Geemarc Ampli DECT150 User manual

Telephone
CAUTION:THIS TELEPHONE PRODUCT IS
SPECIFICALLYDESIGNED FOR PEOPLE WITH HEARING
DIFFICULTIES AND IS PROVIDED WITH A HANDSET
EARPIECE WITH VOLUME CONTROL FOR INDIVIDUAL
REQUIREMENTS. DUE CARE MUST BE TAKEN BY ALL
USERS THAT THE HANDSET EARPIECE VOLUME
CONTROL IS SETTOTHE LOWEST LEVEL ACCEPTABLE
BYEACHRESPECTIVEUSER. CARESHOULDTHEREFORE
BE EXERCISED TO ENSURE THATANYNEW USERSARE
FAMILIAR WITH THIS REQUIREMENT.
ATTENTION:CETELEPHONE PEUTETRE DESTINE
AUXPERSONNESAYANTDESPROBLEMESD’AUDITION.
IL POSSEDE UN ECOUTEUR A VOLUME VARIABLE. A
LA PREMIERE UTILISATION, ASSUREZ VOUS QUE LE
BOUTONDE REGLAGE DUVOLUME SOIT POSITIONNE
SURLAPOSITIONVOLUME MINIMUM.LESPERSONNES
MALENTENDANTES POURRONT PAR LA SUITE
AUGMENTER LE VOLUME POUR L’ADAPTER A LEUR
AUDITION.
Ampli DECT150Ampli DECT150
Ampli DECT150Ampli DECT150
Ampli DECT150
User guide p.2
Notice d’utilisation p.30
GB
F

2
INDEX PAGE
DESCRIPTION
- Handset and base unit controls 6
GENERAL SETTINGS
- How to connect the phone and set the batteries 10
- Charging the batteries 10
- Phone range 11
- Clean the phone 11
BASE SETTINGS
- Base ringer volume 12
HANDSET SETTINGS
- General settings icons displayed 13
- Ringer volume, melody and shaker 13
- Handset registration 14
- Handset dereigistration 14
- Network features, Flash time, Dial pause 15
USING THE PHONE
- Making a call 16
- Answering a call 16
- Use the call back features 16
- How to use the volume and tone functions 16
- Paging the handset 17
- Timer 17
PHONE BOOK
-About the phone book 18
- Phone book handset ring tone settings 18
- Storing a number with a name 19
- Dialling using the phone book 19
- Modify a phone book entry 20
- Delete a phone book entry 20
GB

3
For product support and help visit our website at
www.geemarc.com
telephone [phone]
or fax [phone]
CALLER IDENTIFICATION
- Caller ID features 21
- Dial Caller ID numbers 21
- Store numbers and names into the phone book 21
- Delete stored names and numbers 22
ADDITIONAL HANDSETS
- General settings 23
- Using several handsets 23
- Deregister all additional handsets from the base 24
- Internal calls 24
- Call transfer to another registered handset 25
- Headset option 25
ADDITIONAL BASE UNIT
- General settings 26
- How to add a base unit 26
TROUBLE SHOOTING
- Generality 27
- A warning tone is heard during a call 27
- The phone does not work 27
- No number is displayed when the phone rings 27
GUARANTEE 28

4
SOMMAIRE PAGE
DESCRIPTION
- Description du combiné et de la base 6
INSTALLATION
- Raccordements du téléphone et mise en place des batteries 30
- Chargement des batteries 30
- Rayon d’action 31
- Entretien du téléphone 31
REGLAGE DE LA BASE
- Réglage du volume de sonnerie de la base 32
REGLAGE DU COMBINE
- Présentation des icônes 33
- Volume, mélodie de la sonnerie et vibreur 33
- Enregistrement d’un combiné sur la base 34
- Annuler l’enregistrement d’un combiné de la base 35
- Propiétés du réseau, touche R (Flash) , insertion d’une Pause 35
UTILISATION DU TELEPHONE
-Appeler 37
- Répondre à un appel 37
- Rappeler le dernier numéro composé (BIS) 37
- Réglage du volume et de la tonalité de l’écouteur 37
- Recherche du combiné (pagination) 39
- Minuterie (durée des appels) 39
REPERTOIRE
-Apropos du répertoire 40
- Réglage de la sonnerie du combiné 40
- Répertoire 40
- Enregistrement d’un numéro et d’un nom 41
- Appeler en utilisant le répertoire 42
- Modifier un numéro du répertoire 42
- Effacer un numéro du répertoire 42
F

