the headphones.
Insert the other end of the 3.5mm jack cable into the 3.5mm jack
Headphone jack found at the back of the TV. See page 18.
6
INSTALLATION
6
INSTALLATION
5

e) Plug the AC adaptor into your home power socket.
f) Switch the Charging Base to On.
g) A red light will initially be displayed on the right hand side of the base.
After about 5 seconds the red light should go off and the green light will be
displayed. The green light indicates that the unit is ON and is in standby
mode.
INSTALLATION
INSTALLATION
7
8

-Hur anvander man m Como s e usa
<!>
ON
Place the headphones onto the Charging Station. A red light will show on
the headphones. The red light indicates the headphone’s batteries are
charging. Charging takes 5 hours. After full charge the red light changes
to green.
There is a Micro USB port located at the bottom of one of the earpieces.
This allows charging to take place via other means. Please note the Micro
USB port is not included.
Turning the CL7400 On
After full charge the headphones can be used. Take the headphones from
the base.
Press and hold the Power button on the headphones for 3 seconds. The
Power Button should light up a green colour. The CL7400 is ready for
use.
Place the headphones over your head and ensure the TV is switched on.
Your CL7400 is now set up for the recommended levels. For further
personalisation see the Settings Chapter.
Note: There is no need for paring procedure. The paring stage is done at
the manufacturing stage.
MicroUSB
not included
non inclus
nicht enthalten
no incluido
non incluso
niet inbegrepen
לולכ אל
inte ingår
nincs a
csomagban
INSTALLATION
USING THE CL7400
10
9

Volume Setting
Press ‘+’ button on the headset to increase volume and ‘’-‘ button to
decrease volume. Holding the ‘+’ button or ‘-’ button will increase the
volume or decrease the volume continuously. The Headset will beep
when volume reaches midway volume..
Balance Setting
Max L • -
..:(.(:_()>,::.. •• RMax
SETTINGS
SETTINGS
1111
12
SETTINGS
The balance can be controlled by pressing the balance button on the
headphones. Press and hold this for 2 seconds, the button will light up
red. At this point pushing headset ‘+’ button will alter the audio to the left
earphone. Pushing the ‘-’ button will alter the audio to the right
earphone. At minimum, maximum or middle point a beep will be heard.
Balance setting mode will switch off automatically after 5 seconds.

Tone Setting Stereo/Mono Setting
Stereo or Mono mode can be controlled by moving S/M switch to the
desired side. This switch is found on the underside of the charging base
(using a needle or pencil is helpful).
Moving the switch to “S” side means the CL7200 will work in Stereo
mode. Moving the switch to “M” side means the CL7200 will work in Mono
mode
11111
Min
Mid
'
Max
SETTINGS
13
1414
SETTINGS
The Tone can be controlled by pressing the tone button on the headphones. Press
and hold this for 2 seconds. At this point, pushing headset ‘+’ button will increase the
high tones. Pushing the ‘-’ button will increase the low tones. At minimum, maximum
or middle point a beep will be heard. Tone setting mode will switch off automatically
after 5 seconds.

1
2
Your Headset was paired with the Base at the factory. When you switch
on the Headset, the Headset will automatically recognise the Base; there
is nothing for you to do in order to pair the two devices together.
If for any reason the Headset and Base are no longer paired, there is a
very simple procedure to follow in order to pair the two devices.
1) Switch on the Headset by pressing and holding the On button. The
button should glow Green
2) Press and Hold the Pairing Button found on the Base (a pencil with a
sharp point might help with this operation). Hold for 3 seconds.
3) The Headset and Base will be paired as shown by the Green light on
the Base.
PAIRING
PAIRING
15
16

The CL7400 runs in Eco Mode and this means there is 90% less
emissions produced.
If the TV, Hi Fi or MP3 sound is reduced or muted for 4 minutes, the
headphones will go into sleep mode.
To wake up the headphones, increase the volume on the TV, Hi Fi or MP3
player.
If no sound is transmitted between the base and the headphones for 10
minutes or you place the headphones back on the base, the headphones
will switch off. To turn them back on again either lift the headphones off
the base or switch the Press On button.
CL7400 with HiFi or MP3
Insert one side of cable 3.5mm jack into ‘Audio’ socket found on the
bottom of the Headset. Insert the other side of the 3.5mm jack into audio
out socket of your HI-FI, Mobile Phone, TV or MP3 player
Features
WIRED MODE
18
ECO MODE
17
3

No Sound
Ensure that the mains adapter is pushed fully into the power
outlet and that its cable is properly connected to the DC IN 5V
connector on the base.
Ensure that the headphones On/Off switch is switched to the
On Position and the button is lit Green.
The headphones battery charge level may be low. Replace the
headset back on it's cradle to recharge the batteries until the
green light is illuminated on the left hand headset.
Ensure that your DVD, TV set, Hi-Fi system or audio component
is switched on and set to a channel that broadcasts an audio
signal.
Use the headphones volume control to increase the sound level
(only when use as a wireless headphone).
The audio signal input level is too low. Increase the volume
from the audio source of Hi-Fi, CD, or TV, etc.
The connected audio/video equipment may not be in playback
mode. Start playback on by the equipment.
The headphones output level is set too low. Adjust the volume
to a suitable level.
Distortion
Restart the Pairing process.
The headphone’s batteries charge level may be too low.
Recharge the batteries.
Ensure that the volume setting is correct.
The headphones may be too far away from the base. Move closer
to it.
The audio signal input level is too strong. decrease the volume
from the audio source of Hi-Fi, CD, or TV, etc.
Note:
In the event of the television not having the standard red and white audio
output RCA, or the audio jack, then it is most likely the TV will have an
optical audio output. By purchasing a Geemarc optical converter (our
reference CL7XX_OPT) this will allow the CL7400 to connect to the TV's
optical output successfully.
20
19
TROUBLESHOOTING
TROUBLESHOOTING