5
AFFICHAGE DU NUMERO DE L’APPELANT
- Affichage des numéros d’appels 43
- Sélectionner et appeler un numéro 43
- Transfert de numéros dans le répertoire 44
- Effacer un ou plusieurs numérosenregistrés 44
COMBINES ADDITIONNELS
- Généralités 45
- Utilisation de plusieurs combinés 45
- Annuler l’enregistrement de tous les combinés de la base 46
- Communications internes 46
- Transfert d’appel vers un autre combiné enregistré 47
- Option casque 47
BASE ADDITIONNELLE
- Généralités 48
- Ajouter une base supplémentaire 48
PROBLEMES DIVERS
- Généralités 49
- Emission d’un signal d’alarme pendant la conversation 49
- Le téléphone ne fonctionne pas 49
- Aucun numéro ne s’affiche lorsque le téléphone sonne 49
GARANTIE 50
TEL. SERVICE APRES VENTE :
03 28 58 75 99
Pour tout renseignement technique ou toute
commande visitez notre site web sur
www.geemarc.com.
Parc d’Activités du Basroch
2, rue Galilée
59760 Grande Synthe

6
LCD display
Afficheur LCD
Keypad
Clavier
Amplifier switch
Interrupteur ampli
Shaker switch
Interrupteurvibreur
Speaker
Ecouteur
Microphone
Functionand
phonebookkeys
Touches de fonction et
de répertoire
Amplifierkey
Touche ampli
Tone adjustment
Réglage de la
tonalité
Flash Key
Touche flash
Pick up and hang up key
Touche de décroché et de
raccroché
HANDSET DESCRIPTION
DESCRIPTION DU COMBINE
DESCRIPTION

DESCRIPTION
7
Amplifier volume
button adjustment
Bouton de réglage
volume ampli
Belt clip
Clip ceinture
Batteries cover
Couvercle de batteries
HANDSET DESCRIPTION
DESCRIPTION DU COMBINE
DESCRIPTION

BASE CONTROLS
CONTROLES SUR LA BASE
Pagekey
Touche de pagination
Charge contacts
Contacts de charge
Handset cradle
Support combiné
8
DESCRIPTION

BASE CONNECTIONS
CONNECTIONS SUR LA BASE
Ringer volume setting switch
Interrupteurde réglage sonnerie
* Power adaptor socket
* Connecteur adaptateur
secteur
** Line socket
** Connecteur cordon de ligne
(*) Classified “hazardous voltage” according to EN60950 standard.
Classé “tension dangereuse” selon la norme EN60950.
(**) Classified TNV-3 according to EN60950 standard.
Classée TNT-3 selon la norme EN60950
9
DESCRIPTION

10
GENERAL SETTINGS
1 - HOW TO CONNECT THE PHONE AND SET THE BATTERIES
1 - Plug the adaptor in the power wall socket and the power plug in the
base socket (*).
2 - Connect the line cord plug to the base socket (**).
3 - Connect the line cord to the PTT socket.
4- Insertthe batterieswith thecorrect polarityinto thebatteries compartment
and replace the battery cover.
5 - Place the handset on the base unit then a short beep will be heard
and the battery symbol will flash on the display, except if the batteries are
totallyempty.
NOTE: Do not expose the base to electric equipment like TV, radio, monitors,
sunlight, heat or other phones...to avoid any disturbances of your phone.
2 - CHARGING THE BATTERIES
Thephone issupplied withNiMH rechargeablebatteries. Instandby mode,batteries
are fully charged around 170 hours and talk time is around 8 hours. The battery
charge icon will flash as long as the phone is being charged and will stop when
the charging process is complete. The phone has an automatic charging control to
avoid excessive charging.
IMPORTANT: Batteries must be charged during 24 hours before using the
phone for the first time.
Battery charge icon:
The handset display shows when the batteries are flat and when a warning
signal is heard. If the phone does not have enough power or is not completly
recharged, it switches itself off automatically until it is returned to the base unit.
(*) Classified “hazardous voltage” according to EN60950 standard.
(**) Classified TNV-3 according to EN60950 standard.

11
GENERAL SETTINGS
3 - PHONE RANGE
The phone radio range can work up to 300 m and radio signal can be affected by
many factors like a wall, obstacles...The maximum range if there are no obstacles
between the phone and the base unit is around 300 m.
If the range is restricted by walls in a house or in the office, the base unit should be
in a slightly elevated position.
A warning signal (beep) will be heard when the handset is out of the range, the call
will be stopped if the handset does not come nearer to the base unit.
4 - CLEAN THE PHONE
Clean the phone with a soft cloth. Keep the base and handset charging contacts
clean. Never use polishes or cleaning agents - they could damage the finish or the
electrics inside.
Note:Weadvise you toplace the telephone onatable cloth or similar,asrubberfeet
can mark some surfaces.
Thunderstorms: unplug your phone from the telephone socket during
thunderstorms because it could damage your phone. Your guarantee does not
cover thunderstorm damage.