General
To make the best use of this product and to use it safely, please read
these instructions thoroughly before use and keep them safe for future
reference.
This product can be very loud. Take care to prevent others from using this
product if they do not have the same level of hearing loss. Excessive
sound level from earphones and headphones can cause hearing loss.
Do not insert unattached plug heads in to mains power sockets. Plug
heads must be fitted to the power adaptor.
The unit is designed to operate from a 100-240VAC-50/60Hz supply.
(Classified as ‘hazardous voltage’ according to EN60950 standard).
The unit does not incorporate an integral power on/off switch. To
disconnect the power, either switch off supply at the mains power socket
or unplug the AC adaptor. When installing the unit, ensure that the mains
power socket is readily accessible.
Do not open the unit. Contact the helpline for all repairs.
Do not remove the earpads as they are very difficult to replace.
Please note: The unit may be subject to interference from appliances that
generate strong electrical or magnetic fields e.g. microwaves, mobile
phones, lighting transformers etc.
Cleaning
Clean the CL7400 with a soft cloth. Never use polishes or cleaning agents
- they could damage the finish or the electrics inside.
Environmental
Do not expose to direct sunlight or other heat sources.
Always ensure there is a free flow of air over the surfaces of the CL7400.
Do not place any part of your product in water and do not use it in damp or
humid conditions e.g. bathrooms.
Do not expose your product to fire or other hazardous conditions.
Battery Warnings
Do not attempt to dismantle
Do not dispose of in fire
Do not swallow
Keep away from children
Batteries are to be inserted with the correct polarity
Do not short-circuit the supply terminals
Exhausted batteries are to be removed from the product
Do NOT use another type of battery or non-rechargeable
batteries to replace the rechargeable batteries.
When the headphones are not in use or the batteries are charging, switch
OFF the headphones to avoid damaging the batteries.
The batteries must be fully charged when use for the first time. An initial 5
hours charge is required
Dispose of used batteries according to the instructions.
SAFETY INFORMATION
22
SAFETY INFORMATION
21

Features
 2.4GHz FHSS digital technology with
equalizer features for tone and balance
adjustments.
 High quality stereo sound that is virtually interference-free
 Transmission is not restricted solely to line of sight
 Digital Pairing System on Headphone & Transmitter
 Electronic volume vontrol on headphones
 Built-in Pin-charger on transmitter
 Auto shut-off on headphone
 Auto On/Off RF function on transmitter
 3.5mm Line in feature for wired headphone application
 Operating distance up to 50 meters
 Braille identification on Volume key
 8 hours continuous use
Technical Specification
Transmission mode: 2.4GHz digital FHSS stereo
Carrier frequency: 2.4GHz
Operating voltage: Transmitter 6 V 600 mA
: Receiver 3.7V 1000mA
(built-in Lithium rechargeable battery)
Frequency response : 20 Hz –20 KHz (electrical)
Distortion: 0.5 %
Signal-to-noise ratio: 75 dB
Channel separation: 60 dB
Range : 50 meters (open area)
From the moment your Geemarc product is purchased, Geemarc
guarantee it for the period of one year. During this time, all repairs or
replacements (at our discretion) are free of charge. Should you experience
a problem then contact our help line or visit our website at
www.geemarc.com. The guarantee does not cover accidents, negligence
or breakages to any parts. The product must not be tampered with or
taken apart by anyone who is not an authorised Geemarc representative.
The Geemarc guarantee in no way limits your legal rights.
IMPORTANT: YOUR RECEIPT IS PART OF YOUR GUARANTEE AND
MUST BE RETAINED AND PRODUCED IN THE EVENT OF A
WARRANTY CLAIM.
DECLARATION: Geemarc Telecom SA hereby declares that this
product is in compliance with the essential requirements and other
relevant provisions of the Radio and Telecommunications Terminal
Equipment Directive 1999/5/EEC and in particular article 3 section
1a, 1b and section 3.
Please note: The guarantee applies to
the United Kingdom only
GUARANTEE
9
24
9
23
GENERAL INFORMATION

The WEEE (Waste Electrical and Electronic Equipment) has been put in
place for the products at the end of their useful life are recycled in the best
way.
When this product is finished with, please do not put it in your domestic
waste bin.
Please use one of the following disposal options:
- Remove the batteries and deposit them in an appropriate WEEE skip.
Deposit the product in an appropriate WEEE skip.
- Or, hand the old product to the retailer. If you purchase a new one, they
should accept it.
Thus if you respect these instructions you ensure human health and
environmental protection.
For product support and help visit our website at www.geemarc.com
Telephone [phone]
Or fax [phone] UGCL7400_UK ED.01
25
RECYCLING DIRECTIVES