BASE SETTINGS
BASE RINGER VOLUME
The base ringer volume can be adjusted by using the slider switch located on the
base rear panel.
Remark: It is only possible to adjust the ring volume, the ring tone melody cannot
be adjusted.
The following settings are available:
Switch position Symbol Function
Pos 1 Off
Pos 2 Min
Pos 3 Med
Pos 4 Max
For product support and help visit our website at
www.geemarc.com
telephone [phone]
or fax [phone]
12

HANDSET SETTINGS
1 - GENERAL SETTINGS ICONS DIPSPLAYED
There are three settings icons displayed on the handset:
Ringer volume icon to set the ring volume and melody.
Register handsets icon to register / deregister handsets.
Network settings, Flash time and Dial Pause icon settings to set Network,
Flash time and Pause. The whole menu is controlled by using the following keys:
- To activate or deactivate the menu and programing mode use the key.
-Tomoveforwardinthemenupressthe ( )and ( ) keystomove
backward.
- To move forward to another step or confirm a selection press the key.
2 - HANDSET RINGER VOLUME, MELODY AND SHAKER
To set the volume and melody please follow instructions below:
1 - Press the key.
2 - Press the ()orthe ( ) key to select the desired icon shown
on the display. The selected icon will flash on the display.
3 - Press the key to select the icon.
4 - Now you can select one of the possibilities below:
1/4 ++++ for the Ringer volume.
2/4 for the Normal calls ringer melody.
3/4 for the Phone book ringer melody.
4/4 for the Phone book ringer melody.
Pressthe toscrollthrough themenu. Ifyouwanttomodify entriespress
( )and ( )keys.
5 - Press the key to confirm the settings and exit to the menu.
6 - If you want to exit to the menu press .
7- Inadditiontothering,youcanusetheshakerfunctionwiththeswitch
set to the position.
13

IMPORTANT: If you connect several bases together, the handsets registered
to the additional bases will ring for a few seconds during an incoming call
even if you take the line with one of the first base handsets.
3 - HANDSET REGISTRATION
How to register a handset to a base unit:
1 - Unplug the mains adaptor from the base unit during few seconds.
2 - Replace the adaptor to the power socket.
3 - Press the key.
4-Pressthe ()orthe ( )keytoselectthe iconshownonthe
display. The selected icon will flash on the display, then press key; 1/1 0000
will be displayed.
5 - Enter the base unit PIN code (factory setting to 1111), then press key.
6 - The handset is now searching for the base unit to be registered, a beep will be
heard when the handset is registered to the base.
Note: the handset supplied with the base unit is already registered to the base unit.
So it is not necessary to register this handset.
4 - HANDSET DEREGISTRATION
To deregister the current handset from the base unit follow the instructions
below:
1 - Press the key.
2-Pressthe andthe keystoenter number,1/10000willbedisplayed.
3 - Enter the base unit PIN code (factory setting to 1111), then press key.
The handset is deregistered from the base unit and a beep will be heard when the
handsetisregisteredtothebase.Ifyouwishtouseseveralhandsetsandbaseunits,
all handsets must be registered. Each handset you want to use must be registered
separately to the base unit. You can register up to 2 base units for one handset and
up to 4 handsets can be registered to one base unit.
14
HANDSET SETTINGS

5 - NETWORK FEATURES, FLASH TIME, DIAL PAUSE
1 - Press the key.
2 - Press the ()orthe ( ) key to select the desired icon shown
on the display. The selected icon will flash on the display.
3 - Press the key to select the icon.
4 - You can choose from the menu below:
1/5 1/2 : 1 For UK, 2 for France (CID features).
2/5 Tone/Pulse for dialling must be set to Tone.
3/5 A,B,C,D (Telephone network settings)
4/5 Flash time R key
5/5 Dial pause to insert a pause in the mumber
You can scroll into the menu by pressing the key. Press the ( )or
the () key to modify entries, press to confirm modification.
5 - Press the key to exit the menu.
Network settings
You can choose between 4 network settings:
AFactory setting (default value), B,C,D
These settings are used to match the signal level when working on different
phone networks.
Note: The setting should be left to A
Flash time settings for .You can choose between 2 settings:
a) *** 100 ms for United Kingdom
b) ****** 300 ms for France
Dial pause settings
You can insert a pause time in a phone number after the first digit, the digits after
the pause time are dialled after a 3 seconds delay. Two settings are available to
use this feature Yes or No.
15
HANDSET SETTINGS

USING THE PHONE
16
1 - MAKING A CALL
1 - Dial the phone number you want to call, you can press the key to cancel
an incorrect entry.
2 - Press the , the number is automatically dialled.
3- On completionof thecallsimply pressthe againto releasetheline orput
the handset on the base.
2 - ANSWERING A CALL
When an incoming call is received proceed by:
1 - Press the key to take the line and speak.
2- On completionof thecallsimply pressthe againto releasetheline orput
the handset on the base.
3 - USE THE CALL BACK FEATURES
The five last dialled call numbers will be shown on the display when pressing the
key.
1 - Press the key and scroll through the list by pressing the ( )or
() keys until you select the number you want.
2 - Press the key to dial the number.
Note: Pressing the key again will cancel this process. The displayed entry
can be deleted by pressing the key, a short beep will be heard to confirm.
4 - HOW TO USE THE VOLUME AND TONE FUNCTIONS
Setting the handset volume, treble and bass:
The handset hearing volume can be set during a call by using the volume key
located on the handset rear side. Pressing the volume key increases the handset
volume by 4 steps of 4 dB each time. The phone amplification can be increased
with the V slider switch and the key.

USING THE PHONE
17
The following settings are available:
1 - The V switch set to and activated (key is lighting).
The handset volume can be adjusted within the following values range :
4dB/8dB/12dB/16dB.
2 - The V switch set to and activated (key is lighting).
The handset volume can be adjusted within the following values range:
16dB/20dB/24dB/28dB.
In addition for both settings, you can use the tone control slider switch
to increase treble and bass up to 10 dB.
Notes:
- Pressing the key deactivates the additional amplification and the tone
control functions (Key is not lighting).
- You can leave the V slider switch to position if the phone is always used by
impaired hearing user.
5 - PAGING THE HANDSET
If you wish to locate your handset simply follow the instructions below:
1 - Press the key on the base unit located on the base front side.
2 - All registered handsets will be paged and will ring.
3 - Press twice the on the located handset to stop the paging mode.
Pressing the key on the base unit has the same effect.
6- TIMER
A timer will be displayed on the screen after starting the call. You can check the
call length by using this function.

PHONE BOOK
18
1 - ABOUT THE PHONE BOOK
Names and phone numbers can be stored in the phone book. Each phone number
storedinthephonebookcanbecalledbypressingonlyfewbuttons.IfyourCallerID
service is available, the name and the number of the caller will be displayed during
the incoming call. This will be done only if the caller name and number have been
stored in the phone book.
The phone book is divided into two parts (2 x 10 entries). One phone book can be
used for friends and family numbers and the second one for business contacts. The
entries in both phone books are sorted out by using an alphabetic list. Each name
can contain up to 10 characters and each phone number can have up to 25 digits.
2 - PHONE BOOK HANDSET RING TONE SETTINGS
It is possible to have a different ring to identify which phone book is being used.
You can set it as below:
1 - Normal phone call
2 - Calls from phone numbers and names in the first phone book .
3 - Calls from phone numbers and names in the second phone book .
Differentiated ring tones are only available when the caller ID is activated.
IMPORTANT :
Even if a caller is stored in a phone book, it can happen that only the normal ring
toneistriggered,inthiscasecallermayhaveusedhisorherprivatenumberfunction.

PHONE BOOK
19
3 - STORING A NUMBER WITH A NAME
Follow instructions below to store new entries in the phone book:
1 - Enter the phone number and dialling codes you wish to set in the phone book.
2-Selectoneofthetwophonebooksbypressingthe or key,abeep
will be heard and the phone book icon selected will flash.
3 - Enter the corresponding name and number by pressing the corresponding
number key once or twice to select the desired letter (see the table below).
Key Characters
1 [space] - 1
2 ABC2
3 DEF3
4 GHI4
5 JKL5
6 MNO6
7 PQRS7
8 TUV8
9 WXYZ9
00
* or # To confirm the key and go to another one
Example: forAB pressA*B
4 - Press the key to store the entry then a beep will be heard to confirm.
Note: To cancel the process only press and hold the key.
4 - DIALLING USING THE PHONE BOOK
1 - Select the desired phone book by pressing the or .
2- Select the desired entryin the listby usingthe ( )or ( ) key.
3 - Press the key then the number will be automatically dialled.
Note: The process can be cancelled by pressing the or key.

PHONE BOOK
5 - MODIFY A PHONE BOOK ENTRY
1 - Select the desired phone book by pressing the or key.
2 - Select the desired number to modify by pressing the ()or ( )
keys.
3 - Press the key.
4 - The number will be displayed and can be deleted by pressing the key.
5 - Enter the new number and press the key to store.
6 - DELETE A PHONE BOOK ENTRY
1 - Select the desired phone book by pressing the or key.
2 - Select the desired number to delete by pressing the ()or ( )
keys.
3 - Press the key.
4 - Press the key to delete the entry.
5 - Display will show OK?
5 - Press the to confirm then a beep will be heard.
For product support and help visit our website at
www.geemarc.com
telephone [phone]
or fax [phone]
20
